博雅Flash代理商|512M BIT SPI NOR FLASH BY25QM512FSFIG

国产品牌工业级512M BIT SPI NOR FLASH 博雅BY25QM512FSFIG
Low Power Consumption

• 20mA maximum active current
• 30uA maximum power down current


Read

• Normal Read (Serial): 55MHz clock rate
• Fast Read (Serial): 100MHz clock rate with 30PF load
• Dual I/O data transfer up to 200Mbits/S
• Quad I/O & QPI data transfer up to 400Mbits/S
• DTR Quad I/O Data transfer up to 400Mbits/s
• Allows XIP (execute in place) Operation: Continuous Read with 8/16/32/64-byte Wrap


Program/Erase Speed

• Page Program time: 0.6ms typical
• Sector Erase time: 50ms typical
• Block Erase time: 0.15/0.25s typical
• Chip Erase time: 80s typical


---

存储芯片推荐：

BY25Q16ESSIG、BY25D16ASSIG与GD25Q16E、W25Q16JV、MX25L1606E等完全兼容；

BY25Q32ESSIG、BY25Q32BSSIG与GD25Q32C、W25Q16FV、MX25L3206E等完全兼容

BY25Q64ESSIG、BY25Q64ASSIG与GD25Q64C、W25Q64FV、MX25L6406E等完全兼容

BY25Q128ESSIG与GD25Q127C、W25Q128FV、MX25L12835E等完全兼容

BY25Q256FSFIG与GD25Q256E、W25Q256J、MX25L25673G等完全兼容

BY25QM1GFS、BY25QM1G1FS，1G BIT SPI NOR FLASH

1Gb NAND FLASH：HYF1GQ4IDACAE、HYF1GQ4UDACAE、HYF1GQ4UDAD、HYF1GQ4UTACAE、HYF1GQ4UTADAE、HYF1GQ4UTDCAE。

2Gb NAND FLASH：HYF2GQ4IAACAE，WSON6*8

HYF2GQ4UTACAE，LGA8

HYF2GQ4UTADAE，LGA8

HYF2GQ4UAACAE，WSON6*8

HYF2GQ4UAADAE，WSON6*8

HYF2GQ4UTDCAE，BGA24

4Gb NAND FLASH

HYF4GQ4IAACAE，WSON6*8

HYF4GQ4UTACAE，LGA8

HYF4GQ4UTADAE，LGA8

HYF4GQ4UTDCAE，BGA24

HYF4GQ4UAACAE，WSON6*8

HYF4GQ4UAADAE，WSON6*8

HYF4GQ4UAACBE，WSON6*8

8Gb NAND FLASH

HYF8GQ4UACCAE
