移远EC800M OpenCPU笔记 - threadX RTOS系统

EC800M 编译SDK

E:\esim\EC800M\ql-sdk>build.bat app -- 编译APP镜像(application)
E:\esim\EC800M\ql-sdk>build.bat firmware -- 生成固件
E:\esim\EC800M\ql-sdk>build.bat kernel -- 编译kernel(可选)
E:\esim\EC800M\ql-sdk>build.bat bootloader -- 编译bootloader(可选)



build_all.bat  -- 提供整体编译的功能

build.bat kernel/bootloader/app clean -- 清除命令

固件包地址：

 示例helloworld

 E:\esim\ql-sdk\ql-application\threadx\interface\example\helloworld.c

#include "ql_application.h"
#include "ql_uart.h"
#include <stdarg.h>

int print_bearpi_uart(const char *fmt, ...)
{
    va_list args;
    int i;
    int count;
    char printk_buf[1024];

    memset(printk_buf, 0, sizeof(printk_buf));
    va_start(args, fmt);
    count = vsnprintf(printk_buf, sizeof(printk_buf), fmt, args);
    printk_buf[count] = 0;
    ql_uart_write(QL_USB_CDC_PORT, (uint8_t *)printk_buf, strlen(printk_buf));
    va_end(args);
    return count;
}
#define printf(fmt, args...) print_bearpi_uart(fmt, ##args)

static void helloworld(void * argv)
{
    while(1)
    {
        printf("Hello,world!\r\n");
        ql_rtos_task_sleep_s(1);
    }
}

application_init(helloworld, "helloworld", 1, 0);

E:\esim\ql-sdk\ql-application\threadx\interface\example\Makefile

#-------------------------------------------------------------------------------
# Configure variable
#-------------------------------------------------------------------------------
TOP_DIR:=$(TOP_DIR)
ROOT_DIR:=$(TOP_DIR)/../..
MAKEFILE_PATH :=$(subst $(strip \),/,$(abspath $(lastword $(MAKEFILE_LIST))))


#-------------------------------------------------------------------------------
# Configure source code files
#-------------------------------------------------------------------------------
SRC_FILES+= \
  helloworld.c \

#-------------------------------------------------------------------------------
# the include directories
#-------------------------------------------------------------------------------
INC_DIRS+= \
  -I${TOP_DIR}/ \
  -I${TOP_DIR}/common/include \


#-------------------------------------------------------------------------------
# Configure compile flag for C
#-------------------------------------------------------------------------------
U_FLAGS:=

#-------------------------------------------------------------------------------
# Configure compile flag for C++
#-------------------------------------------------------------------------------
U_CPPFLAGS:=

#-------------------------------------------------------------------------------
# Configure default macro define
#-------------------------------------------------------------------------------
DFLAGS+= \
  -D__TM_ZONE=tm_zone \
  -D__TM_GMTOFF=tm_gmtoff \
  -D_POSIX_THREADS \


#-------------------------------------------------------------------------------
# Configure link library
#-------------------------------------------------------------------------------
U_LIBS:=

#-------------------------------------------------------------------------------
# include mk file
#-------------------------------------------------------------------------------
include ${TOP_DIR}/config/common/makefile.mk

E:\esim\ql-sdk\ql-application\threadx\Makefile

#-------------------------------------------------------------------------------
# Configure variable
#-------------------------------------------------------------------------------
ifneq (${TOP_DIR},)
  TOP_DIR:=${TOP_DIR}
else
  TOP_DIR:=${CURDIR}
endif


#-------------------------------------------------------------------------------
# Configure compile directories
#-------------------------------------------------------------------------------
COMMPILE_DIRS:= \
  interface/posix \
  interface/wifi \
  interface/log/src \
  interface/example \


#-------------------------------------------------------------------------------
# Configure default libarays
#-------------------------------------------------------------------------------
DEFAULT_LIBS+=  \
  common/lib/ql_common_api.lib \
  common/lib/com_cell_locator.lib \
  common/lib/com_ftp.lib \
  common/lib/com_http.lib \
  common/lib/com_mbedtls.lib \
  common/lib/com_paho_mqtt.lib \
  common/lib/com_ssl.lib \



#-------------------------------------------------------------------------------
# include mk file
#-------------------------------------------------------------------------------
include ${TOP_DIR}/config/common/makefile.mk

使用Aboot工具进行下载

 或者

烧录过程中，可能需要断电重启
