一丶前言

　　题目集4和题目集5总体难度上相较于之前，确实有所提升。在题目集4，题目集5中都用到了继承丶构造丶封装等知识点，在题量上相较之前，有明显增加，这和题目中多边形的边数有一定关系。

二丶设计与分析

7-1 sdut-String-2 识蛟龙号载人深潜，立科技报国志（II）（正则表达式）

背景简介：

“蛟龙号”载人深潜器是我国首台自主设计、自主集成研制的作业型深海载人潜水器，设计最大下潜深度为7000米级，也是目前世界上下潜能力最强的作业型载人潜水器。“蛟龙号”可在占世界海洋面积99.8%的广阔海域中使用，对于我国开发利用深海的资源有着重要的意义。

中国是继美、法、俄、日之后世界上第五个掌握大深度载人深潜技术的国家。在全球载人潜水器中，“蛟龙号”属于第一梯队。目前全世界投入使用的各类载人潜水器约90艘，其中下潜深度超过1000米的仅有12艘，更深的潜水器数量更少，目前拥有6000米以上深度载人潜水器的国家包括中国、美国、日本、法国和俄罗斯。除中国外，其他4国的作业型载人潜水器最大工作深度为日本深潜器的6527米，因此“蛟龙号”载人潜水器在西太平洋的马里亚纳海沟海试成功到达7020米海底，创造了作业类载人潜水器新的世界纪录。

从2009年至2012年，蛟龙号接连取得1000米级、3000米级、5000米级和7000米级海试成功。下潜至7000米，说明蛟龙号载人潜水器集成技术的成熟，标志着我国深海潜水器成为海洋科学考察的前沿与制高点之一。

2012年6月27日11时47分，中国“蛟龙”再次刷新“中国深度”——下潜7062米。6月3日，“蛟龙”出征以来，已经连续书写了5个“中国深度”新纪录：6月15日，6671米；6月19日，6965米；6月22日，6963米；6月24日，7020米；6月27日，7062米。下潜至7000米，标志着我国具备了载人到达全球99%以上海洋深处进行作业的能力，标志着“蛟龙”载人潜水器集成技术的成熟，标志着我国深海潜水器成为海洋科学考察的前沿与制高点之一，标志着中国海底载人科学研究和资源勘探能力达到国际领先水平。

‘蛟龙’号是我国载人深潜发展历程中的一个重要里程碑。它不只是一个深海装备，更代表了一种精神，一种不畏艰险、赶超世界的精神，它是中华民族进军深海的号角。

了解蛟龙号”载人深潜器“的骄人业绩，为我国海底载人科学研究和资源勘探能力达到国际领先水平而自豪，小伙伴们与祖国同呼吸、共命运，一定要学好科学文化知识、提高个人能力，增强创新意识，做事精益求精，立科技报国之志！

请编写程序，实现如下功能：读入关于蛟龙号载人潜水器探测数据的多行字符串，从给定的信息找出数字字符，输出每行的数字之和。

提示若输入为“2012年2月”，则该行的输出为：2014。若干个连续的数字字符作为一个整体，以十进制形式相加。

输入格式:

读入关于蛟龙号载人潜水器探测数据的多行字符串，每行字符不超过80个字符。

以"end"结束。

输出格式:

与输入行相对应的各个整数之和。

import java.util.Scanner;
import java.util.regex.Matcher;
import java.util.regex.Pattern;

public class Main {

	public static void main(String[] args) {
		Scanner input = new Scanner(System.in);

		String s = input.nextLine();
		Pattern p = Pattern.compile("[0-9]+");
		while(!s.equals("end")) {
			Matcher o = p.matcher(s);
			int sum = 0;
			while (o.find())
	            sum += Integer.valueOf(o.group());
			System.out.println(sum);
			s = input.nextLine();
		}
	}
}

本体比较简单，因此代码量也很少。

7-2 点线形系列4-凸四边形的计算

用户输入一组选项和数据，进行与四边形有关的计算。
以下四边形顶点的坐标要求按顺序依次输入，连续输入的两个顶点是相邻顶点，第一个和最后一个输入的顶点相邻。
选项包括：
1：输入四个点坐标，判断是否是四边形、平行四边形，判断结果输出true/false，结果之间以一个英文空格符分隔。
2：输入四个点坐标，判断是否是菱形、矩形、正方形，判断结果输出true/false，结果之间以一个英文空格符分隔。若四个点坐标无法构成四边形，输出"not a quadrilateral"
3：输入四个点坐标，判断是凹四边形（false）还是凸四边形(true)，输出四边形周长、面积，结果之间以一个英文空格符分隔。若四个点坐标无法构成四边形，输出"not a quadrilateral"
4：输入六个点坐标，前两个点构成一条直线，后四个点构成一个四边形或三角形，输出直线与四边形（也可能是三角形）相交的交点数量。如果交点有两个，再按面积从小到大输出四边形(或三角形)被直线分割成两部分的面积（不换行）。若直线与四边形或三角形的一条边线重合，输出"The line is coincide with one of the lines"。若后四个点不符合四边形或三角形的输入，输出"not a quadrilateral or triangle"。
后四个点构成三角形的情况：假设三角形一条边上两个端点分别是x、y，边线中间有一点z，另一顶点s：
1）符合要求的输入：顶点重复或者z与xy都相邻，如x x y s、x z y s、x y x s、s x y y。此时去除冗余点，保留一个x、一个y。
2) 不符合要求的输入：z 不与xy都相邻，如z x y s、x z s y、x s z y
5：输入五个点坐标，输出第一个是否在后四个点所构成的四边形（限定为凸四边形，不考虑凹四边形）或三角形（判定方法见选项4）的内部（若是四边形输出in the quadrilateral/outof the quadrilateral，若是三角形输出in the triangle/outof the triangle）。如果点在多边形的某条边上，输出"on the triangle或者on the quadrilateral"。若后四个点不符合四边形或三角形，输出"not a quadrilateral or triangle"。

输入格式:

基本格式：选项+":"+坐标x+","+坐标y+" "+坐标x+","+坐标y。点的x、y坐标之间以英文","分隔，点与点之间以一个英文空格分隔。

输出格式:

基本输出格式见每种选项的描述。
异常情况输出：
如果不符合基本格式，输出"Wrong Format"。
如果符合基本格式，但输入点的数量不符合要求，输出"wrong number of points"。
注意：输出的数据若小数点后超过3位，只保留小数点后3位，多余部分采用四舍五入规则进到最低位。小数点后若不足3位，按原始位数显示，不必补齐。例如：1/3的结果按格式输出为 0.333，1.0按格式输出为1.0

选项1、2、3中，若四边形四个点中有重合点，输出"points coincide"。
选项4中，若前两个输入线的点重合，输出"points coincide"。

import java.util.Scanner;

public class Main {
    public static void main(String[] args) {
        Scanner input = new Scanner(System.in);
        double x1,y1;
        double x2,y2;
        double x3,y3;
        double x4,y4;
        double x5,y5;
        double x6,y6;
        double x,y;
        String s = input.nextLine();
        String s1,s2;
        String[] a = new String[10];
        String[] b = new String[2];
        if(!s.matches("^[0-9]:((\\-|\\+)?\\d+(\\.\\d+)?,(\\-|\\+)?\\d+(\\.\\d+)? ){1,4}(\\-|\\+)?\\d+(\\.\\d+)?,(\\-|\\+)?\\d+(\\.\\d+)?$"))
        {
            System.out.println("Wrong Format");
            return;
        }
        s1 = s.substring(0, 1);
        s2 = s.substring(2);
        a = s2.split(" ");
        //x1,y1,x2,y2,x3,y3,x4,y4
        if(s1.equals("1"))
        {
            if(!numme(a,4))
            {
                System.out.println("wrong number of points");
                return;
            }
            b = a[0].split(",");
            x1 = Double.valueOf(b[0]);
            y1 = Double.valueOf(b[1]);
            b = a[1].split(",");
            x2 = Double.valueOf(b[0]);
            y2 = Double.valueOf(b[1]);
            b = a[2].split(",");
            x3 = Double.valueOf(b[0]);
            y3 = Double.valueOf(b[1]);
            b = a[3].split(",");
            x4 = Double.valueOf(b[0]);
            y4 = Double.valueOf(b[1]);
            if((x1==x2&&y1==y2)||(x1==x3&&y1==y3)||(x1==x4&&y1==y4)||(x3==x2&&y3==y2)||(x4==x2&&y4==y2)||(x3==x4&&y3==y4))
            {
                System.out.println("points coincide");
                return;
            }
            if(sibian(x1,y1,x2,y2,x3,y3,x4,y4))
            {
                System.out.print("true ");
                if(pingxi(x1,y1,x2,y2,x3,y3,x4,y4))
                    System.out.print("true");
                else
                    System.out.print("false");
                return;
            }
            System.out.println("false false");

        }
        else if(s1.equals("2"))
        {
            if(!numme(a,4))
            {
                System.out.println("wrong number of points");
                return;
            }
            b = a[0].split(",");
            x1 = Double.valueOf(b[0]);
            y1 = Double.valueOf(b[1]);
            b = a[1].split(",");
            x2 = Double.valueOf(b[0]);
            y2 = Double.valueOf(b[1]);
            b = a[2].split(",");
            x3 = Double.valueOf(b[0]);
            y3 = Double.valueOf(b[1]);
            b = a[3].split(",");
            x4 = Double.valueOf(b[0]);
            y4 = Double.valueOf(b[1]);
            if((x1==x2&&y1==y2)||(x1==x3&&y1==y3)||(x1==x4&&y1==y4)||(x3==x2&&y3==y2)||(x4==x2&&y4==y2)||(x3==x4&&y3==y4))
            {
                System.out.println("points coincide");
                return;
            }
            if(sibian(x1,y1,x2,y2,x3,y3,x4,y4))
            {
                if(pingxi(x1,y1,x2,y2,x3,y3,x4,y4))
                {
                    if(zfxi(x1,y1,x2,y2,x3,y3,x4,y4))
                    {
                        System.out.println("true true true");
                        return;
                    }
                    if(lingxi(x1,y1,x2,y2,x3,y3,x4,y4))
                    {
                        System.out.println("true false false");
                        return;
                    }
                    if(juxi(x1,y1,x2,y2,x3,y3,x4,y4))
                    {
                        System.out.println("false true false");
                        return;
                    }
                }
            }
            else {
                System.out.println("not a quadrilateral");
                return;
            }
            System.out.println("false false false");
        }
        else if(s1.equals("3"))
        {
            if(!numme(a,4))
            {
                System.out.println("wrong number of points");
                return;
            }
            b = a[0].split(",");
            x1 = Double.valueOf(b[0]);
            y1 = Double.valueOf(b[1]);
            b = a[1].split(",");
            x2 = Double.valueOf(b[0]);
            y2 = Double.valueOf(b[1]);
            b = a[2].split(",");
            x3 = Double.valueOf(b[0]);
            y3 = Double.valueOf(b[1]);
            b = a[3].split(",");
            x4 = Double.valueOf(b[0]);
            y4 = Double.valueOf(b[1]);
            if((x1==x2&&y1==y2)||(x1==x3&&y1==y3)||(x1==x4&&y1==y4)||(x3==x2&&y3==y2)||(x4==x2&&y4==y2)||(x3==x4&&y3==y4))
            {
                System.out.println("points coincide");
                return;
            }
            if(sibian(x1,y1,x2,y2,x3,y3,x4,y4)) {
                System.out.print(tosib(x1,y1,x2,y2,x3,y3,x4,y4)+" ");
                double len = chang(x1,y1,x2,y2)+chang(x3,y3,x2,y2)+chang(x3,y3,x4,y4)+chang(x1,y1,x4,y4);
                double S = 0;
                if(tosib(x1,y1,x2,y2,x3,y3,x4,y4))
                    S = sibim(x1,y1,x2,y2,x3,y3,x4,y4);
                else {
                    double r1 = sanmian(x1,y1,x2,y2,x3,y3);
                            double r2 = sanmian(x1,y1,x3,y3,x4,y4);
                    if(sanmian(x1,y1,x2,y2,x3,y3)+sanmian(x3,y3,x4,y4,x1,y1)<sanmian(x4,y4,x2,y2,x3,y3)+sanmian(x2,y2,x4,y4,x1,y1))
                        S = sanmian(x1,y1,x2,y2,x3,y3)+sanmian(x3,y3,x4,y4,x1,y1);
                    else
                        S = sanmian(x4,y4,x2,y2,x3,y3)+sanmian(x2,y2,x4,y4,x1,y1);
                }

                System.out.printf("%.3f",len);
                System.out.println(" "+S);
            }
            else
                System.out.println("not a quadrilateral");
        }
        else if(s1.equals("4"))
        {
            if(!numme(a,4))
            {
                System.out.println("wrong number of points");
                return;
            }
            b = a[0].split(",");
            x1 = Double.valueOf(b[0]);
            y1 = Double.valueOf(b[1]);
            b = a[1].split(",");
            x2 = Double.valueOf(b[0]);
            y2 = Double.valueOf(b[1]);
            b = a[2].split(",");
            x3 = Double.valueOf(b[0]);
            y3 = Double.valueOf(b[1]);
            b = a[3].split(",");
            x4 = Double.valueOf(b[0]);
            y4 = Double.valueOf(b[1]);
            if((x1==x2&&y1==y2)||(x1==x3&&y1==y3)||(x1==x4&&y1==y4)||(x3==x2&&y3==y2)||(x4==x2&&y4==y2)||(x3==x4&&y3==y4))
            {
                System.out.println("points coincide");
                return;
            }
        }
        else if(s1.equals("5"))
        {
            if(!numme(a,4))
            {
                System.out.println("wrong number of points");
                return;
            }
            b = a[0].split(",");
            x1 = Double.valueOf(b[0]);
            y1 = Double.valueOf(b[1]);
            b = a[1].split(",");
            x2 = Double.valueOf(b[0]);
            y2 = Double.valueOf(b[1]);
            b = a[2].split(",");
            x3 = Double.valueOf(b[0]);
            y3 = Double.valueOf(b[1]);
            b = a[3].split(",");
            x4 = Double.valueOf(b[0]);
            y4 = Double.valueOf(b[1]);
            if((x1==x2&&y1==y2)||(x3==x4&&y3==y4))
            {
                System.out.println("points coincide");
                return;
            }
            if(xielv(x1,y1,x2,y2)==xielv(x3,y3,x4,y4))
            {
                System.out.println("is parallel lines,have no intersection point");
                return;
            }
            y = ((y2-y1)*(x4*y3-x3*y4)-(x2*y1-x1*y2)*(y4-y3))/((y2-y1)*(x4-x3)-(x2-x1)*(y4-y3));
            x = (y*(x2-x1)-( x2*y1-x1*y2))/(y2-y1);
            if((x==x1&&y1==y)||(x==x2&&y2==y)||(x==x3&&y3==y)||(x==x4&&y4==y))
            {
                System.out.println(x+","+y+" flase");
            }
            else
            {
                System.out.println(x+","+y+" true");
            }
        }
        else
        {
            System.out.println("Wrong Format");
            return;
        }
    }
    static double xielv(double x1,double y1,double x2,double y2)
    {

            return (y2-y1)/(x2-x1);
    }
    static boolean numme(String []s,int n)
    {
        if(s.length!=n)
            return false;
        else
            return true;
    }
    static boolean sibian(double x1,double y1,double x2,double y2,double x3,double y3,double x4,double y4) {
        if(judge(x1,y1,x2,y2,x3,y3,x4,y4)||sanjia(x1,y1,x2,y2,x3,y3,x4,y4))
            return false;
        else
            return true;
    }
    static boolean judge(double Ax1,double Ay1,double Ax2,double Ay2,double Bx1,double By1,double Bx2,double By2)
    {
        if(
           ( Math.max(Ax1,Ax2)>=Math.min(Bx1,Bx2)&&Math.min(Ax1,Ax2)<=Math.max(Bx1,Bx2) )&&  //判断x轴投影
           ( Math.max(Ay1,Ay2)>=Math.min(By1,By2)&&Math.min(Ay1,Ay2)<=Math.max(By1,By2) )    //判断y轴投影
          )
        {
            if(
                ( (Bx1-Ax1)*(Ay2-Ay1)-(By1-Ay1)*(Ax2-Ax1) ) *          //判断B是否跨过A
                ( (Bx2-Ax1)*(Ay2-Ay1)-(By2-Ay1)*(Ax2-Ax1) ) <=0 &&
                ( (Ax1-Bx1)*(By2-By1)-(Ay1-By1)*(Bx2-Bx1) ) *          //判断A是否跨过B
                ( (Ax2-Bx1)*(By2-By1)-(Ay2-By1)*(Bx2-Bx1) ) <=0
              )
            {
                return true;
            }
            else
                return false;
        }
        else
            return false;
    }
    static boolean sanjia(double x1,double y1,double x2,double y2,double x3,double y3,double x4,double y4) {
        if(san(x1,y1,x2,y2,x3,y3)||san(x4,y4,x2,y2,x3,y3)||san(x1,y1,x2,y2,x4,y4)||san(x1,y1,x4,y4,x3,y3))
            return true;
        else
            return false;
    }
    static boolean san(double x1,double y1,double x2,double y2,double x3,double y3) {
        if(panxielv(x1,y1,x2,y2)&&panxielv(x3,y3,x2,y2))
            return true;
        else if(panxielv(x1,y1,x2,y2)||panxielv(x3,y3,x2,y2))
            return false;
        else if(xielv(x1,y1,x2,y2)==xielv(x3,y3,x2,y2))
            return true;
        else
            return false;
    }
    static boolean panxielv(double x1,double y1,double x2,double y2)
    {
        if(x1==x2)
            return true;
        else
            return false;
    }
    static boolean pingxi(double x1,double y1,double x2,double y2,double x3,double y3,double x4,double y4) {
        if((panxielv(x1,y1,x2,y2)&&panxielv(x3,y3,x4,y4))||(xielv(x1,y1,x2,y2)==xielv(x3,y3,x4,y4)))
        {
            if((panxielv(x1,y1,x4,y4)&&panxielv(x2,y2,x3,y3))||(xielv(x1,y1,x4,y4)==xielv(x2,y2,x3,y3)))
                return true;
            else
                return false;
        }
        else
            return false;
    }
    static boolean lingxi(double x1,double y1,double x2,double y2,double x3,double y3,double x4,double y4) {
        if(panxielv(x1,y1,x3,y3))
        {
            if(xielv(x2,y2,x4,y4)==0)
                return true;
        }
        if(panxielv(x2,y2,x4,y4))
        {
            if(xielv(x1,y1,x3,y3)==0)
                return true;
        }
        if(xielv(x1,y1,x3,y3)*xielv(x2,y2,x4,y4)==-1)
            return true;
        return false;
    }
    static boolean juxi(double x1,double y1,double x2,double y2,double x3,double y3,double x4,double y4)
    {
        if(panxielv(x1,y1,x2,y2))
        {
            if(xielv(x2,y2,x3,y3)==0)
            {
                if(panxielv(x3,y3,x4,y4))
                {
                    if(xielv(x2,y2,x3,y3)==0)
                    return true;
                }
                if(panxielv(x2,y2,x3,y3))
                {
                    if(xielv(x3,y3,x4,y4)==0)
                    return true;

                }
                if(xielv(x3,y3,x4,y4)*xielv(x2,y2,x3,y3)==-1)
                return true;
            }
        }
        if(panxielv(x2,y2,x3,y3))
        {
            if(xielv(x1,y1,x2,y2)==0)
            {
                if(panxielv(x3,y3,x4,y4))
                {
                    if(xielv(x2,y2,x3,y3)==0)
                    return true;
                }
                if(panxielv(x2,y2,x3,y3))
                {
                    if(xielv(x3,y3,x4,y4)==0)
                    return true;
                }
                if(xielv(x3,y3,x4,y4)*xielv(x2,y2,x3,y3)==-1)
                return true;
            }

        }
        if(xielv(x1,y1,x2,y2)*xielv(x2,y2,x3,y3)==-1)
        {
            if(panxielv(x3,y3,x4,y4))
            {
                if(xielv(x2,y2,x3,y3)==0)
                return true;
            }
            if(panxielv(x2,y2,x3,y3))
            {
                if(xielv(x3,y3,x4,y4)==0)
                return true;
            }
            if(xielv(x3,y3,x4,y4)*xielv(x2,y2,x3,y3)==-1)
            return true;
        }
        return false;
    }
    static boolean zfxi(double x1,double y1,double x2,double y2,double x3,double y3,double x4,double y4)
    {
        if(lingxi(x1,y1,x2,y2,x3,y3,x4,y4)&&juxi(x1,y1,x2,y2,x3,y3,x4,y4))
            return true;
        else
            return false;
    }
    static double sanmian(double x1,double y1,double x2,double y2,double x3,double y3) {
        return Math.abs(0.5*(x1*(y2-y3)+x2*(y3-y1)+x3*(y1-y2)));
    }
    static boolean tosib(double x1,double y1,double x2,double y2,double x3,double y3,double x4,double y4) {
        double s1 = sanmian(x1,y1,x2,y2,x3,y3);
        double s2 = sanmian(x3,y3,x4,y4,x1,y1);
        double s3 = sanmian(x4,y4,x2,y2,x3,y3);
        double s4 = sanmian(x2,y2,x4,y4,x1,y1);
        if(sanmian(x1,y1,x2,y2,x3,y3)+sanmian(x3,y3,x4,y4,x1,y1)==sanmian(x4,y4,x2,y2,x3,y3)+sanmian(x2,y2,x4,y4,x1,y1))
            return true;
        else
            return false;
    }
    static double chang(double x1,double y1,double x2,double y2) {
        return Math.sqrt(Math.pow((x1-x2),2)+Math.pow((y1-y2),2));
    }
    static double sibim(double x1,double y1,double x2,double y2,double x3,double y3,double x4,double y4) {
        /*double k1 = xielv(x1,y1,x3,y3);
        double k2 = xielv(x2,y2,x4,y4);
        double s1 = Math.abs(k1-k2);
        double s2 = chang(x1,y1,x3,y3);
        double s3 = chang(x2,y2,x4,y4);
        double s4 = Math.pow((1+Math.pow(k1,2)*Math.pow(k2,2)+Math.pow(k1,2)+Math.pow(k2,2)),1/2);
        double s5 = Math.abs(k1-k2);*/

        double S = sanmian(x1,y1,x2,y2,x4,y4)+sanmian(x3,y3,x4,y4,x2,y2);
        return S;
        //1/2*chang(x1,y1,x3,y3)*chang(x2,y2,x4,y4)*Math.abs(k1-k2)/Math.pow((1+Math.pow(k1,2)*Math.pow(k2,2)+Math.pow(k1,2)+Math.pow(k2,2))
        //,1/2)
    }
}

本体我写的很混乱，因为根本没有用到类等其他方法，所以在写代码的过程中也是感觉很艰难。

7-3 设计一个银行业务类

编写一个银行业务类BankBusiness，具有以下属性和方法：
（1）公有、静态的属性：银行名称bankName，初始值为“中国银行”。
（2）私有属性：账户名name、密码password、账户余额balance。
（3）银行对用户到来的欢迎（welcome）动作（静态、公有方法），显示“中国银行欢迎您的到来！”，其中“中国银行”自动使用bankName的值。
（4）银行对用户离开的提醒（welcomeNext）动作（静态、公有方法），显示“请收好您的证件和物品，欢迎您下次光临！”
（5）带参数的构造方法，完成开户操作。需要账户名name、密码password信息，同时让账户余额为0。
（6）用户的存款（deposit）操作（公有方法，需要密码和交易额信息），密码不对时无法存款且提示“您的密码错误！”；密码正确、完成用户存款操作后，要提示用户的账户余额，例如“您的余额有1000.0元。”。
（7）用户的取款（withdraw）操作（公有方法，需要密码和交易额信息）。密码不对时无法取款且提示“您的密码错误！”；密码正确但余额不足时提示“您的余额不足！”；密码正确且余额充足时扣除交易额并提示用户的账户余额，例如“请取走钞票，您的余额还有500.0元。”。

编写一个测试类Main，在main方法中，先后执行以下操作：
（1）调用BankBusiness类的welcome()方法。
（2）接收键盘输入的用户名、密码信息作为参数，调用BankBusiness类带参数的构造方法，从而创建一个BankBusiness类的对象account。
（3）调用account的存款方法，输入正确的密码，存入若干元。密码及存款金额从键盘输入。
（4）调用account的取款方法，输入错误的密码，试图取款若干元。密码及取款金额从键盘输入。
（5）调用account的取款方法，输入正确的密码，试图取款若干元（取款金额大于余额）。密码及取款金额从键盘输入。
（6）调用account的取款方法，输入正确的密码，试图取款若干元（取款金额小于余额）。密码及取款金额从键盘输入。
（7）调用BankBusiness类的welcomeNext()方法。

输入格式:

输入开户需要的姓名、密码
输入正确密码、存款金额
输入错误密码、取款金额
输入正确密码、大于余额的取款金额
输入正确密码、小于余额的取款金额

输出格式:

中国银行（银行名称）欢迎您的到来！
您的余额有多少元。
您的密码错误！
您的余额不足！
请取走钞票，您的余额还有多少元。
请收好您的证件和物品，欢迎您下次光临！

import java.util.Scanner;

class User{
    String useName;
    String password;
    float  balance;
}

public class Main {

    public static void main(String[] args) {
        // TODO Auto-generated method stub
        Scanner input = new Scanner(System.in);
        BankBusiness.welcome();
        BankBusiness use = new BankBusiness(input.next(),input.next());


        use.deposit(input.next(), input.nextFloat());
        use.withdrawmoney(input.next(), input.nextFloat());
        use.withdrawmoney(input.next(), input.nextFloat());
        use.withdrawmoney(input.next(), input.nextFloat());

        BankBusiness.welcomeNext();

    }

}

class BankBusiness{
    public static String bankName = "中国银行";
    public static void welcome()
    {
        System.out.println(bankName+"欢迎您的到来！");
    }
    public static void welcomeNext()
    {
        System.out.println("请收好您的证件和物品，欢迎您下次光临！");
    }
    private User us = new User();
    public BankBusiness(String name,String password)
    {
        this.us.useName = name;
        this.us.password = password;
        this.us.balance = 0;
    }
    public void withdrawmoney(String password,float balance)
    {
        if(!(this.us.password.equals(password)))
        {
            System.out.println("您的密码错误！");
            return;
        }
        if(this.us.balance < balance)
        {
            System.out.println("您的余额不足！");
            return;
        }
        this.us.balance-=balance;
        System.out.println("请取走钞票，您的余额还有"+this.us.balance+"元。");
    }
    public void deposit(String password,float balance)
    {
        if(!(this.us.password.equals(password)))
        {
            System.out.println("您的密码错误！");
            return;
        }
        this.us.balance+=balance;
        System.out.println("您的余额有"+this.us.balance+"元。");
    }


}

代码较简单，但没有用到类。

7-1 点线形系列5-凸五边形的计算-1

用户输入一组选项和数据，进行与五边形有关的计算。
以下五边形顶点的坐标要求按顺序依次输入，连续输入的两个顶点是相邻顶点，第一个和最后一个输入的顶点相邻。
选项包括：
1：输入五个点坐标，判断是否是五边形，判断结果输出true/false。
2：输入五个点坐标，判断是凹五边形（false）还是凸五边形(true)，如果是凸五边形，则再输出五边形周长、面积，结果之间以一个英文空格符分隔。若五个点坐标无法构成五边形，输出"not a pentagon"
3：输入七个点坐标，前两个点构成一条直线，后五个点构成一个凸五边形、凸四边形或凸三角形，输出直线与五边形、四边形或三角形相交的交点数量。如果交点有两个，再按面积从小到大输出被直线分割成两部分的面积（不换行）。若直线与多边形形的一条边线重合，输出"The line is coincide with one of the lines"。若后五个点不符合五边形输入，若前两点重合，输出"points coincide"。

以上3选项中，若输入的点无法构成多边形，则输出"not a polygon"。输入的五个点坐标可能存在冗余，假设多边形一条边上两个端点分别是x、y，边线中间有一点z，另一顶点s：
1）符合要求的输入：顶点重复或者z与xy都相邻，如：x x y s、x z y s、x y x s、s x y y。此时去除冗余点，保留一个x、一个y。
2) 不符合要求的输入：z不与xy都相邻，如：z x y s、x z s y、x s z y

输入格式:

基本格式：选项+":"+坐标x+","+坐标y+" "+坐标x+","+坐标y。点的x、y坐标之间以英文","分隔，点与点之间以一个英文空格分隔。

输出格式:

   1 import java.util.Scanner;
   2
   3 public class Main {
   4
   5     public static void main(String[] args) {
   6
   7         Scanner in = new Scanner(System.in);
   8         input In = new input(in.nextLine());
   9         judge jud = new judge();
  10             if(!jud.Is_input(In.s))//格式检测
  11             {
  12                 System.out.println("Wrong Format");
  13                 return;
  14             }
  15         if(In.s1.equals("1"))
  16             option01(In);
  17         else if(In.s1.equals("2"))
  18             option02(In);
  19         else if(In.s1.equals("3"))
  20             option03(In);
  21         else
  22             System.out.println("Wrong Format");
  23
  24             return;
  25     }
  26     static void option01(input In) {
  27         if(!In.jud.Is_point_num(In.a, 5))//点个数检测
  28         {
  29             System.out.println("wrong number of points");
  30             return;
  31         }
  32         judge jud = new judge();
  33         pentagon pent = new pentagon();
  34         int i;
  35         //System.out.println(In.a.length);
  36
  37         for(i=0;i<5;i++)//初始化五边形
  38         {
  39             Point temp = new Point();
  40             In.b = In.a[i].split(",");
  41             temp.x = Double.valueOf(In.b[0]);
  42             temp.y = Double.valueOf(In.b[1]);
  43             pent.poin[i] = temp;
  44         }
  45         pent.Regularity_point_line();//完善五边形边信息
  46         if(!jud.polygon(pent))//是否为多边形
  47         {
  48             System.out.println("false");
  49             return;
  50         }
  51         if(!jud.Is_pentagon(pent))//是否为五边形
  52         {
  53             System.out.println("false");
  54             return;
  55         }
  56         System.out.println(jud.Is_pentagon(pent));
  57
  58     }
  59     static void option02(input In) {
  60         if(!In.jud.Is_point_num(In.a, 5))//点个数检测
  61         {
  62             System.out.println("wrong number of points");
  63             return;
  64         }
  65         judge jud = new judge();
  66         pentagon pent = new pentagon();
  67         int i;
  68
  69         for(i=0;i<5;i++)//五边形初始化
  70         {
  71             In.b = In.a[i].split(",");
  72             Point temp = new Point();
  73             temp.x = Double.valueOf(In.b[0]);
  74             temp.y = Double.valueOf(In.b[1]);
  75             pent.poin[i] = temp;
  76         }
  77         pent.Regularity_point_line();//完善边信息
  78         pent.Regularity_point_triangle();//把五边形分成三个三角形，方便计算面积
  79         if(!jud.polygon(pent))//是否为多边形
  80         {
  81             System.out.println("not a pentagon");
  82             return;
  83         }
  84         if(!jud.Is_pentagon(pent))//是否为五边形
  85         {
  86             System.out.println("not a pentagon");
  87             return;
  88         }
  89         System.out.print(jud.Is_pentagon_Convex(pent));//判断五边形的凹凸性
  90         if(jud.Is_pentagon_Convex(pent)) {//凸五边形打印周长、面积
  91             System.out.printf(" %.3f %.1f",pent.Perimeter(),pent.area());
  92         }
  93     }
  94     static void option03(input In) {
  95         if(!In.jud.Is_point_num(In.a, 7))//点数检测
  96         {
  97             System.out.println("wrong number of points");
  98             return;
  99         }
 100         int i;
 101         judge jud = new judge();
 102         pentagon pent = new pentagon();
 103         Line L = new Line();
 104
 105         for(i=0;i<2;i++) {//初始化直线
 106             In.b = In.a[i].split(",");
 107             Point pol = new Point();
 108             pol.x = Double.valueOf(In.b[0]);
 109             pol.y = Double.valueOf(In.b[1]);
 110             L.point[i] = pol;
 111         }
 112         for(i=0;i<5;i++)//初始化五边形
 113         {
 114             In.b = In.a[i+2].split(",");
 115             Point temp = new Point();
 116             temp.x = Double.valueOf(In.b[0]);
 117             temp.y = Double.valueOf(In.b[1]);
 118             pent.poin[i] = temp;
 119         }
 120         pent.Regularity_point_line();//完善边信息
 121         pent.Regularity_point_triangle();//把五边形分为三个三角形
 122         L.Regularity();//完善直线的k、b值
 123         if(!jud.polygon(pent))
 124         {
 125             System.out.println("not a pontagon");
 126             return;
 127         }//判断是否为多边形
 128
 129         if(jud.point_coincidence(L.point[0], L.point[1]))
 130         {
 131             System.out.println("points coincide");
 132             return;
 133         }//判断直线两点是否重合
 134         for(i=0;i<5;i++) {
 135             if(L.coin_line(pent.lin[i]))
 136             {
 137                 System.out.println("The line is coincide with one of the lines");
 138                 return;
 139             }
 140         }//判断直线与多边形的边是否重合
 141         if(jud.Is_pentagon(pent))//五边形
 142         {
 143             double area_pent = pent.area();
 144             double area_pent01;
 145             double area_pent02;
 146             Point[] p2 = new Point[2];
 147             System.out.print(pent.pentagon_straight_coin(L));//打印直线与五边形的交点个数
 148             if(pent.pentagon_straight_coin(L)==2) {//直线与五边形的交点数为2
 149                 p2 = pent.pentagon_straight_find(L);//五边形与直线交点坐标
 150                 if(pent.Select_through_point()==2) {//直线与五边形角的交点个数为2
 151
 152                     triangle tri = new triangle();
 153                     tri = pent.through_give_triangle02();//求直线与五边形围成的三角形
 154                     area_pent01 = tri.triangle_area();//求面积
 155                 }
 156                 else if(pent.Select_through_point()==1&&pent.Select_through_line()==1) {//直线与五边形角的交点个数为1
 157                     if(pent.pent_create_triangle02()[2]==1)//直线与五边形围成的图案有三角形
 158                     {
 159                         triangle tri = new triangle();
 160                         tri = pent.through_give_triangle01(L);//求直线与五边形围成的三角形
 161                         area_pent01 = tri.triangle_area();
 162                     }
 163                     else {//直线与五边形围成的图案没有三角形
 164                         quadrilateral qua = new quadrilateral();
 165                         qua = pent.give_quadrilateral01(L);
 166                         area_pent01 = qua.quadrilateral_area();
 167                     }
 168                 }
 169                 else {//直线与五边形角的交点个数为0
 170                     if(pent.pent_create_triangle00()[2]==1) {//直线与五边形围成的图案有三角形
 171                         triangle tri = new triangle();
 172                         tri = pent.through_give_triangle00(L);
 173                         area_pent01 = tri.triangle_area();
 174                     }
 175                     else {//直线与五边形围成的图案没有三角形
 176                         quadrilateral qua = new quadrilateral();
 177                         qua = pent.give_quadrilateral00(L);
 178                         area_pent01 = qua.quadrilateral_area();
 179                     }
 180                 }
 181                 area_pent02 = area_pent-area_pent01;
 182                 if(area_pent02>area_pent01)
 183                 System.out.println(" "+area_pent01+" "+area_pent02);
 184                 else
 185                     System.out.println(" "+area_pent02+" "+area_pent01);//求面积
 186             }
 187         }
 188         else if(jud.Is_point5_quadrilateral(pent)) {//五个点围成了一个四边形
 189             quadrilateral qua = new quadrilateral();
 190             qua = pent.pentagon_reduce_quadrilateral();
 191             qua.Regularity();
 192             qua.Regularity_point_triangle();
 193             double area_pent = qua.quadrilateral_area();
 194             double area_pent01;
 195             double area_pent02;
 196             System.out.print(qua.quadrilateral_straight_coin(L));
 197             if(qua.quadrilateral_straight_coin(L)==2) {
 198                 if(qua.Select_through_point()==2) {
 199                     triangle tri = new triangle();
 200                     tri = qua.through_give_triangle02(L);
 201                     area_pent01 = tri.triangle_area();
 202                 }
 203                 else if(qua.Select_through_point()==1) {
 204                     triangle tri = new triangle();
 205                     tri = qua.through_give_triangle01(L);
 206                     area_pent01 = tri.triangle_area();
 207                 }
 208                 else {
 209                     if(qua.quadrilateral_create_triangle00()[2]==1) {
 210                         triangle tri = new triangle();
 211                         tri = qua.through_give_triangle00(L);
 212                         area_pent01 = tri.triangle_area();
 213                     }
 214                     else {
 215                         quadrilateral qua01 = new quadrilateral();
 216                     qua01 = qua.through_give_quadrilateral(L);
 217                     area_pent01 = qua01.quadrilateral_area();
 218                     }
 219
 220                 }
 221                 area_pent02 = area_pent-area_pent01;
 222                 if(area_pent02>area_pent01)
 223                     System.out.println(" "+area_pent01+" "+area_pent02);
 224                     else
 225                         System.out.println(" "+area_pent02+" "+area_pent01);//求面积
 226             }
 227         }
 228         else if(jud.Is_point5_triangle(pent)) {
 229             triangle tri = new triangle();
 230             tri = pent.pentagon_reduce_triangle();
 231             tri.Regularity_point_line();
 232             double area_pent = tri.triangle_area();
 233             double area_pent01;
 234             double area_pent02;
 235             System.out.print(tri.triangle_straight_coin(L));
 236             if(tri.triangle_straight_coin(L)==2) {
 237                 if(tri.Select_through_point()==1) {
 238                     triangle tri01 = new triangle();
 239                     tri01 = tri.through_give_triangle01(L);
 240                     area_pent01 = tri01.triangle_area();
 241                 }
 242                 else {
 243                     triangle tri01 = new triangle();
 244                     tri01 = tri.through_give_triangle00(L);
 245                     area_pent01 = tri01.triangle_area();
 246                 }
 247                 area_pent02 = area_pent-area_pent01;
 248                 if(area_pent02>area_pent01)
 249                     System.out.println(" "+area_pent01+" "+area_pent02);
 250                     else
 251                         System.out.println(" "+area_pent02+" "+area_pent01);//求面积
 252             }
 253
 254         }
 255         /*for(i=0;i<5;i++) {
 256             if(L.straight_point_existence(pent.poin[i]))
 257             {
 258                 System.out.println("1");
 259                 return;
 260             }
 261         }*/
 262
 263     }
 264 }
 265
 266 class Point {
 267     double x;
 268     double y;
 269     int through;
 270     int flag;
 271     public Point() {
 272         flag = 0;
 273         through = 0;
 274     }
 275     public Point(double x,double y) {
 276         this.x = x;
 277         this.y = y;
 278         flag = 0;
 279         through = 0;
 280     }
 281
 282 }
 283 class Line{
 284     Point[] point = new Point[2];
 285     Point vector = new Point();
 286     double k;
 287     double b;
 288     int through;
 289     public Line() {
 290         through = 0;
 291     }
 292     public Line(Point[] poin) {
 293         through = 0;
 294         this.point = poin;
 295     }
 296
 297     public double Line_distance() {
 298         return (Math.pow((Math.pow(this.point[1].y-this.point[0].y, 2))+(Math.pow(this.point[1].x-this.point[0].x, 2)), 0.5));
 299     }
 300     public boolean Is_Line_Slope() {
 301         if(this.point[0].x==this.point[1].x)
 302             return false;
 303         else
 304             return true;
 305     }
 306     public double Line_Slope() {
 307         return ((this.point[1].y-this.point[0].y)/(this.point[1].x-this.point[0].x));
 308     }
 309     public void vector_get() {
 310         Point Ls = new Point();
 311         Ls = this.vector;
 312         Ls.x = this.point[1].x-this.point[0].x;
 313         Ls.y = this.point[1].y-this.point[0].y;
 314     }
 315     public double Crossproduct(Line l) {
 316         Point Ls = new Point();
 317         Ls = this.vector;
 318         Point le = new Point();
 319         le = l.vector;
 320         return (Ls.x*le.x+Ls.y*le.y);
 321     }
 322     public void Regularity() {
 323         if(!this.Is_Line_Slope())
 324             this.b = this.point[0].x;
 325         else {
 326             this.k = this.Line_Slope();
 327             this.b = this.point[0].y-this.k*this.point[0].x;
 328         }
 329     }
 330     public boolean coin_line(Line l) {
 331         if(!(this.Is_Line_Slope()||l.Is_Line_Slope()))
 332         {
 333             if(this.b==l.b)
 334                 return true;
 335         }
 336         else if(this.k==l.k)
 337         {
 338             if(this.b==l.b)
 339                 return true;
 340         }
 341
 342         return false;
 343     }
 344     public boolean straight_point_existence(Point p) {
 345         if(!this.Is_Line_Slope())
 346         {
 347             if(p.x==this.b)
 348                 return true;
 349         }
 350         else
 351         {
 352             if(p.y==this.k*p.x+this.b)
 353                 return true;
 354         }
 355
 356         return false;
 357     }
 358     public boolean segment_point_existence(Point p) {
 359         if(straight_point_existence(p))
 360         {
 361             if(this.k==0&&p.y==this.point[0].y)
 362                 return true;
 363
 364             if((p.y<this.point[0].y&&p.y>this.point[1].y)||(p.y>this.point[0].y&&p.y<this.point[1].y))
 365                 return true;
 366         }
 367
 368         return false;
 369     }
 370     public Point get_intersection(Line l) {
 371         Point p = new Point();
 372         if(!this.Is_Line_Slope()) {
 373             p.x = this.b;
 374             p.y = l.k*p.x+l.b;
 375         }
 376         else if(!l.Is_Line_Slope()) {
 377             p.x = l.b;
 378             p.y = this.k*p.x+this.b;
 379         }
 380         else {
 381             p.y = (this.b-l.b)/(l.k-this.k);
 382             p.x = (p.y-this.b)/this.k;
 383         }
 384
 385         return p;
 386     }
 387 }
 388
 389 class input {
 390     String s;
 391     String s1,s2;
 392     String[] a = new String[20];
 393     String[] b = new String[2];
 394
 395     public input(String s) {//输入数据处理
 396         this.s = s;
 397         this.s1 = s.substring(0, 1);
 398         this.s2 = s.substring(2);
 399         this.a = s2.split(" ");
 400     }
 401     judge jud = new judge();
 402
 403
 404 }
 405 class judge {
 406     Line l = new Line();
 407     public boolean Point3_Collinear(Line l1,Line l2) {//判断三点是否在同一直线
 408         if(!(l1.Is_Line_Slope()||l2.Is_Line_Slope()))
 409             return true;
 410         else if(!(l1.Is_Line_Slope()&&l2.Is_Line_Slope()))
 411             return false;
 412         else if(l1.Line_Slope()==l2.Line_Slope())
 413             return true;
 414         else
 415             return false;
 416     }
 417     public boolean polygon(pentagon p) {//判断是否为多边形
 418
 419             p.poin[5]=p.poin[0];
 420             for(int i=0;i<5;++i)//枚举第一条线段
 421             for(int j=i+1;j<5;++j)//枚举第二条线段
 422             {
 423                 if(j==i+1 || (j+1)%5==i )
 424                     continue;//两线段本来就相邻
 425                 if(Is_intersect_segment(p.lin[i],p.lin[j]))
 426                     return false;
 427             }
 428             return true;
 429     }
 430     public boolean Is_pentagon(pentagon p) {//判断是否为五边形
 431         //Point3_Collinear
 432         if(Is_pentagon_pointcoin(p))
 433             return false;
 434         if(!(Point3_Collinear(p.lin[0],p.lin[1])||Point3_Collinear(p.lin[1],p.lin[2])||Point3_Collinear(p.lin[2],p.lin[3])||Point3_Collinear(p.lin[3],p.lin[4])||Point3_Collinear(p.lin[4],p.lin[0])))
 435             return true;
 436         else
 437             return false;
 438     }
 439     public boolean Is_pentagon_Convex(pentagon p) {//判断是否为凸五边形
 440         int i;
 441         for(i=0;i<5;i++) {
 442             if(p.lin[i].Crossproduct(p.lin[(i+1)%5])<0)
 443                 return false;
 444         }
 445         return true;
 446     }
 447     public boolean Is_pentagon_concave(pentagon p) {//判断是否为凹五边形
 448         if(!Is_pentagon_Convex(p))
 449             return true;
 450         else
 451             return false;
 452     }
 453     public boolean Is_triangle(triangle t) {//判断是否为三角形
 454         if(!Point3_Collinear(t.lin[0], t.lin[1]))
 455             return true;
 456         else
 457             return false;
 458     }
 459     public boolean Is_quadrilateral(quadrilateral q) {//判断是否为四边形
 460         if(!(Point3_Collinear(q.lin[0],q.lin[1])||Point3_Collinear(q.lin[1],q.lin[2])||Point3_Collinear(q.lin[2],q.lin[3])||Point3_Collinear(q.lin[3],q.lin[0])))
 461             return true;
 462         else
 463             return false;
 464     }
 465     public boolean Is_input(String s) {//正则表达式判断输入字符串格式是否正确
 466         if(!s.matches("[1-5]\\:([+|-]?(0|[1-9][0-9]*)(\\.\\d+)?,[+|-]?(0|[1-9][0-9]*)(\\.\\d+)?\\ ?)+"))
 467             return false;
 468         else
 469             return true;
 470     }
 471     public boolean Is_point_num(String[] s,int n) {//判断点的个数是否正确
 472         if(s.length!=n)
 473             return false;
 474         else
 475             return true;
 476     }
 477     public boolean Is_intersect_segment(Line l1,Line l2) {//判断两线段是否相交
 478         double Ax1 = l1.point[0].x;
 479         double Ay1 = l1.point[0].y;
 480         double Ax2 = l1.point[1].x;
 481         double Ay2 = l1.point[1].y;
 482         double Bx1 = l2.point[0].x;
 483         double By1 = l2.point[0].y;
 484         double Bx2 = l2.point[1].x;
 485         double By2 = l2.point[1].y;
 486         if(
 487                ( Math.max(Ax1,Ax2)>=Math.min(Bx1,Bx2)&&Math.min(Ax1,Ax2)<=Math.max(Bx1,Bx2) )&&  //判断x轴投影
 488                ( Math.max(Ay1,Ay2)>=Math.min(By1,By2)&&Math.min(Ay1,Ay2)<=Math.max(By1,By2) )    //判断y轴投影
 489               )
 490             {
 491                 if(
 492                     ( (Bx1-Ax1)*(Ay2-Ay1)-(By1-Ay1)*(Ax2-Ax1) ) *          //判断B是否跨过A
 493                     ( (Bx2-Ax1)*(Ay2-Ay1)-(By2-Ay1)*(Ax2-Ax1) ) <=0 &&
 494                     ( (Ax1-Bx1)*(By2-By1)-(Ay1-By1)*(Bx2-Bx1) ) *          //判断A是否跨过B
 495                     ( (Ax2-Bx1)*(By2-By1)-(Ay2-By1)*(Bx2-Bx1) ) <=0
 496                   )
 497                 {
 498                     return true;
 499                 }
 500                 else
 501                     return false;
 502             }
 503             else
 504                 return false;
 505
 506
 507     }
 508     public boolean point_coincidence(Point p1,Point p2) {//判断两点是否重合
 509         if(p1.x==p2.x&&p1.y==p2.y)
 510             return true;
 511         else
 512             return false;
 513     }
 514     public boolean straight_segment_intersect(Line l1,Line l2) {//判断直线与线段是否相交
 515
 516         if(!Point3_Collinear(l1,l2))
 517             {
 518             double x1,y1;
 519             double x2,y2;
 520             double y3,y4;
 521             x1 = l2.point[0].x;
 522             x2 = l2.point[1].x;
 523             if(!l1.Is_Line_Slope())
 524             {
 525                 if((x1>l1.b&&x2<l1.b)||(x1<l1.b&&x2>l1.b))
 526                     return true;
 527             }
 528             else if(!l2.Is_Line_Slope())
 529             {
 530                 y1 = l1.k*x1+l1.b;
 531                 if((l2.point[0].y>y1&&l2.point[1].y<y1)||(l2.point[0].y<y1&&l2.point[1].y>y1))
 532                     return true;
 533             }
 534             else {
 535                 l2.k = l2.Line_Slope();
 536                 l2.b = l2.point[0].y-l2.k*l2.point[0].x;
 537                 y1 = l2.k*x1+l2.b;
 538                 y2 = l2.k*x2+l2.b;
 539                 y3 = l1.k*x1+l1.b;
 540                 y4 = l1.k*x2+l1.b;
 541                 if((y1>y3&&y2<y4)||(y1>y3&&y2<y4)||(y1<y3&&y2>y4)||(y1<y3&&y2>y4))
 542                     return true;
 543             }
 544         }
 545
 546         return false;
 547     }
 548     public boolean Is_pentagon_pointcoin(pentagon p) {//判断五边形的五个点是否有重合
 549         for(int i=0;i<5;i++) {
 550             for(int o =i+1;o<5;o++) {
 551                 if(point_coincidence(p.poin[i],p.poin[o]))
 552                     return true;
 553             }
 554         }
 555         return false;
 556     }
 557     public boolean Is_point5_quadrilateral(pentagon p) {//判断五个点是否能形成四边形
 558         int tmp=0;
 559         for(int o=0;o<5;o++) {
 560             if(this.point_coincidence(p.poin[o], p.poin[(o+1)%5])) {
 561                 tmp++;
 562                 p.poin[o].flag = 1;
 563             }
 564
 565         }
 566         if(tmp==1)
 567             return true;
 568         tmp = 0;
 569         for(int i=5;i<10;i++) {
 570             if(this.Point3_Collinear(p.lin[(i-1)%5], p.lin[i%5])) {
 571                 tmp++;
 572                 p.poin[i%5].flag = 1;
 573             }
 574
 575         }
 576         if(tmp==1)
 577             return true;
 578
 579             return false;
 580     }
 581     public boolean Is_point5_triangle(pentagon p) {//判断五个点能否形成三角形
 582         int tmp=0;
 583
 584         for(int o=0;o<5;o++) {
 585             if(this.point_coincidence(p.poin[o], p.poin[(o+1)%5])) {
 586                     tmp++;
 587             p.poin[o].flag = 1;
 588             }
 589
 590         }
 591         if(tmp==2)
 592             return true;
 593         tmp = 0;
 594         for(int i=5;i<10;i++) {
 595             if(this.Point3_Collinear(p.lin[(i-1)%5], p.lin[i%5])) {
 596                 tmp++;
 597                 p.poin[i%5].flag = 1;
 598             }
 599
 600         }
 601         if(tmp==2)
 602             return true;
 603
 604             return false;
 605     }
 606 }
 607 class pentagon extends polygon {
 608     public pentagon(){//无参构造器
 609         super();
 610     }
 611     public pentagon(Point p1,Point p2,Point p3,Point p4,Point p5) {//带参构造器
 612         super();
 613         this.poin[0] = p1;
 614         this.poin[1] = p2;
 615         this.poin[2] = p3;
 616         this.poin[3] = p4;
 617         this.poin[4] = p5;
 618     }
 619     judge jud = new judge();
 620     void Regularity_point_line() {//五边形边初始化
 621
 622         for(int i=0;i<5;i++) {
 623             Line l = new Line();
 624             Point p = new Point();
 625             l.point[0] = super.poin[i%5];
 626             l.point[1] = super.poin[(i+1)%5];
 627             super.lin[i] = l;
 628             p = super.lin[i].vector;
 629             p.x = super.poin[i%5].x-super.poin[(i+1)%5].x;
 630             p.y = super.poin[i%5].y-super.poin[(i+1)%5].y;
 631         }
 632         for(int o=0;o<5;o++) {
 633             if(!this.lin[o].Is_Line_Slope()){
 634                 this.lin[o].b = this.lin[o].point[0].x;
 635             }
 636             else {
 637                 this.lin[o].k = this.lin[o].Line_Slope();
 638                 this.lin[o].b = this.lin[o].point[0].y-this.lin[o].k*this.lin[o].point[0].x;
 639             }
 640         }
 641     }
 642     double Perimeter() {//五边形周长
 643         double sum = 0;
 644         for(int i=0;i<5;i++)
 645         {
 646             sum+=this.lin[i].Line_distance();
 647         }
 648         return sum;
 649     }
 650         triangle tri1 = new triangle();
 651         triangle tri2 = new triangle();
 652         triangle tri3 = new triangle();
 653         public void Regularity_point_triangle() {//五边形的三角形初始化
 654             this.tri1.triangle_point_give(this.poin[0], this.poin[1], this.poin[2]);
 655             this.tri2.triangle_point_give(this.poin[2], this.poin[3], this.poin[4]);
 656             this.tri3.triangle_point_give(this.poin[0], this.poin[4], this.poin[2]);
 657         }
 658         //this.poin[0],this.poin[1],this.poin[2]
 659                 //this.poin[2],this.poin[3],this.poin[4]
 660                     //    this.poin[0],this.poin[4],this.poin[2]
 661
 662     double area() {//计算五边形面积
 663         return(this.tri1.triangle_area()+this.tri2.triangle_area()+this.tri3.triangle_area());
 664     }
 665     public int pentagon_straight_coin(Line l) {//五边形与直线交点个数（未作标记）
 666         int num01 = 0;
 667         int num02 = 0;
 668         int i;
 669         for(i=0;i<5;i++) {
 670             if(l.straight_point_existence(this.poin[i])) {
 671                     num01++;
 672             this.poin[i].through = 1;
 673             }
 674
 675         }
 676         for(i=0;i<5;i++) {
 677             if(jud.straight_segment_intersect(l, this.lin[i])) {
 678                 num02++;
 679                 this.lin[i].through = 1;
 680             }
 681
 682         }
 683
 684         return num01+num02;
 685     }
 686     public Point[] pentagon_straight_find(Line l) {//寻找直线与五边形交点坐标
 687         Point[] p = new Point[2];
 688         int i;
 689         int m = 0;
 690         for(i=0;i<5;i++) {
 691             if(l.straight_point_existence(this.poin[i]))
 692             {
 693                 p[m] = this.poin[i];
 694                 this.poin[i].through = 1;
 695                 m++;
 696             }
 697         }
 698         for(i=0;i<5;i++) {
 699             if(jud.straight_segment_intersect(l, this.lin[i])) {
 700                 p[m] = l.get_intersection(this.lin[i]);
 701                 this.lin[i].through = 1;
 702                 m++;
 703             }
 704
 705         }
 706         return p;
 707     }
 708     public int Select_through_point() {//查询直线与角交点个数
 709         int sum = 0;
 710         for(int i=0;i<5;i++) {
 711             if(this.poin[i].through==1)
 712                 sum++;
 713         }
 714
 715         return sum;
 716     }
 717     public int Select_through_line() {//查询直线与边交点个数
 718         int sum = 0;
 719         for(int i=0;i<5;i++) {
 720             if(this.lin[i].through==1)
 721                 sum++;
 722         }
 723
 724         return sum;
 725     }
 726     public triangle through_give_triangle00(Line L){//与五边形的角没有交点的直线与五边形围成的三角形
 727         triangle t = new triangle();
 728         int i1 = this.pent_create_triangle00()[0];
 729         int i2 = this.pent_create_triangle00()[1];
 730         int i;
 731         if((i1==0&&i2==4)||(i1==4&&i2==0))
 732             i=0;
 733         else {
 734             i = (i1+i2+1)/2;
 735         }
 736         t.triangle_point_give(L.get_intersection(this.lin[i1]), L.get_intersection(this.lin[i2]), this.poin[i]);
 737         return t;
 738
 739     }
 740     public triangle through_give_triangle02() {//与五边形的角有两个交点的直线与五边形围成的三角形
 741         triangle t = new triangle();
 742         int m=0;
 743         double j = 0;
 744         int o;
 745         for(int i=0;i<5;i++) {
 746             if(this.poin[i].through==1) {
 747                 t.poin[m] = this.poin[i];
 748                 j+=i;
 749                 m++;
 750             }
 751
 752         }
 753         j = j/2;
 754         if(j==2.5)
 755             o = 0;
 756         else if(j==1.5)
 757             o = 4;
 758         else
 759             o = (int)j;
 760         t.poin[2] = this.poin[o];
 761         return t;
 762     }
 763     public triangle through_give_triangle01(Line L) {//与五边形的角有一个交点的直线与五边形围成的三角形
 764         triangle t = new triangle();
 765         int m = 0;
 766         int n = 0;
 767         int l;
 768         for(int i=0;i<5;i++) {
 769             if(this.poin[i].through==1)
 770                 m = i;
 771             else if(this.lin[i].through==1)
 772                 n = i;
 773         }
 774         if(n==(m+1)%5)
 775             l = n;
 776         else {
 777             l = n+1;
 778         }
 779             t.triangle_point_give(this.poin[m], this.poin[n], L.get_intersection(this.lin[l]));
 780         return t;
 781     }
 782     public int[] pent_create_triangle02() {//与五边形的角有一个交点的直线与五边形是否围成一个三角形以及交点信息
 783         int[] fb = new int[3];
 784         int i1=0;
 785         for(int i=0;i<5;i++) {
 786             if(this.poin[i].through==1)
 787             {
 788                 fb[i1]=i;
 789                 i1++;
 790             }
 791             else if(this.lin[i].through==1)
 792                 fb[1]=i;
 793         }
 794         if((fb[1]-fb[0]==2)||(fb[1]-fb[0]==-3))
 795             fb[2] = 0;
 796         else
 797             fb[2] = 1;
 798
 799         return fb;
 800     }
 801     public quadrilateral give_quadrilateral01(Line l) {//与五边形的角有一个交点的直线与五边形围成的四边形的信息
 802         quadrilateral qua = new quadrilateral();
 803         Point p = new Point();
 804         p = l.get_intersection(this.lin[this.pent_create_triangle02()[1]]);
 805         qua.poin[0] = p;
 806         for(int i=1;i<4;i++) {
 807             qua.poin[i] = this.poin[(this.pent_create_triangle02()[1]+1)%5];
 808         }
 809         return qua;
 810     }
 811     public quadrilateral give_quadrilateral00(Line l) {//与五边形的角没有交点的直线与五边形围成的四边形的信息
 812         quadrilateral qua = new quadrilateral();
 813         int i1 = this.pent_create_triangle00()[0];
 814         int i2 = this.pent_create_triangle00()[1];
 815         int o1,o2;
 816         if(Math.abs((i1+1)%5-i2)==1) {
 817             o1 = (i1+1)%5;
 818             o2 = i2;
 819         }
 820         else {
 821             o1 = i1;
 822             o2 = (i2+1)%5;
 823         }
 824         qua.quadrilateral_point_give(l.get_intersection(this.lin[i1]), this.poin[o1], this.poin[o2], l.get_intersection(this.lin[i2]));
 825         return qua;
 826     }
 827     public int[] pent_create_triangle00() {//与五边形的角没有个交点的直线与五边形是否围成一个三角形以及交点信息
 828         int[] fb = new int[3];
 829         int i1=0;
 830         for(int i=0;i<5;i++) {
 831             if(this.lin[i].through==1)
 832             {
 833                 fb[i1]=i;
 834                 i1++;
 835             }
 836         }
 837         if(Math.abs(fb[0]-fb[1])==1)
 838             fb[2] = 1;
 839         else
 840             fb[2] = 0;
 841
 842         return fb;
 843     }
 844     public quadrilateral pentagon_reduce_quadrilateral() {//五边形信息转换为四边形
 845         int m=0;
 846         quadrilateral qua = new quadrilateral();
 847         for(int i=0;i<5;i++) {
 848             if(this.poin[i].flag==0) {
 849                 qua.poin[m] = this.poin[i];
 850                 m++;
 851             }
 852
 853         }
 854
 855         return qua;
 856     }
 857     public triangle pentagon_reduce_triangle() {
 858         int m = 0;
 859         triangle tri = new triangle();
 860         for(int i=0;i<5;i++) {
 861             if(this.poin[i].flag==0) {
 862                 tri.poin[m] = this.poin[i];
 863                 m++;
 864             }
 865
 866         }
 867         return tri;
 868     }
 869 }
 870 class polygon {//多边形
 871     Point[] poin = new Point[10];
 872     Line[] lin = new Line[10];
 873     public polygon() {
 874
 875     }
 876 }
 877 class quadrilateral extends polygon{//四边形
 878     judge jud = new judge();
 879     triangle tri1 = new triangle();
 880     triangle tri2 = new triangle();
 881
 882     public void Regularity_point_triangle() {//四边形被分成两个三角形
 883         this.tri1.triangle_point_give(this.poin[0], this.poin[1], this.poin[2]);
 884         this.tri2.triangle_point_give(this.poin[2], this.poin[3], this.poin[0]);
 885     }
 886     public void quadrilateral_point_give(Point p1,Point p2,Point p3,Point p4) {//给四边形赋予信息
 887         this.poin[0] = p1;
 888         this.poin[1] = p2;
 889         this.poin[2] = p3;
 890         this.poin[3] = p4;
 891     }
 892     void Regularity() {//四边形边初始化
 893         for(int i=0;i<4;i++) {
 894             Line l = new Line();
 895             l.point[0] = super.poin[i%4];
 896             l.point[1] = super.poin[(i+1)%4];
 897             super.lin[i] = l;
 898         }
 899     }
 900     public int quadrilateral_straight_coin(Line l) {//四边形与直线交点个数
 901         int num01 = 0;
 902         int num02 = 0;
 903         int i;
 904         for(i=0;i<4;i++) {
 905             if(l.straight_point_existence(this.poin[i])) {
 906                     num01++;
 907             this.poin[i].through = 1;
 908             }
 909         }
 910         for(i=0;i<4;i++) {
 911             if(jud.straight_segment_intersect(l, this.lin[i])) {
 912                     num02++;
 913             this.lin[i].through = 1;
 914             }
 915
 916         }
 917
 918         return num01+num02;
 919     }
 920     public int Select_through_point() {//查询直线与角交点个数
 921         int sum = 0;
 922         for(int i=0;i<4;i++) {
 923             if(this.poin[i].through==1)
 924                 sum++;
 925         }
 926
 927         return sum;
 928     }
 929     public int Select_through_line() {//查询直线与边交点个数
 930         int sum = 0;
 931         for(int i=0;i<4;i++) {
 932             if(this.lin[i].through==1)
 933                 sum++;
 934         }
 935
 936         return sum;
 937     }
 938     public double quadrilateral_area() {//四边形面积
 939         return (this.tri1.triangle_area()+this.tri2.triangle_area());
 940     }
 941     public int[] quadrilateral_create_triangle02() {
 942         int[] p = new int[3];
 943         int m=0;
 944         for(int i=0;i<4;i++) {
 945             if(this.poin[i].through==1) {
 946                 p[m] = i;
 947                 m++;
 948             }
 949         }
 950         return p;
 951     }
 952     public int[] quadrilateral_create_triangle01() {
 953         int[] p = new int[3];
 954         int m=0;
 955         for(int i=0;i<4;i++) {
 956             if(this.poin[i].through==1) {
 957                 p[m] = i;
 958                 m++;
 959             }
 960             if(this.lin[i].through==1) {
 961                 p[m] = i;
 962                 p[2] = m;
 963                 m++;
 964             }
 965         }
 966         return p;
 967     }
 968     public int[] quadrilateral_create_triangle00() {
 969         int[] p = new int[3];
 970         int m=0;
 971         for(int i=0;i<4;i++) {
 972             if(this.lin[i].through==1) {
 973                 p[m] = i;
 974                 m++;
 975             }
 976         }
 977         if((p[0]+1)%4==p[1]||(p[1]+1)%4==p[0])
 978             p[2] = 1;
 979         else
 980             p[2] = 0;
 981         return p;
 982     }
 983     public triangle through_give_triangle02(Line l) {//找出直线与四边形中两个角相交的三角形
 984         triangle tri = new triangle();
 985         int i1 = this.quadrilateral_create_triangle02()[0];
 986         int i2 = this.quadrilateral_create_triangle02()[1];
 987         tri.triangle_point_give(this.poin[i1], this.poin[i2], this.poin[(i1+1)%4]);
 988         return tri;
 989     }
 990     public triangle through_give_triangle01(Line l) {//找出直线与四边形中一个角相交的三角形
 991         triangle tri = new triangle();
 992         int i1,i2,i;
 993         if(this.quadrilateral_create_triangle01()[2]==0) {
 994             i2 = this.quadrilateral_create_triangle01()[0];
 995             i1 = this.quadrilateral_create_triangle01()[1];
 996         }
 997         else {
 998             i1 = this.quadrilateral_create_triangle01()[0];
 999             i2 = this.quadrilateral_create_triangle01()[1];
1000         }
1001         Point p =new Point();
1002         p = l.get_intersection(this.lin[i2]);
1003         if((i1+1)%4==i2)
1004             i = i2;
1005         else {
1006             i = (i2+1)%4;
1007         }
1008         tri.triangle_point_give(this.poin[i1], p, this.poin[i]);
1009         return tri;
1010     }
1011     public triangle through_give_triangle00(Line l) {
1012         triangle tri = new triangle();
1013         int i1 = this.quadrilateral_create_triangle00()[0];
1014         int i2 = this.quadrilateral_create_triangle00()[1];
1015         int i;
1016         if((i1==0&&i2==3)||(i2==0&&i1==3))
1017             i=0;
1018         else if(i1>i2)
1019             i = i1;
1020         else
1021             i = i2;
1022         Point[] p = new Point[2];
1023         p[0] = l.get_intersection(this.lin[i1]);
1024         p[1] = l.get_intersection(this.lin[i2]);
1025         tri.triangle_point_give(p[0], p[1], this.poin[i]);
1026         return tri;
1027     }
1028     public quadrilateral through_give_quadrilateral(Line l) {
1029         quadrilateral qua = new quadrilateral();
1030         int i1 = this.quadrilateral_create_triangle00()[0];
1031         int i2 = this.quadrilateral_create_triangle00()[1];
1032         Point[] p = new Point[2];
1033         p[0] = l.get_intersection(this.lin[i1]);
1034         p[1] = l.get_intersection(this.lin[i2]);
1035
1036         qua.quadrilateral_point_give(p[0], this.poin[(i1+1)%4], this.poin[(i1+2)%4], p[1]);
1037         return qua;
1038     }
1039 }
1040 class triangle extends polygon{//三角形
1041     public triangle() {
1042         super();
1043     }
1044     public triangle(Point p1,Point p2,Point p3) {//构造器
1045         super();
1046         this.poin[0] = p1;
1047         this.poin[1] = p2;
1048         this.poin[2] = p3;
1049     }
1050     judge jud = new judge();
1051     public void triangle_point_give(Point p1,Point p2,Point p3) {//三角形赋予信息
1052         this.poin[0] = p1;
1053         this.poin[1] = p2;
1054         this.poin[2] = p3;
1055     }
1056     void Regularity_point_line() {//三角形边初始化
1057         for(int i=0;i<3;i++) {
1058             Line l = new Line();
1059             l.point[0] = super.poin[i%3];
1060             l.point[1] = super.poin[(i+1)%3];
1061             super.lin[i] = l;
1062         }
1063         for(int o=0;o<3;o++) {
1064             if(!this.lin[o].Is_Line_Slope()){
1065                 this.lin[o].b = this.lin[o].point[0].x;
1066             }
1067             else {
1068                 this.lin[o].k = this.lin[o].Line_Slope();
1069                 this.lin[o].b = this.lin[o].point[0].y-this.lin[o].k*this.lin[o].point[0].x;
1070             }
1071         }
1072     }
1073     public double triangle_area() {//三角形面积
1074         double r1 = this.poin[0].x*(this.poin[1].y-this.poin[2].y);
1075         double r2 = this.poin[1].x*(this.poin[2].y-this.poin[0].y);
1076         double r3 = this.poin[2].x*(this.poin[0].y-this.poin[1].y);
1077         double r = Math.abs(0.5*(r1+r2+r3));
1078         return r;
1079     }
1080     public int triangle_straight_coin(Line l) {//直线与三角形交点个数
1081         int num01 = 0;
1082         int num02 = 0;
1083         int i;
1084         for(i=0;i<3;i++) {
1085             if(l.straight_point_existence(this.poin[i])) {
1086                     num01++;
1087             this.poin[i].through = 1;
1088             }
1089
1090         }
1091         for(i=0;i<3;i++) {
1092             if(jud.straight_segment_intersect(l, this.lin[i])) {
1093                     num02++;
1094             this.lin[i].through = 1;
1095             }
1096
1097         }
1098
1099         return num01+num02;
1100     }
1101     public int Select_through_point() {//查询直线与角交点个数
1102         int sum = 0;
1103         for(int i=0;i<3;i++) {
1104             if(this.poin[i].through==1)
1105                 sum++;
1106         }
1107
1108         return sum;
1109     }
1110     public int Select_through_line() {//查询直线与边交点个数
1111         int sum = 0;
1112         for(int i=0;i<3;i++) {
1113             if(this.lin[i].through==1)
1114                 sum++;
1115         }
1116
1117         return sum;
1118     }
1119     public int[] triangle_create_triangle01() {
1120         int[] p = new int[3];
1121         int m=0;
1122         for(int i=0;i<3;i++) {
1123             if(this.poin[i].through==1) {
1124                 p[m] = i;
1125                 m++;
1126             }
1127             if(this.lin[i].through==1) {
1128                 p[m] = i;
1129                 p[2] = m;
1130                 m++;
1131             }
1132
1133         }
1134         return p;
1135     }
1136     public int[] triangle_create_triangle00() {
1137         int[] p = new int[3];
1138         int m=0;
1139         for(int i=0;i<3;i++) {
1140             if(this.lin[i].through==1) {
1141                 p[m] = i;
1142                 m++;
1143             }
1144         }
1145         return p;
1146     }
1147     public triangle through_give_triangle01(Line l) {
1148         triangle tri = new triangle();
1149         int i1,i2,i;
1150         if(this.triangle_create_triangle01()[2]==0)
1151         {
1152             i2 = this.triangle_create_triangle01()[0];
1153             i1 = this.triangle_create_triangle01()[1];
1154         }
1155         else {
1156             i1 = this.triangle_create_triangle01()[0];
1157             i2 = this.triangle_create_triangle01()[1];
1158         }
1159         i = i2;
1160         tri.triangle_point_give(this.poin[i1], l.get_intersection(this.lin[i2]), this.poin[i2]);
1161         return tri;
1162     }
1163     public triangle through_give_triangle00(Line l) {
1164         triangle tri = new triangle();
1165         int i1,i2,i;
1166         i1 = this.triangle_create_triangle00()[0];
1167         i2 = this.triangle_create_triangle00()[1];
1168         if((i1==0&&i2==2)||(i1==0&&i2==2))
1169             i=0;
1170         else if(i1>i2)
1171             i = i2;
1172         else {
1173             i = i1;
1174         }
1175         tri.triangle_point_give(this.poin[i], l.get_intersection(this.lin[i1]), l.get_intersection(this.lin[i2]));
1176         return tri;
1177     }
1178 }

本次代码题量很大，同时我也用到了类等方法，发现确实和普通面向过程相比，更加的有条理。

7-2 点线形系列5-凸五边形的计算-2

用户输入一组选项和数据，进行与五边形有关的计算。
以下五边形顶点的坐标要求按顺序依次输入，连续输入的两个顶点是相邻顶点，第一个和最后一个输入的顶点相邻。
选项包括：
4：输入十个点坐标，前、后五个点分别构成一个凸多边形（三角形、四边形、五边形），判断它们两个之间是否存在包含关系（一个多边形有一条或多条边与另一个多边形重合，其他部分都包含在另一个多边形内部，也算包含）。
两者存在六种关系：1、分离（完全无重合点） 2、连接（只有一个点或一条边重合） 3、完全重合 4、被包含（前一个多边形在后一个多边形的内部）5、交错 6、包含（后一个多边形在前一个多边形的内部）。
各种关系的输出格式如下：
1、no overlapping area between the previous triangle/quadrilateral/ pentagon and the following triangle/quadrilateral/ pentagon
2、the previous triangle/quadrilateral/ pentagon is connected to the following triangle/quadrilateral/ pentagon
3、the previous triangle/quadrilateral/ pentagon coincides with the following triangle/quadrilateral/ pentagon
4、the previous triangle/quadrilateral/ pentagon is inside the following triangle/quadrilateral/ pentagon
5、the previous triangle/quadrilateral/ pentagon is interlaced with the following triangle/quadrilateral/ pentagon
6、the previous triangle/quadrilateral/ pentagon contains the following triangle/quadrilateral/ pentagon

5：输入十个点坐标，前、后五个点分别构成一个凸多边形（三角形、四边形、五边形），输出两个多边形公共区域的面积。注：只考虑每个多边形被另一个多边形分割成最多两个部分的情况，不考虑一个多边形将另一个分割成超过两个区域的情况。
6：输入六个点坐标，输出第一个是否在后五个点所构成的多边形（限定为凸多边形，不考虑凹多边形），的内部（若是五边形输出in the pentagon/outof the pentagon，若是四边形输出in the quadrilateral/outof the quadrilateral，若是三角形输出in the triangle/outof the triangle）。输入入错存在冗余点要排除，冗余点的判定方法见选项5。如果点在多边形的某条边上，输出"on the triangle/on the quadrilateral/on the pentagon"。
以上4、5、6选项输入的五个点坐标可能存在冗余，假设多边形一条边上两个端点分别是x、y，边线中间有一点z，另一顶点s：
1）符合要求的输入：顶点重复或者z与xy都相邻，如：x x y s、x z y s、x y x s、s x y y。此时去除冗余点，保留一个x、一个y。
2) 不符合要求的输入：z不与xy都相邻，如：z x y s、x z s y、x s z y

输入格式:

基本格式：选项+":"+坐标x+","+坐标y+" "+坐标x+","+坐标y。点的x、y坐标之间以英文","分隔，点与点之间以一个英文空格分隔。

输出格式:

输出的数据若小数点后超过3位，只保留小数点后3位，多余部分采用四舍五入规则进到最低位。小数点后若不足3位，按原始位数显示，不必补齐。例如：1/3的结果按格式输出为 0.333，1.0按格式输出为1.0

   1 import java.util.Scanner;
   2
   3 public class Main {
   4
   5     public static void main(String[] args) {
   6
   7         Scanner in = new Scanner(System.in);
   8         input In = new input(in.nextLine());
   9         judge jud = new judge();
  10             if(!jud.Is_input(In.s))//格式检测
  11             {
  12                 System.out.println("Wrong Format");
  13                 return;
  14             }
  15         if(In.s1.equals("1"))
  16             option01(In);
  17         else if(In.s1.equals("2"))
  18             option02(In);
  19         else if(In.s1.equals("3"))
  20             option03(In);
  21         else if(In.s1.equals("4"))
  22             option04(In);
  23         else if(In.s1.equals("5"))
  24             option05(In);
  25         else if(In.s1.equals("6"))
  26             option06(In);
  27         else
  28             System.out.println("Wrong Format");
  29
  30             return;
  31     }
  32     static void option01(input In) {
  33         if(!In.jud.Is_point_num(In.a, 5))//点个数检测
  34         {
  35             System.out.println("wrong number of points");
  36             return;
  37         }
  38         judge jud = new judge();
  39         pentagon pent = new pentagon();
  40         int i;
  41         //System.out.println(In.a.length);
  42
  43         for(i=0;i<5;i++)//初始化五边形
  44         {
  45             Point temp = new Point();
  46             In.b = In.a[i].split(",");
  47             temp.x = Double.valueOf(In.b[0]);
  48             temp.y = Double.valueOf(In.b[1]);
  49             pent.poin[i] = temp;
  50         }
  51         pent.Regularity_point_line();//完善五边形边信息
  52         if(!jud.polygon(pent))//是否为多边形
  53         {
  54             System.out.println("false");
  55             return;
  56         }
  57         if(!jud.Is_pentagon(pent))//是否为五边形
  58         {
  59             System.out.println("false");
  60             return;
  61         }
  62         System.out.println(jud.Is_pentagon(pent));
  63
  64     }
  65     static void option02(input In) {
  66         if(!In.jud.Is_point_num(In.a, 5))//点个数检测
  67         {
  68             System.out.println("wrong number of points");
  69             return;
  70         }
  71         judge jud = new judge();
  72         pentagon pent = new pentagon();
  73         int i;
  74
  75         for(i=0;i<5;i++)//五边形初始化
  76         {
  77             In.b = In.a[i].split(",");
  78             Point temp = new Point();
  79             temp.x = Double.valueOf(In.b[0]);
  80             temp.y = Double.valueOf(In.b[1]);
  81             pent.poin[i] = temp;
  82         }
  83         pent.Regularity_point_line();//完善边信息
  84         pent.Regularity_point_triangle();//把五边形分成三个三角形，方便计算面积
  85         if(!jud.polygon(pent))//是否为多边形
  86         {
  87             System.out.println("not a pentagon");
  88             return;
  89         }
  90         if(!jud.Is_pentagon(pent))//是否为五边形
  91         {
  92             System.out.println("not a pentagon");
  93             return;
  94         }
  95         System.out.print(jud.Is_pentagon_Convex(pent));//判断五边形的凹凸性
  96         if(jud.Is_pentagon_Convex(pent)) {//凸五边形打印周长、面积
  97             System.out.printf(" %.3f %.1f",pent.Perimeter(),pent.area());
  98         }
  99     }
 100     static void option03(input In) {
 101         if(!In.jud.Is_point_num(In.a, 7))//点数检测
 102         {
 103             System.out.println("wrong number of points");
 104             return;
 105         }
 106         int i;
 107         judge jud = new judge();
 108         pentagon pent = new pentagon();
 109         Line L = new Line();
 110
 111         for(i=0;i<2;i++) {//初始化直线
 112             In.b = In.a[i].split(",");
 113             Point pol = new Point();
 114             pol.x = Double.valueOf(In.b[0]);
 115             pol.y = Double.valueOf(In.b[1]);
 116             L.point[i] = pol;
 117         }
 118         for(i=0;i<5;i++)//初始化五边形
 119         {
 120             In.b = In.a[i+2].split(",");
 121             Point temp = new Point();
 122             temp.x = Double.valueOf(In.b[0]);
 123             temp.y = Double.valueOf(In.b[1]);
 124             pent.poin[i] = temp;
 125         }
 126         pent.Regularity_point_line();//完善边信息
 127         pent.Regularity_point_triangle();//把五边形分为三个三角形
 128         L.Regularity();//完善直线的k、b值
 129         if(!jud.polygon(pent))
 130         {
 131             System.out.println("not a pontagon");
 132             return;
 133         }//判断是否为多边形
 134
 135         if(jud.point_coincidence(L.point[0], L.point[1]))
 136         {
 137             System.out.println("points coincide");
 138             return;
 139         }//判断直线两点是否重合
 140         for(i=0;i<5;i++) {
 141             if(L.coin_line(pent.lin[i]))
 142             {
 143                 System.out.println("The line is coincide with one of the lines");
 144                 return;
 145             }
 146         }//判断直线与多边形的边是否重合
 147         if(jud.Is_pentagon(pent))//五边形
 148         {
 149             double area_pent = pent.area();
 150             double area_pent01;
 151             double area_pent02;
 152             Point[] p2 = new Point[2];
 153             System.out.print(pent.pentagon_straight_coin(L));//打印直线与五边形的交点个数
 154             if(pent.pentagon_straight_coin(L)==2) {//直线与五边形的交点数为2
 155                 p2 = pent.pentagon_straight_find(L);//五边形与直线交点坐标
 156                 if(pent.Select_through_point()==2) {//直线与五边形角的交点个数为2
 157
 158                     triangle tri = new triangle();
 159                     tri = pent.through_give_triangle02();//求直线与五边形围成的三角形
 160                     area_pent01 = tri.triangle_area();//求面积
 161                 }
 162                 else if(pent.Select_through_point()==1&&pent.Select_through_line()==1) {//直线与五边形角的交点个数为1
 163                     if(pent.pent_create_triangle02()[2]==1)//直线与五边形围成的图案有三角形
 164                     {
 165                         triangle tri = new triangle();
 166                         tri = pent.through_give_triangle01(L);//求直线与五边形围成的三角形
 167                         area_pent01 = tri.triangle_area();
 168                     }
 169                     else {//直线与五边形围成的图案没有三角形
 170                         quadrilateral qua = new quadrilateral();
 171                         qua = pent.give_quadrilateral01(L);
 172                         area_pent01 = qua.quadrilateral_area();
 173                     }
 174                 }
 175                 else {//直线与五边形角的交点个数为0
 176                     if(pent.pent_create_triangle00()[2]==1) {//直线与五边形围成的图案有三角形
 177                         triangle tri = new triangle();
 178                         tri = pent.through_give_triangle00(L);
 179                         area_pent01 = tri.triangle_area();
 180                     }
 181                     else {//直线与五边形围成的图案没有三角形
 182                         quadrilateral qua = new quadrilateral();
 183                         qua = pent.give_quadrilateral00(L);
 184                         area_pent01 = qua.quadrilateral_area();
 185                     }
 186                 }
 187                 area_pent02 = area_pent-area_pent01;
 188                 if(area_pent02>area_pent01)
 189                 System.out.println(" "+area_pent01+" "+area_pent02);
 190                 else
 191                     System.out.println(" "+area_pent02+" "+area_pent01);//求面积
 192             }
 193         }
 194         else if(jud.Is_point5_quadrilateral(pent)) {//五个点围成了一个四边形
 195             quadrilateral qua = new quadrilateral();
 196             qua = pent.pentagon_reduce_quadrilateral();
 197             qua.Regularity();
 198             qua.Regularity_point_triangle();
 199             double area_pent = qua.quadrilateral_area();
 200             double area_pent01;
 201             double area_pent02;
 202             System.out.print(qua.quadrilateral_straight_coin(L));
 203             if(qua.quadrilateral_straight_coin(L)==2) {
 204                 if(qua.Select_through_point()==2) {
 205                     triangle tri = new triangle();
 206                     tri = qua.through_give_triangle02(L);
 207                     area_pent01 = tri.triangle_area();
 208                 }
 209                 else if(qua.Select_through_point()==1) {
 210                     triangle tri = new triangle();
 211                     tri = qua.through_give_triangle01(L);
 212                     area_pent01 = tri.triangle_area();
 213                 }
 214                 else {
 215                     if(qua.quadrilateral_create_triangle00()[2]==1) {
 216                         triangle tri = new triangle();
 217                         tri = qua.through_give_triangle00(L);
 218                         area_pent01 = tri.triangle_area();
 219                     }
 220                     else {
 221                         quadrilateral qua01 = new quadrilateral();
 222                     qua01 = qua.through_give_quadrilateral(L);
 223                     area_pent01 = qua01.quadrilateral_area();
 224                     }
 225
 226                 }
 227                 area_pent02 = area_pent-area_pent01;
 228                 if(area_pent02>area_pent01)
 229                     System.out.println(" "+area_pent01+" "+area_pent02);
 230                     else
 231                         System.out.println(" "+area_pent02+" "+area_pent01);//求面积
 232             }
 233         }
 234         else if(jud.Is_point5_triangle(pent)) {
 235             triangle tri = new triangle();
 236             tri = pent.pentagon_reduce_triangle();
 237             tri.Regularity_point_line();
 238             double area_pent = tri.triangle_area();
 239             double area_pent01;
 240             double area_pent02;
 241             System.out.print(tri.triangle_straight_coin(L));
 242             if(tri.triangle_straight_coin(L)==2) {
 243                 if(tri.Select_through_point()==1) {
 244                     triangle tri01 = new triangle();
 245                     tri01 = tri.through_give_triangle01(L);
 246                     area_pent01 = tri01.triangle_area();
 247                 }
 248                 else {
 249                     triangle tri01 = new triangle();
 250                     tri01 = tri.through_give_triangle00(L);
 251                     area_pent01 = tri01.triangle_area();
 252                 }
 253                 area_pent02 = area_pent-area_pent01;
 254                 if(area_pent02>area_pent01)
 255                     System.out.println(" "+area_pent01+" "+area_pent02);
 256                     else
 257                         System.out.println(" "+area_pent02+" "+area_pent01);//求面积
 258             }
 259
 260         }
 261         /*for(i=0;i<5;i++) {
 262             if(L.straight_point_existence(pent.poin[i]))
 263             {
 264                 System.out.println("1");
 265                 return;
 266             }
 267         }*/
 268
 269     }
 270     static void option04(input In) {
 271         if(!In.jud.Is_point_num(In.a, 10))//点数检测
 272         {
 273             System.out.println("wrong number of points");
 274             return;
 275         }
 276         int intpent01;
 277         int intpent02;
 278         int i;
 279         String[] pol = {"pentagon","quadrilateral","triangle"};
 280         int mag01,mag02;
 281         judge jud = new judge();
 282         pentagon pent01 = new pentagon();
 283         pentagon pent02 = new pentagon();
 284
 285         for(i=0;i<5;i++)//初始化五边形
 286         {
 287             In.b = In.a[i+2].split(",");
 288             Point temp = new Point();
 289             temp.x = Double.valueOf(In.b[0]);
 290             temp.y = Double.valueOf(In.b[1]);
 291             pent01.poin[i] = temp;
 292         }
 293         for(i=0;i<5;i++)//初始化五边形
 294         {
 295             In.b = In.a[i+2].split(",");
 296             Point temp = new Point();
 297             temp.x = Double.valueOf(In.b[0]);
 298             temp.y = Double.valueOf(In.b[1]);
 299             pent02.poin[i] = temp;
 300         }
 301         pent01.Regularity_point_line();//完善边信息
 302         pent01.Regularity_point_triangle();//把五边形分为三个三角形
 303         if(!jud.polygon(pent01))
 304         {
 305             System.out.println("not a pontagon");
 306             return;
 307         }//判断是否为多边形
 308         pent02.Regularity_point_line();//完善边信息
 309         pent02.Regularity_point_triangle();//把五边形分为三个三角形
 310         if(!jud.polygon(pent02))
 311         {
 312             System.out.println("not a pontagon");
 313             return;
 314         }//判断是否为多边形
 315         int diag = pent01.polygon_in_polygon(pent02);
 316         if(jud.Is_pentagon(pent01))
 317             intpent01 = 0;
 318         else if(jud.Is_point5_quadrilateral(pent01))
 319             intpent01 = 1;
 320         else
 321             intpent01 = 2;
 322
 323         if(jud.Is_pentagon(pent02))
 324             intpent02 = 0;
 325         else if(jud.Is_point5_quadrilateral(pent02))
 326             intpent02 = 1;
 327         else
 328             intpent02 = 2;
 329
 330         if(diag==1)
 331             System.out.println("no overlapping area between the previous "+pol[intpent01]+" and the following "+pol[intpent02]);
 332         else if(diag==2)
 333             System.out.println("the previous "+pol[intpent01]+" is connected to the following "+pol[intpent02]);
 334         else if(diag==3)
 335             System.out.println("the previous "+pol[intpent01]+" coincides with the following "+pol[intpent02]);
 336         else if(diag==4)
 337             System.out.println("the previous "+pol[intpent01]+" is inside the following "+pol[intpent02]);
 338         else if(diag==5)
 339             System.out.println("the previous "+pol[intpent01]+" is interlaced with the following "+pol[intpent02]);
 340         else if(diag==6)
 341             System.out.println("the previous "+pol[intpent01]+" contains the following "+pol[intpent02]);
 342
 343
 344     }
 345     static void option05(input In) {
 346
 347     }
 348     static void option06(input In) {
 349
 350     }
 351 }
 352
 353 class Point {
 354     double x;
 355     double y;
 356     int through;
 357     int flag;
 358     public Point() {
 359         flag = 0;
 360         through = 0;
 361     }
 362     public Point(double x,double y) {
 363         this.x = x;
 364         this.y = y;
 365         flag = 0;
 366         through = 0;
 367     }
 368
 369 }
 370 class Line{
 371     Point[] point = new Point[2];
 372     Point vector = new Point();
 373     double k;
 374     double b;
 375     int through;
 376     public Line() {
 377         through = 0;
 378     }
 379     public Line(Point[] poin) {
 380         through = 0;
 381         this.point = poin;
 382     }
 383
 384     public double Line_distance() {
 385         return (Math.pow((Math.pow(this.point[1].y-this.point[0].y, 2))+(Math.pow(this.point[1].x-this.point[0].x, 2)), 0.5));
 386     }
 387     public boolean Is_Line_Slope() {
 388         if(this.point[0].x==this.point[1].x)
 389             return false;
 390         else
 391             return true;
 392     }
 393     public double Line_Slope() {
 394         return ((this.point[1].y-this.point[0].y)/(this.point[1].x-this.point[0].x));
 395     }
 396     public void vector_get() {
 397         Point Ls = new Point();
 398         Ls = this.vector;
 399         Ls.x = this.point[1].x-this.point[0].x;
 400         Ls.y = this.point[1].y-this.point[0].y;
 401     }
 402     public double Crossproduct(Line l) {
 403         Point Ls = new Point();
 404         Ls = this.vector;
 405         Point le = new Point();
 406         le = l.vector;
 407         return (Ls.x*le.x+Ls.y*le.y);
 408     }
 409     public void Regularity() {
 410         if(!this.Is_Line_Slope())
 411             this.b = this.point[0].x;
 412         else {
 413             this.k = this.Line_Slope();
 414             this.b = this.point[0].y-this.k*this.point[0].x;
 415         }
 416     }
 417     public boolean coin_line(Line l) {
 418         if(!(this.Is_Line_Slope()||l.Is_Line_Slope()))
 419         {
 420             if(this.b==l.b)
 421                 return true;
 422         }
 423         else if(this.k==l.k)
 424         {
 425             if(this.b==l.b)
 426                 return true;
 427         }
 428
 429         return false;
 430     }
 431     public boolean straight_point_existence(Point p) {
 432         if(!this.Is_Line_Slope())
 433         {
 434             if(p.x==this.b)
 435                 return true;
 436         }
 437         else
 438         {
 439             if(p.y==this.k*p.x+this.b)
 440                 return true;
 441         }
 442
 443         return false;
 444     }
 445     public boolean segment_point_existence(Point p) {
 446         if(straight_point_existence(p))
 447         {
 448             if(this.k==0&&p.y==this.point[0].y)
 449                 return true;
 450
 451             if((p.y<this.point[0].y&&p.y>this.point[1].y)||(p.y>this.point[0].y&&p.y<this.point[1].y))
 452                 return true;
 453         }
 454
 455         return false;
 456     }
 457     public Point get_intersection(Line l) {
 458         Point p = new Point();
 459         if(!this.Is_Line_Slope()) {
 460             p.x = this.b;
 461             p.y = l.k*p.x+l.b;
 462         }
 463         else if(!l.Is_Line_Slope()) {
 464             p.x = l.b;
 465             p.y = this.k*p.x+this.b;
 466         }
 467         else {
 468             p.y = (this.b-l.b)/(l.k-this.k);
 469             p.x = (p.y-this.b)/this.k;
 470         }
 471
 472         return p;
 473     }
 474 }
 475
 476 class input {
 477     String s;
 478     String s1,s2;
 479     String[] a = new String[20];
 480     String[] b = new String[2];
 481
 482     public input(String s) {//输入数据处理
 483         this.s = s;
 484         this.s1 = s.substring(0, 1);
 485         this.s2 = s.substring(2);
 486         this.a = s2.split(" ");
 487     }
 488     judge jud = new judge();
 489
 490
 491 }
 492 class judge {
 493     Line l = new Line();
 494     public boolean Point3_Collinear(Line l1,Line l2) {//判断三点是否在同一直线
 495         if(!(l1.Is_Line_Slope()||l2.Is_Line_Slope()))
 496             return true;
 497         else if(!(l1.Is_Line_Slope()&&l2.Is_Line_Slope()))
 498             return false;
 499         else if(l1.Line_Slope()==l2.Line_Slope())
 500             return true;
 501         else
 502             return false;
 503     }
 504     public boolean polygon(pentagon p) {//判断是否为多边形
 505
 506             p.poin[5]=p.poin[0];
 507             for(int i=0;i<5;++i)//枚举第一条线段
 508             for(int j=i+1;j<5;++j)//枚举第二条线段
 509             {
 510                 if(j==i+1 || (j+1)%5==i )
 511                     continue;//两线段本来就相邻
 512                 if(Is_intersect_segment(p.lin[i],p.lin[j]))
 513                     return false;
 514             }
 515             return true;
 516     }
 517     public boolean Is_pentagon(pentagon p) {//判断是否为五边形
 518         //Point3_Collinear
 519         if(Is_pentagon_pointcoin(p))
 520             return false;
 521         if(!(Point3_Collinear(p.lin[0],p.lin[1])||Point3_Collinear(p.lin[1],p.lin[2])||Point3_Collinear(p.lin[2],p.lin[3])||Point3_Collinear(p.lin[3],p.lin[4])||Point3_Collinear(p.lin[4],p.lin[0])))
 522             return true;
 523         else
 524             return false;
 525     }
 526     public boolean Is_pentagon_Convex(pentagon p) {//判断是否为凸五边形
 527         int i;
 528         for(i=0;i<5;i++) {
 529             if(p.lin[i].Crossproduct(p.lin[(i+1)%5])<0)
 530                 return false;
 531         }
 532         return true;
 533     }
 534     public boolean Is_pentagon_concave(pentagon p) {//判断是否为凹五边形
 535         if(!Is_pentagon_Convex(p))
 536             return true;
 537         else
 538             return false;
 539     }
 540     public boolean Is_triangle(triangle t) {//判断是否为三角形
 541         if(!Point3_Collinear(t.lin[0], t.lin[1]))
 542             return true;
 543         else
 544             return false;
 545     }
 546     public boolean Is_quadrilateral(quadrilateral q) {//判断是否为四边形
 547         if(!(Point3_Collinear(q.lin[0],q.lin[1])||Point3_Collinear(q.lin[1],q.lin[2])||Point3_Collinear(q.lin[2],q.lin[3])||Point3_Collinear(q.lin[3],q.lin[0])))
 548             return true;
 549         else
 550             return false;
 551     }
 552     public boolean Is_input(String s) {//正则表达式判断输入字符串格式是否正确
 553         if(!s.matches("[1-5]\\:([+|-]?(0|[1-9][0-9]*)(\\.\\d+)?,[+|-]?(0|[1-9][0-9]*)(\\.\\d+)?\\ ?)+"))
 554             return false;
 555         else
 556             return true;
 557     }
 558     public boolean Is_point_num(String[] s,int n) {//判断点的个数是否正确
 559         if(s.length!=n)
 560             return false;
 561         else
 562             return true;
 563     }
 564     public boolean Is_intersect_segment(Line l1,Line l2) {//判断两线段是否相交
 565         double Ax1 = l1.point[0].x;
 566         double Ay1 = l1.point[0].y;
 567         double Ax2 = l1.point[1].x;
 568         double Ay2 = l1.point[1].y;
 569         double Bx1 = l2.point[0].x;
 570         double By1 = l2.point[0].y;
 571         double Bx2 = l2.point[1].x;
 572         double By2 = l2.point[1].y;
 573         if(
 574                ( Math.max(Ax1,Ax2)>=Math.min(Bx1,Bx2)&&Math.min(Ax1,Ax2)<=Math.max(Bx1,Bx2) )&&  //判断x轴投影
 575                ( Math.max(Ay1,Ay2)>=Math.min(By1,By2)&&Math.min(Ay1,Ay2)<=Math.max(By1,By2) )    //判断y轴投影
 576               )
 577             {
 578                 if(
 579                     ( (Bx1-Ax1)*(Ay2-Ay1)-(By1-Ay1)*(Ax2-Ax1) ) *          //判断B是否跨过A
 580                     ( (Bx2-Ax1)*(Ay2-Ay1)-(By2-Ay1)*(Ax2-Ax1) ) <=0 &&
 581                     ( (Ax1-Bx1)*(By2-By1)-(Ay1-By1)*(Bx2-Bx1) ) *          //判断A是否跨过B
 582                     ( (Ax2-Bx1)*(By2-By1)-(Ay2-By1)*(Bx2-Bx1) ) <=0
 583                   )
 584                 {
 585                     return true;
 586                 }
 587                 else
 588                     return false;
 589             }
 590             else
 591                 return false;
 592
 593
 594     }
 595     public boolean point_coincidence(Point p1,Point p2) {//判断两点是否重合
 596         if(p1.x==p2.x&&p1.y==p2.y)
 597             return true;
 598         else
 599             return false;
 600     }
 601     public boolean straight_segment_intersect(Line l1,Line l2) {//判断直线与线段是否相交
 602
 603         if(!Point3_Collinear(l1,l2))
 604             {
 605             double x1,y1;
 606             double x2,y2;
 607             double y3,y4;
 608             x1 = l2.point[0].x;
 609             x2 = l2.point[1].x;
 610             if(!l1.Is_Line_Slope())
 611             {
 612                 if((x1>l1.b&&x2<l1.b)||(x1<l1.b&&x2>l1.b))
 613                     return true;
 614             }
 615             else if(!l2.Is_Line_Slope())
 616             {
 617                 y1 = l1.k*x1+l1.b;
 618                 if((l2.point[0].y>y1&&l2.point[1].y<y1)||(l2.point[0].y<y1&&l2.point[1].y>y1))
 619                     return true;
 620             }
 621             else {
 622                 l2.k = l2.Line_Slope();
 623                 l2.b = l2.point[0].y-l2.k*l2.point[0].x;
 624                 y1 = l2.k*x1+l2.b;
 625                 y2 = l2.k*x2+l2.b;
 626                 y3 = l1.k*x1+l1.b;
 627                 y4 = l1.k*x2+l1.b;
 628                 if((y1>y3&&y2<y4)||(y1>y3&&y2<y4)||(y1<y3&&y2>y4)||(y1<y3&&y2>y4))
 629                     return true;
 630             }
 631         }
 632
 633         return false;
 634     }
 635     public boolean Is_pentagon_pointcoin(pentagon p) {//判断五边形的五个点是否有重合
 636         for(int i=0;i<5;i++) {
 637             for(int o =i+1;o<5;o++) {
 638                 if(point_coincidence(p.poin[i],p.poin[o]))
 639                     return true;
 640             }
 641         }
 642         return false;
 643     }
 644     public boolean Is_point5_quadrilateral(pentagon p) {//判断五个点是否能形成四边形
 645         int tmp=0;
 646         for(int o=0;o<5;o++) {
 647             if(this.point_coincidence(p.poin[o], p.poin[(o+1)%5])) {
 648                 tmp++;
 649                 p.poin[o].flag = 1;
 650             }
 651
 652         }
 653         if(tmp==1)
 654             return true;
 655         tmp = 0;
 656         for(int i=5;i<10;i++) {
 657             if(this.Point3_Collinear(p.lin[(i-1)%5], p.lin[i%5])) {
 658                 tmp++;
 659                 p.poin[i%5].flag = 1;
 660             }
 661
 662         }
 663         if(tmp==1)
 664             return true;
 665
 666             return false;
 667     }
 668     public boolean Is_point5_triangle(pentagon p) {//判断五个点能否形成三角形
 669         int tmp=0;
 670
 671         for(int o=0;o<5;o++) {
 672             if(this.point_coincidence(p.poin[o], p.poin[(o+1)%5])) {
 673                     tmp++;
 674             p.poin[o].flag = 1;
 675             }
 676
 677         }
 678         if(tmp==2)
 679             return true;
 680         tmp = 0;
 681         for(int i=5;i<10;i++) {
 682             if(this.Point3_Collinear(p.lin[(i-1)%5], p.lin[i%5])) {
 683                 tmp++;
 684                 p.poin[i%5].flag = 1;
 685             }
 686
 687         }
 688         if(tmp==2)
 689             return true;
 690
 691             return false;
 692     }
 693
 694 }
 695 class pentagon extends polygon {
 696     public pentagon(){//无参构造器
 697         super();
 698     }
 699     public pentagon(Point p1,Point p2,Point p3,Point p4,Point p5) {//带参构造器
 700         super();
 701         this.poin[0] = p1;
 702         this.poin[1] = p2;
 703         this.poin[2] = p3;
 704         this.poin[3] = p4;
 705         this.poin[4] = p5;
 706     }
 707     judge jud = new judge();
 708     void Regularity_point_line() {//五边形边初始化
 709
 710         for(int i=0;i<5;i++) {
 711             Line l = new Line();
 712             Point p = new Point();
 713             l.point[0] = super.poin[i%5];
 714             l.point[1] = super.poin[(i+1)%5];
 715             super.lin[i] = l;
 716             p = super.lin[i].vector;
 717             p.x = super.poin[i%5].x-super.poin[(i+1)%5].x;
 718             p.y = super.poin[i%5].y-super.poin[(i+1)%5].y;
 719         }
 720         for(int o=0;o<5;o++) {
 721             if(!this.lin[o].Is_Line_Slope()){
 722                 this.lin[o].b = this.lin[o].point[0].x;
 723             }
 724             else {
 725                 this.lin[o].k = this.lin[o].Line_Slope();
 726                 this.lin[o].b = this.lin[o].point[0].y-this.lin[o].k*this.lin[o].point[0].x;
 727             }
 728         }
 729     }
 730     double Perimeter() {//五边形周长
 731         double sum = 0;
 732         for(int i=0;i<5;i++)
 733         {
 734             sum+=this.lin[i].Line_distance();
 735         }
 736         return sum;
 737     }
 738         triangle tri1 = new triangle();
 739         triangle tri2 = new triangle();
 740         triangle tri3 = new triangle();
 741         public void Regularity_point_triangle() {//五边形的三角形初始化
 742             this.tri1.triangle_point_give(this.poin[0], this.poin[1], this.poin[2]);
 743             this.tri2.triangle_point_give(this.poin[2], this.poin[3], this.poin[4]);
 744             this.tri3.triangle_point_give(this.poin[0], this.poin[4], this.poin[2]);
 745         }
 746         //this.poin[0],this.poin[1],this.poin[2]
 747                 //this.poin[2],this.poin[3],this.poin[4]
 748                     //    this.poin[0],this.poin[4],this.poin[2]
 749
 750     double area() {//计算五边形面积
 751         return(this.tri1.triangle_area()+this.tri2.triangle_area()+this.tri3.triangle_area());
 752     }
 753     public int pentagon_straight_coin(Line l) {//五边形与直线交点个数（未作标记）
 754         int num01 = 0;
 755         int num02 = 0;
 756         int i;
 757         for(i=0;i<5;i++) {
 758             if(l.straight_point_existence(this.poin[i])) {
 759                     num01++;
 760             this.poin[i].through = 1;
 761             }
 762
 763         }
 764         for(i=0;i<5;i++) {
 765             if(jud.straight_segment_intersect(l, this.lin[i])) {
 766                 num02++;
 767                 this.lin[i].through = 1;
 768             }
 769
 770         }
 771
 772         return num01+num02;
 773     }
 774     public Point[] pentagon_straight_find(Line l) {//寻找直线与五边形交点坐标
 775         Point[] p = new Point[2];
 776         int i;
 777         int m = 0;
 778         for(i=0;i<5;i++) {
 779             if(l.straight_point_existence(this.poin[i]))
 780             {
 781                 p[m] = this.poin[i];
 782                 this.poin[i].through = 1;
 783                 m++;
 784             }
 785         }
 786         for(i=0;i<5;i++) {
 787             if(jud.straight_segment_intersect(l, this.lin[i])) {
 788                 p[m] = l.get_intersection(this.lin[i]);
 789                 this.lin[i].through = 1;
 790                 m++;
 791             }
 792
 793         }
 794         return p;
 795     }
 796     public int Select_through_point() {//查询直线与角交点个数
 797         int sum = 0;
 798         for(int i=0;i<5;i++) {
 799             if(this.poin[i].through==1)
 800                 sum++;
 801         }
 802
 803         return sum;
 804     }
 805     public int Select_through_line() {//查询直线与边交点个数
 806         int sum = 0;
 807         for(int i=0;i<5;i++) {
 808             if(this.lin[i].through==1)
 809                 sum++;
 810         }
 811
 812         return sum;
 813     }
 814     public triangle through_give_triangle00(Line L){//与五边形的角没有交点的直线与五边形围成的三角形
 815         triangle t = new triangle();
 816         int i1 = this.pent_create_triangle00()[0];
 817         int i2 = this.pent_create_triangle00()[1];
 818         int i;
 819         if((i1==0&&i2==4)||(i1==4&&i2==0))
 820             i=0;
 821         else {
 822             i = (i1+i2+1)/2;
 823         }
 824         t.triangle_point_give(L.get_intersection(this.lin[i1]), L.get_intersection(this.lin[i2]), this.poin[i]);
 825         return t;
 826
 827     }
 828     public triangle through_give_triangle02() {//与五边形的角有两个交点的直线与五边形围成的三角形
 829         triangle t = new triangle();
 830         int m=0;
 831         double j = 0;
 832         int o;
 833         for(int i=0;i<5;i++) {
 834             if(this.poin[i].through==1) {
 835                 t.poin[m] = this.poin[i];
 836                 j+=i;
 837                 m++;
 838             }
 839
 840         }
 841         j = j/2;
 842         if(j==2.5)
 843             o = 0;
 844         else if(j==1.5)
 845             o = 4;
 846         else
 847             o = (int)j;
 848         t.poin[2] = this.poin[o];
 849         return t;
 850     }
 851     public triangle through_give_triangle01(Line L) {//与五边形的角有一个交点的直线与五边形围成的三角形
 852         triangle t = new triangle();
 853         int m = 0;
 854         int n = 0;
 855         int l;
 856         for(int i=0;i<5;i++) {
 857             if(this.poin[i].through==1)
 858                 m = i;
 859             else if(this.lin[i].through==1)
 860                 n = i;
 861         }
 862         if(n==(m+1)%5)
 863             l = n;
 864         else {
 865             l = n+1;
 866         }
 867             t.triangle_point_give(this.poin[m], this.poin[n], L.get_intersection(this.lin[l]));
 868         return t;
 869     }
 870     public int[] pent_create_triangle02() {//与五边形的角有一个交点的直线与五边形是否围成一个三角形以及交点信息
 871         int[] fb = new int[3];
 872         int i1=0;
 873         for(int i=0;i<5;i++) {
 874             if(this.poin[i].through==1)
 875             {
 876                 fb[i1]=i;
 877                 i1++;
 878             }
 879             else if(this.lin[i].through==1)
 880                 fb[1]=i;
 881         }
 882         if((fb[1]-fb[0]==2)||(fb[1]-fb[0]==-3))
 883             fb[2] = 0;
 884         else
 885             fb[2] = 1;
 886
 887         return fb;
 888     }
 889     public quadrilateral give_quadrilateral01(Line l) {//与五边形的角有一个交点的直线与五边形围成的四边形的信息
 890         quadrilateral qua = new quadrilateral();
 891         Point p = new Point();
 892         p = l.get_intersection(this.lin[this.pent_create_triangle02()[1]]);
 893         qua.poin[0] = p;
 894         for(int i=1;i<4;i++) {
 895             qua.poin[i] = this.poin[(this.pent_create_triangle02()[1]+1)%5];
 896         }
 897         return qua;
 898     }
 899     public quadrilateral give_quadrilateral00(Line l) {//与五边形的角没有交点的直线与五边形围成的四边形的信息
 900         quadrilateral qua = new quadrilateral();
 901         int i1 = this.pent_create_triangle00()[0];
 902         int i2 = this.pent_create_triangle00()[1];
 903         int o1,o2;
 904         if(Math.abs((i1+1)%5-i2)==1) {
 905             o1 = (i1+1)%5;
 906             o2 = i2;
 907         }
 908         else {
 909             o1 = i1;
 910             o2 = (i2+1)%5;
 911         }
 912         qua.quadrilateral_point_give(l.get_intersection(this.lin[i1]), this.poin[o1], this.poin[o2], l.get_intersection(this.lin[i2]));
 913         return qua;
 914     }
 915     public int[] pent_create_triangle00() {//与五边形的角没有个交点的直线与五边形是否围成一个三角形以及交点信息
 916         int[] fb = new int[3];
 917         int i1=0;
 918         for(int i=0;i<5;i++) {
 919             if(this.lin[i].through==1)
 920             {
 921                 fb[i1]=i;
 922                 i1++;
 923             }
 924         }
 925         if(Math.abs(fb[0]-fb[1])==1)
 926             fb[2] = 1;
 927         else
 928             fb[2] = 0;
 929
 930         return fb;
 931     }
 932     public quadrilateral pentagon_reduce_quadrilateral() {//五边形信息转换为四边形
 933         int m=0;
 934         quadrilateral qua = new quadrilateral();
 935         for(int i=0;i<5;i++) {
 936             if(this.poin[i].flag==0) {
 937                 qua.poin[m] = this.poin[i];
 938                 m++;
 939             }
 940
 941         }
 942
 943         return qua;
 944     }
 945     public triangle pentagon_reduce_triangle() {
 946         int m = 0;
 947         triangle tri = new triangle();
 948         for(int i=0;i<5;i++) {
 949             if(this.poin[i].flag==0) {
 950                 tri.poin[m] = this.poin[i];
 951                 m++;
 952             }
 953
 954         }
 955         return tri;
 956     }
 957     public boolean point_in_pentagon(Point p) {
 958         double area = this.area();
 959         double areap = 0;
 960         for(int i=0;i<5;i++) {
 961             triangle tri = new triangle(p,this.poin[i],this.poin[(i+1)%5]);
 962             areap+=tri.triangle_area();
 963         }
 964         if(area==areap)
 965             return true;
 966         else
 967             return false;
 968     }
 969     public int polygon_in_polygon(pentagon p) {
 970         judge jud = new judge();
 971         int flag = 1;
 972         int n1 = 0;
 973         for(int i=0;i<5;i++) {
 974             if(this.point_in_pentagon(p.poin[i]))
 975                 n1++;
 976         }
 977         if(n1==5) {
 978             flag=6;
 979             return flag;
 980         }
 981
 982         else if(n1!=0)
 983             flag = 2;
 984
 985
 986         int n2=0;
 987         for(int i=0;i<5;i++) {
 988             if(p.point_in_pentagon(this.poin[i]))
 989                 n2++;
 990         }
 991         if(n2==5){
 992             flag=4;
 993             return flag;
 994         }
 995         else if(n2!=0)
 996             flag = 2;
 997             if(n1==0&&n2==0)
 998             {
 999                 flag=1;
1000                 return flag;
1001             }
1002
1003         for(int o=0;o<5;o++) {
1004             int l=0;
1005             for(int u=0;u<5;u++) {
1006                 if(jud.point_coincidence(this.poin[(o+u)%5], p.poin[u]))
1007                     l++;
1008             }
1009             if(l==5)
1010             {
1011                 flag=3;
1012                 return flag;
1013             }
1014         }
1015         for(int i=0;i<5;i++) {
1016             if(this.point_in_pentagon(p.poin[i])) {
1017                 int m=0;
1018                 for(int o=0;o<5;o++) {
1019                     if(this.lin[o].segment_point_existence(p.poin[i]))
1020                         m++;
1021                     if(jud.point_coincidence(this.poin[o], p.poin[i]))
1022                         m++;
1023                 }
1024                 if(m==0)
1025                 {
1026                     flag =5;
1027                     return flag;
1028                 }
1029             }
1030             if(p.point_in_pentagon(this.poin[i])) {
1031                 int m=0;
1032                 for(int o=0;o<5;o++) {
1033                     if(p.lin[o].segment_point_existence(this.poin[i]))
1034                         m++;
1035                     if(jud.point_coincidence(p.poin[o], this.poin[i]))
1036                         m++;
1037                 }
1038                 if(m==0)
1039                 {
1040                     flag =5;
1041                     return flag;
1042                 }
1043             }
1044
1045         }
1046         flag = 2;
1047         return flag;
1048     }
1049 }
1050 class polygon {//多边形
1051     Point[] poin = new Point[10];
1052     Line[] lin = new Line[10];
1053     public polygon() {
1054
1055     }
1056 }
1057 class quadrilateral extends polygon{//四边形
1058     judge jud = new judge();
1059     triangle tri1 = new triangle();
1060     triangle tri2 = new triangle();
1061
1062     public void Regularity_point_triangle() {//四边形被分成两个三角形
1063         this.tri1.triangle_point_give(this.poin[0], this.poin[1], this.poin[2]);
1064         this.tri2.triangle_point_give(this.poin[2], this.poin[3], this.poin[0]);
1065     }
1066     public void quadrilateral_point_give(Point p1,Point p2,Point p3,Point p4) {//给四边形赋予信息
1067         this.poin[0] = p1;
1068         this.poin[1] = p2;
1069         this.poin[2] = p3;
1070         this.poin[3] = p4;
1071     }
1072     void Regularity() {//四边形边初始化
1073         for(int i=0;i<4;i++) {
1074             Line l = new Line();
1075             l.point[0] = super.poin[i%4];
1076             l.point[1] = super.poin[(i+1)%4];
1077             super.lin[i] = l;
1078         }
1079     }
1080     public int quadrilateral_straight_coin(Line l) {//四边形与直线交点个数
1081         int num01 = 0;
1082         int num02 = 0;
1083         int i;
1084         for(i=0;i<4;i++) {
1085             if(l.straight_point_existence(this.poin[i])) {
1086                     num01++;
1087             this.poin[i].through = 1;
1088             }
1089         }
1090         for(i=0;i<4;i++) {
1091             if(jud.straight_segment_intersect(l, this.lin[i])) {
1092                     num02++;
1093             this.lin[i].through = 1;
1094             }
1095
1096         }
1097
1098         return num01+num02;
1099     }
1100     public int Select_through_point() {//查询直线与角交点个数
1101         int sum = 0;
1102         for(int i=0;i<4;i++) {
1103             if(this.poin[i].through==1)
1104                 sum++;
1105         }
1106
1107         return sum;
1108     }
1109     public int Select_through_line() {//查询直线与边交点个数
1110         int sum = 0;
1111         for(int i=0;i<4;i++) {
1112             if(this.lin[i].through==1)
1113                 sum++;
1114         }
1115
1116         return sum;
1117     }
1118     public double quadrilateral_area() {//四边形面积
1119         return (this.tri1.triangle_area()+this.tri2.triangle_area());
1120     }
1121     public int[] quadrilateral_create_triangle02() {
1122         int[] p = new int[3];
1123         int m=0;
1124         for(int i=0;i<4;i++) {
1125             if(this.poin[i].through==1) {
1126                 p[m] = i;
1127                 m++;
1128             }
1129         }
1130         return p;
1131     }
1132     public int[] quadrilateral_create_triangle01() {
1133         int[] p = new int[3];
1134         int m=0;
1135         for(int i=0;i<4;i++) {
1136             if(this.poin[i].through==1) {
1137                 p[m] = i;
1138                 m++;
1139             }
1140             if(this.lin[i].through==1) {
1141                 p[m] = i;
1142                 p[2] = m;
1143                 m++;
1144             }
1145         }
1146         return p;
1147     }
1148     public int[] quadrilateral_create_triangle00() {
1149         int[] p = new int[3];
1150         int m=0;
1151         for(int i=0;i<4;i++) {
1152             if(this.lin[i].through==1) {
1153                 p[m] = i;
1154                 m++;
1155             }
1156         }
1157         if((p[0]+1)%4==p[1]||(p[1]+1)%4==p[0])
1158             p[2] = 1;
1159         else
1160             p[2] = 0;
1161         return p;
1162     }
1163     public triangle through_give_triangle02(Line l) {//找出直线与四边形中两个角相交的三角形
1164         triangle tri = new triangle();
1165         int i1 = this.quadrilateral_create_triangle02()[0];
1166         int i2 = this.quadrilateral_create_triangle02()[1];
1167         tri.triangle_point_give(this.poin[i1], this.poin[i2], this.poin[(i1+1)%4]);
1168         return tri;
1169     }
1170     public triangle through_give_triangle01(Line l) {//找出直线与四边形中一个角相交的三角形
1171         triangle tri = new triangle();
1172         int i1,i2,i;
1173         if(this.quadrilateral_create_triangle01()[2]==0) {
1174             i2 = this.quadrilateral_create_triangle01()[0];
1175             i1 = this.quadrilateral_create_triangle01()[1];
1176         }
1177         else {
1178             i1 = this.quadrilateral_create_triangle01()[0];
1179             i2 = this.quadrilateral_create_triangle01()[1];
1180         }
1181         Point p =new Point();
1182         p = l.get_intersection(this.lin[i2]);
1183         if((i1+1)%4==i2)
1184             i = i2;
1185         else {
1186             i = (i2+1)%4;
1187         }
1188         tri.triangle_point_give(this.poin[i1], p, this.poin[i]);
1189         return tri;
1190     }
1191     public triangle through_give_triangle00(Line l) {
1192         triangle tri = new triangle();
1193         int i1 = this.quadrilateral_create_triangle00()[0];
1194         int i2 = this.quadrilateral_create_triangle00()[1];
1195         int i;
1196         if((i1==0&&i2==3)||(i2==0&&i1==3))
1197             i=0;
1198         else if(i1>i2)
1199             i = i1;
1200         else
1201             i = i2;
1202         Point[] p = new Point[2];
1203         p[0] = l.get_intersection(this.lin[i1]);
1204         p[1] = l.get_intersection(this.lin[i2]);
1205         tri.triangle_point_give(p[0], p[1], this.poin[i]);
1206         return tri;
1207     }
1208     public quadrilateral through_give_quadrilateral(Line l) {
1209         quadrilateral qua = new quadrilateral();
1210         int i1 = this.quadrilateral_create_triangle00()[0];
1211         int i2 = this.quadrilateral_create_triangle00()[1];
1212         Point[] p = new Point[2];
1213         p[0] = l.get_intersection(this.lin[i1]);
1214         p[1] = l.get_intersection(this.lin[i2]);
1215
1216         qua.quadrilateral_point_give(p[0], this.poin[(i1+1)%4], this.poin[(i1+2)%4], p[1]);
1217         return qua;
1218     }
1219     public boolean point_in_pentagon(Point p) {
1220         double area = this.quadrilateral_area();
1221         double areap = 0;
1222         for(int i=0;i<4;i++) {
1223             triangle tri = new triangle(p,this.poin[i],this.poin[(i+1)%5]);
1224             areap+=tri.triangle_area();
1225         }
1226         if(area==areap)
1227             return true;
1228         else
1229             return false;
1230     }
1231 }
1232 class triangle extends polygon{//三角形
1233     public triangle() {
1234         super();
1235     }
1236     public triangle(Point p1,Point p2,Point p3) {//构造器
1237         super();
1238         this.poin[0] = p1;
1239         this.poin[1] = p2;
1240         this.poin[2] = p3;
1241     }
1242     judge jud = new judge();
1243     public void triangle_point_give(Point p1,Point p2,Point p3) {//三角形赋予信息
1244         this.poin[0] = p1;
1245         this.poin[1] = p2;
1246         this.poin[2] = p3;
1247     }
1248     void Regularity_point_line() {//三角形边初始化
1249         for(int i=0;i<3;i++) {
1250             Line l = new Line();
1251             l.point[0] = super.poin[i%3];
1252             l.point[1] = super.poin[(i+1)%3];
1253             super.lin[i] = l;
1254         }
1255         for(int o=0;o<3;o++) {
1256             if(!this.lin[o].Is_Line_Slope()){
1257                 this.lin[o].b = this.lin[o].point[0].x;
1258             }
1259             else {
1260                 this.lin[o].k = this.lin[o].Line_Slope();
1261                 this.lin[o].b = this.lin[o].point[0].y-this.lin[o].k*this.lin[o].point[0].x;
1262             }
1263         }
1264     }
1265     public double triangle_area() {//三角形面积
1266         double r1 = this.poin[0].x*(this.poin[1].y-this.poin[2].y);
1267         double r2 = this.poin[1].x*(this.poin[2].y-this.poin[0].y);
1268         double r3 = this.poin[2].x*(this.poin[0].y-this.poin[1].y);
1269         double r = Math.abs(0.5*(r1+r2+r3));
1270         return r;
1271     }
1272     public int triangle_straight_coin(Line l) {//直线与三角形交点个数
1273         int num01 = 0;
1274         int num02 = 0;
1275         int i;
1276         for(i=0;i<3;i++) {
1277             if(l.straight_point_existence(this.poin[i])) {
1278                     num01++;
1279             this.poin[i].through = 1;
1280             }
1281
1282         }
1283         for(i=0;i<3;i++) {
1284             if(jud.straight_segment_intersect(l, this.lin[i])) {
1285                     num02++;
1286             this.lin[i].through = 1;
1287             }
1288
1289         }
1290
1291         return num01+num02;
1292     }
1293     public int Select_through_point() {//查询直线与角交点个数
1294         int sum = 0;
1295         for(int i=0;i<3;i++) {
1296             if(this.poin[i].through==1)
1297                 sum++;
1298         }
1299
1300         return sum;
1301     }
1302     public int Select_through_line() {//查询直线与边交点个数
1303         int sum = 0;
1304         for(int i=0;i<3;i++) {
1305             if(this.lin[i].through==1)
1306                 sum++;
1307         }
1308
1309         return sum;
1310     }
1311     public int[] triangle_create_triangle01() {
1312         int[] p = new int[3];
1313         int m=0;
1314         for(int i=0;i<3;i++) {
1315             if(this.poin[i].through==1) {
1316                 p[m] = i;
1317                 m++;
1318             }
1319             if(this.lin[i].through==1) {
1320                 p[m] = i;
1321                 p[2] = m;
1322                 m++;
1323             }
1324
1325         }
1326         return p;
1327     }
1328     public int[] triangle_create_triangle00() {
1329         int[] p = new int[3];
1330         int m=0;
1331         for(int i=0;i<3;i++) {
1332             if(this.lin[i].through==1) {
1333                 p[m] = i;
1334                 m++;
1335             }
1336         }
1337         return p;
1338     }
1339     public triangle through_give_triangle01(Line l) {
1340         triangle tri = new triangle();
1341         int i1,i2,i;
1342         if(this.triangle_create_triangle01()[2]==0)
1343         {
1344             i2 = this.triangle_create_triangle01()[0];
1345             i1 = this.triangle_create_triangle01()[1];
1346         }
1347         else {
1348             i1 = this.triangle_create_triangle01()[0];
1349             i2 = this.triangle_create_triangle01()[1];
1350         }
1351         i = i2;
1352         tri.triangle_point_give(this.poin[i1], l.get_intersection(this.lin[i2]), this.poin[i2]);
1353         return tri;
1354     }
1355     public triangle through_give_triangle00(Line l) {
1356         triangle tri = new triangle();
1357         int i1,i2,i;
1358         i1 = this.triangle_create_triangle00()[0];
1359         i2 = this.triangle_create_triangle00()[1];
1360         if((i1==0&&i2==2)||(i1==0&&i2==2))
1361             i=0;
1362         else if(i1>i2)
1363             i = i2;
1364         else {
1365             i = i1;
1366         }
1367         tri.triangle_point_give(this.poin[i], l.get_intersection(this.lin[i1]), l.get_intersection(this.lin[i2]));
1368         return tri;
1369     }
1370     public boolean point_in_pentagon(Point p) {
1371         double area = this.triangle_area();
1372         double areap = 0;
1373         for(int i=0;i<3;i++) {
1374             triangle tri = new triangle(p,this.poin[i],this.poin[(i+1)%5]);
1375             areap+=tri.triangle_area();
1376         }
1377         if(area==areap)
1378             return true;
1379         else
1380             return false;
1381     }
1382 }

本次代码同过软件的分析结果明显比以前的更加好。

7-1 点与线（类设计）

设计一个类表示平面直角坐标系上的点Point，私有属性分别为横坐标x与纵坐标y，数据类型均为实型数，除构造方法以及属性的getter与setter方法外，定义一个用于显示信息的方法display(),用来输出该坐标点的坐标信息，格式如下：(x,y)，数值保留两位小数。为简化题目，其中，坐标点的取值范围设定为(0,200]。若输入有误，系统则直接输出Wrong Format
设计一个类表示平面直角坐标系上的线Line，私有属性除了标识线段两端的点point1、point2外，还有一个字符串类型的color，用于表示该线段的颜色，同样，除构造方法以及属性的getter与setter方法外，定义一个用于计算该线段长度的方法getDistance(),还有一个用于显示信息的方法display(),用来输出线段的相关信息，输出格式如下：
```
  ```
      The line's color is:颜色值
      The line's begin point's Coordinate is:
      (x1,y1)
      The line's end point's Coordinate is:
      (x2,y2)
      The line's length is:长度值
  ```
```
其中，所有数值均保留两位小数，建议可用String.format("%.2f", data)方法。

7-2 点线面问题重构（继承与多态）

在“点与线（类设计）”题目基础上，对题目的类设计进行重构，以实现继承与多态的技术性需求。

对题目中的点Point类和线Line类进行进一步抽象，定义一个两个类的共同父类Element（抽象类），将display()方法在该方法中进行声明（抽象方法），将Point类和Line类作为该类的子类。
再定义一个Element类的子类面Plane，该类只有一个私有属性颜色color，除了构造方法和属性的getter、setter方法外，display()方法用于输出面的颜色，输出格式如下：The Plane's color is:颜色
在主方法内，定义两个Point（线段的起点和终点）对象、一个Line对象和一个Plane对象，依次从键盘输入两个Point对象的起点、终点坐标和颜色值（Line对象和Plane对象颜色相同），然后定义一个Element类的引用，分别使用该引用调用以上四个对象的display()方法，从而实现多态特性。示例代码如下：
```
      element = p1;//起点Point
      element.display();

      element = p2;//终点Point
      element.display();

      element = line;//线段
      element.display();

      element = plane;//面
      element.display();
```

7-3 点线面问题再重构（容器类）

在“点与线（继承与多态）”题目基础上，对题目的类设计进行重构，增加容器类保存点、线、面对象，并对该容器进行相应增、删、遍历操作。

在原有类设计的基础上，增加一个GeometryObject容器类，其属性为ArrayList<Element>类型的对象（若不了解泛型，可以不使用<Element>）
增加该类的add()方法及remove(int index)方法，其功能分别为向容器中增加对象及删除第index - 1（ArrayList中index>=0）个对象

在主方法中，用户循环输入要进行的操作（choice∈[0,4]），其含义如下：

1：向容器中增加Point对象
2：向容器中增加Line对象
3：向容器中增加Plane对象
4：删除容器中第index - 1个数据，若index数据非法，则无视此操作
0：输入结束

示例代码如下：

   choice = input.nextInt();
    while(choice != 0) {
        switch(choice) {
        case 1://insert Point object into list
          ...
            break;
        case 2://insert Line object into list
            ...
            break;
        case 3://insert Plane object into list
            ...
            break;
        case 4://delete index - 1 object from list
            int index = input.nextInt();
            ...
        }
        choice = input.nextInt();
    }

输入结束后，按容器中的对象顺序分别调用每个对象的display()方法进行输出。

  1 import java.util.ArrayList;
  2 import java.util.Scanner;
  3
  4 public class Main {
  5
  6     public static void main(String[] args) {
  7          Scanner input=new Scanner(System.in);
  8             int num;
  9             int index;
 10             GeometryObject g = new GeometryObject();
 11             num=input.nextInt();
 12             while(num!=0)
 13             {
 14                 switch(num)
 15                 {
 16                     case 1:{
 17                         Point p = new Point(input.nextDouble(),input.nextDouble());
 18                         g.add(p);
 19                     }
 20                     break;
 21                     case 2:{
 22                         Point p1 = new Point(input.nextDouble(),input.nextDouble());
 23                         Point p2 = new Point(input.nextDouble(),input.nextDouble());
 24                         Line l = new Line(p1,p2,input.next());
 25                         g.add(l);
 26
 27                     }
 28                     break;
 29                     case 3:
 30                     {
 31                         Plane p = new Plane(input.next());
 32                         g.add(p);
 33                     }
 34                     break;
 35                     case 4:
 36                     {
 37                         index = input.nextInt();
 38                         if(g.getList().size()>=index)
 39                             g.remove(index-1);
 40                     }
 41                 }
 42                 num = input.nextInt();
 43             }
 44             ArrayList<Element> list = g.getList();
 45             for(int i=0;i<list.size();i++)
 46             {
 47                 list.get(i).display();
 48             }
 49     }
 50
 51 }
 52 abstract class Element {
 53     public abstract void display();
 54 }
 55 class GeometryObject {
 56     private ArrayList<Element> list = new ArrayList<Element>();
 57     public GeometryObject() {
 58
 59     }
 60     public GeometryObject(ArrayList<Element> list) {
 61         this.list = list;
 62     }
 63     public void add(Element element) {
 64         list.add(element);
 65     }
 66     public void remove(int index) {
 67         list.remove(index);
 68     }
 69     public ArrayList<Element> getList(){
 70         return this.list;
 71     }
 72     public void setList(ArrayList<Element> list){
 73         this.list = list;
 74     }
 75 }
 76 class Line extends Element{
 77     private Point point1;
 78     private Point point2;
 79     String color;
 80     public Line() {
 81
 82     }
 83     public Line(Point point1,Point point2,String color) {
 84         this.point1 = point1;
 85         this.point2 = point2;
 86         this.color = color;
 87     }
 88     public Point getPoint1() {
 89         return this.point1;
 90     }
 91     public void setPoint1(Point point1) {
 92         this.point1 = point1;
 93     }
 94     public Point getPoint2() {
 95         return this.point1;
 96     }
 97     public void setPoint2(Point point2) {
 98         this.point2 = point2;
 99     }
100     public String getColor() {
101         return this.color;
102     }
103     public void setColor(String color) {
104         this.color = color;
105     }
106     public double getDistance() {
107         return Math.pow((Math.pow(point1.getY()-point2.getY(), 2)+Math.pow(point1.getX()-point2.getX(), 2)), 0.5);
108     }
109     public void display() {
110         System.out.println("The line's color is:"+color);
111         System.out.println("The line's begin point's Coordinate is:");
112         point1.display();
113         System.out.println("The line's end point's Coordinate is:");
114         point2.display();
115         System.out.println("The line's length is:"+String.format("%.2f", this.getDistance()));
116     }
117
118 }
119 class Plane extends Element{
120     private String color;
121     public Plane() {
122
123     }
124     public Plane(String color) {
125         this.color = color;
126     }
127     public String getColor() {
128         return this.color;
129     }
130     public void setColor(String color) {
131         this.color = color;
132     }
133     @Override
134     public void display() {
135         System.out.println("The Plane's color is:"+this.color);
136     }
137
138 }
139 class Point extends Element{
140     private double x;
141     private double y;
142     public Point() {
143
144     }
145     public Point(double x,double y) {
146         this.x = x;
147         this.y = y;
148         if(x<=0||x>200)
149         {
150             System.out.println("Wrong Format");
151             System.exit(1);
152         }
153         else if(y<=0||y>200) {
154             System.out.println("Wrong Format");
155             System.exit(1);
156         }
157     }
158     public double getX() {
159         return this.x;
160     }
161     public void setX(double x) {
162         this.x = x;
163     }
164     public double getY() {
165         return this.y;
166     }
167     public void setY(double y) {
168         this.y = y;
169     }
170     public void display() {
171         System.out.println("("+String.format("%.2f", this.x)+","+String.format("%.2f", this.y)+")");
172     }
173 }
