k8s系列-13-生成证书和各组件的认证配置

老板们，点个关注吧。

要知道我们相互访问需要的是什么，需要的是安全性，那么我们就使用https来控制相互间的访问吧，那么我们就需要使用证书，我们这里采用自建证书来实现。

安装证书生成服务

只需要在一个节点上安装即可，我这里选择的是node1节点。

[root@node1 ~]# wget https://pkg.cfssl.org/R1.2/cfssl_linux-amd64 -O /usr/local/bin/cfssl
[root@node1 ~]# wget https://pkg.cfssl.org/R1.2/cfssljson_linux-amd64 -O /usr/local/bin/cfssljson
[root@node1 ~]# chmod +x /usr/local/bin/cfssl
[root@node1 ~]# chmod +x /usr/local/bin/cfssljson
[root@node1 ~]# cfssl version
Version: 1.2.0
Revision: dev
Runtime: go1.6
[root@node1 ~]#

根证书

根证书是共享的，只需要创建一个，其他证书统一由这个根证书来签名，只需要在一个节点操作即可，我这里在node1节点上操作。

PS：最好单独创建一个单独存放证书的目录，不然会乱掉。

[root@node1 ~]# mkdir pki
[root@node1 ~]# cd pki/
[root@node1 pki]#
# 可以看到下面的过期时间，我们设置的很长，几乎不用考虑过期这一说
[root@node1 pki]# cat > ca-config.json <<EOF
{
  "signing": {
    "default": {
      "expiry": "876000h"
    },
    "profiles": {
      "kubernetes": {
        "usages": ["signing", "key encipherment", "server auth", "client auth"],
        "expiry": "876000h"
      }
    }
  }
}
EOF
[root@node1 pki]#
[root@node1 pki]# cat > ca-csr.json <<EOF
{
  "CN": "Kubernetes",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "US",
      "L": "Portland",
      "O": "Kubernetes",
      "OU": "CA",
      "ST": "Oregon"
    }
  ]
}
EOF
[root@node1 pki]#

生成证书和私钥：

[root@node1 pki]# cfssl gencert -initca ca-csr.json | cfssljson -bare ca
[root@node1 pki]# ls
ca-config.json  ca.csr  ca-csr.json  ca-key.pem  ca.pem
[root@node1 pki]#

admin客户端证书

[root@node1 pki]# cat > admin-csr.json <<EOF
{
  "CN": "admin",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "BeiJing",
      "L": "BeiJing",
      "O": "system:masters",
      "OU": "seven"
    }
  ]
}
EOF
[root@node1 pki]#

生成admin客户端和私钥

[root@node1 pki]# cfssl gencert \
  -ca=ca.pem \
  -ca-key=ca-key.pem \
  -config=ca-config.json \
  -profile=kubernetes \
  admin-csr.json | cfssljson -bare admin
[root@node1 pki]# ls
admin.csr  admin-csr.json  admin-key.pem  admin.pem  ca-config.json  ca.csr  ca-csr.json  ca-key.pem  ca.pem
[root@node1 pki]#

kubelet客户端证书

要给每个工作节点生成证书，所以这步中你要写你自己的node名字和IP地址哈。

# 设置你的worker节点列表
[root@node1 pki]# for ((i=0;i<${#WORKERS[@]};i++)); do
cat > ${WORKERS[$i]}-csr.json <<EOF
{
  "CN": "system:node:${WORKERS[$i]}",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "L": "Beijing",
      "O": "system:nodes",
      "OU": "seven",
      "ST": "Beijing"
    }
  ]
}
EOF
cfssl gencert \
  -ca=ca.pem \
  -ca-key=ca-key.pem \
  -config=ca-config.json \
  -hostname=${WORKERS[$i]},${WORKER_IPS[$i]} \
  -profile=kubernetes \
  ${WORKERS[$i]}-csr.json | cfssljson -bare ${WORKERS[$i]}
done
[root@node1 pki]#

查看证书：

[root@node1 pki]# ls
admin.csr       admin-key.pem  ca-config.json  ca-csr.json  ca.pem     node2-csr.json  node2.pem  node3-csr.json  node3.pem
admin-csr.json  admin.pem      ca.csr          ca-key.pem   node2.csr  node2-key.pem   node3.csr  node3-key.pem
[root@node1 pki]#

kube-controller-manager证书

[root@node1 pki]# cat > kube-controller-manager-csr.json <<EOF
{
    "CN": "system:kube-controller-manager",
    "key": {
        "algo": "rsa",
        "size": 2048
    },
    "names": [
      {
        "C": "CN",
        "ST": "BeiJing",
        "L": "BeiJing",
        "O": "system:kube-controller-manager",
        "OU": "seven"
      }
    ]
}
EOF
[root@node1 pki]#

生成证书：

[root@node1 pki]# cfssl gencert \
  -ca=ca.pem \
  -ca-key=ca-key.pem \
  -config=ca-config.json \
  -profile=kubernetes \
  kube-controller-manager-csr.json | cfssljson -bare kube-controller-manager
[root@node1 pki]#

查看：

[root@node1 pki]# ls
admin.csr       admin.pem       ca-csr.json  kube-controller-manager.csr       kube-controller-manager.pem  node2-key.pem  node3-csr.json
admin-csr.json  ca-config.json  ca-key.pem   kube-controller-manager-csr.json  node2.csr                    node2.pem      node3-key.pem
admin-key.pem   ca.csr          ca.pem       kube-controller-manager-key.pem   node2-csr.json               node3.csr      node3.pem
[root@node1 pki]#

kube-proxy客户端证书

[root@node1 pki]# cat > kube-proxy-csr.json <<EOF
{
  "CN": "system:kube-proxy",
  "key": {
    "algo": "rsa",
    "size": 2048
  },
  "names": [
    {
      "C": "CN",
      "ST": "BeiJing",
      "L": "BeiJing",
      "O": "k8s",
      "OU": "seven"
    }
  ]
}
EOF
‍
[root@node1 pki]#

生成证书：

[root@node1 pki]# cfssl gencert \
  -ca=ca.pem \
  -ca-key=ca-key.pem \
  -config=ca-config.json \
  -profile=kubernetes \
  kube-proxy-csr.json | cfssljson -bare kube-proxy

查看：

[root@node1 pki]# ls
admin.csr       admin.pem       ca-csr.json  kube-controller-manager.csr       kube-controller-manager.pem  kube-proxy-key.pem  node2-csr.json  node3.csr       node3.pem
admin-csr.json  ca-config.json  ca-key.pem   kube-controller-manager-csr.json  kube-proxy.csr               kube-proxy.pem      node2-key.pem   node3-csr.json
admin-key.pem   ca.csr          ca.pem       kube-controller-manager-key.pem   kube-proxy-csr.json          node2.csr           node2.pem       node3-key.pem
[root@node1 pki]#

kube-scheduler证书

[root@node1 pki]# cat > kube-scheduler-csr.json <<EOF
{
    "CN": "system:kube-scheduler",
    "key": {
        "algo": "rsa",
        "size": 2048
    },
    "names": [
      {
        "C": "CN",
        "ST": "BeiJing",
        "L": "BeiJing",
        "O": "system:kube-scheduler",
        "OU": "seven"
      }
    ]
}
EOF
[root@node1 pki]#

生成证书：

[root@node1 pki]# cfssl gencert \
  -ca=ca.pem \
  -ca-key=ca-key.pem \
  -config=ca-config.json \
  -profile=kubernetes \
  kube-scheduler-csr.json | cfssljson -bare kube-scheduler
‍
[root@node1 pki]#

查看：

[root@node1 pki]# ls
admin.csr       ca-config.json  ca.pem                            kube-controller-manager.pem  kube-proxy.pem           kube-scheduler.pem  node2.pem       node3.pem
admin-csr.json  ca.csr          kube-controller-manager.csr       kube-proxy.csr               kube-scheduler.csr       node2.csr           node3.csr
admin-key.pem   ca-csr.json     kube-controller-manager-csr.json  kube-proxy-csr.json          kube-scheduler-csr.json  node2-csr.json      node3-csr.json
admin.pem       ca-key.pem      kube-controller-manager-key.pem   kube-proxy-key.pem           kube-scheduler-key.pem   node2-key.pem       node3-key.pem
[root@node1 pki]#

**kube-apiserver证书
**
