仿照ArcCatalog创建一个shapefile

仿照ArcCatalog创建一个shapefile：







Imports ESRI.ArcGIS.Geometry
Imports ESRI.ArcGIS.DataSourcesFile
Imports ESRI.ArcGIS.Geodatabase
Imports ESRI.ArcGIS.CatalogUI


Public Class frmCreateNewShapefileClass frmCreateNewShapefile
    Inherits System.Windows.Forms.Form

    Dim pSpatialReference As ISpatialReference

    Private Sub Button2_Click()Sub Button2_Click(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles Button2.Click
        Dim ShpName As String
        Dim ShpType As String

        ShpName = TextBox1.Text
        ShpType = ComboBox1.Text

        Try
            CreateShapeFile("G:\", ShpName, ShpType, pSpatialReference)
        Catch ex As Exception
            MessageBox.Show(ex.Message, "异常", MessageBoxButtons.OK, MessageBoxIcon.Information, MessageBoxDefaultButton.Button1)
        End Try

        Me.Close()
        pSpatialReference = New UnknownCoordinateSystem
    End Sub

    Private Sub Button1_Click()Sub Button1_Click(ByVal sender As Object, ByVal e As System.EventArgs) Handles Button1.Click
        Dim pDialog As ISpatialReferenceDialog
        pDialog = New SpatialReferenceDialog
        pSpatialReference = pDialog.DoModalCreate(True, False, False, 0)

        If pSpatialReference Is Nothing Then
            pSpatialReference = New UnknownCoordinateSystem
            Exit Sub
        End If

        Dim pGeoCoordsys As IGeographicCoordinateSystem
        Dim pProjectedcoordSys As IProjectedCoordinateSystem
        If CheckBox1.CheckState = False Then
            If TypeOf pSpatialReference Is IGeographicCoordinateSystem Then
                pGeoCoordsys = pSpatialReference
                ListBox1.Items.Clear()
                ListBox1.Items.Add("Geographic Coordinate System")
                ListBox1.Items.Add("Name:" & pSpatialReference.Name)
            End If
            If TypeOf pSpatialReference Is IProjectedCoordinateSystem Then
                pProjectedcoordSys = pSpatialReference
                ListBox1.Items.Clear()
                ListBox1.Items.Add("Projected Coordinate System")
                ListBox1.Items.Add("Name:" & pSpatialReference.Name)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("Geographic Coordinate System")
                ListBox1.Items.Add("  Name:" & pProjectedcoordSys.GeographicCoordinateSystem.Name)
            End If
        End If

        If CheckBox1.CheckState = True Then
            If TypeOf pSpatialReference Is IGeographicCoordinateSystem Then
                ListBox1.Items.Clear()
                pGeoCoordsys = pSpatialReference
                ListBox1.Items.Add("Type:Geographic Coordinate System")
                ListBox1.Items.Add("Units:" & pGeoCoordsys.CoordinateUnit.Name)
                ListBox1.Items.Add("Datum")
                ListBox1.Items.Add("    Name:" & pGeoCoordsys.Datum.Name)
                ListBox1.Items.Add("    Spheroid")
                ListBox1.Items.Add("        Name:" & pGeoCoordsys.Datum.Spheroid.Name)
                ListBox1.Items.Add("        Flattening:" & pGeoCoordsys.Datum.Spheroid.Flattening)
                ListBox1.Items.Add("        SimiMajorAxis:" & pGeoCoordsys.Datum.Spheroid.SemiMajorAxis)
                ListBox1.Items.Add("        SimiMinorAxis:" & pGeoCoordsys.Datum.Spheroid.SemiMinorAxis)
                ListBox1.Items.Add("Prime Meridian")
                ListBox1.Items.Add("    Name:" & pGeoCoordsys.PrimeMeridian.Name)
                ListBox1.Items.Add("        Longitude:" & pGeoCoordsys.PrimeMeridian.Longitude)
                ListBox1.Items.Add("        Factory Code: " & pGeoCoordsys.PrimeMeridian.FactoryCode)
            ElseIf TypeOf pSpatialReference Is IProjectedCoordinateSystem Then
                ListBox1.Items.Clear()
                pProjectedcoordSys = pSpatialReference
                ListBox1.Items.Add("Type:Projected Coordinate System")
                ListBox1.Items.Add("CoordinateUnits")
                ListBox1.Items.Add("    Name:" & pProjectedcoordSys.CoordinateUnit.Name)
                ListBox1.Items.Add("    Factor:" & pProjectedcoordSys.CoordinateUnit.ConversionFactor)
                ListBox1.Items.Add("Factory Code:" & pProjectedcoordSys.FactoryCode)
                ListBox1.Items.Add("Projection")
                ListBox1.Items.Add("    Name:" & pProjectedcoordSys.Projection.Name)
                ListBox1.Items.Add("        Classification:" & pProjectedcoordSys.Projection.Classification)
                ListBox1.Items.Add("        Factory Code:" & pProjectedcoordSys.Projection.FactoryCode)
                ListBox1.Items.Add("Factory Code:" & pProjectedcoordSys.FactoryCode)
                ListBox1.Items.Add("False Easting:" & pProjectedcoordSys.FalseEasting)
                ListBox1.Items.Add("False Northing:" & pProjectedcoordSys.FalseNorthing)
                ListBox1.Items.Add("Geographic Coordinate System:")
                ListBox1.Items.Add("    Name:" & pProjectedcoordSys.GeographicCoordinateSystem.Name)
            End If
        End If
    End Sub

    Private Sub CreateShapeFile()Sub CreateShapeFile(ByVal sFilePath As String, ByVal sFileName As String, ByVal sFileType As String, ByVal pSpatialReference As ISpatialReference)
        Dim pFeatureWorkspace As IFeatureWorkspace
        Dim pWorkspaceFactory As IWorkspaceFactory
        Dim pFields As IFields
        Dim pField As IField
        Dim pFieldsEdit As IFieldsEdit
        Dim pFieldEdit As IFieldEdit
        Dim pGeometryDef As IGeometryDef
        Dim pGeometryDefEdit As IGeometryDefEdit
        Dim pFeatClass As IFeatureClass
        Dim sShapeFieldName As String
        Dim sNewShapeFileName As String

        Try
            sNewShapeFileName = Dir(sFilePath & sFileName & ".shp")
            If (sNewShapeFileName <> "") Then
                MessageBox.Show("文件已经存在")
                Exit Sub
            End If

            sShapeFieldName = "Shape"

            pWorkspaceFactory = New ShapefileWorkspaceFactory
            pFeatureWorkspace = pWorkspaceFactory.OpenFromFile(sFilePath, 0)

            pFields = New Fields
            pFieldsEdit = pFields
            pFieldsEdit.FieldCount_2 = 7

            pGeometryDef = New GeometryDef
            pGeometryDefEdit = pGeometryDef
            Select Case sFileType
                Case "Point"
                    pGeometryDefEdit.GeometryType_2 = esriGeometryType.esriGeometryPoint
                Case "Polyline"
                    pGeometryDefEdit.GeometryType_2 = esriGeometryType.esriGeometryPolyline
                Case "Polygon"
                    pGeometryDefEdit.GeometryType_2 = esriGeometryType.esriGeometryPolygon
                Case "MultiPoint"
                    pGeometryDefEdit.GeometryType_2 = esriGeometryType.esriGeometryMultipoint
                Case "MultiPatch"
                    pGeometryDefEdit.GeometryType_2 = esriGeometryType.esriGeometryMultiPatch
            End Select
            pGeometryDefEdit.SpatialReference_2 = pSpatialReference

            pField = New Field
            pFieldEdit = pField
            With pFieldEdit
                .Type_2 = esriFieldType.esriFieldTypeGeometry
                .GeometryDef_2 = pGeometryDef
                .Name_2 = sShapeFieldName
            End With
            pFieldsEdit.Field_2(0) = pField

            pField = New Field
            pFieldEdit = pField
            With pFieldEdit
                .Name_2 = "SmallInteger"
                .Type_2 = esriFieldType.esriFieldTypeSmallInteger
            End With
            pFieldsEdit.Field_2(1) = pField

            pField = New Field
            pFieldEdit = pField
            With pFieldEdit
                .Name_2 = "Integer"
                .Type_2 = esriFieldType.esriFieldTypeInteger
            End With
            pFieldsEdit.Field_2(2) = pField

            pField = New Field
            pFieldEdit = pField
            With pFieldEdit
                .Name_2 = "Single"
                .Type_2 = esriFieldType.esriFieldTypeSingle
            End With
            pFieldsEdit.Field_2(3) = pField

            pField = New Field
            pFieldEdit = pField
            With pFieldEdit
                .Precision_2 = 5
                .Scale_2 = 5
                .Name_2 = "Double"
                .Type_2 = esriFieldType.esriFieldTypeDouble
            End With
            pFieldsEdit.Field_2(4) = pField

            pField = New Field
            pFieldEdit = pField
            With pFieldEdit
                .Length_2 = 30
                .Name_2 = "String"
                .Type_2 = esriFieldType.esriFieldTypeString
            End With
            pFieldsEdit.Field_2(5) = pField

            pField = New Field
            pFieldEdit = pField
            With pFieldEdit
                .Name_2 = "Date"
                .Type_2 = esriFieldType.esriFieldTypeDate
            End With
            pFieldsEdit.Field_2(6) = pField

            pFeatClass = pFeatureWorkspace.CreateFeatureClass(sFileName, pFields, Nothing, Nothing, esriFeatureType.esriFTSimple, sShapeFieldName, "")
            sNewShapeFileName = Dir(sFilePath & "\" & sFileName & ".shp")
            '         If (sNewShapeFileName <> "") Then
            ' MessageBox.Show("Build Success")
            'Else
            'MessageBox.Show("Build Fail")
            'End If
            Exit Sub
        Catch ex As Exception
            MessageBox.Show(ex.Message, "异常", MessageBoxButtons.OK, MessageBoxIcon.Information, MessageBoxDefaultButton.Button1)
        End Try
    End Sub

    Private Sub Button3_Click()Sub Button3_Click(ByVal sender As System.Object, ByVal e As System.EventArgs) Handles Button3.Click
        Me.Close()
    End Sub


    Private Sub frmCreateNewShapefile_Load()Sub frmCreateNewShapefile_Load(ByVal sender As Object, ByVal e As System.EventArgs) Handles Me.Load
        ListBox1.Items.Clear()
        pSpatialReference = New UnknownCoordinateSystem
        ListBox1.Items.Add("Unknown Coordinate System")
        CheckBox1.Checked = False
    End Sub


    Private Sub CheckBox1_CheckStateChanged()Sub CheckBox1_CheckStateChanged(ByVal sender As Object, ByVal e As System.EventArgs) Handles CheckBox1.CheckStateChanged
        Dim pGeoCoordsys As IGeographicCoordinateSystem
        Dim pProjectedcoordSys As IProjectedCoordinateSystem
        Dim dXmin, dXmax, dYmin, dYmax, dMinZ, dMaxZ, dMinM, dmaxM As Double


        If pSpatialReference Is Nothing Then
            pSpatialReference = New UnknownCoordinateSystem
        End If

        If pSpatialReference.HasXYPrecision Then
            pSpatialReference.GetDomain(dXmin, dXmax, dYmin, dYmax)
        End If

        If pSpatialReference.HasZPrecision Then
            pSpatialReference.GetZDomain(dMinZ, dMaxZ)
        End If

        If pSpatialReference.HasMPrecision Then
            pSpatialReference.GetMDomain(dMinM, dmaxM)
        End If

        If CheckBox1.Checked = True Then
            If TypeOf pSpatialReference Is IGeographicCoordinateSystem Then
                ListBox1.Items.Clear()
                pGeoCoordsys = pSpatialReference
                ListBox1.Items.Add("Geographic Coordinate System")
                ListBox1.Items.Add("Name:" & pSpatialReference.Name)
                ListBox1.Items.Add("Datum")
                ListBox1.Items.Add("    Name:" & pGeoCoordsys.Datum.Name)
                ListBox1.Items.Add("    Spheroid")
                ListBox1.Items.Add("        Name:" & pGeoCoordsys.Datum.Spheroid.Name)
                ListBox1.Items.Add("        Flattening:" & pGeoCoordsys.Datum.Spheroid.Flattening)
                ListBox1.Items.Add("        SimiMajorAxis:" & pGeoCoordsys.Datum.Spheroid.SemiMajorAxis)
                ListBox1.Items.Add("        SimiMinorAxis:" & pGeoCoordsys.Datum.Spheroid.SemiMinorAxis)
                ListBox1.Items.Add("Prime Meridian")
                ListBox1.Items.Add("    Name:" & pGeoCoordsys.PrimeMeridian.Name)
                ListBox1.Items.Add("        Longitude:" & pGeoCoordsys.PrimeMeridian.Longitude)
                ListBox1.Items.Add("        Factory Code: " & pGeoCoordsys.PrimeMeridian.FactoryCode)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("XY Domain")
                ListBox1.Items.Add("    Xmin:" & dXmin)
                ListBox1.Items.Add("    Xmax:" & dXmax)
                ListBox1.Items.Add("    Ymin:" & dYmin)
                ListBox1.Items.Add("    Ymax:" & dYmax)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("Z domain")
                ListBox1.Items.Add("    Zmin:" & dMinZ)
                ListBox1.Items.Add("    Zmax:" & dMaxZ)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("M domain")
                ListBox1.Items.Add("    Mmin:" & dMinM)
                ListBox1.Items.Add("    Mmax:" & dmaxM)

            ElseIf TypeOf pSpatialReference Is IProjectedCoordinateSystem Then
                ListBox1.Items.Clear()
                pProjectedcoordSys = pSpatialReference
                ListBox1.Items.Add("Projected Coordinate System")
                ListBox1.Items.Add("Name:" & pSpatialReference.Name)
                ListBox1.Items.Add("CoordinateUnits")
                ListBox1.Items.Add("    Name:" & pProjectedcoordSys.CoordinateUnit.Name)
                ListBox1.Items.Add("    Factor:" & pProjectedcoordSys.CoordinateUnit.ConversionFactor)
                ListBox1.Items.Add("Factory Code:" & pProjectedcoordSys.FactoryCode)
                ListBox1.Items.Add("Projection")
                ListBox1.Items.Add("    Name:" & pProjectedcoordSys.Projection.Name)
                ListBox1.Items.Add("        Classification:" & pProjectedcoordSys.Projection.Classification)
                ListBox1.Items.Add("        Factory Code:" & pProjectedcoordSys.Projection.FactoryCode)
                ListBox1.Items.Add("Factory Code:" & pProjectedcoordSys.FactoryCode)
                ListBox1.Items.Add("False Easting:" & pProjectedcoordSys.FalseEasting)
                ListBox1.Items.Add("False Northing:" & pProjectedcoordSys.FalseNorthing)
                ListBox1.Items.Add("Geographic Coordinate System:")
                ListBox1.Items.Add("    Name:" & pProjectedcoordSys.GeographicCoordinateSystem.Name)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("XY Domain")
                ListBox1.Items.Add("    Xmin:" & dXmin)
                ListBox1.Items.Add("    Xmax:" & dXmax)
                ListBox1.Items.Add("    Ymin:" & dYmin)
                ListBox1.Items.Add("    Ymax:" & dYmax)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("Z domain")
                ListBox1.Items.Add("    Zmin:" & dMinZ)
                ListBox1.Items.Add("    Zmax:" & dMaxZ)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("M domain")
                ListBox1.Items.Add("    Mmin:" & dMinM)
                ListBox1.Items.Add("    Mmax:" & dmaxM)

            ElseIf TypeOf pSpatialReference Is IUnknownCoordinateSystem Then
                ListBox1.Items.Clear()
                ListBox1.Items.Add("Unknown Coordinate System")
                ListBox1.Items.Add("")
                ListBox1.Items.Add("XY Domain")
                ListBox1.Items.Add("    Xmin:" & dXmin)
                ListBox1.Items.Add("    Xmax:" & dXmax)
                ListBox1.Items.Add("    Ymin:" & dYmin)
                ListBox1.Items.Add("    Ymax:" & dYmax)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("Z domain")
                ListBox1.Items.Add("    Zmin:" & dMinZ)
                ListBox1.Items.Add("    Zmax:" & dMaxZ)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("M domain")
                ListBox1.Items.Add("    Mmin:" & dMinM)
                ListBox1.Items.Add("    Mmax:" & dmaxM)
            End If
        Else
            If TypeOf pSpatialReference Is IGeographicCoordinateSystem Then
                pGeoCoordsys = pSpatialReference
                ListBox1.Items.Clear()
                ListBox1.Items.Add("Geographic Coordinate System")
                ListBox1.Items.Add("  Name:" & pSpatialReference.Name)

            End If
            If TypeOf pSpatialReference Is IProjectedCoordinateSystem Then
                pProjectedcoordSys = pSpatialReference
                ListBox1.Items.Clear()
                ListBox1.Items.Add("Projected Coordinate System")
                ListBox1.Items.Add("Name:" & pSpatialReference.Name)
                ListBox1.Items.Add("")
                ListBox1.Items.Add("Geographic Coordinate System")
                ListBox1.Items.Add("Name:" & pProjectedcoordSys.GeographicCoordinateSystem.Name)
            ElseIf TypeOf pSpatialReference Is IUnknownCoordinateSystem Then
                ListBox1.Items.Clear()
                ListBox1.Items.Add("Unknown Coordinate System")
            End If
        End If
    End Sub
End Class
