wpf的grid等布局

参考

https://learn.microsoft.com/zh-cn/dotnet/desktop/wpf/xaml/?view=netdesktop-6.0

http://www.taodudu.cc/news/show-4778613.html?action=onClick

 https://zhuanlan.zhihu.com/p/44547350?utm_id=0

<Window x:Class="Samples.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        Title="MainWindow" Height="600" Width="800">
    <Grid >
        <Grid.RowDefinitions>
            <RowDefinition Height="20"/>
            <RowDefinition Height="50"/>
            <RowDefinition Height="30"/>
            <RowDefinition Height="*"/>
            <RowDefinition Height="30"/>
        </Grid.RowDefinitions>
        <Grid.ColumnDefinitions>
            <ColumnDefinition Width="150"/>
            <ColumnDefinition Width="*"/>
            <ColumnDefinition Width="200"/>
        </Grid.ColumnDefinitions>
        <Grid Grid.Column="1" Grid.ColumnSpan="2">
            <StackPanel Orientation="Horizontal" HorizontalAlignment="Right">
                <Button Content="何戈洲" Margin="5,0,0,0"/>
                <Button Content="我的博客" Margin="5,0,0,0"/>
                <Button Content="短消息" Margin="5,0,0,0"/>
                <Button Content="设置" Margin="5,0,0,0"/>
                <Button Content="退出" Margin="5,0,0,0"/>
            </StackPanel>
        </Grid>
        <Grid Grid.Column="0" Grid.Row="1">
            <Image Source="/Samples;Component/Images/logo_small.gif" />
        </Grid>
        <Grid Grid.Column="0" Grid.ColumnSpan="3" Grid.Row="2">
            <StackPanel Orientation="Horizontal">
                <Button Margin="5,0,0,0">园子</Button>
                <Button Margin="5,0,0,0">新闻</Button>
                <Button Margin="5,0,0,0">博问</Button>
                <Button Margin="5,0,0,0">闪存</Button>
                <Button Margin="5,0,0,0">网摘</Button>
                <Button Margin="5,0,0,0">招聘</Button>
                <Button Margin="5,0,0,0">专题</Button>
                <Button Margin="5,0,0,0">知识</Button>
            </StackPanel>
        </Grid>
        <Grid Grid.Column="0" Grid.ColumnSpan="3" Grid.Row="3">
            <Image Source="/Samples;Component/Images/main.png" />
        </Grid>
        <Grid Grid.Column="0" Grid.ColumnSpan="3" Grid.Row="4">
            <StackPanel Orientation="Horizontal" HorizontalAlignment="Center">
                <Button Margin="5,0,0,0">关于我们</Button>
                <Button Margin="5,0,0,0">联系我们</Button>
                <Button Margin="5,0,0,0">广告服务</Button>
                <Button Margin="5,0,0,0">人才服务</Button>
                <Button Margin="5,0,0,0">版权</Button>
            </StackPanel>
        </Grid>
    </Grid>
</Window>



从上面的代码可以看出来，非常的简单，Grid特别适合软件系统的整体布局，在实际的项目中通过Grid与其他的布局控件相结合一起完成页面的整体布局。
