22-drawing-app











html

<!DOCTYPE html>
<html lang="en">
<head>
    <meta charset="UTF-8">
    <meta http-equiv="X-UA-Compatible" content="IE=edge">
    <meta name="viewport" content="width=device-width, initial-scale=1.0">
    <link rel="stylesheet" href="style.css">
    <title>Document</title>
</head>
<body>
    <canvas id="canvas" width="800" height="700"></canvas>
    <div class="toolbox">
        <button id="decrease">-</button>
        <span id="size">10</span>
        <button id="increase">+</button>
        <input type="color" id="color">
        <button id="clear">X</button>
    </div>
    <script src="./script.js"></script>
</body>
</html>





css

@import url('https://fonts.googleapis.com/css2?family=Roboto:wght@400;700&display=swap');

* {
  box-sizing: border-box;
}

body{
    background-color: #f5f5f5;
    font-family: 'Roboto',sans-serif;
    display: flex;
    flex-direction: column;
    align-items: center;
    justify-content: center;
    height: 100vh;
    margin: 0;
}

canvas{
    border: 2px solid steelblue;
}

.toolbox{
    background-color: steelblue;
    border: 1px solid slateblue;
    display: flex;
    width: 804px;
    padding: 1rem;
}

.toolbox > * {
    background-color: #fff;
    border: none;
    display: inline-flex;
    align-items: center;
    justify-content: center;
    font-size: 2rem;
    height: 50px;
    width: 50px;
    margin: 0.25rem;
    padding: 0.25rem;
    cursor: pointer;
}

.toolbox > *:last-child{
    margin-left: auto;
}





javascript

const canvas = document.getElementById('canvas');
const increaseBtn = document.getElementById('increase')
const decreaseBtn = document.getElementById('decrease')
const sizeEL = document.getElementById('size')
const colorEl = document.getElementById('color')
const clearEl = document.getElementById('clear')

const ctx = canvas.getContext('2d')

let size = 10
let isPressed = false
colorEl.value='black'
let color = colorEl.value
let x
let y

canvas.addEventListener('mousedown',(e)=>{
    isPressed = true

    x=e.offsetX
    y=e.offsetY
})

document.addEventListener('mouseup',(e)=>{
    isPressed=false
    x=undefined
    y=undefined
})


canvas.addEventListener('mousemove',(e)=>{
    if(isPressed){
        const x2 = e.offsetX
        const y2 = e.offsetY

        drawCircle(x2,y2)
        drawLine(x,y,x2,y2)

        x=x2
        y=y2
    }
})

function drawCircle(x,y){
    ctx.beginPath();
    ctx.arc(x,y,size,0,Math.PI*2)
    ctx.fillStyle = color
    ctx.fill()
}


function drawLine(x1,y1,x2,y2){
    ctx.beginPath()
    ctx.moveTo(x1,y1)
    ctx.lineTo(x2,y2)
    ctx.strokeStyle=color
    ctx.lineWidth = size*2
    ctx.stroke()
}

function updateSizeOnScreen(){
    sizeEL.innerText = size
}

increaseBtn.addEventListener('click',()=>{
    size += 5
    if(size > 50){
        size = 50
    }

    updateSizeOnScreen()
})

decreaseBtn.addEventListener('click',()=>{
    size -= 5
    if(size < 5){
        size = 5
    }

    updateSizeOnScreen()
})


colorEl.addEventListener('change',(e)=>color=e.target.value)

clearEl.addEventListener('click',()=>ctx.clearRect(0,0,canvas.width,canvas.height))
