zabbix 监控交换机

1.





2.









3.







3.





3.

 3.













[root@localhost ~]# snmpwalk -v 2c -c jxetv2016 192.168.30.254 | more
SNMPv2-MIB::sysDescr.0 = STRING: H3C Comware Platform Software, Software Version 5.20 Release 2220P02
H3C S5500-28C-EI
Copyright (c) 2004-2013 Hangzhou H3C Tech. Co., Ltd. All rights reserved.
SNMPv2-MIB::sysObjectID.0 = OID: SNMPv2-SMI::enterprises.25506.1.1
DISMAN-EVENT-MIB::sysUpTimeInstance = Timeticks: (746203880) 86 days, 8:47:18.80
SNMPv2-MIB::sysContact.0 = STRING: Hangzhou H3C Tech. Co., Ltd.
SNMPv2-MIB::sysName.0 = STRING: coresw
SNMPv2-MIB::sysLocation.0 = STRING: Hangzhou, China
SNMPv2-MIB::sysServices.0 = INTEGER: 78
IF-MIB::ifNumber.0 = INTEGER: 43
IF-MIB::ifIndex.1 = INTEGER: 1
IF-MIB::ifIndex.2 = INTEGER: 2
IF-MIB::ifIndex.3 = INTEGER: 3
IF-MIB::ifIndex.4 = INTEGER: 4
IF-MIB::ifIndex.5 = INTEGER: 5
IF-MIB::ifIndex.6 = INTEGER: 6
IF-MIB::ifIndex.7 = INTEGER: 7
IF-MIB::ifIndex.8 = INTEGER: 8
IF-MIB::ifIndex.9 = INTEGER: 9



[root@localhost ~]# snmpget -v 2c -c jxetv2016 -On 192.168.30.254 IF-MIB::ifDescr.15
.1.3.6.1.2.1.2.2.1.2.15 = STRING: GigabitEthernet1/0/15
