Kubernetes集群常见操作完整指南

原创岱军云云众生s 2024-02-29 00:00 山东听全文

涵盖了 Kubernetes 集群管理的各个方面，可以当作一个速查手册。

译自Comprehensive Guide to Common Operations in Kubernetes Clusters，作者 Mohamed BEN HASSINE。

1. 删除步骤

# uninstall:kubeadm reset
# Cleanup:kubeadm reset -fmodprobe -r ipiplsmodrm -rf ~/.kube/rm -rf /etc/kubernetes/rm -rf /etc/systemd/system/kubelet.service.drm -rf /etc/systemd/system/kubelet.servicerm -rf /usr/bin/kube*rm -rf /etc/cnirm -rf /opt/cnirm -rf /var/lib/etcdrm -rf /var/etcd

2. 进程列表

[root@teckbootcamps ~] ps -ef|grep kuberoot      8395 26979  0 18:03 pts/1    00:00:00 grep --color=auto kuberoot     20501     1  2 13:42 ?        00:06:50 /usr/bin/kubelet --bootstrap-kubeconfig=/etc/kubernetes/bootstrap-kubelet.conf --kubeconfig=/etc/kubernetes/kubelet.conf --pod-manifest-path=/etc/kubernetes/manifests --allow-privileged=true --network-plugin=cni --cni-conf-dir=/etc/cni/net.d --cni-bin-dir=/opt/cni/bin --cluster-dns=10.96.0.10 --cluster-domain=cluster.local --authorization-mode=Webhook --client-ca-file=/etc/kubernetes/pki/ca.crt --cadvisor-port=0 --teckbootcamps-driver=systemd --rotate-certificates=true --cert-dir=/var/lib/kubelet/pki
root     20744 20728  0 13:42 ?        00:02:26 etcd --advertise-client-urls=https://127.0.0.1:2379 --cert-file=/etc/kubernetes/pki/etcd/server.crt --client-cert-auth=true --data-dir=/var/lib/etcd --initial-advertise-peer-urls=https://127.0.0.1:2380 --initial-cluster=teckbootcamps=https://127.0.0.1:2380 --key-file=/etc/kubernetes/pki/etcd/server.key --listen-client-urls=https://127.0.0.1:2379 --listen-peer-urls=https://127.0.0.1:2380 --name=teckbootcamps --peer-cert-file=/etc/kubernetes/pki/etcd/peer.crt --peer-client-cert-auth=true --peer-key-file=/etc/kubernetes/pki/etcd/peer.key --peer-trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt --snapshot-count=10000 --trusted-ca-file=/etc/kubernetes/pki/etcd/ca.crt
root     20793 20745  1 13:42 ?        00:03:56 kube-controller-manager --address=127.0.0.1 --allocate-node-cidrs=true --cluster-cidr=192.168.0.0/16 --cluster-signing-cert-file=/etc/kubernetes/pki/ca.crt --cluster-signing-key-file=/etc/kubernetes/pki/ca.key --controllers=*,bootstrapsigner,tokencleaner --kubeconfig=/etc/kubernetes/controller-manager.conf --leader-elect=true --node-cidr-mask-size=24 --root-ca-file=/etc/kubernetes/pki/ca.crt --service-account-private-key-file=/etc/kubernetes/pki/sa.key --use-service-account-credentials=trueroot     20806 20746  1 13:42 ?        00:04:47 kube-apiserver --authorization-mode=Node,RBAC --advertise-address=172.17.211.142 --allow-privileged=true --client-ca-file=/etc/kubernetes/pki/ca.crt --disable-admission-plugins=PersistentVolumeLabel --enable-admission-plugins=NodeRestriction --enable-bootstrap-token-auth=true --etcd-cafile=/etc/kubernetes/pki/etcd/ca.crt --etcd-certfile=/etc/kubernetes/pki/apiserver-etcd-client.crt --etcd-keyfile=/etc/kubernetes/pki/apiserver-etcd-client.key --etcd-servers=https://127.0.0.1:2379 --insecure-port=0 --kubelet-client-certificate=/etc/kubernetes/pki/apiserver-kubelet-client.crt --kubelet-client-key=/etc/kubernetes/pki/apiserver-kubelet-client.key --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname --proxy-client-cert-file=/etc/kubernetes/pki/front-proxy-client.crt --proxy-client-key-file=/etc/kubernetes/pki/front-proxy-client.key --requestheader-allowed-names=front-proxy-client --requestheader-client-ca-file=/etc/kubernetes/pki/front-proxy-ca.crt --requestheader-extra-headers-prefix=X-Remote-Extra- --requestheader-group-headers=X-Remote-Group --requestheader-username-headers=X-Remote-User --secure-port=6443 --service-account-key-file=/etc/kubernetes/pki/sa.pub --service-cluster-ip-range=10.96.0.0/12 --tls-cert-file=/etc/kubernetes/pki/apiserver.crt --tls-private-key-file=/etc/kubernetes/pki/apiserver.key
root     20814 20760  0 13:42 ?        00:01:18 kube-scheduler --address=127.0.0.1 --kubeconfig=/etc/kubernetes/scheduler.conf --leader-elect=true
root     21095 21071  0 13:43 ?        00:00:22 /usr/local/bin/kube-proxy --config=/var/lib/kube-proxy/config.conf
root     22065 22047  0 13:43 ?        00:00:03 /usr/bin/kube-controllers65534    22166 22137  0 13:43 ?        00:00:12 /heapster --source=kubernetes:https://kubernetes.default --sink=influxdb:http://monitoring-influxdb.kube-system.svc:8086

3. 重启方法

[root@teckbootcamps ~]# swapoff -a && systemctl stop kubelet

4. 常用命令

1. 查看 cluster-info

[root@teckbootcamps /]kubectl cluster-infoKubernetes master is running at https://172.17.211.142:6443Heapster is running at https://172.17.211.142:6443/api/v1/namespaces/kube-system/services/heapster/proxyKubeDNS is running at https://172.17.211.142:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxymonitoring-grafana is running at https://172.17.211.142:6443/api/v1/namespaces/kube-system/services/monitoring-grafana/proxymonitoring-influxdb is running at https://172.17.211.142:6443/api/v1/namespaces/kube-system/services/monitoring-influxdb/proxyTo further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.
[root@teckbootcamps /]kubectl cluster-infoKubernetes master is running at https://172.17.211.142:6443Heapster is running at https://172.17.211.142:6443/api/v1/namespaces/kube-system/services/heapster/proxyKubeDNS is running at https://172.17.211.142:6443/api/v1/namespaces/kube-system/services/kube-dns:dns/proxymonitoring-grafana is running at https://172.17.211.142:6443/api/v1/namespaces/kube-system/services/monitoring-grafana/proxymonitoring-influxdb is running at https://172.17.211.142:6443/api/v1/namespaces/kube-system/services/monitoring-influxdb/proxyTo further debug and diagnose cluster problems, use 'kubectl cluster-info dump'.

2. 通过 cluster-info 查看 dump 信息

[root@teckbootcamps ~]kubectl cluster-info dump{"kind": "NodeList","apiVersion": "v1","metadata": {"selfLink": "/api/v1/nodes","resourceVersion": "35732"},

3. 查看 deployment

[root@teckbootcamps ~]kubectl -n kube-system get deploymentsNAME                          DESIRED   CURRENT   UP-TO-DATE   AVAILABLE   AGEcalico-kube-controllers       1         1         1            1           98dcoredns                       2         2         2            2           98dheapster                      1         1         1            1           98dheapster-teckbootcamps              1         0         0            0           1hheapster-teckbootcamps2             1         0         0            0           1hkubernetes-dashboard          1         1         1            1           98dmonitoring-grafana            1         1         1            1           98dmonitoring-grafana-teckbootcamps    1         0         0            0           1hmonitoring-influxdb           1         1         1            1           98dmonitoring-influxdb-teckbootcamps   1         0         0            0           2h

4. 删除 deployment

[root@teckbootcamps ~]kubectl -n kube-system delete deployment heapster-teckbootcamps
deployment.extensions "heapster-teckbootcamps" deleted

5. 查看 services

[root@teckbootcamps shell]kubectl -n kube-system get svc -o wideNAME                   TYPE        CLUSTER-IP       EXTERNAL-IP   PORT(S)                  AGE   SELECTORheapster               ClusterIP   10.106.70.78     <none>        80/TCP                   23h   k8s-app=heapsterkube-dns               ClusterIP   10.96.0.10       <none>        53/UDP,53/TCP,9153/TCP   23h   k8s-app=kube-dnskubelet                ClusterIP   None             <none>        10250/TCP                23h   <none>kubernetes-dashboard   NodePort    10.110.202.105   <none>        443:32000/TCP            23h   k8s-app=kubernetes-dashboardmonitoring-grafana     NodePort    10.98.68.122     <none>        80:32001/TCP             23h   k8s-app=grafanamonitoring-influxdb    ClusterIP   10.104.109.169   <none>        8086/TCP                 23h   k8s-app=influxdb

6. 查看 nodes

[root@teckbootcamps ~]kubectl get nodesNAME             STATUS   ROLES    AGE   VERSIONteckbootcamps    Ready    <none>   90d   v1.26.0teckbootcamps2   Ready    <none>   90d   v1.26.0teckbootcamps3   Ready    master   98d   v1.26.0

7. 查看 Service Account

[root@teckbootcamps3 ~]kubectl get sa --all-namespacesNAMESPACE     NAME                                 SECRETS   AGEdefault       default                              1         98dkube-public   default                              1         98dkube-system   attachdetach-controller              1         98d... (output truncated for brevity)kube-system   service-controller                   1         98dkube-system   statefulset-controller               1         98dkube-system   token-cleaner                        1         98dkube-system   ttl-controller                       1         98d

8. 查看集群 DNS Service 信息

[root@teckbootcamps /]kubectl get service -l k8s-app=kube-dns --namespace=kube-systemNAME       TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)         AGEkube-dns   ClusterIP   10.96.0.10   <none>        53/UDP,53/TCP   12d

9. 查看 cluster DNS 副本控制器

[root@teckbootcamps /]# kubectl get pod --selector k8s-app=kube-dns --namespace=kube-systemNAME                       READY     STATUS    RESTARTS   AGEcoredns-78fcdf6894-m7rgl   1/1       Running   0          3dcoredns-78fcdf6894-tpkql   1/1       Running   0          3d

10. 查看 cluster DNS 服务

[root@teckbootcamps /]kubectl get service -l k8s-app=kube-dns --namespace=kube-systemNAME       TYPE        CLUSTER-IP   EXTERNAL-IP   PORT(S)         AGEkube-dns   ClusterIP   10.96.0.10   <none>        53/UDP,53/TCP   12d

11. 查看组件

[root@teckbootcamps /] kubectl -s https://172.17.211.142:6443 get componentstatusNAME                 STATUS    MESSAGE              ERRORcontroller-manager   Healthy   okscheduler            Healthy   oketcd-0               Healthy   {"health": "true"}

12. 查看 endpoint

[root@teckbootcamps shell] kubectl get endpointsNAME         ENDPOINTS             AGEkubernetes   172.17.211.142:6443   23h

13. 查看 node 列表

[root@teckbootcamps /]kubectl -s https://172.17.211.142:6443 get nodes
NAME       STATUS    ROLES     AGE       VERSIONteckbootcamps    Ready     <none>    3d        v1.11.0teckbootcamps2   Ready     <none>    3d        v1.11.0teckbootcamps3   Ready     master    12d       v1.11.0

14. 查看 node 详情

[root@teckbootcamps shell]# kubectl get nodeNAME       STATUS   ROLES    AGE   VERSIONteckbootcamps    Ready    <none>   17m   v1.14.4teckbootcamps2   Ready    <none>   13h   v1.14.4teckbootcamps3   Ready    master   23h   v1.14.4
[root@teckbootcamps shell] kubectl describe node teckbootcamps
Name:               teckbootcampsRoles:              <none>Labels:             beta.kubernetes.io/arch=amd64beta.kubernetes.io/os=linuxkubernetes.io/arch=amd64kubernetes.io/hostname=teckbootcampskubernetes.io/os=linuxAnnotations:        kubeadm.alpha.kubernetes.io/cri-socket: /var/run/dockershim.socknode.alpha.kubernetes.io/ttl: 0projectcalico.org/IPv4Address: 172.17.211.143/20projectcalico.org/IPv4IPIPTunnelAddr: 100.67.134.64volumes.kubernetes.io/controller-managed-attach-detach: trueCreationTimestamp:  Sun, 28 Jul 2019 10:51:34 +0800Taints:             <none>Unschedulable:      falseConditions:Type                 Status  LastHeartbeatTime                 LastTransitionTime                Reason                       Message----                 ------  -----------------                 ------------------                ------                       -------NetworkUnavailable   False   Sun, 28 Jul 2019 10:51:58 +0800   Sun, 28 Jul 2019 10:51:58 +0800   CalicoIsUp                   Calico is running on this nodeMemoryPressure       False   Sun, 28 Jul 2019 11:09:15 +0800   Sun, 28 Jul 2019 10:51:33 +0800   KubeletHasSufficientMemory   kubelet has sufficient memory availableDiskPressure         False   Sun, 28 Jul 2019 11:09:15 +0800   Sun, 28 Jul 2019 10:51:33 +0800   KubeletHasNoDiskPressure     kubelet has no disk pressurePIDPressure          False   Sun, 28 Jul 2019 11:09:15 +0800   Sun, 28 Jul 2019 10:51:33 +0800   KubeletHasSufficientPID      kubelet has sufficient PID availableReady                True    Sun, 28 Jul 2019 11:09:15 +0800   Sun, 28 Jul 2019 10:52:04 +0800   KubeletReady                 kubelet is posting ready statusAddresses:InternalIP:  172.17.211.143Hostname:    teckbootcampsCapacity:cpu:                2ephemeral-storage:  41152832Kihugepages-1Gi:      0hugepages-2Mi:      0memory:             3882308Kipods:               110Allocatable:cpu:                2ephemeral-storage:  37926449909hugepages-1Gi:      0hugepages-2Mi:      0memory:             3779908Kipods:               110System Info:Machine ID:                 7d26c16f128042a684ea474c9e2c240fSystem UUID:                09D50368-65D8-41BD-A923-FBCF9B8851ABBoot ID:                    acc62473-6237-49e9-8bf8-222771e267e1Kernel Version:             3.10.0-327.28.2.el7.x86_64OS Image:                   CentOS Linux 7 (Core)Operating System:           linuxArchitecture:               amd64Container Runtime Version:  docker://18.6.1Kubelet Version:            v1.14.4Kube-Proxy Version:         v1.14.4PodCIDR:                     100.64.2.0/24Non-terminated Pods:         (4 in total)Namespace                  Name                            CPU Requests  CPU Limits  Memory Requests  Memory Limits  AGE---------                  ----                            ------------  ----------  ---------------  -------------  ---kube-system                calico-node-stc89               250m (12%)    0 (0%)      0 (0%)           0 (0%)         18mkube-system                kube-proxy-qzplb                0 (0%)        0 (0%)      0 (0%)           0 (0%)         18mkube-system                kube-sealyun-lvscare-teckbootcamps    0 (0%)        0 (0%)      0 (0%)           0 (0%)         18mmonitoring                 node-exporter-tz6ms             112m (5%)     270m (13%)  200Mi (5%)       240Mi (6%)     18mAllocated resources:(Total limits may be over 100 percent, i.e., overcommitted.)Resource           Requests    Limits--------           --------    ------cpu                362m (18%)  270m (13%)memory             200Mi (5%)  240Mi (6%)ephemeral-storage  0 (0%)      0 (0%)Events:Type     Reason                            Age                 From                 Message----     ------                            ----                ----                 -------Normal   Starting                          18m                 kubelet, teckbootcamps     Starting kubelet.Normal   NodeHasSufficientMemory           18m                 kubelet, teckbootcamps     Node teckbootcamps status is now: NodeHasSufficientMemoryNormal   NodeHasNoDiskPressure             18m                 kubelet, teckbootcamps     Node teckbootcamps status is now: NodeHasNoDiskPressureNormal   NodeHasSufficientPID              18m                 kubelet, teckbootcamps     Node teckbootcamps status is now: NodeHasSufficientPIDNormal   Starting                          18m                 kube-proxy, teckbootcamps  Starting kube-proxy.Normal   NodeReady                         17m                 kubelet, teckbootcamps     Node teckbootcamps status is now: NodeReadyWarning  ImageGCFailed                     13m                 kubelet, teckbootcamps     wanted to free 1747577241 bytes, but freed 1771511194 bytes space with errors in image deletion: [rpc error: code = Unknown desc = Error response from daemon: conflict: unable to delete abf312888d13 (must be forced) - image is being used by stopped container e5285e77b550, rpc error: code = Unknown desc = Error response from daemon: conflict: unable to remove repository reference "tutum/influxdb:0.13" (must force) - container c986b59b91ed is using its referenced image 39fa42a093e0, rpc error: code = Unknown desc = Error response from daemon: conflict: unable to remove repository reference "teckbootcamps-tomcat8-2:latest" (must force) - container ddc7e49946f1 is using its referenced image c375edce8dfd, rpc error: code = Unknown desc = Error response from daemon: conflict: unable to remove repository reference "teckbootcamps-tomcat8:latest" (must force) - container f627e4cb0dbc is using its referenced image 7e69e1b21246]Warning  FailedNodeAllocatableEnforcement  27s (x19 over 18m)  kubelet, teckbootcamps     Failed to update Node Allocatable Limits ["kubepods"]: failed to set supported teckbootcamps subsystems for teckbootcamps [kubepods]: Failed to find subsystem mount for required subsystem: pids

15. 查看系统日志

[root@teckbootcamps /] journalctl -xeu kubelet-- Logs begin at Mon 2023-02-27 10:00:20 UTC, end at Wed 2023-02-28 10:16:01 UTC. --Feb 28 10:16:01 teckbootcamps kubelet[1963]: I0228 10:16:01.517740    1963 kubelet.go:2107] syncLoop (PLEG): "kube-proxy-teckbootcamps/172.17.211.142:6443" did not receive an update for 3m45.215672686s, fallback to rate-limited syncFeb 28 10:16:01 teckbootcamps kubelet[1963]: I0228 10:16:01.517792    1963 kubelet.go:2107] syncLoop (PLEG): "weave-net-c69dt_kube-system(87511ea3-98d5-4ff6-89a2-74fd50f6d7f2)": waiting for 3m20.702903443s to syncFeb 28 10:16:01 teckbootcamps kubelet[1963]: I0228 10:16:01.517814    1963 kubelet.go:2107] syncLoop (PLEG): "coredns-78fcdf6894-m7rgl_kube-system(73649fbc-791a-4b99-a575-53a6a77d5a43)": waiting for 3m5.682036808s to sync

16. 查看 kubelet 配置信息

[root@teckbootcamps shell] kubectl config viewapiVersion: v1clusters:- cluster:    certificate-authority-data: DATA+OMITTED    server: https://172.17.211.142:6443  name: kubernetescontexts:- context:    cluster: kubernetes    user: kubernetes-admin  name: kubernetes-admin@kubernetescurrent-context: kubernetes-admin@kuberneteskind: Configpreferences: {}users:- name: kubernetes-admin  user:    client-certificate-data: REDACTED    client-key-data: REDACTED

17. 检查 Kubernetes 版本

[root@teckbootcamps kubernets]kubelet --version
Kubernetes v1.28

18. 查看配置

[root@teckbootcamps ~]kubeadm config view
apiServer:  extraArgs:    authorization-mode: Node,RBAC    timeoutForControlPlane: 4m0sapiVersion: kubeadm.k8s.io/v1beta2certificatesDir: /etc/kubernetes/pkiclusterName: kubernetesdns:  type: CoreDNSetcd:  local:    dataDir: /var/lib/etcd  imageRepository: k8s.gcr.iokind: ClusterConfigurationkubernetesVersion: v1.14.4networking:  dnsDomain: cluster.local  podSubnet: 100.64.0.0/10  serviceSubnet: 10.96.0.0/12

19. 列出需要的镜像

[root@teckbootcamps ~] kubeadm config images listW0728 10:09:45.567500   28248 version.go:98] could not fetch a Kubernetes version from the internet: unable to get URL "https://dl.k8s.io/release/stable-1.txt": Get https://dl.k8s.io/release/stable-1.txt: net/http: request canceled while waiting for connection (Client.Timeout exceeded while awaiting headers)W0728 10:09:45.567584   28248 version.go:99] falling back to the local client version: v1.15.0k8s.gcr.io/kube-apiserver:v1.15.0k8s.gcr.io/kube-controller-manager:v1.15.0k8s.gcr.io/kube-scheduler:v1.15.0k8s.gcr.io/kube-proxy:v1.15.0k8s.gcr.io/pause:3.1k8s.gcr.io/etcd:3.3.10k8s.gcr.io/coredns:1.3.1

20. 查看默认初始化参数配置

[root@teckbootcamps ~]kubeadm config print init-defaults
apiVersion: kubeadm.k8s.io/v1beta2bootstrapTokens:- groups:  - system:bootstrappers:kubeadm:default-node-token  token: abcdef.0123456789abcdef  ttl: 24h0m0s  usages:  - signing  - authenticationkind: InitConfigurationlocalAPIEndpoint:  advertiseAddress: 1.2.3.4  bindPort: 6443nodeRegistration:  criSocket: /var/run/dockershim.sock  name: teckbootcamps  taints:  - effect: NoSchedule    key: node-role.kubernetes.io/master---apiServer:  timeoutForControlPlane: 4m0sapiVersion: kubeadm.k8s.io/v1beta2certificatesDir: /etc/kubernetes/pkiclusterName: kubernetesdns:  type: CoreDNSetcd:  local:    dataDir: /var/lib/etcd  imageRepository: k8s.gcr.iokind: ClusterConfigurationkubernetesVersion: v1.14.0networking:  dnsDomain: cluster.local  serviceSubnet: 10.96.0.0/12

21. 查看 pod 日志

查看特定 pod 的日志

kubectl logs <pod_name>kubectl logs -f <pod_name>#View similar to tail -f (tail -f to view the log file in real time tail -f log file log)

查看特定 Pod 特定容器的日志

kubectl logs <pod_name> -c <container_name>PS: View Docker container logsdocker logs <container_id>

22. 查看 pod 的 YAML 文件

kubectl get pod <pod-name> -n <ns-name> -o yaml

例如：

[root@teckbootcamps shell]kubectl get pod -n kube-system kube-apiserver-teckbootcamps -o yaml
apiVersion: v1kind: Podmetadata:  annotations:    kubernetes.io/config.hash: 4c09c523e34dd307dbfa1702d7e5f326    kubernetes.io/config.mirror: 4c09c523e34dd307dbfa1702d7e5f326    kubernetes.io/config.seen: "2019-07-27T11:32:59.183084282+08:00"    kubernetes.io/config.source: file  creationTimestamp: "2019-07-27T03:34:32Z"  labels:    component: kube-apiserver    tier: control-plane  name: kube-apiserver-teckbootcamps  namespace: kube-system  resourceVersion: "41809"  selfLink: /api/v1/namespaces/kube-system/pods/kube-apiserver-teckbootcamps  uid: 72b76059-b01f-11e9-9ad8-00163e06971espec:  containers:  - command:    - kube-apiserver    - --advertise-address=172.17.211.142    - --allow-privileged=true    ...

23. 登陆到容器

登录容器时，需要关注容器支持的 shell。

kubectl exec -it <pod-name> -n <ns-name> bashkubectl exec -it <pod-name> -n <ns-name> sh[root@teckbootcamps shell] kubectl exec -it monitoring-grafana-95cbdd789-fzl49 -n kube-system /bin/sh /ls
bin         dashboards  dev         etc         home        proc        root        run.sh      sys         tmp         usr         var

登录时报错：

kubectl  OCI runtime exec failed: exec failed: container_linux.go:345: starting container process ca

, 表明shell类型不正确。

24. 根据 YAML 创建资源

# Create resources based on yaml. Apply can be executed repeatedly, but create cannot.kubectl create -f pod.yamlkubectl apply -f pod.yaml

25. 根据 YAML 删除 Pod

#  Delete a pod based on the name defined in pod.yamlkubectl delete -f pod.yaml

26. 根据标签删除pod和服务

# Delete all pods and services containing a certain labelkubectl delete pod,svc -l name=<label-name>

27. 删除 Pod

[root@teckbootcamps ~]kubectl get pods
NAME                 READY   STATUS    RESTARTS   AGEfrontend-2szjk       1/1     Running   0          3d1hfrontend-cv5qw       1/1     Running   0          3d1hfrontend-lp4tc       0/1     Evicted   0          3d2hfrontend-sccqj       1/1     Running   0          2d7hredis-master-6ssmn   1/1     Running   3          3d1hredis-slave-6vtrs    1/1     Running   1          3d2h[root@teckbootcamps ~]kubectl delete pod frontend-lp4tcpod "frontend-lp4tc" deleted
[root@teckbootcamps ~]kubectl get pods
NAME                 READY   STATUS    RESTARTS   AGEfrontend-2szjk       1/1     Running   0          3d1hfrontend-cv5qw       1/1     Running   0          3d1hfrontend-sccqj       1/1     Running   0          2d7hredis-master-6ssmn   1/1     Running   3          3d1hredis-slave-6vtrs    1/1     Running   1          3d2h

28. 检查节点或 Pod 的资源利用情况

[root@teckbootcamps ~]kubectl top nodesNAME       CPU(cores)   CPU%   MEMORY(bytes)   MEMORY%teckbootcamps    129m         6%     1567Mi          42%teckbootcamps2   233m         11%    1811Mi          49%teckbootcamps3   510m         25%    2651Mi          71%

[root@teckbootcamps3 ~]kubectl top pod
NAME                 CPU(cores)   MEMORY(bytes)frontend-2szjk       0m           16Mifrontend-cv5qw       0m           16Mifrontend-sccqj       0m           21Miredis-master-6ssmn   0m           1Miredis-slave-6vtrs    1m           8Mi

29. 编辑 Pod 的 yaml 文件

#Edit pod’s yaml filekubectl get deployment -n <ns-name>
kubectl edit depolyment <pod-name> -n <ns-name> -o yaml以下示例:[root@teckbootcamps shell] kubectl get deployment -n kube-system
NAME                      READY   UP-TO-DATE   AVAILABLE   AGEcalico-kube-controllers   1/1     1            1           23hcoredns                   2/2     2            2           23hheapster                  1/1     1            1           23hkubernetes-dashboard      1/1     1            1           23hmonitoring-grafana        1/1     1            1           23hmonitoring-influxdb       1/1     1            1           23h[root@teckbootcamps shell]kubectl edit deployment monitoring-grafana -n kube-system -o yaml

30. 进入 POD

[root@teckbootcamps data]kubectl exec -it monitoring-grafana-95cbdd789-fzl49 sh -n kube-system /lsbin         dashboards  dev         etc         home        proc        root        run.sh      sys         tmp         usr         var

5. 配置文件目录

[root@teckbootcamps kubernetes]pwd/etc/kubernetes
[root@teckbootcamps kubernetes] tree -h.├── [5.3K]  admin.conf├── [5.4K]  controller-manager.conf├── [5.3K]  kubelet.conf├── [4.0K]  manifests│   ├── [1.9K]  etcd.yaml│   ├── [2.5K]  kube-apiserver.yaml│   ├── [2.2K]  kube-controller-manager.yaml│   └── [ 990]  kube-scheduler.yaml├── [4.0K]  pki│   ├── [1.2K]  apiserver.crt│   ├── [1.1K]  apiserver-etcd-client.crt│   ├── [1.6K]  apiserver-etcd-client.key│   ├── [1.6K]  apiserver.key│   ├── [1.1K]  apiserver-kubelet-client.crt│   ├── [1.6K]  apiserver-kubelet-client.key│   ├── [1.0K]  ca.crt│   ├── [1.6K]  ca.key│   ├── [4.0K]  etcd│   │   ├── [1021]  ca.crt│   │   ├── [1.6K]  ca.key│   │   ├── [1.1K]  healthcheck-client.crt│   │   ├── [1.6K]  healthcheck-client.key│   │   ├── [1.1K]  peer.crt│   │   ├── [1.6K]  peer.key│   │   ├── [1.1K]  server.crt│   │   └── [1.6K]  server.key│   ├── [1.0K]  front-proxy-ca.crt│   ├── [1.6K]  front-proxy-ca.key│   ├── [1.0K]  front-proxy-client.crt│   ├── [1.6K]  front-proxy-client.key│   ├── [1.6K]  sa.key│   └── [ 451]  sa.pub└── [5.3K]  scheduler.conf3 directories, 30 files

6. 配置 SSL

1. 生成 SSL

1.1. CA 颁发证书的过程如下：

Zees-Air-2:ssl Zee$ openssl genrsa -des3 -passout pass:x -out dashboard.pass.key 2048Generating RSA private key, 2048 bit long modulus.....+++........................+++e is 65537 (0x10001)Zees-Air-2:ssl Zee$ lltotal 32-rw-r--r--  1 Zee  staff  1751 Nov 22 09:23 dashboard.pass.keyZees-Air-2:ssl Zee$ openssl rsa -passin pass:x -in dashboard.pass.key -out dashboard.keywriting RSA keyZees-Air-2:ssl Zee$ lltotal 40-rw-r--r--  1 Zee  staff  1751 Nov 22 09:23 dashboard.pass.key-rw-r--r--  1 Zee  staff  1679 Nov 22 09:23 dashboard.keyZees-Air-2:ssl Zee$ openssl req -new -key dashboard.key -out dashboard.csrYou are about to be asked to enter information that will be incorporatedinto your certificate request.What you are about to enter is what is called a Distinguished Name or a DN.There are quite a few fields but you can leave some blankFor some fields there will be a default value,If you enter '.', the field will be left blank.-----Country Name (2 letter code) [AU]:CNState or Province Name (full name) [Some-State]:BeiJingLocality Name (eg, city) []:BeiJingOrganization Name (eg, company) [Internet Widgits Pty Ltd]:teckbootcampsOrganizational Unit Name (eg, section) []:teckbootcampsCommon Name (e.g. server FQDN or YOUR name) []:teckbootcamps.comEmail Address []:Please enter the following 'extra' attributesto be sent with your certificate requestA challenge password []:An optional company name []:Zees-Air-2:ssl Zee$ lltotal 48-rw-r--r--  1 Zee  staff  1751 Nov 22 09:23 dashboard.pass.key-rw-r--r--  1 Zee  staff  1679 Nov 22 09:23 dashboard.key-rw-r--r--  1 Zee  staff  1009 Nov 22 09:24 dashboard.csrZees-Air-2:ssl Zee$ openssl x509 -req -sha256 -days 365 -in dashboard.csr -signkey dashboard.key -out dashboard.crtSignature oksubject=/C=CN/ST=BeiJing/L=BeiJing/O=teckbootcamps/OU=teckbootcamps/CN=teckbootcamps.comGetting Private key
Zees-Air-2:ssl Zee$ lltotal 56-rw-r--r--  1 Zee  staff  1751 Nov 22 09:23 dashboard.pass.key-rw-r--r--  1 Zee  staff  1679 Nov 22 09:23 dashboard.key-rw-r--r--  1 Zee  staff  1009 Nov 22 09:24 dashboard.csr-rw-r--r--  1 Zee  staff  1212 Nov 22 09:25 dashboard.crtZees-Air-2:ssl Zee$ openssl x509 -in dashboard.crt -out dashboard.pem
Zees-Air-2:ssl Zee$ lltotal 72-rw-r--r--  1 Zee  staff  1751 Nov 22 09:23 dashboard.pass.key-rw-r--r--  1 Zee  staff  1679 Nov 22 09:23 dashboard.key-rw-r--r--  1 Zee  staff  1009 Nov 22 09:24 dashboard.csr-rw-r--r--  1 Zee  staff  1212 Nov 22 09:25 dashboard.crt-rw-r--r--  1 Zee  staff  1212 Nov 22 09:28 dashboard.out-rw-r--r--  1 Zee  staff  1212 Nov 22 09:28 dashboard.pem

服务器证书的生成方式如下:

Zees-Air-2:ssl Zee$ openssl genrsa -out server.key 2048
Generating RSA private key, 2048 bit long modulus..................................................................................................................................................................+++.............................................+++e is 65537 (0x10001)Zees-Air-2:ssl Zee$ lltotal 72-rw-r--r--  1 Zee  staff  1751 Nov 22 09:23 dashboard.pass.key-rw-r--r--  1 Zee  staff  1679 Nov 22 09:23 dashboard.key-rw-r--r--  1 Zee  staff  1009 Nov 22 09:24 dashboard.csr-rw-r--r--  1 Zee  staff  1212 Nov 22 09:25 dashboard.crt-rw-r--r--  1 Zee  staff  1212 Nov 22 09:28 dashboard.pem-rw-r--r--  1 Zee  staff  1679 Nov 22 09:54 server.keyZees-Air-2:ssl Zee$ openssl req -new -key server.key -subj "/CN=teckbootcamps" -out server.csrZees-Air-2:ssl Zee$ lltotal 80-rw-r--r--  1 Zee  staff  1751 Nov 22 09:23 dashboard.pass.key-rw-r--r--  1 Zee  staff  1679 Nov 22 09:23 dashboard.key-rw-r--r--  1 Zee  staff  1009 Nov 22 09:24 dashboard.csr-rw-r--r--  1 Zee  staff  1212 Nov 22 09:25 dashboard.crt-rw-r--r--  1 Zee  staff  1212 Nov 22 09:28 dashboard.pem-rw-r--r--  1 Zee  staff  1679 Nov 22 09:54 server.key-rw-r--r--  1 Zee  staff   891 Nov 22 09:55 server.csrZees-Air-2:ssl Zee$ openssl x509 -req -in server.csr -CA dashboard.crt -CAkey dashboard.key -CAcreateserial -out server.crt -days 5000Signature oksubject=/CN=teckbootcampsGetting CA Private Key
Zees-Air-2:ssl Zee$ lltotal 96-rw-r--r--  1 Zee  staff  1751 Nov 22 09:23 dashboard.pass.key-rw-r--r--  1 Zee  staff  1679 Nov 22 09:23 dashboard.key-rw-r--r--  1 Zee  staff  1009 Nov 22 09:24 dashboard.csr-rw-r--r--  1 Zee  staff  1212 Nov 22 09:25 dashboard.crt-rw-r--r--  1 Zee  staff  1212 Nov 22 09:28 dashboard.pem-rw-r--r--  1 Zee  staff  1679 Nov 22 09:54 server.key-rw-r--r--  1 Zee  staff   891 Nov 22 09:55 server.csr-rw-r--r--  1 Zee  staff  1094 Nov 22 09:56 server.crt-rw-r--r--  1 Zee  staff    17 Nov 22 09:56 dashboard.srl
