第八周

1、创建私有CA并进行证书申请。

1.1 创建CA相关目录和文件[root@centos8 ~]#mkdir -pv /etc/pki/CA/{certs,crl,newcerts,private}mkdir: created directory '/etc/pki/CA'

mkdir: created directory '/etc/pki/CA/certs'
mkdir: created directory '/etc/pki/CA/crl'
mkdir: created directory '/etc/pki/CA/newcerts'
mkdir: created directory '/etc/pki/CA/private'
[root@centos8 ~]#tree /etc/pki/CA/
/etc/pki/CA/
├── certs
├── crl
├── newcerts
└── private
4 directories, 0 files
[root@centos8 ~]#touch /etc/pki/CA/index.txt
[root@centos8 ~]#echo 01 > /etc/pki/CA/serial
1.2 创建CA的私钥
[root@centos8 ~]#cd /etc/pki/CA/
[root@centos8 CA]#(umask 066; openssl genrsa -out private/cakey.pem 2048)
Generating RSA private key, 2048 bit long modulus (2 primes)
..........................................................................+++++
.............................+++++
e is 65537 (0x010001)
[root@centos8 CA]#tree
.
├── certs
├── crl
├── newcerts
└── private
└── cakey.pem
4 directories, 1 file
1.3给CA颁发自签名证书
[root@centos8 ~]#openssl req -new -x509 -key /etc/pki/CA/private/cakey.pem -days  3650 -out /etc/pki/CA/cacert.pem

You are about to be asked to enter information that will be incorporatedinto your certificate request.

What you are about to enter is what is called a Distinguished Name or a DN.

There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [XX]:CN
State or Province Name (full name) []:beijing
Locality Name (eg, city) [Default City]:beijing
Organization Name (eg, company) [Default Company Ltd]:magedu
Organizational Unit Name (eg, section) []:devops
Common Name (eg, your name or your server's hostname) []:ca.magedu.org
Email Address []:admin@magedu.org
1.4 用户生成私钥和证书申请
[root@centos8 ~]#mkdir /data/app1
[root@centos8 ~]#(umask 066; openssl genrsa -out /data/app1/app1.key 2048)
Generating RSA private key, 2048 bit long modulus (2 primes)
....................+++++
....................................+++++
e is 65537 (0x010001)
[root@centos8 ~]#openssl req -new -key /data/app1/app1.key -out
/data/app1/app1.csr
You are about to be asked to enter information that will be incorporated
into your certificate request.
What you are about to enter is what is called a Distinguished Name or a DN.
There are quite a few fields but you can leave some blank
For some fields there will be a default value,
If you enter '.', the field will be left blank.
-----
Country Name (2 letter code) [XX]:CN
State or Province Name (full name) []:beijing
Locality Name (eg, city) [Default City]:bj
Organization Name (eg, company) [Default Company Ltd]:magedu
Organizational Unit Name (eg, section) []:it
Common Name (eg, your name or your server's hostname) []:app1.magedu.org
Email Address []:root@magedu.org
Please enter the following 'extra' attributes
to be sent with your certificate request
A challenge password []:
An optional company name []:
1.5 CA颁发证书
[root@centos8 ~]#openssl ca -in /data/app1/app1.csr -out
/etc/pki/CA/certs/app1.crt -days 1000

2、总结ssh常用参数、用法

telnet协议是使用明文的方式进行传输，这就非常地不安全，而ssh协议是密文传输的，实现了加密通信。在CentOS系统上默认安装了openssh(ssh协议的开源实现)。
ssh执行指纹核对（fingerprint verification）来确保用户连接到正确的远程主机。在第一次连接到服务器上时，ssh默认会存储指纹信息，在之后的连接过程中核对该指纹。
ssh命令是ssh客户端，允许实现对远程系统经验证地加密安全访问。

ssh用法:





3、总结sshd服务常用参数。

sshd：openssh服务器守护进程。

服务器端：sshd

服务器端的配置文件: /etc/ssh/sshd_config

常用参数：

Port #生产建议修改
ListenAddress ip
LoginGraceTime 2m
PermitRootLogin yes #默认ubuntu不允许root远程ssh登录
StrictModes yes #检查.ssh/文件的所有者，权限等
MaxAuthTries 6 #pecifies the maximum number of authentication
attempts permitted per connection. Once the number of failures reaches half this
value, additional failures are logged. The default is 6.
MaxSessions 10 #同一个连接最大会话
PubkeyAuthentication yes #基于key验证
PermitEmptyPasswords no #空密码连接
PasswordAuthentication yes #基于用户名和密码连接
GatewayPorts no
ClientAliveInterval 10 #单位:秒
ClientAliveCountMax 3 #默认3
UseDNS yes #提高速度可改为no
GSSAPIAuthentication yes #提高速度可改为no
MaxStartups #未认证连接最大值，默认值10
Banner /path/file

#以下可以限制可登录用户的办法：
AllowUsers user1 user2 user3
DenyUsers user1 user2 user3
AllowGroups g1 g2
DenyGroups g1 g2

ssh服务的最佳实践：
（1）建议使用非默认端口
（2）禁止使用protocol version 1
（3）限制可登录用户
（4）设定空闲会话超时时长
（5）利用防火墙设置ssh访问策略
（6）仅监听特定的IP地址
（7）基于口令认证时，使用强密码策略，比如：tr -dc A-Za-z0-9_ < /dev/urandom | head -c 12|
xargs
（8）使用基于密钥的认证
（9）禁止使用空密码
（10）禁止root用户直接登录
（11）限制ssh的访问频度和并发在线数
（12）经常分析日志

4、搭建dhcp服务，实现ip地址申请分发

yum -y install dhcp(centos7)/dhcp-server(centos8)

修改/etc/dhcp/dhcpd.conf配置文件

option domain-name "example.org";
option domain-name-servers 180.76.76.76, 223.6.6.6;

default-lease-time 86400;
max-lease-time 106400;

subnet 10.0.0.0 netmask 255.255.255.0 {
range 10.0.0.9 10.0.0.100;
option routers 10.0.0.2;
next-server 10.0.0.8;
filename "pxelinux.0";
}

systemctl enable --now dhcpd  #启动dhcp

ss -ntul 查看udp67端口

在 /var/lib/dhcpd/dhcpd.leases中查看分配的地址
