使用canvas画图片的点阵

<!DOCTYPE html>
<html>
<head>
    <meta charset="utf-8">
    <title>HTML龙</title>
    <style type="text/css">
        html,body{
            margin: 0;
            padding: 0;
            background: #333;
        }
        .bubble
        {
            position: absolute;
            animation-timing-function: linear;
            animation-name: floating;
            animation-iteration-count: infinite;
        }

        @keyframes floating
        {
            0%{
                transform: translateY(0px);
            }
            50%{
                transform: translateY(-5px);
            }
            100%{
                transform: translateY(0px);
            }
        }
    </style>
    <script type="text/javascript">
        window.onload=function(){
            init();
        }
        function init(){
            drawDragonImageInCanvas();
        }
        function drawDragonImageInCanvas(cb){
            var canvas = document.getElementById("canvas");
            var ctx = canvas.getContext("2d");

            var image = new Image();//使用的new方法拉实现
            // console.log(image);
            image.src = "dragon.jpg";
            image.onload = function(){
                canvas.width = image.width;
                canvas.height = image.height;

                ctx.drawImage(image,0,0);

                var imageData = ctx.getImageData(0,0,image.width,image.height).data;
                // console.log(image.width);
                // console.log(image.height);

                ctx.clearRect(0,0,image.width,image.height);

                var gap = 10;

                var dragonContainer = document.getElementById("container");
                var dragonScale = 2;

                for (var h = 0; h < image.height; h+=gap) {
                    for(var w = 0; w < image.width; w+=gap){
                            var position = (image.width * h + w) * 4;
                            var r = imageData[position], g = imageData[position + 1], b = imageData[position + 2];

                            if(r+g+b==0){
                                var bubble = document.createElement("img");
                                bubble.src = "bubble.png";
                                bubble.setAttribute("class","bubble");

                                var bubbleSize = Math.random()*10+20;

                                bubble.style.left = (w*dragonScale-bubbleSize/2) + "px";
                                bubble.style.top = (h*dragonScale-bubbleSize/2) + "px";

                                bubble.style.width = bubble.style.height = bubbleSize+"px";

                                bubble.style.animationDuration = Math.random()*6+4 + "s";

                                 dragonContainer.appendChild(bubble);
                            }
                    }
                }


            }
        }
    </script>
</head>
<body>
    <div id='container' style="width: 100%;height: 100%;position: absolute;z-index: 2;"></div>
    <canvas id='canvas' style="position: absolute;z-index: 1;filter: blur(5px);"></canvas>
</body>
</html>





图片自己下载，然后把代码里面的路径修改一下。

注意

调用getImageData()报跨域的错误，原因是图片存储在本地时，是默认没有域名的，用getImageData方法时，浏览器会判定为跨域而报错。
使用VsCode，下载一个叫 Live Server 的插件
