【微前端】singleSpa&importHTMLEntry（流程图）源码解析

single-spa v5.9.3

通过轻量级路由劫持和状态机设计，实现微前端的动态加载与隔离，主要实现

  • 路由管理：hashchange、popstate、history.pushState、history.replaceState进行劫持，路由变化时，触发 reroute()
  • 子应用状态管理：不同执行逻辑转化不同的状态，比如
  • 加载流程：toLoadPromise→toBootstrapPromise→toMountPromise
  • 卸载流程：toUnmountPromise→toUnloadPromise
  • 子应用生命周期触发：
  • app.bootstrap()：初始化时仅执行一次
  • app.mount()：应用激活时触发
  • app.unmount()：应用从激活变为非激活状态时触发
  • app.unload()：最终卸载时触发一次

single-spa 采用 JS Entry 的方式接入微前端

我们需要在基座中注册子应用，比如下面代码中，我们注册了对应的映射路径 path 以及对应的加载的方法

registerApplication({
  name: "app1",
  app: loadApp(url),
  activeWhen: activeWhen("/app1"),
  customProps: {},
});

整体流程图

1. registerApplication()

在基座初始化时，会调用 registerApplication() 进行子应用的注册

从下面的源码我可以知道，主要执行：

  • 格式化用户传递的子应用配置参数：sanitizeArguments()
  • 将子应用加入到 apps 中
  • 如果是浏览器，则触发
  • ensureJQuerySupport()：增加 JQuery的支持
  • reroute()：统一处理路由的方法
function registerApplication(
  appNameOrConfig,
  appOrLoadApp,
  activeWhen,
  customProps
) {
  var registration = sanitizeArguments(
    appNameOrConfig,
    appOrLoadApp,
    activeWhen,
    customProps
  );
  apps.push(
    assign(
      {
        loadErrorTime: null,
        status: NOT_LOADED,
        parcels: {},
        devtools: {
          overlays: {
            options: {},
            selectors: [],
          },
        },
      },
      registration
    )
  );
  if (isInBrowser) {
    ensureJQuerySupport();
    reroute();
  }
}

reroute()

  • 状态计算：通过 getAppChanges() 根据当前的 URL 筛选出需要 加载/卸载 的应用，主要分为 4 种类型
  • 根据是否已经触发 start()，从而决定要触发
  • loadApps()： 加载应用资源，没有其他逻辑
  • performAppChanges()：卸载非 active 状态的应用（调用 umount 生命周期） + 加载并挂载 active 子应用
function reroute() {
  if (appChangeUnderway) {
    return new Promise(function (resolve, reject) {
      peopleWaitingOnAppChange.push({
        resolve: resolve,
        reject: reject,
        eventArguments: eventArguments,
      });
    });
  }
  var { appsToUnload, appsToUnmount, appsToLoad, appsToMount } =
    getAppChanges();
  if (isStarted()) {
    appChangeUnderway = true;
    appsThatChanged = appsToUnload.concat(
      appsToLoad,
      appsToUnmount,
      appsToMount
    );
    return performAppChanges();
  } else {
    appsThatChanged = appsToLoad;
    return loadApps();
  }
}

1.1 getAppChanges()

根据目前 app.status 的状态进行不同数组数据的组装

  • appsToLoad
  • appsToUnload
  • appsToMount
  • appsToUnmount
apps.forEach(function (app) {
  var appShouldBeActive =
    app.status !== SKIP_BECAUSE_BROKEN && shouldBeActive(app);
  switch (app.status) {
    case LOAD_ERROR:
      if (appShouldBeActive && currentTime - app.loadErrorTime >= 200) {
        appsToLoad.push(app);
      }
      break;
    case NOT_LOADED:
    case LOADING_SOURCE_CODE:
      if (appShouldBeActive) {
        appsToLoad.push(app);
      }
      break;
    case NOT_BOOTSTRAPPED:
    case NOT_MOUNTED:
      if (!appShouldBeActive && getAppUnloadInfo(toName(app))) {
        appsToUnload.push(app);
      } else if (appShouldBeActive) {
        appsToMount.push(app);
      }
      break;
    case MOUNTED:
      if (!appShouldBeActive) {
        appsToUnmount.push(app);
      }
      break;
    // all other statuses are ignored
  }
});

1.2 loadApps()

在 loadApps() 中，就是遍历 appsToLoad 数组 => toLoadPromise(app)，本质就是触发 app.loadApp()进行子应用的加载

function loadApps() {
  return Promise.resolve().then(function () {
    var loadPromises = appsToLoad.map(toLoadPromise);
    return (
      Promise.all(loadPromises)
        .then(callAllEventListeners)
        // there are no mounted apps, before start() is called, so we always return []
        .then(function () {
          return [];
        })
        .catch(function (err) {
          callAllEventListeners();
          throw err;
        })
    );
  });
}
1.2.1 toLoadPromise()

触发 app.loadApp()进行子应用的加载

需要子应用提供一个 loadApp()并且返回 Promise

状态改为 NOT_BOOTSTRAPPED

function toLoadPromise(app) {
  return Promise.resolve().then(function () {
    if (app.loadPromise) {
      return app.loadPromise;
    }
    if (app.status !== NOT_LOADED && app.status !== LOAD_ERROR) {
      return app;
    }
    app.status = LOADING_SOURCE_CODE;
    var appOpts, isUserErr;
    return (app.loadPromise = Promise.resolve()
      .then(function () {
        var loadPromise = app.loadApp(getProps(app));
        return loadPromise.then(function (val) {
          app.loadErrorTime = null;
          appOpts = val;
          app.status = NOT_BOOTSTRAPPED;
          app.bootstrap = flattenFnArray(appOpts, "bootstrap");
          app.mount = flattenFnArray(appOpts, "mount");
          app.unmount = flattenFnArray(appOpts, "unmount");
          app.unload = flattenFnArray(appOpts, "unload");
          app.timeouts = ensureValidAppTimeouts(appOpts.timeouts);
          delete app.loadPromise;
          return app;
        });
      })
      .catch(function (err) {
        //...
      }));
  });
}

2. 监听路由变化

single-spa 源码中有自动执行的一系列代码：

  • 监听 hashchange 和 popstate 变化，触发urlReroute()->reroute()
  • 劫持 window.addEventListener 和 window.removeEventListener，将外部应用通过注册的 ["hashchange", "popstate"] 的监听方法 放入到 capturedEventListeners 中，在下面的 unmountAllPromise.then() 之后才会调用 capturedEventListeners 存储的方法执行
  • 重写 history.pushState() 和 history.replaceState() 方法，在原来的基础上增加 window.dispatchEvent(createPopStateEvent(window.history.state, methodName)) ，从而触发第一步的 popstate 监听，从而触发 urlReroute()->reroute() 进行子应用路由的状态同步

总结：

  • 路由变化触发微前端子应用加载
  • pushState 和 replaceState 改变路由触发微前端子应用加载
  • 阻止外部的hashchange、popstate对应的监听方法直接执行，而是等待微前端执行后才触发这些方法
var routingEventsListeningTo = ["hashchange", "popstate"];
if (isInBrowser) {
  window.addEventListener("hashchange", urlReroute);
  window.addEventListener("popstate", urlReroute);

  var originalAddEventListener = window.addEventListener;
  var originalRemoveEventListener = window.removeEventListener;
  window.addEventListener = function (eventName, fn) {
    if (typeof fn === "function") {
      if (
        routingEventsListeningTo.indexOf(eventName) >= 0 &&
        !find(capturedEventListeners[eventName], function (listener) {
          return listener === fn;
        })
      ) {
        capturedEventListeners[eventName].push(fn);
        return;
      }
    }
    return originalAddEventListener.apply(this, arguments);
  };
  window.removeEventListener = function (eventName, listenerFn) {
    //...
  };
  window.history.pushState = patchedUpdateState(
    window.history.pushState,
    "pushState"
  );
  window.history.replaceState = patchedUpdateState(
    window.history.replaceState,
    "replaceState"
  );
  if (window.singleSpaNavigate) {
    //...
  } else {
    window.singleSpaNavigate = navigateToUrl;
  }
}

function urlReroute() {
  reroute([], arguments);
}

function callAllEventListeners() {
  pendingPromises.forEach(function (pendingPromise) {
    callCapturedEventListeners(pendingPromise.eventArguments);
  });
  callCapturedEventListeners(eventArguments);
}

3. start()启动开始状态

当基座主动触发 single-spa 的 start() 方法时

function start(opts) {
  started = true;
  if (opts && opts.urlRerouteOnly) {
    setUrlRerouteOnly(opts.urlRerouteOnly);
  }
  if (isInBrowser) {
    reroute();
  }
}

此时已经在监听路由变化，然后进行 active 子应用的挂载 performAppChanges()

function reroute() {
  if (appChangeUnderway) {
    return new Promise(function (resolve, reject) {
      peopleWaitingOnAppChange.push({
        resolve: resolve,
        reject: reject,
        eventArguments: eventArguments,
      });
    });
  }
  var { appsToUnload, appsToUnmount, appsToLoad, appsToMount } =
    getAppChanges();
  if (isStarted()) {
    appChangeUnderway = true;
    appsThatChanged = appsToUnload.concat(
      appsToLoad,
      appsToUnmount,
      appsToMount
    );
    return performAppChanges();
  } else {
    appsThatChanged = appsToLoad;
    return loadApps();
  }
}

3.1 getAppChanges()

根据目前 app.status 的状态进行不同数组数据的组装

  • appsToLoad
  • appsToUnload
  • appsToMount
  • appsToUnmount
apps.forEach(function (app) {
  var appShouldBeActive =
    app.status !== SKIP_BECAUSE_BROKEN && shouldBeActive(app);
  switch (app.status) {
    case LOAD_ERROR:
      if (appShouldBeActive && currentTime - app.loadErrorTime >= 200) {
        appsToLoad.push(app);
      }
      break;
    case NOT_LOADED:
    case LOADING_SOURCE_CODE:
      if (appShouldBeActive) {
        appsToLoad.push(app);
      }
      break;
    case NOT_BOOTSTRAPPED:
    case NOT_MOUNTED:
      if (!appShouldBeActive && getAppUnloadInfo(toName(app))) {
        appsToUnload.push(app);
      } else if (appShouldBeActive) {
        appsToMount.push(app);
      }
      break;
    case MOUNTED:
      if (!appShouldBeActive) {
        appsToUnmount.push(app);
      }
      break;
    // all other statuses are ignored
  }
});

3.2 performAppChanges()

而当 start() 方法触发后，started 设置为 true， 标志着应用从 初始化注册应用（加载应用）的模式进入到 运行阶段（监听路由变化）

此时触发 reroute()，则进入 performAppChanges()

urlRerouteOnly控制路由触发规则：

  • urlRerouteOnly=true：用户点击或者使用 API 才会触发 reroute()
  • urlRerouteOnly=false：任何 history.pushState() 的调用都会触发 reroute()
function start(opts) {
  started = true;
  if (opts && opts.urlRerouteOnly) {
    setUrlRerouteOnly(opts.urlRerouteOnly);
  }
  if (isInBrowser) {
    reroute();
  }
}

在 performAppChanges() 中，先组装出需要卸载的子应用

var unloadPromises = appsToUnload.map(toUnloadPromise);
var unmountUnloadPromises = appsToUnmount
  .map(toUnmountPromise)
  .map(function (unmountPromise) {
    return unmountPromise.then(toUnloadPromise);
  });
var allUnmountPromises = unmountUnloadPromises.concat(unloadPromises);
var unmountAllPromise = Promise.all(allUnmountPromises);

再组装出需要加载的应用

/* We load and bootstrap apps while other apps are unmounting, but we
 * wait to mount the app until all apps are finishing unmounting
 */
var loadThenMountPromises = appsToLoad.map(function (app) {
  return toLoadPromise(app).then(function (app) {
    return tryToBootstrapAndMount(app, unmountAllPromise);
  });
});

/* These are the apps that are already bootstrapped and just need
 * to be mounted. They each wait for all unmounting apps to finish up
 * before they mount.
 */
var mountPromises = appsToMount
  .filter(function (appToMount) {
    return appsToLoad.indexOf(appToMount) < 0;
  })
  .map(function (appToMount) {
    return tryToBootstrapAndMount(appToMount, unmountAllPromise);
  });

先触发 unmountAllPromise ，然后再触发 loadThenMountPromises.concat(mountPromises)，最终全部完成后触发finishUpAndReturn

return unmountAllPromise
  .catch(function (err) {
    callAllEventListeners();
    throw err;
  })
  .then(function () {
    /* Now that the apps that needed to be unmounted are unmounted, their DOM navigation
     * events (like hashchange or popstate) should have been cleaned up. So it's safe
     * to let the remaining captured event listeners to handle about the DOM event.
     */
    callAllEventListeners();
    return Promise.all(loadThenMountPromises.concat(mountPromises))
      .catch(function (err) {
        pendingPromises.forEach(function (promise) {
          return promise.reject(err);
        });
        throw err;
      })
      .then(finishUpAndReturn);
  });

在上面的方法中，我们看到了很多封装的方法，比如toLoadPromise()、tryToBootstrapAndMount()、toUnloadPromise()、finishUpAndReturn()，接下来我们将展开分析

3.2.1 tryToBootstrapAndMount()

当用户目前的路由是 /app1，导航到 /app2时：

  • 调用 app.activeWhen() 进行子应用状态的检测（需要子应用提供实现方法），shouldBeActive(app2) 返回 true
  • 触发 toBootstrapPromise(app2) 更改状态为 BOOTSTRAPPING，并且触发子应用提供的 app2.bootstrap() 生命周期方法 => 更改状态为 NOT_MOUNTED
  • 触发传入的unmountAllPromise，进行 /app1 卸载，然后再触发 toMountPromise(app2) 执行子应用提供的 app2.mount() 生命周期方法，然后更改状态为 MOUNTED

如果卸载完成 /app1 后，我们再次检测 shouldBeActive(app2) 的时候发现路由改变，不是 /app2，那么 app2 停止挂载，直接返回 app2，状态仍然保留在 toBootstrapPromise(app2) 时的 NOT_MOUNTED

function tryToBootstrapAndMount(app, unmountAllPromise) {
  if (shouldBeActive(app)) {
    return toBootstrapPromise(app).then(function (app) {
      return unmountAllPromise.then(function () {
        return shouldBeActive(app) ? toMountPromise(app) : app;
      });
    });
  } else {
    return unmountAllPromise.then(function () {
      return app;
    });
  }
}
function shouldBeActive(app) {
  return app.activeWhen(window.location);
}
function toBootstrapPromise(appOrParcel, hardFail) {
  return Promise.resolve().then(function () {
    if (appOrParcel.status !== NOT_BOOTSTRAPPED) {
      return appOrParcel;
    }
    appOrParcel.status = BOOTSTRAPPING;
    if (!appOrParcel.bootstrap) {
      // Default implementation of bootstrap
      return Promise.resolve().then(successfulBootstrap);
    }
    return reasonableTime(appOrParcel, "bootstrap")
      .then(successfulBootstrap)
      .catch(function (err) {
        //...
      });
  });
  function successfulBootstrap() {
    appOrParcel.status = NOT_MOUNTED;
    return appOrParcel;
  }
}
function toMountPromise(appOrParcel, hardFail) {
  return Promise.resolve().then(function () {
    return reasonableTime(appOrParcel, "mount")
      .then(function () {
        appOrParcel.status = MOUNTED;
        //...
        return appOrParcel;
      })
      .catch(function (err) {
        //...
      });
  });
}
3.2.2 toUnloadPromise()

逻辑也非常简单，就是触发子应用提供的 app2.unload() 生命周期方法，将状态改为 UNLOADING => 将状态改为 NOT_LOADED

var appsToUnload = {};
function toUnloadPromise(app) {
  return Promise.resolve().then(function () {
    var unloadInfo = appsToUnload[toName(app)];

    if (app.status === NOT_LOADED) {
      finishUnloadingApp(app, unloadInfo);
      return app;
    }
    if (app.status === UNLOADING) {
      return unloadInfo.promise.then(function () {
        return app;
      });
    }
    if (app.status !== NOT_MOUNTED && app.status !== LOAD_ERROR) {
      return app;
    }
    var unloadPromise =
      app.status === LOAD_ERROR
        ? Promise.resolve()
        : reasonableTime(app, "unload");
    app.status = UNLOADING;
    return unloadPromise
      .then(function () {
        finishUnloadingApp(app, unloadInfo);
        return app;
      })
      .catch(function (err) {
        errorUnloadingApp(app, unloadInfo, err);
        return app;
      });
  });
}
function finishUnloadingApp(app, unloadInfo) {
  delete appsToUnload[toName(app)];
  delete app.bootstrap;
  delete app.mount;
  delete app.unmount;
  delete app.unload;
  app.status = NOT_LOADED;
  unloadInfo.resolve();
}
3.3.3 finishUpAndReturn()
  • 返回已经挂载应用的列表
  • 处理等待中的 pendingPromises
  • 触发全局事件通知
  • 重置全局状态 appChangeUnderway = false
  • 检测是否有未处理的后续请求，如果有，则重新触发 reroute() 处理
function finishUpAndReturn() {
  var returnValue = getMountedApps();
  pendingPromises.forEach(function (promise) {
    return promise.resolve(returnValue);
  });
  var appChangeEventName =
    appsThatChanged.length === 0
      ? "single-spa:no-app-change"
      : "single-spa:app-change";
  window.dispatchEvent(
    new customEvent(appChangeEventName, getCustomEventDetail())
  );
  window.dispatchEvent(
    new customEvent("single-spa:routing-event", getCustomEventDetail())
  );

  appChangeUnderway = false;
  if (peopleWaitingOnAppChange.length > 0) {
    var nextPendingPromises = peopleWaitingOnAppChange;
    peopleWaitingOnAppChange = [];
    reroute(nextPendingPromises);
  }
  return returnValue;
}

import-html-entry v1.17.0

假设我们要转化的 index.html 为：

<!DOCTYPE html>
<html>
<head>
    <link rel="stylesheet" href="style.css">
</head>
<body>
    <h1>Hello Micro Frontend</h1>
    <script src="app.js" entry></script>
    <script src="async.js" async></script>
    <script>console.log('Inline script');</script>
</body>
</html>

style.css 的具体内容为：

body { background-color: lightblue; }

app.js 内容为：

// 子应用导出的生命周期钩子
export function bootstrap() {
  console.log("Sub app bootstrap");
}
export function mount() {
  console.log("Sub app mounted");
}
bootstrap();

async.js 内容为：

console.log("Async script loaded");

我们在外部使用这个库一般直接使用 importEntry() 获取子应用的数据

在我们这个示例中，会传入一个 entry = "index.html"，因此会直接走 importHTML()

function importEntry(entry, opts = {}) {
  const {
    fetch = defaultFetch,
    getTemplate = defaultGetTemplate,
    postProcessTemplate,
  } = opts;
  const getPublicPath =
    opts.getPublicPath || opts.getDomain || defaultGetPublicPath;

  // html entry
  if (typeof entry === "string") {
    return importHTML(entry, {
      fetch,
      getPublicPath,
      getTemplate,
      postProcessTemplate,
    });
  }

  // config entry
  if (Array.isArray(entry.scripts) || Array.isArray(entry.styles)) {
    //...
  } else {
    throw new SyntaxError("entry scripts or styles should be array!");
  }
}

从下面代码可以知道，主要分为几个步骤：

  • 获取 HTML 内容：通过fetch直接请求对应的 https 得到对应的 HTML 字符串（也就是我们上面示例的 index.html 内容）
  • 解析 HTML：调用 processTpl() 解析 HTML 得到
  • scripts = ["/app.js ", ""]
  • entry = "/app.js "
  • styles = ["/style.css "]
  • 将 CSS 样式进行内联：在 getEmbedHTML() 下载 style.css 的内容，替换 template 模板中 为 的內联样式

    function getEmbedHTML(template, styles, opts = {}) {
  const { fetch = defaultFetch } = opts;
  let embedHTML = template;

  return getExternalStyleSheets(styles, fetch).then((styleSheets) => {
    embedHTML = styleSheets.reduce((html, styleSheet) => {
      const styleSrc = styleSheet.src;
      const styleSheetContent = styleSheet.value;
      html = html.replace(
        genLinkReplaceSymbol(styleSrc),
        isInlineCode(styleSrc)
          ? `${styleSrc}`
          : `<style>/* ${styleSrc} */${styleSheetContent}</style>`
      );
      return html;
    }, embedHTML);
    return embedHTML;
  });
}

    3. 返回值对象解析

    3.1 template

    替换 template 模板中 为 內联样式替换到 template 中，然后返回一个对象数据，包括

    • template：替换了所有 styles 的模板数据
    • assetPublicPath：微应用的路径
    • getExternalScripts()：提供外部调用可以下载 scripts = ["/app.js ", ""] 的方法
    • getExternalStyleSheets()：提供外部调用可以下载 styles = ["/style.css "] 的方法
    • execScripts()：执行 getExternalScripts() 下载 scripts，然后调用 geval() 生成沙箱代码并执行，确保 JS 在代理的上下文中运行，避免全局污染
    function importHTML(url, opts = {}) {
  //...
  return (
    embedHTMLCache[url] ||
    (embedHTMLCache[url] = fetch(url)
      .then((response) => readResAsString(response, autoDecodeResponse))
      .then((html) => {
        const assetPublicPath = getPublicPath(url);
        const { template, scripts, entry, styles } = processTpl(
          getTemplate(html),
          assetPublicPath,
          postProcessTemplate
        );

        return getEmbedHTML(template, styles, { fetch }).then((embedHTML) => ({
          template: embedHTML,
          assetPublicPath,
          getExternalScripts: () => getExternalScripts(scripts, fetch),
          getExternalStyleSheets: () => getExternalStyleSheets(styles, fetch),
          execScripts: (proxy, strictGlobal, opts = {}) => {
            if (!scripts.length) {
              return Promise.resolve();
            }
            return execScripts(entry, scripts, proxy, {
              fetch,
              strictGlobal,
              ...opts,
            });
          },
        }));
      }))
  );
}
posted @ 2025-05-22 16:43  ebuybay  阅读(21)  评论(0)    收藏  举报
