监控etcd

---

kubectl -n monitoring create secret generic etcd-certs --from-file=/etc/kubernetes/pki/etcd/peer.crt
--from-file=/etc/kubernetes/pki/etcd/peer.key
--from-file=/etc/kubernetes/pki/etcd/ca.crt

---

给etcd创建SVC

apiVersion: v1
kind: Service
metadata:
name: etcd-k8s
namespace: kube-system
labels:
k8s-app: etcd
spec:
type: ClusterIP
clusterIP: None
ports:

• name: etcd-port
  port: 2379

---

apiVersion: v1
kind: Endpoints
metadata:
name: etcd-k8s
namespace: kube-system
labels:
k8s-app: etcd
subsets:

• addresses:
  • ip: 10.72.40.16
    nodeName: etcd-master
    ports:
  • name: etcd-port
    port: 2379

---

创建 ServiceMonitor
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
name: etcd-k8s
namespace: monitoring
labels:
k8s-app: etcd-k8s
spec:
jobLabel: k8s-app
endpoints:

• port: etcd-port
  interval: 30s
  scheme: https
  tlsConfig:
  caFile: /etc/prometheus/secrets/etcd-certs/ca.crt
  certFile: /etc/prometheus/secrets/etcd-certs/peer.crt
  keyFile: /etc/prometheus/secrets/etcd-certs/peer.key
  insecureSkipVerify: true
  selector:
  matchLabels:
  k8s-app: etcd
  namespaceSelector:
  matchNames:
  • kube-system

---
