使用 Jenkins + NetCore + Harbor 自动发布应用到 Docker

使用 Jenkins + NetCore + Harbor 自动发布应用到 Docker

--

防火墙设置

  1. 关闭防火墙

    systemctl stop firewalld.service
setenforce 0
systemctl disable firewalld

  2. 安装基础环境

    # docker 基础环境
 yum install -y yum-utils device-mapper-persistent-data lvm2

安装 Docker

  1. 配置宿主机网卡转发

    cat <<EOF> /etc/sysctl.d/docker.conf
net.bridge.bridge-nf-call-ip6tables = 1
net.bridge.bridge-nf-call-iptables = 1
net.ipv4.ip_forward = 1
EOF

  2. 使配置生效

    sysctl -p /etc/sysctl.d/docker.conf

  3. 配置阿里源地址

    curl -o /etc/yum.repos.d/Centos-7.repo <http://mirrors.aliyun.com/repo/Centos-7.repo>
curl -o /etc/yum.repos.d/docker-ce.repo <http://mirrors.aliyun.com/docker-ce/linux/centos/docker-ce.repo>

yum clean all && yum makecache

  4. yum 安装 docker

    # 有安装过先删除
yum remove docker  docker-common docker-selinux docker-engine
# 查看源中可用版本
yum list docker-ce --showduplicates | sort -r
yum install docker-ce-20.10.8 -y

  5. 设置开机自启

    systemctl enable docker
systemctl daemon-reload

  6. 启动 docker

    systemctl start docker

注意：系统自带的 yum 源安装版本为，1.13.1，后面在 Jenkins 里面挂载宿主机 docker 时会报错，必须升级为新版本 docker

安装 Harbor

  1. 安装 docker-compose

    wget https://github.com/docker/compose/releases/download/1.24.1/docker-compose-Linux-x86_64
mv docker-compose-Linux-x86_64 /usr/local/bin/docker-compose
chmod +x /usr/local/bin/docker-compose
docker-compose version

  2. 下载

    wget https://github.com/goharbor/harbor/releases/download/v2.9.1/harbor-offline-installer-v2.9.1.tgz

  3. 解压缩

    tar xzvf harbor-offline-installer-v2.9.1.tgz -C /home/application
cd /home/application/harbor

  4. 配置（需要提前准备好域名和证书）

    cp harbor.yml.tmpl harbor.yml
vim harbor.yml

# 开起https访问提前准备好域名证书，也可不开启，但是在docker中需要配置`insecure-registries`
hostname: harbor.codingbugs.fun
port: 443
certificate: /certificate.pem
private_key: /certificate.key
# 默认帐号admin，修改管理密码
harbor_admin_password: Harbor12345

# 数据持久化
data_volume: /home/applicatoin/harbor/data

# 启用外部nginx代理需放开
#external_url: https://harbor.codingbugs.fun:443

# 日志地址
location: /var/log/harbor

  5. 修改安装脚本

    vim prepare
# 54行位置
docker run --rm -v $input_dir:/input \
-v $data_path:/data \
-v $harbor_prepare_path:/compose_location \
-v $config_dir:/config \
-v /home/application/harbor/certs:/hostfs \
--privileged \
goharbor/prepare:v2.9.1 prepare $@

  6. 安装

    ./prepare
./install.sh

    注意此处2.9版本会报找不到证书，解决方案，harbor.yml中的证书地址也需要删除到只保留证书和密钥名称，2.3版本没有发现这个问题

安装 Jenkins

  1. 创建持久目录

    mkdir -p /home/application/jenkins/jenkins_home
chmod 777 /home/application/jenkins/jenkins_home

  2. 使用 docker 安装

    # 启动jenkins
docker run \
--env JAVA_OPTS="-server -Xms1024m -Xmx2048m -XX:PermSize=512m -XX:MaxPermSize=512m" \
--name jenkins \
--privileged=true \
--restart=on-failure \
-itd \
-p 8080:8080 \
-p 50000:50000 \
-e JENKINS_OPTS='--prefix=/jenkins' \
-e TZ='Asia/Shanghai' \
-e JENKINS_ARGS='--prefix=/jenkins' \
-v /home/application/jenkins/jenkins_home:/var/jenkins_home \
-v /etc/localtime:/etc/localtime \
-v /var/run/docker.sock:/var/run/docker.sock \
-v /usr/bin/docker:/usr/bin/docker \
-v /usr/lib64/libltdl.so.7:/usr/lib/x86_64-linux-gnu/libltdl.so.7 \
jenkins/jenkins:2.414-centos7
    • 注意其它教程版本为 Debian12.2，只支持 NET6 以上版本，官网，如需使用 NET6 以下版本需要使用jenkins/jenkins:2.414-lts-jdk11（不带小版本），本教程使用jenkins/jenkins:2.414-centos7
    • 更多版本
    • --privileged：使其能操作系统文件
    • -v /var/run/docker.sock:/var/run/docker.sock -v /usr/bin/docker:/usr/bin/docker -v /usr/lib64/libltdl.so.7:/usr/lib/x86_64-linux-gnu/libltdl.so.7：使用宿主机的 docker

  3. 登录及配置

    • docker logs jenkins 找到初始密码
    • ip:8080/jenkins登陆系统
    • 安装git和pipeline插件

安装 NetCore 运行时

  1. 进入容器

    docker exec -it -uroot jenkins /bin/bash

  2. 查看 Debian 版本

    cat /etc/debian_version

  3. 配置 netcore 源，安装 dotnet

    # 注意版本号
rpm -Uvh https://packages.microsoft.com/config/rhel/7/packages-microsoft-prod.rpm
sudo yum update -y
rm packages-microsoft-prod.deb

# 安装sdk
yum install -y dotnet-sdk-5.0

# 安装运行时，安装aspnetcore-runtime会默认安装netcore-runtime
yum install -y aspnetcore-runtime-5.0.x86_64
yum install -y dotnet-runtime-5.x86_64

# 检查
dotnet --list-sdks
dotnet --list-runtimes

    其他版本

在 jenkins 容器中安装 python3

  1. 进入容器

    docker exec -it -uroot jenkins /bin/bash

  2. 安装 python3

    • 安装依赖环境
    yum -y groupinstall "Development tools"
yum -y install zlib-devel bzip2-devel openssl-devel ncurses-devel sqlite-devel readline-devel tk-devel gdbm-devel db4-devel libpcap-devel xz-devel
yum install -y libffi-devel zlib1g-dev
yum install zlib* -y
    • 下载安装包
    wget https://www.python.org/ftp/python/3.9.1/Python-3.9.1.tar.xz

    更多版本

    • 编译安装
    tar -xvf Python-3.9.1.tar.xz
mkdir /usr/local/python3
cd Python-3.9.1
./configure --prefix=/usr/local/python3 --with-ssl
make && make install
    • 创建软连接
    ln -s /usr/local/python3/bin/python3 /usr/local/bin/python3
ln -s /usr/local/python3/bin/pip3 /usr/local/bin/pip3
    • 验证是否安装成功
    python3 -V
pip3 -V

  3. 升级OpenSSL

    • 检查 Python 的 ssl 模块版本
    # 若低于1.1版本则需升级，否则跳过
python3 -c "import ssl; print(ssl.OPENSSL_VERSION)"
    • 升级OpenSSL
    wget https://www.openssl.org/source/openssl-1.1.1n.tar.gz --no-check-certificate
tar zxf openssl-1.1.1n.tar.gz
cd openssl-1.1.1n/
./config --prefix=/usr/local/openssl
make -j && make install

# 添加到系统动态库查找路径
export LD_LIBRARY_PATH=/usr/local/openssl/lib:$LD_LIBRARY_PATH
source /etc/profile

# 重新编译python
cd python
yum install libffi-devel -y
make clean
./configure --prefix=/usr/local/python3 --with-openssl=/usr/local/openssl --with-ssl-default-suites=openssl --with-system-ffi
make -j && make install

# 检查版本
python3 -c "import ssl; print(ssl.OPENSSL_VERSION)"
# 结果应该为：`OpenSSL 1.1.1n  15 Mar 2022` 则升级成功

配置 Pipeline

  1. 配置密钥

    • 进入路径Manage Jenkins/Credentials/System/Global cerdentials(unrestricted)
    • 点击Add Credentials添加 git 仓库和 harbor 凭证

  2. 创建 Pipeline 类型 Job

        pipeline {
    agent any

    environment {
        // 代码仓库配置
        GIT_URL = "http://刘春阳@url:10101/r/ContainerTest.git"
        BRANCH_NAME = "master"

        // 项目配置
        PROJECT_PATH = "./ContainerTest/ContainerTest.csproj"

        // 镜像仓库配置
        HARBOR_PROJECT_NAME = "fineex_test"
        DOCKER_IMAGE_NAME = "containertest"

        // 发布服务配置
        EnvName = "Master"
        AppName = "FineEx.Test"

        // 基础配置（不修改）
        GIT_CRT_ID = "0ce9e30c-ed14-4945-9444-62c9885594cb"
        HARBOR_REGISTRY = "harbor.test.com"
        HARBOR_CRT_ID = 'e50b42a5-cbd6-4f51-bea8-074c8690b912'
    }

    stages {
        stage('=========拉取代码=========') {
            steps {
                git branch: "${BRANCH_NAME}", credentialsId: "${GIT_CRT_ID}", url: "${GIT_URL}"

                script {
                    def commitHash = sh(returnStdout: true, script: 'git rev-parse --short HEAD').trim()
                    env.VERSION_NUMBER = commitHash
                }
            }
        }
        stage('=========还原代码依赖=========') {
            steps {
                sh 'dotnet restore -nowarn:msb3202,nu1503,cs1591 ${PROJECT_PATH} --configfile $JENKINS_HOME/nuget/nuget.config'
            }
        }
        stage('=========编译代码=========') {
            steps {
                sh 'dotnet build -nowarn:msb3202,nu1503,cs1591 --no-restore ${PROJECT_PATH}'
            }
        }
        stage('=========发布代码========='){
            steps{
                script {
                    def publishPath = './JenkinsBuilds/'+env.JOB_NAME+'/'+env.BUILD_NUMBER
                    env.PUBLISH_PATH = publishPath
                }

                sh 'dotnet publish  ${PROJECT_PATH} -c Release  -o ${PUBLISH_PATH}'
            }
        }
        stage('=========构建镜像========='){
            steps{
                // 切换目录
                sh "cd ${PUBLISH_PATH}"
                sh "ls -l ${PUBLISH_PATH}"
                sh "pwd"
                sh "ls -l"

                // 编译镜像
                sh "docker build -t ${HARBOR_REGISTRY}/${HARBOR_PROJECT_NAME}/${DOCKER_IMAGE_NAME}:${VERSION_NUMBER} -f ${PUBLISH_PATH}/Dockerfile ${PUBLISH_PATH}"
            }
        }
        stage('=========推送到镜像仓库========='){
            steps{
                withCredentials([usernamePassword(credentialsId: "${HARBOR_CRT_ID}", passwordVariable: 'HARBOR_PASSWORD', usernameVariable: 'HARBOR_USERNAME')]) {
                    sh (script: """
                    # 登录harbor
                    HARBOR_PASSWORD=${HARBOR_PASSWORD} && echo "\$HARBOR_PASSWORD" | docker login ${HARBOR_REGISTRY}  -u ${HARBOR_USERNAME} --password-stdin

                    # 推送镜像
                    docker push ${HARBOR_REGISTRY}/${HARBOR_PROJECT_NAME}/${DOCKER_IMAGE_NAME}:${VERSION_NUMBER}

                    # 删除镜像
                    docker rmi ${HARBOR_REGISTRY}/${HARBOR_PROJECT_NAME}/${DOCKER_IMAGE_NAME}:${VERSION_NUMBER}
                    """)
                }
            }
        }
         stage('=========调用发布服务发布应用========='){
            steps{
                sh 'python3 $JENKINS_HOME/scripts/develop_client.py ${EnvName} ${AppName} ${VERSION_NUMBER}'
            }
        }
    }
    post{
        failure{
            echo '执行失败需要发送通知'
            sh 'python3 $JENKINS_HOME/scripts/sendReport.py ${EnvName} ${AppName} false'
        }
        success
        {
            echo '执行成功时需要发送通知'
            sh 'python3 $JENKINS_HOME/scripts/sendReport.py ${EnvName} ${AppName} true'
        }
    }
}

    /home/application/jenkins/jenkins_home/nuget/nuget.config内容

    <?xml version="1.0" encoding="utf-8"?>
 <configuration>
     <packageSources>
         <add key="nuget.org" value="https://api.nuget.org/v3/index.json" protocolVersion="3" />
         <!-- 内部nuget服务 -->
         <add key="nuget.fineex" value="http://nuget:8888/Nuget" />
     </packageSources>
     <activePackageSource>
         <add key="Microsoft and .NET" value="https://www.nuget.org/api/v2/curated-feeds/microsoftdotnet/" />
     </activePackageSource>
     <packageRestore>
         <add key="enabled" value="True" />
         <add key="automatic" value="True" />
     </packageRestore>
     <bindingRedirects>
         <add key="skip" value="False" />
     </bindingRedirects>
     <packageManagement>
         <add key="format" value="0" />
         <add key="disabled" value="False" />
     </packageManagement>
 </configuration>

    /home/application/jenkins/jenkins_home/scripts/develop_client.py内容，自定义简单逻辑，仅供参考

     import pymysql
 import requests
 import sys
 import json


 def sendPublishRequest(environment, appName, imageVersion):
     infos = getAppInfo(environment, appName)
     for info in infos:
         url = info['connect']
         param = {
             'environment': environment,
             'appName': appName,
             'imageVersion': imageVersion
         }
         response = requests.get(url=url, params=param)
         print(json.loads(response.text)['message'])


 def getAppInfo(environment, appName):
     sql = f"""
             select
                 `appid`,
                 `appname`,
                 `connect`
             from table_release_container
             where
                 appname='{appName}'
                 and environment = '{environment}'
         """
     try:
         conn = pymysql.connect(host="host", user="user", passwd="passwd", db="db_name", port=3306)
         with conn.cursor(cursor=pymysql.cursors.DictCursor) as cursor:
             cursor.execute(sql)
             result = cursor.fetchall()
             cursor.close()
             conn.close()
             return result
     except pymysql.MySQLError as error:
         cursor.close()
         conn.close()
         raise error


 if __name__ == '__main__':
     module = sys.modules[__name__]
     func = getattr(module, 'sendPublishRequest')
     args = None
     if len(sys.argv) > 0:
         args = sys.argv[1:]

     res = func(*args)
     print(res)

    /home/application/jenkins/jenkins_home/scripts/sendReport.py内容，自定义简单逻辑，仅供参考

    import pymysql
import sys
import datetime
from FineEx.Middleware.Message.pywechat import WorkChatSender


def sendMessage(environment, appName, success):
    info = getAppManager(appName, environment)
    incharge = info['incharge'].split(',')
    for item in incharge:
        if success.lower() == 'true':
            sendSuccessMessageToChat(appName, environment, item)
        else:
            sendFailureMessageToChat(appName, environment, item)


def sendSuccessMessageToChat(appName, environment, incharge):
    corpid = 'corpid'
    corpsecret = 'corpsecret'
    agentid = 'agentid'
    workSender = WorkChatSender(corpid=corpid, corpsecret=corpsecret, agentid=agentid)
    subject = '应用上线成功'

    current_time = datetime.datetime.now()
    current_time_text = current_time.strftime("%Y-%m-%d %H:%M:%S")

    message = f"""
            >**发布详情**
            系统名称：<font color=\"info\">{appName}</font>
            运行环境：<font color=\"info\">{environment}</font>
            时　间：<font color=\"info\">{current_time_text}</font>
            请尽快安排人员验证！
            """
    workSender.send_markdown(subject + "\n" + message.strip(), touser=incharge)


def sendFailureMessageToChat(appName, environment, incharge):
    corpid = 'corpid'
    corpsecret = 'corpsecret'
    agentid = 'agentid'
    workSender = WorkChatSender(corpid=corpid, corpsecret=corpsecret, agentid=agentid)
    subject = '应用上线失败'

    current_time = datetime.datetime.now()
    current_time_text = current_time.strftime("%Y-%m-%d %H:%M:%S")

    message = f"""
            >**发布详情**
            系统名称：<font color=\"warning\">{appName}</font>
            运行环境：<font color=\"warning\">{environment}</font>
            时　间：<font color=\"warning\">{current_time_text}</font>
            请尽快安排人员排查！
            """
    workSender.send_markdown(subject + "\n" + message.strip(), touser=incharge)


def getAppManager(appName, environment):
    sql = f"""
            select
                `appid`,
                `appname`,
                `incharge`
            from table_release_container
            where
                appname='{appName}'
                and environment = '{environment}'
            """
    try:
        conn = pymysql.connect(host="host", user="user", passwd="passwd", db="db",
                            port=3306)
        with conn.cursor(cursor=pymysql.cursors.DictCursor) as cursor:
            cursor.execute(sql)
            result = cursor.fetchone()
            cursor.close()
            conn.close()
            return result
    except pymysql.MySQLError as error:
        cursor.close()
        conn.close()
        raise error


if __name__ == '__main__':
    module = sys.modules[__name__]
    func = getattr(module, 'sendMessage')
    args = None
    if len(sys.argv) > 0:
        args = sys.argv[1:]

    res = func(*args)
    print(res)

  3. 编写服务端

    from flask import Flask, request, Response
import simplejson as json
import pymysql
import socket
import os

app = Flask(__name__)


@app.route('/publish')
def publish():
    try:
        environment = request.args.get('environment')
        appName = request.args.get('appName')
        imageVersion = request.args.get('imageVersion')

        app_config = getAppInfo(environment, appName)
        for con in app_config:
            # 生成容器运行命令
            cmd = generateCommand(con, con['project'], con['imagename'], imageVersion)
            # 登录仓库
            loginDepository()
            # 拉取镜像
            return_code = imagePull(con['project'], con['imagename'], imageVersion)
            if return_code == 0:
                # 停止老容器
                stopContainer(appName)
                # 删除老容器
                removeContainer(appName)
                # 启动新容器
                return_code = startContainer(cmd)
                if return_code == 0:
                    res = {
                        "success": True,
                        "message": f"""{appName}:{imageVersion}在{environment}环境发版成功"""
                    }
                    return Response(json.dumps(res), mimetype='application/json')
                else:
                    res = {
                        "success": False,
                        "message": f"""{appName}:{imageVersion}在{environment}环境发版失败, 失败编码{return_code}"""
                    }
                    return Response(json.dumps(res), mimetype='application/json')
    except Exception as e:
        res = {
            "success": False,
            "message": f"""{appName}:{imageVersion}在{environment}环境发版失败，失败信息：{e}"""
        }
        return Response(json.dumps(res), mimetype='application/json')


def imagePull(projectName, imageName, imageVersion):
    """
    拉取镜像
    :param projectName: 项目名
    :param imageName: 镜像名
    :param imageVersion: 镜像版本
    :return: 是否成功
    """
    # 修改仓库地址
    pull_cmd = f"""docker pull harbor.test.com/{projectName}/{imageName}:{imageVersion}"""
    result = os.system(pull_cmd)
    return result


def generateCommand(con, projectName, imageName, imageVersion):
    volumn_mount_sql = f"""
        select host_path,app_path from table_release_containervolumn where appid ={con['appid']}
    """

    port_map_sql = f"""
        select host_port,app_port from table_release_containerport where appid = {con['appid']}
    """

    env_parm_sql = f"""
        select `key`,`value` from table_release_containerenv where appid = {con['appid']}
    """
    try:
        conn = pymysql.connect(host="host", user="user", passwd="passwd", db="db_name",
                            port=3306)
        with conn.cursor(cursor=pymysql.cursors.DictCursor) as cursor:
            # 获取挂载卷配置
            cursor.execute(volumn_mount_sql)
            volumn_mount_result = cursor.fetchall()

            # 获取端口映射配置
            cursor.execute(port_map_sql)
            port_map_result = cursor.fetchall()

            # 获取环境变量配置
            cursor.execute(env_parm_sql)
            env_parm_result = cursor.fetchall()

            volumn_mount_str = " ".join(
                ["-v " + item['host_path'] + ":" + item['app_path'] for item in volumn_mount_result])
            port_map_str = " ".join(
                ["-p " + str(item['host_port']) + ":" + str(item['app_port']) for item in port_map_result])
            env_parm_str = " ".join(["-e " + str(item['key']) + "=" + str(item['value']) for item in env_parm_result])
            # 修改仓库地址
            command = f"""docker run -{con['mode']} --name {con['appname'].lower()} {port_map_str} {volumn_mount_str} {env_parm_str} harbor.test.com/{projectName}/{imageName}:{imageVersion}"""
            cursor.close()
            conn.close()
            return command
    except pymysql.MySQLError as error:
        cursor.close()
        conn.close()
        raise error


def loginDepository():
    # 修改帐号密码
    result = os.system("docker login -u User -p Passwor harbor.test.com")
    print(result)


def stopContainer(appName):
    result = os.system(f"""docker stop {appName.lower()}""")
    print(result)


def removeContainer(appName):
    result = os.system(f"""docker rm {appName.lower()}""")
    print(result)


def startContainer(cmd):
    return os.system(cmd)


def getLocalIp():
    """
    获取本机ip地址
    :return: ip地址
    """
    s = socket.socket(socket.AF_INET, socket.SOCK_DGRAM)
    s.connect(('114.114.114.114', 80))
    hostname = s.getsockname()[0]
    ip_address = socket.gethostbyname(hostname)
    s.close()
    return ip_address


def getAppInfo(environment, appName):
    """
    获取应用配置信息
    :param environment: 环境
    :param appName: 应用名
    :return: 应用配置信息
    """
    ip = getLocalIp()

    sql = f"""
        select
            appid,
            appname,
            project,
            imagename,
            mode,
            restart
        from table_release_container
        where
            appname='{appName}'
            and environment = '{environment}'
            and ip = '{ip}'
    """

    try:
        conn = pymysql.connect(host="host", user="user", passwd="passwd", db="db_name",
                            port=3306)
        with conn.cursor(cursor=pymysql.cursors.DictCursor) as cursor:
            cursor.execute(sql)
            result = cursor.fetchall()
            cursor.close()
            conn.close()
            return result
    except pymysql.MySQLError as error:
        cursor.close()
        conn.close()
        raise error


if __name__ == '__main__':
    app.run(host='0.0.0.0', port=5000, debug=True)

    用到的 mysql 表结构

    CREATE TABLE `table_release_container` (
`appid` int(10) unsigned NOT NULL AUTO_INCREMENT COMMENT '应用id',
`appname` varchar(255) NOT NULL COMMENT '应用名称',
`project` varchar(255) NOT NULL COMMENT '项目名称（harbor）',
`imagename` varchar(255) NOT NULL COMMENT '镜像名称',
`type` varchar(255) NOT NULL COMMENT '应用类型 1：站点  2：任务',
`environment` varchar(255) NOT NULL COMMENT '环境',
`ip` varchar(255) NOT NULL COMMENT '部署的内网ip',
`connect` varchar(255) NOT NULL COMMENT '服务暴露的外网ip',
`mark` varchar(255) NOT NULL COMMENT '备注',
`incharge` varchar(255) NOT NULL COMMENT '应用负责人',
`mode` varchar(255) NOT NULL COMMENT '运行模式',
`restart` tinyint(4) NOT NULL COMMENT '失败重启',
PRIMARY KEY (`appid`)
) ENGINE=InnoDB  DEFAULT CHARSET=utf8mb4 COMMENT '应用表'

CREATE TABLE `table_release_containerenv` (
 `appid` int(11) NOT NULL COMMENT '应用id',
 `key` varchar(255) NOT NULL COMMENT '环境变量名',
 `value` varchar(255) NOT NULL COMMENT '环境变量值'
 ) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4 COMMENT '应用运行参数'

 CREATE TABLE `table_release_containerport` (
 `appid` int(11) NOT NULL COMMENT '应用id',
 `host_port` int(255) NOT NULL COMMENT '宿主机端口',
 `app_port` int(255) NOT NULL COMMENT '应用端口'
 ) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4 COMMENT '应用映射端口'

 CREATE TABLE `table_release_containervolumn` (
 `appid` int(11) NOT NULL COMMENT '应用id',
 `host_path` varchar(2000) NOT NULL COMMENT '宿主机目录',
 `app_path` varchar(2000) NOT NULL COMMENT 'app目录'
 ) ENGINE=InnoDB DEFAULT CHARSET=utf8mb4 COMMENT '应用映射目录'

  4. 部署服务端

    • 准备 requirements.txt
    aliyun-python-sdk-core==2.14.0
aliyun-python-sdk-dysmsapi==2.1.2
certifi==2023.11.17
cffi==1.15.1
charset-normalizer==2.0.12
click==8.0.4
cryptography==40.0.2
dataclasses==0.8
distlib==0.3.7
docker==5.0.3
Flask==2.0.3
idna==3.6
importlib-metadata==4.8.3
itsdangerous==2.0.1
Jinja2==3.0.3
jmespath==0.10.0
mailutils==0.0.2
MarkupSafe==2.0.1
pycparser==2.21
PyMySQL==1.0.2
requests==2.27.1
simplejson==3.19.2
typing_extensions==4.1.1
urllib3==1.26.18
websocket-client==1.3.1
Werkzeug==2.0.3
zipp==3.6.0
    • 准备 Dockerfile
    FROM python:3.6-slim-buster

LABEL authors="liuchunyang"
LABEL email="<liuchunyang@fineex.com>"

WORKDIR /flask_app
COPY . /flask_app

ENV TZ Asia/Shanghai

RUN pip install -r ./requirements.txt -i <https://pypi.tuna.tsinghua.edu.cn/simple>

EXPOSE 5000

CMD ["python", "/flask_app/develop_server.py"]

  5. 打包后运行

    docker run -d --net=host --name develop_server -p 5000:5000 -v /var/run/docker.sock:/var/run/docker.sock -v /usr/bin/docker:/usr/bin/docker -v /usr/lib64/libltdl.so.7:/usr/lib/x86_64-linux-gnu/libltdl.so.7 --restart=always --privileged harbor.test.com/fineex_devops/develop_service:1.0.0

    --net=host 使用主机网络，脚本里有逻辑
    -v /var/run/docker.sock:/var/run/docker.sock -v /usr/bin/docker:/usr/bin/docker -v /usr/lib64/libltdl.so.7:/usr/lib/x86_64-linux-gnu/libltdl.so.7 使用宿主机 docker
    --privileged 使用 root 权限

写在最后

如果Jenkins和应用服务器网络通的情况下，可以直接通过ssh去部署，另外服务端最好加安全验证，这里只是随便搞搞，没写多复杂的逻辑。
如果对你有帮助，且心情愉悦的话，想搞杯速溶咖啡；如果有不理解的地方可以评论或者联系我个人微信

image image
posted @ 2023-12-18 14:43  CodingBugs  阅读(108)  评论(0)    收藏  举报
