.NET MAUI 使用 WebView 实现 JS 与 C# 交互和数据传输，解决访问 URL 白屏与 A JavaScript exception occurred 问题

参考

• 豆包
• DeepSeek
• https://learn.microsoft.com/zh-cn/dotnet/maui/user-interface/controls/webview
• https://learn.microsoft.com/zh-cn/dotnet/maui/?view=net-maui-10.0

环境

软件/系统	版本	说明
macOS	macOS 15.6.1	Apple M2 芯片
Safari	18.6
.NET	10.0.100
Visual Studio Code	1.107.1
Visual Studio Code 扩展: .NET MAUI	1.12.15
Visual Studio Code 扩展: C#	2.110.4
Visual Studio Code 扩展: .NET Install Tool	3.0.0
Visual Studio Code 扩展: C# Dev Kit	1.90.2

注意

iOS 和 Mac Catalyst：使用 WKWebView，它基于 Safari WebKit 浏览器引擎。 这是 iOS 和 macOS 上的 Safari 浏览器使用的相同引擎。 -- https://learn.microsoft.com/zh-cn/dotnet/maui/user-interface/controls/webview

1. WKWebView 存在 JS 兼容问题，建议先在 Safari 中进行验证与测试。
2. 在 WKWebView 注入自定义函数时出现下面的错误, 是多行JS直接作为字符串传递可能会出现问题，因为里面有换行符。多行必须转换为一行。

   Error Domain=WKErrorDomain Code=4 "A JavaScript exception occurred" UserInfo={WKJavaScriptExceptionLineNumber=1, WKJavaScriptExceptionMessage=SyntaxError: Unexpected EOF, WKJavaScriptExceptionColumnNumber=0, WKJavaScriptExceptionSourceURL=https://www.xxxx.com/, NSLocalizedDescription=A JavaScript exception occurred}


3. 在 iOS 和 Mac Catalyst 上配置应用传输安全性（允许 http 请求），在 项目/Platforms/MacCatalyst/Info.plist 添加以下代码：

   <!-- 允许不安全的请求 https://learn.microsoft.com/zh-cn/dotnet/maui/user-interface/controls/webview?view=net-maui-10.0&pivots=devices-maccatalyst#inspect-a-webview-on-mac-catalyst -->
   <key>NSAppTransportSecurity</key>
   <dict>
   	<key>NSAllowsArbitraryLoads</key>
   	<true/>
   </dict>


正文

客户端代码

JS->C# 通过JS触发 Navigating 事件进行解析数据传递相关的 URL进行数据传输。
C#->JS 通过 webView.EvaluateJavaScriptAsync(js) 进行执行JS。

1. MainPage.xaml.cs

   using System.Diagnostics;
   using System.Web;

   namespace xqc_test_maui_app;

   public partial class MainPage : ContentPage
   {
   	public MainPage()
   	{
   		InitializeComponent();
   	}

   	private void AddLog(string msg)
   	{
   		if (string.IsNullOrEmpty(msg))
   		{
   			return;
   		}
   		Debug.WriteLine(msg);
   		MainThread.InvokeOnMainThreadAsync(() =>
   		{
   			logEditor.Text = $"[{DateTime.Now}]:" + msg + "\r\n" + logEditor.Text;
   		});
   	}
   	/// <summary>
   	/// 导航完成事件
   	/// </summary>
   	/// <param name="sender"></param>
   	/// <param name="e"></param>
   	private void webView_Navigated(object sender, WebNavigatedEventArgs e)
   	{
   		Debug.WriteLine("导航完毕");
   	}
   	/// <summary>
   	/// 监听窗口刷新
   	/// </summary>
   	/// <param name="sender"></param>
   	/// <param name="e"></param>
   	private async void WebView_Navigating(object sender, WebNavigatingEventArgs e)
   	{
   		var url = e.Url;
   		if (!url.StartsWith("maui://"))
   		{
   			return;
   		}
   		//
   		AddLog(url);
   		// 阻止网页跳转
   		e.Cancel = true;
   		// 当前URL
   		Uri uri = new Uri(url);
   		var function = uri.Host;
   		var paramses = HttpUtility.ParseQueryString(uri.Query);
   		//
   		if (function == "JsSendTestMessage")
   		{
   			AddLog($"JS发送测试消息,{paramses["message"]}");
   		}
   		else
   		{
   			AddLog($"JS调用：{function} (暂未生效),数据:{paramses.ToString()}");
   		}
   	}
   	private void Go_Clicked(object sender, EventArgs e)
   	{
   		webView.Source = inputUrl.Text;
   	}
   	private void Ref_Clicked(object sender, EventArgs e)
   	{
   		webView.Reload();
   	}
   	private void Back_Clicked(object sender, EventArgs e)
   	{
   		webView.GoBack();
   	}
   	/// <summary>
   	/// 执行js
   	/// </summary>
   	/// <param name="sender"></param>
   	/// <param name="e"></param>
   	private async void EvaluateJavaScriptAsync_Clicked(object sender, EventArgs e)
   	{
   		if (string.IsNullOrEmpty(jsEditor.Text))
   		{
   			return;
   		}
   		try
   		{
   			AddLog(await webView.EvaluateJavaScriptAsync(jsEditor.Text));
   		}
   		catch (Exception ex)
   		{
   			AddLog(ex.Message);
   		}
   	}
   	/// <summary>
   	/// 测试js调用C#
   	/// </summary>
   	/// <param name="sender"></param>
   	/// <param name="e"></param>
   	private async void TestJsCallCSharp_Clicked(object sender, EventArgs e)
   	{
   		var msg = await webView.EvaluateJavaScriptAsync(@"window.location.href = ""maui://callcs?msg=我是JS的简单消息"" + new Date().getTime();");
   		AddLog(msg);
   	}
   }



2. MainPage.xaml

   <?xml version="1.0" encoding="utf-8" ?>
   <ContentPage xmlns="http://schemas.microsoft.com/dotnet/2021/maui"
   			 xmlns:x="http://schemas.microsoft.com/winfx/2009/xaml"
   			 x:Class="xqc_test_maui_app.MainPage">
   	<ContentPage.Resources>
   		<Style TargetType="Entry"
   			   x:Key="webViewEntry">
   			<Setter Property="HeightRequest"
   					Value="50"></Setter>
   			<Setter Property="WidthRequest"
   					Value="300"></Setter>
   		</Style>
   		<Style TargetType="Button"
   			   x:Key="webViewBtn">
   			<Setter Property="HeightRequest"
   					Value="50"></Setter>
   			<Setter Property="Margin"
   					Value="0, 0, 10, 0"></Setter>
   		</Style>
   	</ContentPage.Resources>
   	<Grid RowDefinitions="80,*"
   		  Padding="10"
   		  ColumnDefinitions="*,300">
   		<Border Stroke="Gray"
   				Padding="10"
   				Grid.Row="0"
   				Grid.Column="0"
   				Grid.ColumnSpan="2 ">
   			<StackLayout Orientation="Horizontal"
   						 Spacing="10">
   				<StackLayout Orientation="Horizontal"
   							 Spacing="10">
   					<Label Text="URL"
   							HeightRequest="20"></Label>
   					<Entry x:Name="inputUrl"
   						   Style="{StaticResource webViewEntry}"></Entry>
   				</StackLayout>
   				<Button Clicked="Go_Clicked"
   						Text="前往"
   						Style="{StaticResource webViewBtn}"></Button>
   				<Button Clicked="Ref_Clicked"
   						Text="刷新"
   						Style="{StaticResource webViewBtn}"></Button>
   				<Button Clicked="Back_Clicked"
   						Text="返回"
   						Style="{StaticResource webViewBtn}"></Button>
   			</StackLayout>
   		</Border>
   		<Border Stroke="Gray"
   				Padding="10"
   				Grid.Row="1"
   				Grid.Column="0">
   			<WebView x:Name="webView"
   					Source="https://www.cnblogs.com/xiaqiuchu"
   					Navigated="WebView_Navigated"
   					Navigating="WebView_Navigating"></WebView>
   		</Border>
   		<Border Stroke="Gray"
   				Padding="10"
   				Grid.Row="1"
   				Grid.Column="1">
   			<StackLayout Padding="10"
   						 Spacing="10"
   					VerticalOptions="Center">
   				<Border Stroke="Gray"
   						HeightRequest="300">
   					<Editor x:Name="jsEditor"></Editor>
   				</Border>
   				<Button Clicked="EvaluateJavaScriptAsync_Clicked"
   						Text="执行JS"></Button>
   				<Button Clicked="TestJsCallCSharp_Clicked"
   						Text="测试通信JS->C#"></Button>
   				<Border Stroke="Gray"
   						HeightRequest="300">
   					<Editor x:Name="logEditor"
   							IsReadOnly="True"></Editor>
   				</Border>
   			</StackLayout>
   		</Border>
   	</Grid>


   </ContentPage>



注入JS示例

• 压缩前

  // alert(JSON.stringify(CSharpDocumentJsObject))

  // C#调用
  function setDataAndStart(callFunctionName) {
  	callFunctionName && callFunctionName();
  }
  // JS 调用
  function sendData(paramers = {}) {
  	callCSharp('JsSendCurrentData', paramers)
  }
  function sendTestMessage(message = 'sendTestMessage') {
  	callCSharp('JsSendTestMessage', {
  		message: message
  	})
  }
  function callCSharp(functionName, paramers = {}) {
  	location.href = 'maui://' + functionName + objectToQueryString(paramers)
  }
  function objectToQueryString(obj = {}) {
  	return '?' + Object.keys(obj).map(key => {
  		return encodeURIComponent(key) + '=' + encodeURIComponent(obj[key])
  	}).join('&')
  }
  function waitForElement(selector, callback, interval = 100, timeout = 10000) {
  	const startTime = Date.now();
  	const checkElement = () => {
  		const element = document.querySelector(selector);
  		if (element) {
  			callback(element);
  			return true
  		}
  		if (Date.now() - startTime > timeout) {
  			console.warn(`等待元素${selector}超时`);
  			return false
  		}
  		setTimeout(checkElement, interval)
  	};
  	checkElement()
  }


• 压缩后

  function setDataAndStart(callFunctionName){callFunctionName&&callFunctionName()}function sendData(paramers={}){callCSharp('JsSendCurrentData',paramers)}function sendTestMessage(message='sendTestMessage'){callCSharp('JsSendTestMessage',{message:message})}function callCSharp(functionName,paramers={}){location.href='maui://'+functionName+objectToQueryString(paramers)}function objectToQueryString(obj={}){return'?'+Object.keys(obj).map(key=>{return encodeURIComponent(key)+'='+encodeURIComponent(obj[key])}).join('&')}function waitForElement(selector,callback,interval=100,timeout=10000){const startTime=Date.now();const checkElement=()=>{const element=document.querySelector(selector);if(element){callback(element);return true}if(Date.now()-startTime>timeout){console.warn(`等待元素${selector}超时`);return false}setTimeout(checkElement,interval)};checkElement()}
