关于翻录

一些论坛：

1、https://cs.rin.ru/forum/viewtopic.php?t=100672
这个帖子是用来查询和请求解压虚幻文件的AES KEY。
2、https://www.gildor.org/smf/index.php
这个是Umoder下兴者自己建立的论坛，主要是用来讨论 (寻找方法)解决一些有特殊加密的虚幻文件
3、https://forum.xentax.com/index.php
这是一个论坛，主要是解决各种非“通用”引擎的游戏文件
4、https://discord.gg/7yixAVhS
这是个Discord聊天群，主要用来解决一些有特殊加密的Unity3D的文件



displacement to normal

Shader "Saber/Unlit/DisplacementToNormals"
{
    Properties
    {
        _DisplacementMap("Displacement Map", 2D) = "black" {}
        _NormalStrength("Normal Strength", float) = 1
    }

    SubShader
    {
        Pass
        {
            Tags
            {
                "RenderType" = "Opaque"
                "RenderPipeline" = "UniversalPipeline"
                "Queue" = "Geometry"
            }
            HLSLPROGRAM
            #pragma vertex vert
            #pragma fragment frag

            #include "Packages/com.unity.render-pipelines.universal/ShaderLibrary/Core.hlsl"

            TEXTURE2D(_DisplacementMap);
            SAMPLER(sampler_DisplacementMap);

            float4 _DisplacementMap_TexelSize;
            float _NormalStrength;

            struct Attributes
            {
                float4 vertex : POSITION;
                float2 uv : TEXCOORD0;
            };

            struct Varyings
            {
                float2 uv : TEXCOORD0;
                float4 vertex : SV_POSITION;
            };

            Varyings vert(Attributes input)
            {
                Varyings output;

                output.vertex = TransformObjectToHClip(input.vertex.xyz);
                output.uv = input.uv;

                return output;
            }

            float4 frag(Varyings input) : SV_Target
            {
                float2 uv = input.uv;
                float radius = _DisplacementMap_TexelSize;

                float xLeft = SAMPLE_TEXTURE2D(_DisplacementMap, sampler_DisplacementMap, float2(uv.xy - float2(radius, 0.0))).x;
                float xRight = SAMPLE_TEXTURE2D(_DisplacementMap, sampler_DisplacementMap, float2(uv.xy + float2(radius, 0.0))).x;
                float yUp = SAMPLE_TEXTURE2D(_DisplacementMap, sampler_DisplacementMap, float2(uv.xy - float2(0.0, radius))).x;
                float yDown = SAMPLE_TEXTURE2D(_DisplacementMap, sampler_DisplacementMap, float2(uv.xy + float2(0.0, radius))).x;

                float3 normalTS = float3(xRight - xLeft, yUp - yDown, 0) * _NormalStrength;
                normalTS.z = sqrt(1 - dot(normalTS.xy, normalTS.xy));

                float3 normalColor = normalTS * 0.5 + 0.5;
                return half4(normalColor,1);
            }
            ENDHLSL
        }
    }
}



dynamic effect:

using UnityEngine;
using System;
using UnityEngine.Rendering.Universal;
using UnityEngine.Rendering;
using UnityEngine.Experimental.Rendering;
using UnityEditor;

namespace GameLogic
{
    [ExecuteAlways]
    public class ToonWaterDynamicEffects : MonoBehaviour
    {
        [Serializable]
        public enum Quality
        {
            VeryHigh,
            High,
            Medium,
            Low
        }

        [Header("Base")]
        [SerializeField]
        [Tooltip("Effect texture resolution\nVery High: 2048\nHigh: 1024\nMedium: 512\nLow: 256")]
        private Quality _Quality = Quality.High;

        [SerializeField]
        [Tooltip("Layers that will be used to capture the dynamic effects.")]
        private LayerMask _LayerMask = 2;

        [SerializeField]
        [Tooltip("Size of the capture region.")]
        private float _CaptureSize = 10f;

        [SerializeField]
        [Tooltip("Y distance of the capture camera from the target.")]
        private float _CaptureDistance = 10f;

        [SerializeField]
        [Range(0, 60)]
        [Tooltip("Limits the update of the render texture. Set this to 0 for no limits.")]
        private int _CapturePerSeconds = 0;

        [SerializeField]
        [Range(0.1f, 1f)]
        private float _EdgeMaskSize = 0.1f;


        [Header("Normals")]
        [SerializeField]
        private bool _EnableNormalBlur = false;

        [SerializeField]
        [Range(0, 4)]
        private float _NormalBlur = 1;

        [SerializeField]
        [Range(0, 2)]
        private float _NormalStrength = 1;

        [SerializeField]
        private Shader _EffectsShader;

#if UNITY_EDITOR
        [Header("Debug")]
        [SerializeField]
        private bool _ShowRegion = false;
#endif

        private RenderTexture _DynamicEffectsTexture;
        private RenderTexture _CompRT;
        private RenderTexture _TempRT1;
        private RenderTexture _TempRT2;


        private readonly int _NormalSharpId = Shader.PropertyToID("_NormalMap");
        private readonly int _BaseTexId = Shader.PropertyToID("_BaseTex");
        private readonly int _DynamicEffectsTextureId = Shader.PropertyToID("_DynamicEffectsTexture");
        private readonly int _DynamicEffectsParams = Shader.PropertyToID("_DynamicEffectsParams");
        private readonly int _NormalStrengthId = Shader.PropertyToID("_NormalStrength");
        private readonly int _NormalBlurId = Shader.PropertyToID("_BlurStrength");
        private readonly int _DebugTextureId = Shader.PropertyToID("_DebugTexture");

        private Camera _DynamicEffectsCamera;
        private Material _EffectsMaterial;
        private bool _EnableRender = false;

        const RenderTextureFormat _HdrFormat = RenderTextureFormat.ARGB32;

        public static event Action<ScriptableRenderContext, Camera> BeginDynamicEffects;


        private void OnEnable()
        {
            RenderPipelineManager.beginCameraRendering += ComputeEffects;

            if (_CapturePerSeconds > 0)
            {
                InvokeRepeating("ResetTime", 0f, 1f / _CapturePerSeconds);
            }
        }

        // Cleanup all the objects we possibly have created
        private void OnDisable()
        {
            Cleanup();
        }

        private void OnDestroy()
        {
            Cleanup();
        }

        private void ResetTime()
        {
            _EnableRender = true;
        }

        private void ComputeEffects(ScriptableRenderContext context, Camera camera)
        {
            // Frame limiter
            if (_CapturePerSeconds == 0 || _EnableRender)
            {
                _EnableRender = false;
            }
            else
            {
                return;
            }

            // For overlay Camera
            var cameraData = camera.GetUniversalAdditionalCameraData();

            if (cameraData.renderType != CameraRenderType.Base)
                return;

            // we dont want to render planar reflections in reflections or previews
            var cameraType = camera.cameraType;

            if (cameraType == CameraType.Reflection || cameraType == CameraType.Preview)
                return;

            if (_DynamicEffectsCamera == null)
            {
                _DynamicEffectsCamera = CreateEffectsCamera();
            }

            CreateEffectsMaterial();

            CreateEffectsTextures(); // create and assign RenderTexture

            UpdateEffectsCamera(_DynamicEffectsCamera);

            var data = new DynamicEffectsData(); // save quality settings and lower them for the planar reflections
            data.Set(); // set quality settings

            BeginDynamicEffects?.Invoke(context, _DynamicEffectsCamera); // callback Action for dynamic effect

#pragma warning disable CS0618
            UniversalRenderPipeline.RenderSingleCamera(context, _DynamicEffectsCamera); // render dynamic effect
#pragma warning restore CS0618

            DrawTextures();

            data.Restore(); // restore the quality settings
            SetShaderProperties();
        }

        /// <summary>
        /// Textures manipulations using shader
        /// </summary>
        private void DrawTextures()
        {
            _EffectsMaterial.SetFloat(_NormalStrengthId, _NormalStrength);
            _EffectsMaterial.SetFloat("_EdgeMaskSize", _EdgeMaskSize);

            // Create Normal
            if (_EnableNormalBlur)
            {
                _EffectsMaterial.SetFloat(_NormalBlurId, _NormalBlur);
            }
            else
            {
                _EffectsMaterial.SetFloat(_NormalBlurId, 0.0f);
            }


            Graphics.Blit(_DynamicEffectsTexture, _CompRT, _EffectsMaterial, 0);

            if (_EnableNormalBlur)
            {
                _EffectsMaterial.SetTexture(_BaseTexId, _CompRT);
                _EffectsMaterial.SetFloat(_NormalBlurId, _NormalBlur);

                // Blur Pass 1
                Graphics.Blit(_CompRT, _TempRT1, _EffectsMaterial, 1); // Blur H
                Graphics.Blit(_TempRT1, _TempRT2, _EffectsMaterial, 2); // Blur V

                // Blur Pass 2
                Graphics.Blit(_TempRT2, _TempRT1, _EffectsMaterial, 1); // Blur H
                Graphics.Blit(_TempRT1, _TempRT2, _EffectsMaterial, 2); // Blur V

                // Composite Channels
                _EffectsMaterial.SetTexture(_BaseTexId, _DynamicEffectsTexture);
                Graphics.Blit(_TempRT2, _CompRT, _EffectsMaterial, 3);
            }
            else
            {
                _EffectsMaterial.SetTexture(_BaseTexId, _DynamicEffectsTexture);

                Graphics.Blit(_CompRT, _TempRT1);
                Graphics.Blit(_TempRT1, _CompRT, _EffectsMaterial, 3); // Composite Channels
            }
        }

        private void SetShaderProperties()
        {
            var pos = transform.position;
            var parameters = new Vector4();
            parameters.x = pos.x;
            parameters.y = pos.y;
            parameters.z = pos.z;
            parameters.w = _CaptureSize * 2.0f;
            Shader.SetGlobalVector(_DynamicEffectsParams, parameters);

            // Assign texture to water shader
            Shader.SetGlobalTexture(_DynamicEffectsTextureId, _CompRT);
        }

        #region Camera

        private void UpdateEffectsCamera(Camera cam)
        {
            cam.orthographicSize = _CaptureSize;
            cam.farClipPlane = _CaptureDistance;
        }


        private Camera CreateEffectsCamera()
        {
            var go = new GameObject("Effects Camera", typeof(Camera));
            go.hideFlags = HideFlags.HideAndDontSave;
            go.transform.parent = this.transform;
            var cameraData = go.AddComponent(typeof(UniversalAdditionalCameraData)) as UniversalAdditionalCameraData;

            cameraData.renderShadows = false;
            cameraData.requiresColorOption = CameraOverrideOption.Off;
            cameraData.requiresDepthOption = CameraOverrideOption.Off;
            cameraData.SetRenderer(0);

            var t = transform;
            var position = Vector3.zero;
            var rotation = Quaternion.Euler(new Vector3(90f, 0f, 0));


            var effectsCamera = go.GetComponent<Camera>();
            effectsCamera.transform.localPosition = position;
            effectsCamera.transform.localRotation = rotation;
            effectsCamera.cullingMask = _LayerMask;
            effectsCamera.orthographic = true;
            effectsCamera.orthographicSize = _CaptureSize;
            effectsCamera.nearClipPlane = 0f;
            effectsCamera.farClipPlane = _CaptureDistance;
            effectsCamera.clearFlags = CameraClearFlags.Color;
            effectsCamera.backgroundColor = new Color(0.0f, 0.0f, 0.0f, 0.0f);
            effectsCamera.aspect = 1;
            effectsCamera.depth = -100;
            effectsCamera.enabled = false;

            return effectsCamera;
        }

        #endregion

        #region Material

        private void CreateEffectsMaterial()
        {
            if (_EffectsShader == null)
            {
                _EffectsShader = _EffectsShader = Shader.Find("Omnigames/Water/Hidden/WaterEffects");
            }

            if (_EffectsMaterial == null)
            {
                _EffectsMaterial = new Material(_EffectsShader);
            }
        }

        #endregion


        #region Texture

        private void CreateEffectsTextures()
        {
            var res = EffectsResolution(UniversalRenderPipeline.asset.renderScale);
            var x = (int)res.x;
            var y = (int)res.y;

            if (_DynamicEffectsTexture == null)
            {
                _DynamicEffectsTexture = RenderTexture.GetTemporary(x, y, 16, GraphicsFormatUtility.GetGraphicsFormat(_HdrFormat, false));
                _DynamicEffectsTexture.useMipMap = false;
                _DynamicEffectsTexture.autoGenerateMips = false;
            }

            if (_CompRT == null)
            {
                _CompRT = RenderTexture.GetTemporary(x, y, 16, GraphicsFormatUtility.GetGraphicsFormat(_HdrFormat, false));
                _CompRT.useMipMap = false;
                _CompRT.autoGenerateMips = false;
            }

            if (_TempRT1 == null)
            {
                _TempRT1 = RenderTexture.GetTemporary(x / 2, y / 2, 16, GraphicsFormatUtility.GetGraphicsFormat(_HdrFormat, false));
                _TempRT1.useMipMap = false;
                _TempRT1.autoGenerateMips = false;
            }

            if (_EnableNormalBlur && _TempRT2 == null)
            {
                _TempRT2 = RenderTexture.GetTemporary(x / 2, y / 2, 16, GraphicsFormatUtility.GetGraphicsFormat(_HdrFormat, false));
                _TempRT2.useMipMap = false;
                _TempRT2.autoGenerateMips = false;
            }


            _DynamicEffectsCamera.targetTexture = _DynamicEffectsTexture;
        }

        private Vector2 EffectsResolution(float scale)
        {
            var x = (int)(2048 * scale * GetScaleValue());
            var y = (int)(2048 * scale * GetScaleValue());
            return new Vector2(x, y);
        }

        #endregion

        private Vector3 XZPos(Vector3 pos)
        {
            return new Vector3(pos.x, pos.y + _CaptureDistance, pos.z);
        }

        private float GetScaleValue()
        {
            switch (_Quality)
            {
                case Quality.VeryHigh:
                    return 1f;
                case Quality.High:
                    return 0.5f;
                case Quality.Medium:
                    return 0.33f;
                case Quality.Low:
                    return 0.25f;
                default:
                    return 0.5f;
            }
        }

        private void Cleanup()
        {
            RenderPipelineManager.beginCameraRendering -= ComputeEffects;

            if (_DynamicEffectsCamera)
            {
                _DynamicEffectsCamera.targetTexture = null;
                SafeDestroy(_DynamicEffectsCamera.gameObject);
            }

            if (_DynamicEffectsTexture)
            {
                RenderTexture.ReleaseTemporary(_DynamicEffectsTexture);
            }

            if (_CompRT)
            {
                RenderTexture.ReleaseTemporary(_CompRT);
            }

            if (_EffectsMaterial)
            {
                SafeDestroy(_EffectsMaterial);
            }

            if (_TempRT1)
            {
                RenderTexture.ReleaseTemporary(_TempRT1);
            }

            if (_TempRT2)
            {
                RenderTexture.ReleaseTemporary(_TempRT2);
            }
        }

        private static void SafeDestroy(UnityEngine.Object obj)
        {
            if (Application.isEditor)
            {
                DestroyImmediate(obj);
            }
            else
            {
                Destroy(obj);
            }
        }

        void OnDrawGizmos()
        {
#if UNITY_EDITOR

            if (_ShowRegion == false || _DynamicEffectsCamera == null)
            {
                return;
            }


            var pos = _DynamicEffectsCamera.transform.position;
            pos.y -= _DynamicEffectsCamera.farClipPlane * 0.5f;

            var size = new Vector3(_CaptureSize * 2.0f, _DynamicEffectsCamera.farClipPlane, _CaptureSize * 2.0f);
            Gizmos.color = new Color(0, 0.5f, 1, 0.5f);
            Gizmos.DrawCube(pos, size);
            Gizmos.color = new Color(0, 0.5f, 1, 0.9f);
            Gizmos.DrawWireCube(pos, size);
#endif
        }

        /// <summary>
        /// Get or set the size of the capture.
        /// </summary>
        public float CaptureSize
        {
            get => _CaptureSize;
            set { _CaptureSize = value; }
        }

        /// <summary>
        /// Get or set the Y distance range of the capture.
        /// </summary>
        public float CaptureDistance
        {
            get => _CaptureDistance;
            set { _CaptureDistance = value; }
        }


        class DynamicEffectsData
        {
            private readonly bool _Fog;
            private readonly int _MaxLod;
            private readonly float _LodBias;
            private readonly bool _DrawGizmos;

            public DynamicEffectsData()
            {
                _Fog = RenderSettings.fog;
                _MaxLod = QualitySettings.maximumLODLevel;
                _LodBias = QualitySettings.lodBias;
#if UNITY_EDITOR
                if (SceneView.currentDrawingSceneView != null)
                    _DrawGizmos = SceneView.currentDrawingSceneView.drawGizmos;
#endif
            }

            public void Set()
            {
                //GL.invertCulling = true;
#if UNITY_EDITOR
                if (SceneView.currentDrawingSceneView != null)
                    SceneView.currentDrawingSceneView.drawGizmos = false;
#endif
                RenderSettings.fog = false; // disable fog for now as it's incorrect with projection
                QualitySettings.maximumLODLevel = 1;
                QualitySettings.lodBias = _LodBias * 0.5f;
            }

            public void Restore()
            {
                GL.invertCulling = false;
#if UNITY_EDITOR
                if (SceneView.currentDrawingSceneView != null)
                    SceneView.currentDrawingSceneView.drawGizmos = _DrawGizmos;
#endif
                RenderSettings.fog = _Fog;
                QualitySettings.maximumLODLevel = _MaxLod;
                QualitySettings.lodBias = _LodBias;
            }
        }
    }
}



toon water blur

#ifndef URPWATER_BLUR_INCLUDED
#define URPWATER_BLUR_INCLUDED

//#include "Packages/com.unity.render-pipelines.universal/ShaderLibrary/Core.hlsl"

static const float _Offset[] = { 0.0, 1.0, 2.0, 3.0, 4.0 };
static const float _Weight[] = { 0.2270270270, 0.1945945946, 0.1216216216,0.0540540541, 0.0162162162 };


struct appdataBlur
{
    float4 vertex : POSITION;
    float2 uv : TEXCOORD0;
};


struct v2fBlur
{
    float4 vertex : SV_POSITION;
    float2 uv : TEXCOORD0;
};

v2fBlur vertBlur(appdataBlur v)
{
    v2fBlur o;
    o.vertex = UnityObjectToClipPos(v.vertex);
    o.uv = v.uv;

    return o;
}

float4 fragBlur(v2fBlur IN) : SV_Target
{
    float2 Offset = float2(1,0);

    #ifdef BLUR_H
    Offset = float2(1, 0);
    #endif

    #ifdef BLUR_V
    Offset = float2(0, 1);
    #endif

    Offset *= _MainTex_TexelSize.xy * _BlurStrength;


    float4 SharpColor = tex2D(_MainTex, IN.uv);
    float4 FragmentColor = SharpColor * _Weight[0];


    UNITY_LOOP
    for (int i = 1; i < 5; i++)
    {
        float2 o = _Offset[i] * Offset;

        FragmentColor += tex2D(_MainTex, IN.uv + o) * _Weight[i];
        FragmentColor += tex2D(_MainTex, IN.uv - o) * _Weight[i];
    }

    FragmentColor = saturate(FragmentColor);
    FragmentColor.b = 0.5;

    return FragmentColor;
}

#endif



toon water effect

// Copyright(C) Yan Verde - All Rights Reserved
// Copyright protected under Unity Asset Store EULA
// Refer to https://unity3d.com/legal/as_terms for more informations
// -----------------------------------------------------------------------------
// URP Water
// Author : Yan Verde
// Date : April 10, 2021
// -----------------------------------------------------------------------------

Shader "Omnigames/Water/Hidden/WaterEffects"
{
    Properties
    {
        _MainTex ("Texture", 2D) = "white" {}
        _EdgeMaskSize ("EdgeMask Size", float) = 0.1
    }

    SubShader
    {
        // No culling or depth
        Cull Off ZWrite Off ZTest Always

        CGINCLUDE

        CBUFFER_START(UnityPerMaterial)
        sampler2D _MainTex;
        float4 _MainTex_TexelSize;
        float _EdgeMaskSize;
        CBUFFER_END

        sampler2D _BaseTex;
        sampler2D _NormalMap;

        float _NormalStrength;
        float _BlurStrength;



        float3 RemapNormals(float3 from, float3 to, float3 value) {
            return (value - from) / (to - from);
        }

        float3 SafeNormalize(float3 inVec)
        {
            float dp3 = max(0.001, dot(inVec, inVec));
            return inVec * rsqrt(dp3);
        }

        struct appdata
        {
            float4 vertex : POSITION;
            float2 uv : TEXCOORD0;
        };

        struct v2f
        {
            float4 vertex : SV_POSITION;
            float2 uv : TEXCOORD0;

        };

        v2f vert(appdata v)
        {
            v2f o;
            o.vertex = UnityObjectToClipPos(v.vertex);
            o.uv = v.uv;
            return o;
        }

        ENDCG


        Pass
        {
            name "Base"
            CGPROGRAM
            #pragma vertex vert
            #pragma fragment frag

            #include "UnityCG.cginc"

            float4 frag(v2f i) : SV_Target
            {
                // Original
                float3 duv = float3(_MainTex_TexelSize.xy, 0);
                float4 v0 = tex2D(_MainTex, i.uv);

                // Create Normal
                float v1 = tex2D(_MainTex, i.uv - duv.xz).r;
                float v2 = tex2D(_MainTex, i.uv + duv.xz).r;
                float v3 = tex2D(_MainTex, i.uv - duv.zy).r;
                float v4 = tex2D(_MainTex, i.uv + duv.zy).r;

                float BlurMult = lerp(1, 16, _BlurStrength * 0.25);
                float3 n = SafeNormalize(float3(v2 - v1, v4 - v3, 0.0)) * _NormalStrength * BlurMult;

                // Blend with heightmap for smooth borders
                n *= v0.rrr;

                // Put back to 0-1 range in order to use non HDR texture.
                n = saturate(RemapNormals(-1, 1, n));

                return float4(n.x, n.y, v0.b, v0.a);
            }
            ENDCG
        }

        Pass
        {
            name "BlurV"
            CGPROGRAM

            #pragma vertex vertBlur
            #pragma fragment fragBlur

            #define BLUR_H
            #include "UnityCG.cginc"
            #include "ToonWaterBlur.hlsl"


            ENDCG
        }

        Pass
        {
            name "BlurV"
            CGPROGRAM

            #pragma vertex vertBlur
            #pragma fragment fragBlur

            #define BLUR_V
            #include "UnityCG.cginc"
            #include "ToonWaterBlur.hlsl"


            ENDCG
        }

        Pass
        {
            name "CompositeBlur"
            CGPROGRAM
            #pragma vertex vert
            #pragma fragment fragComp

            #include "UnityCG.cginc"

            float4 fragComp(v2f i) : SV_Target
            {
                // Blurred / Normals
                float4 NormalsTex = tex2D(_MainTex, i.uv);
                // Original
                float4 BaseTex = tex2D(_BaseTex, i.uv);

                float2 edgeMaskUV = abs(i.uv * 2 - 1);
                float edgeMask = 1 - max(edgeMaskUV.x, edgeMaskUV.y);
                float mask = smoothstep(0, _EdgeMaskSize, edgeMask);

                BaseTex.ba *= mask;
                NormalsTex.a *= mask;

                return float4(NormalsTex.rg, BaseTex.b, NormalsTex.a);
            }

            ENDCG
        }
    }
}



foam fx

Shader "Omnigames/Water/FoamFX"
{
    Properties
    {
        _MainTex ("Foam Mask", 2D) = "white" {}
    }
    SubShader
    {
        Tags {"Queue"="Transparent" "RenderType"="Transparent"  "RenderPipeline"="UniversalPipeline"}
        ColorMask RGB
        Blend SrcAlpha OneMinusSrcAlpha
        Zwrite Off
        LOD 100

        Pass
        {
            Name "URPWaterFoamFX"

            HLSLPROGRAM
            #pragma vertex vert
            #pragma fragment frag
            #pragma prefer_hlslcc gles
            #pragma exclude_renderers d3d11_9x
            #pragma multi_compile_instancing

            #include "Packages/com.unity.render-pipelines.universal/ShaderLibrary/Core.hlsl"


            struct appdata
            {
                float4 vertex : POSITION;
                float2 uv : TEXCOORD0;
                float4 color : COLOR;

                UNITY_VERTEX_INPUT_INSTANCE_ID
            };

            struct v2f
            {
                float4 vertex : SV_POSITION;
                float2 uv : TEXCOORD0;
                float4 color : COLOR;

                UNITY_VERTEX_INPUT_INSTANCE_ID
                UNITY_VERTEX_OUTPUT_STEREO
            };

            CBUFFER_START(UnityPerMaterial)
            sampler2D _MainTex;
            float4 _MainTex_ST;
            CBUFFER_END

            v2f vert (appdata v)
            {
                v2f o;

                UNITY_SETUP_INSTANCE_ID(v);
                UNITY_TRANSFER_INSTANCE_ID(v, o);
                UNITY_INITIALIZE_VERTEX_OUTPUT_STEREO(o);

                o.vertex = TransformObjectToHClip(v.vertex.xyz);
                o.uv = TRANSFORM_TEX(v.uv, _MainTex);
                o.color = v.color;

                return o;
            }

            half4 frag (v2f i) : SV_Target
            {
                half4 col = tex2D(_MainTex, i.uv) * i.color;
                col *= half4(0, 0, 1, 1 * col.b);

                return col;
            }
            ENDHLSL
        }
    }
}



normal fx

Shader "Omnigames/Water/NormalFX"
{
    Properties
    {
        _MainTex ("Foam Mask", 2D) = "white" {}
    }
    SubShader
    {
        Tags {"Queue"="Transparent" "RenderType"="Transparent"  "RenderPipeline"="UniversalPipeline"}
        Blend SrcAlpha OneMinusSrcAlpha
        Zwrite Off
        LOD 100

        Pass
        {
            Name "URPWaterNormalFX"

            HLSLPROGRAM
            #pragma vertex vert
            #pragma fragment frag
            #pragma prefer_hlslcc gles
            #pragma exclude_renderers d3d11_9x
            #pragma multi_compile_instancing

            #include "Packages/com.unity.render-pipelines.universal/ShaderLibrary/Core.hlsl"


            struct appdata
            {
                float4 vertex : POSITION;
                float2 uv : TEXCOORD0;
                float4 color : COLOR;

                UNITY_VERTEX_INPUT_INSTANCE_ID
            };

            struct v2f
            {
                float4 vertex : SV_POSITION;
                float2 uv : TEXCOORD0;
                float4 color : COLOR;

                UNITY_VERTEX_INPUT_INSTANCE_ID
                UNITY_VERTEX_OUTPUT_STEREO
            };

            CBUFFER_START(UnityPerMaterial)
            sampler2D _MainTex;
            float4 _MainTex_ST;
            CBUFFER_END

            v2f vert (appdata v)
            {
                v2f o;

                UNITY_SETUP_INSTANCE_ID(v);
                UNITY_TRANSFER_INSTANCE_ID(v, o);
                UNITY_INITIALIZE_VERTEX_OUTPUT_STEREO(o);

                o.vertex = TransformObjectToHClip(v.vertex.xyz);
                o.uv = TRANSFORM_TEX(v.uv, _MainTex);
                o.color = v.color;

                return o;
            }

            half4 frag (v2f i) : SV_Target
            {
                half4 col = tex2D(_MainTex, i.uv);
                col.rgb *= half3(1,0,0);
                col.a = col.r * i.color.a;
                return col;
            }
            ENDHLSL
        }
    }
}





normal tanget draw

using System.Text;
using UnityEngine;
using UnityEditor;

[ExecuteAlways]
public class NormalTangentVisualizer : MonoBehaviour
{
    [Header("显示设置")]
    public bool showNormals = true;

    public bool showTangents = true;
    public bool showBitangents = true;
    public float normalLength = 0.1f;
    public float tangentLength = 0.05f;

    [Header("颜色设置")]
    public Color normalColor = Color.blue;

    public Color tangentColor = Color.red;
    public Color bitangentColor = Color.green;

    private Mesh mesh;
    private Vector3[] vertices;
    private Vector3[] normals;
    private Vector4[] tangents;

    void OnEnable()
    {
        RefreshMeshData();
    }

    void RefreshMeshData()
    {
        MeshFilter mf = GetComponent<MeshFilter>();
        if (mf != null && mf.sharedMesh != null)
        {
            mesh = mf.sharedMesh;
            vertices = mesh.vertices;
            normals = mesh.normals;
            tangents = mesh.tangents;
        }
    }

    void OnDrawGizmosSelected()
    {
        if (mesh == null) RefreshMeshData();
        if (mesh == null) return;

        Transform transform = this.transform;

        if (showNormals && normals != null && normals.Length == vertices.Length)
        {
            Gizmos.color = normalColor;
            for (int i = 0; i < vertices.Length; i++)
            {
                Vector3 worldPos = transform.TransformPoint(vertices[i]);
                Vector3 worldNormal = transform.TransformDirection(normals[i]);
                Gizmos.DrawLine(worldPos, worldPos + worldNormal * normalLength);
            }
        }

        if ((showTangents || showBitangents) && tangents != null && tangents.Length == vertices.Length)
        {
            // 切线
            Gizmos.color = tangentColor;
            for (int i = 0; i < vertices.Length; i++)
            {
                Vector3 worldPos = transform.TransformPoint(vertices[i]);
                Vector4 tangent4 = tangents[i];
                Vector3 tangent = new Vector3(tangent4.x, tangent4.y, tangent4.z);
                Vector3 worldTangent = transform.TransformDirection(tangent);

                if (showTangents)
                {
                    Gizmos.DrawLine(worldPos, worldPos + worldTangent * tangentLength);
                }

                if (showBitangents)
                {
                    // 副切线
                    if (tangent4.w != 0 && normals != null && i < normals.Length)
                    {
                        Gizmos.color = bitangentColor;
                        Vector3 worldNormal = transform.TransformDirection(normals[i]);
                        Vector3 bitangent = Vector3.Cross(worldNormal, worldTangent) * tangent4.w;
                        Gizmos.DrawLine(worldPos, worldPos + bitangent * tangentLength);
                        Gizmos.color = tangentColor;
                    }
                }
            }
        }
    }

    [ContextMenu("打印法线切线数据")]
    public void PrintNormalTangentData()
    {
        RefreshMeshData();
        if (mesh == null)
        {
            Debug.LogError("没有找到Mesh数据");
            return;
        }

        Debug.Log($"=== {gameObject.name} 法线切线数据 ===");
        Debug.Log($"顶点数: {vertices.Length}");
        Debug.Log($"法线数: {normals.Length}");
        Debug.Log($"切线数: {tangents.Length}");

        StringBuilder sb = new StringBuilder();
        for (int i = 0; i < Mathf.Min(vertices.Length, 10); i++) // 只显示前10个
        {
            sb.AppendLine($"顶点 {i}:");
            sb.AppendLine($"  位置: {vertices[i]}");
            sb.AppendLine($"  法线: {normals[i]}");
            if (i < tangents.Length)
                sb.AppendLine($"  切线: {tangents[i]} (w={tangents[i].w})");
            sb.AppendLine();
        }

        Debug.Log(sb.ToString());
    }
}



kajiya

Shader "Omnigames/Role/Hair Kajiya Lit Demo"
{
    Properties
    {
        [MainTexture] _BaseMap("Texture", 2D) = "white" {}
        [MainColor] _BaseColor("Color", Color) = (1, 1, 1, 1)
        _NormalMap("Normal Map", 2D) = "bump" {}
        _AnosioMap("Anosio", 2D) = "white" {}

        _Cutoff("Alpha Cutoff", Range(0, 1)) = 0.5

        [Header(Specular1)]
        _Specular1Roughness("Specular 1 Roughness", Range(0,1)) = 1
        _Specular1Tint("Specular 1 Tint", Color) = (0.1,0.1,0.1,0)
        _Specular1Shift("Specular 1 Shift", Range(-2,2)) = 0

        [Header(Specular2)]
        [Toggle] _UseSecondSpecular("Use Second Specular", float) = 0
        _Specular2Roughness("Specular 2 Roughness", Range(0,1)) = 1
        _Specular2Tint("Specular 2 Tint", Color) = (0.1,0.1,0.1,0)
        _Specular2Shift("Specular 2 Shift", Range(-2,2)) = 0
    }
    SubShader
    {
        Tags
        {
            "RenderType" = "Opaque"
            "RenderPipeline" = "UniversalPipeline"
            "Queue" = "Geometry"
        }
        LOD 100

        Pass
        {
            HLSLPROGRAM
            #pragma vertex UnlitPassVertex
            #pragma fragment UnlitPassFragment
            #include "Packages/com.unity.render-pipelines.universal/ShaderLibrary/Core.hlsl"
            #include "Packages/com.unity.render-pipelines.universal/ShaderLibrary/Lighting.hlsl"

            #pragma shader_feature_fragment _USESECONDSPECULAR_ON

            TEXTURE2D(_BaseMap);
            SAMPLER(sampler_BaseMap);
            TEXTURE2D(_NormalMap);
            SAMPLER(sampler_NormalMap);
            TEXTURE2D(_AnosioMap);
            SAMPLER(sampler_AnosioMap);

            CBUFFER_START(UnityPerMaterial)
                half4 _BaseColor;
                half _Cutoff;

                float4 _AnosioMap_ST;

                half _Specular1Roughness;
                half4 _Specular1Tint;
                half _Specular1Shift;

                half _Specular2Roughness;
                half4 _Specular2Tint;
                half _Specular2Shift;
            CBUFFER_END

            struct Attributes
            {
                float4 positionOS : POSITION;
                float2 uv : TEXCOORD0;
                float4 tangentOS : TANGENT;
                float3 normalOS : NORMAL;

                UNITY_VERTEX_INPUT_INSTANCE_ID
            };

            struct Varyings
            {
                float2 uv : TEXCOORD0;
                float4 positionCS : SV_POSITION;
                float3 normalWS : TEXCOORD1;
                float3 tangentWS : TEXCOORD2;
                float3 bitangentWS : TEXCOORD3;
                float3 positionWS : TEXCOORD4;

                UNITY_VERTEX_INPUT_INSTANCE_ID
            };

            Varyings UnlitPassVertex(Attributes input)
            {
                Varyings output = (Varyings)0;

                UNITY_SETUP_INSTANCE_ID(input);
                UNITY_TRANSFER_INSTANCE_ID(input, output);

                VertexPositionInputs positionInputs = GetVertexPositionInputs(input.positionOS.xyz);
                VertexNormalInputs normalInputs = GetVertexNormalInputs(input.normalOS, input.tangentOS);

                output.positionCS = positionInputs.positionCS;
                output.uv = input.uv;
                output.positionWS = positionInputs.positionWS;
                output.normalWS = normalInputs.normalWS;
                output.tangentWS = normalInputs.tangentWS;
                output.bitangentWS = normalInputs.bitangentWS;

                return output;
            }

            real RoughnessToBlinnPhongSpecularExponent(real roughness)
            {
                return clamp(2 * rcp(roughness * roughness) - 2, FLT_EPS, rcp(FLT_EPS));
            }

            half4 UnlitPassFragment(Varyings input) : SV_Target0
            {
                UNITY_SETUP_INSTANCE_ID(input);

                float3 positionWS = input.positionWS;
                float3 V = GetWorldSpaceNormalizeViewDir(positionWS);

                float3 NModel = normalize(input.normalWS);
                float3 T = normalize(input.tangentWS);
                float3 B = normalize(input.bitangentWS);

                half4 normalMap = SAMPLE_TEXTURE2D(_NormalMap, sampler_NormalMap, input.uv);
                float3 normalTS = UnpackNormal(normalMap);
                float3x3 TBN = float3x3(T, B, NModel);
                float3 N = TransformTangentToWorld(normalTS, TBN, true);

                Light mainLight = GetMainLight();
                float3 L = mainLight.direction;
                float NoL = max(0, dot(N, L));
                half3 radiance = mainLight.color * NoL; // * mainLight.shadowAttenuation * mainLight.distanceAttenuation;
                float3 H = normalize(L + V);

                half4 baseMap = SAMPLE_TEXTURE2D(_BaseMap, sampler_BaseMap, input.uv);
                half3 albedo = baseMap.rgb * _BaseColor.rgb;
                half alpha = baseMap.a * _BaseColor.a;

                // diffuse
                half3 diffuse = albedo;

                half4 anosioMap = SAMPLE_TEXTURE2D(_AnosioMap, sampler_AnosioMap, input.uv * _AnosioMap_ST.xy);

                // kaijiya-kay model
                float specularShift1 = _Specular1Shift + anosioMap.r;
                half3 t1 = ShiftTangent(B, N, specularShift1);
                float gloss1 = RoughnessToBlinnPhongSpecularExponent(_Specular1Roughness * anosioMap.g);
                half3 specular = _Specular1Tint.rgb * D_KajiyaKay(t1, H, gloss1);

                #if _USESECONDSPECULAR_ON
                float specularShift2 = _Specular2Shift + anosioMap.r;
                half3 t2 = ShiftTangent(B, N, specularShift2);
                float gloss2 = RoughnessToBlinnPhongSpecularExponent(_Specular2Roughness * anosioMap.g);
                half3 specular2 = _Specular2Tint.rgb * D_KajiyaKay(t2, H, gloss2);
                specular += specular2;
                #endif

                half4 color;
                color.a = alpha;
                color.rgb = (diffuse + specular) * radiance;

                return color;
            }
            ENDHLSL
        }
    }

    FallBack "Hidden/Universal Render Pipeline/FallbackError"
}
