Springboot源码分析笔记



实例化SpringApplication：

SpringApplication初始化时主要做三件事情：

1.根据classpath下是否存在(ConfigurableWebApplicationContext)判断是否要启动一个web applicationContext
2.SpringFactoriesInstances加载classpath下所有可用的ApplicationContextInitializer
3.SpringFactoriesInstances加载classpath下所有可用的ApplicationListener

public SpringApplication(ResourceLoader resourceLoader, Class<?>... primarySources) {
    this.resourceLoader = resourceLoader;
    Assert.notNull(primarySources, "PrimarySources must not be null");
    this.primarySources = new LinkedHashSet<>(Arrays.asList(primarySources));
    //1.根据classpath下是否存在(ConfigurableWebApplicationContext)判断是否要启动一个web applicationContext
    this.webApplicationType = WebApplicationType.deduceFromClasspath();
    //2.SpringFactoriesInstances加载classpath下所有可用的ApplicationContextInitializer
    setInitializers((Collection) getSpringFactoriesInstances(ApplicationContextInitializer.class));
    //3.SpringFactoriesInstances加载classpath下所有可用的ApplicationListener
    setListeners((Collection) getSpringFactoriesInstances(ApplicationListener.class));
    this.mainApplicationClass = deduceMainApplicationClass();
}

实例化完成后调用run()方法：

调用run()方法执行的过程主要分为以下几步：

1.遍历SpringApplication初始化过程中加载的SpringApplicationRunListeners
2.调用Starting()监听SpringApplication的启动
3.加载SpringBoot配置环境(ConfigurableEnvironment)
4.设置banner属性
5.创建ConfigurableApplicationContext（应用配置上下文）
6.将listeners、environment、applicationArguments、bannner等重要组件与上下文对象关联
7.bean的实力化完成

public ConfigurableApplicationContext run(String... args) {
    StopWatch stopWatch = new StopWatch();
    stopWatch.start();
    ConfigurableApplicationContext context = null;
    Collection<SpringBootExceptionReporter> exceptionReporters = new ArrayList<>();
    configureHeadlessProperty();
    //1.遍历SpringApplication初始化过程中加载的SpringApplicationRunListeners
    SpringApplicationRunListeners listeners = getRunListeners(args);
    //2.调用starting()监听SpringApplication的启动
    listeners.starting();
    try {
        ApplicationArguments applicationArguments = new DefaultApplicationArguments(args);
        //3.加载SpringBoot配置环境
        ConfigurableEnvironment environment = prepareEnvironment(listeners, applicationArguments);
        configureIgnoreBeanInfo(environment);
        //4.设置banner属性
        Banner printedBanner = printBanner(environment);
        //5.创建ConfigurableApplicationContext(应用配置上下文)
        context = createApplicationContext();
        exceptionReporters = getSpringFactoriesInstances(SpringBootExceptionReporter.class,
                new Class[] { ConfigurableApplicationContext.class }, context);
        //6.将listeners、environment、applicationArguments、banner等重要组件与上下文对象关联
        prepareContext(context, environment, listeners, applicationArguments, printedBanner);
        //7.实例化bean
        refreshContext(context);
        afterRefresh(context, applicationArguments);
        stopWatch.stop();
        if (this.logStartupInfo) {
            new StartupInfoLogger(this.mainApplicationClass).logStarted(getApplicationLog(), stopWatch);
        }
        listeners.started(context);
        callRunners(context, applicationArguments);
    }
    catch (Throwable ex) {
        handleRunFailure(context, ex, exceptionReporters, listeners);
        throw new IllegalStateException(ex);
    }

    try {
        listeners.running(context);
    }
    catch (Throwable ex) {
        handleRunFailure(context, ex, exceptionReporters, null);
        throw new IllegalStateException(ex);
    }
    return context;
}

1.遍历SpringApplication初始化过程中加载的SpringApplicationRunListeners

private SpringApplicationRunListeners getRunListeners(String[] args) {
    Class<?>[] types = new Class<?>[] { SpringApplication.class, String[].class };
    return new SpringApplicationRunListeners(logger,
            getSpringFactoriesInstances(SpringApplicationRunListener.class, types, this, args));
}

2.调用Starting()监听SpringApplication的启动

public void starting() {
    //遍历所有的SpringApplicationRunListener，调用starting()方法监听SpringApplication的启动
    for (SpringApplicationRunListener listener : this.listeners) {
        listener.starting();
    }
}

3.加载SpringBoot配置环境(ConfigurableEnvironment)

 加载SpringBoot配置环境（configurableEnvironment），如果是通过web容器发布，会加载StandardEnvironment。将配置文件(Environment)加入到监听器对象中(SpringApplicationRunListeners)

private ConfigurableEnvironment prepareEnvironment(SpringApplicationRunListeners listeners,
        ApplicationArguments applicationArguments) {
    // Create and configure the environment
    //如果environment不为空直接返回 || 如果是web环境则直接实例化StandardServletEnvironment类 || 如果不是web环境则直接实例化StandardEnvironment类
    ConfigurableEnvironment environment = getOrCreateEnvironment();
    //配置环境信息
    configureEnvironment(environment, applicationArguments.getSourceArgs());
    //通知所有的监听者，环境已经准备好了
    listeners.environmentPrepared(environment);
    bindToSpringApplication(environment);
    if (!this.isCustomEnvironment) {
        environment = new EnvironmentConverter(getClassLoader()).convertEnvironmentIfNecessary(environment,
                deduceEnvironmentClass());
    }
    ConfigurationPropertySources.attach(environment);
    return environment;
}

4.设置banner属性

private Banner printBanner(ConfigurableEnvironment environment) {
    //如果未开启banner打印直接返回
    if (this.bannerMode == Banner.Mode.OFF) {
        return null;
    }
    //创建ResourceLoader对象
    ResourceLoader resourceLoader = (this.resourceLoader != null) ? this.resourceLoader
            : new DefaultResourceLoader(getClassLoader());
    //创建SpringApplicationBannerPrinter，该对象用来打印banner
    SpringApplicationBannerPrinter bannerPrinter = new SpringApplicationBannerPrinter(resourceLoader, this.banner);
    //如果bannerMode模式为LOG，则将bannner打印到log文件中
    if (this.bannerMode == Mode.LOG) {
        return bannerPrinter.print(environment, this.mainApplicationClass, logger);
    }
    //打印banner到控制台
    return bannerPrinter.print(environment, this.mainApplicationClass, System.out);
}

5.初始化ConfigurableApplicationContext（应用配置上下文）SpringApplicationRunListeners

　　在SpringBoot中，应用类型分为三类

public enum WebApplicationType {
    /**
     * The application should not run as a web application and should not start an
     * embedded web server.
     */
    // 应用程序不是web应用，也不应该用web服务器去启动
    NONE,
    /**
     * The application should run as a servlet-based web application and should start an
     * embedded servlet web server.
     */
    //应用程序应作为基于servlet的web应用程序运行，并应启动嵌入式servlet web（tomcat）服务器
    SERVLET,
    /**
     * The application should run as a reactive web application and should start an
     * embedded reactive web server.
     */
    //应用程序应作为 reactive web应用程序运行，并应启动嵌入式 reactive web服务器。
    REACTIVE;
}

　　根据webEnvironment是否是web环境创建默认的contextClass，AnnotationConfigEnbeddedWebApplicationContext(通过扫描所有注解类来加载bean)和ConfigurableWebApplicationContext),最后通过BeanUtils实例化上下文对象，并返回。

protected ConfigurableApplicationContext createApplicationContext() {
    //根据webEnvironment是否是web环境创建默认的contextClass
    Class<?> contextClass = this.applicationContextClass;
    if (contextClass == null) {
        try {
            switch (this.webApplicationType) {
            case SERVLET:
                //AnnotationConfigServletWebServerApplicationContext
                contextClass = Class.forName(DEFAULT_SERVLET_WEB_CONTEXT_CLASS);
                break;
            case REACTIVE:
                //AnnotationConfigReactiveWebServerApplicationContext
                contextClass = Class.forName(DEFAULT_REACTIVE_WEB_CONTEXT_CLASS);
                break;
            default:
                //AnnotationConfigApplicationContext
                contextClass = Class.forName(DEFAULT_CONTEXT_CLASS);
            }
        }
        catch (ClassNotFoundException ex) {
            throw new IllegalStateException(
                    "Unable create a default ApplicationContext, " + "please specify an ApplicationContextClass",
                    ex);
        }
    }
    //BeanUtils实例化上下文对象
    return (ConfigurableApplicationContext) BeanUtils.instantiateClass(contextClass);
}

6.将listeners、environment、applicationArguments、banner等重要组件与上下文对象关联

private void prepareContext(ConfigurableApplicationContext context, ConfigurableEnvironment environment,
        SpringApplicationRunListeners listeners, ApplicationArguments applicationArguments, Banner printedBanner) {
    //设置上下文的environment
    context.setEnvironment(environment);
    //应用上下文后处理
    postProcessApplicationContext(context);
    //在context refresh之前，对其应用ApplicationContextInitializer
    applyInitializers(context);
    //上下文准备
    listeners.contextPrepared(context);
    //打印启动日志和启动应用的profile
    if (this.logStartupInfo) {
        logStartupInfo(context.getParent() == null);
        logStartupProfileInfo(context);
    }
    // Add boot specific singleton beans
    ConfigurableListableBeanFactory beanFactory = context.getBeanFactory();
    //向beanFactory注册单例bean：命令行参数bean
    beanFactory.registerSingleton("springApplicationArguments", applicationArguments);
    if (printedBanner != null) {
        //向beanFactory注册单例bean：banner bean
        beanFactory.registerSingleton("springBootBanner", printedBanner);
    }
    if (beanFactory instanceof DefaultListableBeanFactory) {
        ((DefaultListableBeanFactory) beanFactory)
                .setAllowBeanDefinitionOverriding(this.allowBeanDefinitionOverriding);
    }
    // Load the sources
    //获取SpringApplication的primarySources属性
    Set<Object> sources = getAllSources();
    Assert.notEmpty(sources, "Sources must not be empty");
    //将bean加载到应用上下文
    load(context, sources.toArray(new Object[0]));
    //向上下文添加ApplicationListener，并广播ApplicationPreparedEvent事件
    listeners.contextLoaded(context);
}

7.bean的实例化完成，刷新应用上下文
