Dynamic CRM插件中记录日志-Nlog记录到文本

Dynamic CRM插件中记录日志的方式有多种 通常情况下分为ITracingService记录、单独日志表插入记录、文本记录三种。
之前整理过ITracingService记录的方式,但这种记录有限制,只有存在异常时才会在插件跟踪日志中查到,异常报错时排查问题到可以,但插件详细的日志记录查看就不很方便,并且插件跟踪日志中记录到最上层的插件,直接通过插件名查询不方便。

单独日志表的方式,也很简单,自定义一个日志表,在插件中调用封装好的日志插入方法即可,但这个存在一个致命的问题,像是普通的信息记录没问题,若存在异常,插入操作会回滚,所以无法通过这种记录排查异常。

第三种文本记录,需要引用第三方组件,比如Nlog或者Lognet4,我使用的Nlog
Nlog日志记录单例类早就有封装,可以在插件程序集中直接引用过来,最核心的地方就是Nlog的config文件,在插件程序集中不需要单独放置一份NLog.config,只需要在CRM的应用服务的Dynamics 365\CRMWeb\bin文件夹中放置好即可,并且保证CRMWeb里bin中的NLog.dll与插件程序集中引用的版本一致
提示:
1.通常服务器上CRMWeb路径为:C:\Program Files\Dynamics 365\CRMWeb\bin
2.NLog.config中具体指明一下文件存放的路径






附上NLog帮助类和服务器上NLog.config配置:
  1     /// <summary>
  2     /// Nlog日志帮助类
  3     /// </summary>
  4     public class LoggerHelper
  5     {
  6         #region 单例模式
  7         private LoggerHelper()
  8         {
  9         }
 10         private static readonly object LockObj = new object();
 11         private static LoggerHelper _instance;
 12
 13         /// <summary>
 14         /// 获得对象实例
 15         /// </summary>
 16         public static LoggerHelper Instance
 17         {
 18             get
 19             {
 20                 lock (LockObj)
 21                 {
 22                     if (_instance == null)
 23                     {
 24                         _instance = new LoggerHelper();
 25                     }
 26                     return _instance;
 27                 }
 28             }
 29         }
 30
 31         #endregion 单例模式
 32
 33         #region 属性
 34
 35         private Logger _log;
 36         /// <summary>
 37         /// 日志实例
 38         /// </summary>
 39         public Logger Log
 40         {
 41             get
 42             {
 43                 if (_log == null) _log = LogManager.GetCurrentClassLogger();
 44                 return _log;
 45             }
 46             private set { _log = value; }
 47         }
 48         #endregion 属性
 49
 50         #region 方法
 51
 52         #region 普通方式
 53         public void Debug(string msg)
 54         {
 55             Log.Debug(msg);
 56         }
 57         public void Debug(string msg, params object[] args)
 58         {
 59             Log.Debug(msg, args);
 60         }
 61         public void Debug(string msg, Exception ex)
 62         {
 63             Log.Debug(ex, msg);
 64         }
 65         public void Warn(string msg)
 66         {
 67             Log.Warn(msg);
 68         }
 69         public void Warn(string msg, params object[] args)
 70         {
 71             Log.Warn(msg, args);
 72         }
 73         public void Warn(string msg, Exception ex)
 74         {
 75             Log.Warn(ex, msg);
 76         }
 77         public void Trace(string msg)
 78         {
 79             Log.Trace(msg);
 80         }
 81         public void Trace(string msg, params object[] args)
 82         {
 83             Log.Trace(msg, args);
 84         }
 85         public void Trace(string msg, Exception ex)
 86         {
 87             Log.Trace(ex, msg);
 88         }
 89         public void Fatal(string msg, params object[] args)
 90         {
 91             Log.Fatal(msg, args);
 92         }
 93
 94         public void Fatal(string msg, Exception ex)
 95         {
 96             Log.Fatal(ex, msg);
 97         }
 98         #endregion 普通方式
 99
100         #region 运行时日志
101         /// <summary>
102         /// 运行时日志
103         /// </summary>
104         /// <param name="msg">记录的信息</param>
105         public void Info(string msg)
106         {
107             LogEventInfo logInfo = SetCustomInfo(LogLevel.Info, "Runlog", msg);
108             Log.Log(LogLevel.Info, logInfo);
109         }
110         #endregion 运行时日志
111
112         #region 错误日志
113         /// <summary>
114         /// 错误记录
115         /// </summary>
116         /// <param name="msg">方法名</param>
117         /// <param name="ex">异常</param>
118         public void Error(string msg)
119         {
120             LogEventInfo logInfo = SetCustomInfo(LogLevel.Error, "ExceptionLogger", msg);
121             logInfo.Properties["ErrorHead"] = "程序发生错误:";
122             Log.Log(LogLevel.Error, logInfo);
123         }
124         /// <summary>
125         /// 错误记录
126         /// </summary>
127         /// <param name="msg">方法名</param>
128         /// <param name="ex">异常</param>
129         public void Error(string msg, Exception ex)
130         {
131             LogEventInfo logInfo = SetCustomInfo(LogLevel.Error, "ExceptionLogger", msg);
132             logInfo.Properties["ErrorHead"] = "程序发生错误:";
133             logInfo.Exception = ex;
134             Log.Log(LogLevel.Error, logInfo);
135         }
136         #endregion 错误日志
137
138         #region 私有方法
139         /// <summary>
140         /// 设置自定义日志事件
141         /// </summary>
142         /// <param name="level"></param>
143         /// <param name="loggerName"></param>
144         /// <param name="message"></param>
145         /// <param name="customPropertie"></param>
146         /// <param name="customPropertieValue"></param>
147         /// <returns></returns>
148         private LogEventInfo SetCustomInfo(LogLevel level, string loggerName, string message, string customPropertie = "", string customPropertieValue = "")
149         {
150             LogEventInfo ei = new LogEventInfo(level, loggerName, message); //也可以用LogEventInfo.Create(level, loggerName, message);
151             if (!string.IsNullOrEmpty(customPropertie) && !string.IsNullOrEmpty(customPropertieValue))
152                 ei.Properties[customPropertie] = customPropertieValue;
153             return ei;
154
155         }
156         #endregion 私有方法
157
158         #endregion 方法
NLog.config配置:
 1 <?xml version="1.0" encoding="utf-8" ?>
 2 <nlog xmlns="http://www.nlog-project.org/schemas/NLog.xsd"
 3       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
 4       xsi:schemaLocation="http://www.nlog-project.org/schemas/NLog.xsd NLog.xsd"
 5       autoReload="true">
 6
 7   <!-- Use below one for debugging-->
 8   <!--nlog xmlns="http://www.nlog-project.org/schemas/NLog.xsd"
 9       xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
10       xsi:schemaLocation="http://www.nlog-project.org/schemas/NLog.xsd NLog.xsd"
11       autoReload="true"
12       throwExceptions="true"
13       internalLogLevel="Trace"
14       internalLogFile="c:\temp\nlog-internal.log"-->
15
16   <extensions>
17     <add assembly="Microsoft.Xrm.Log"/>
18   </extensions>
19
20   <variable name="floderInfo" value="Info"/>
21   <variable name="floderError" value="Error"/>
22
23   <targets>
24     <target name="XrmTraceETWTarget" xsi:type="XrmTraceETWTarget" />
25
26     <target name="DataProviderExecutionETWTarget" xsi:type="DataProviderExecutionETWTarget" />
27     <!-- ${basedir} -->
28     <target name="XrmTraceFileTarget" xsi:type="File"
29         layout="${longdate}|${logger}|${level:uppercase=true}|${message}|${all-event-properties}|${exception:format=tostring}"
30         fileName="D:/CrmLog/logs/logfile.txt"
31         archiveFileName="D:/CrmLog/archives/log.{#####}.txt"
32         archiveAboveSize="1024000"
33         archiveNumbering="Sequence"
34         concurrentWrites="true"
35         keepFileOpen="false"
36         encoding="utf-8" />
37     <!-- ${basedir} -->
38     <target name="debug_info_file" xsi:type="File"
39         layout="${longdate}|${logger}|${level:uppercase=true}|${message}|${all-event-properties}|${exception:format=tostring}"
40         fileName="D:/CrmLog/logs/${floderInfo}/${shortdate}.txt"
41         archiveFileName="D:/CrmLog/archives/${shortdate}.{#####}.txt"
42         archiveAboveSize="1024000"
43         archiveNumbering="Sequence"
44         concurrentWrites="true"
45         keepFileOpen="false"
46         encoding="utf-8" />
47     <!--错误记录 开始-->
48     <target name="error_file" xsi:type="File"
49         layout="${newline}${longdate} ${level:uppercase=true} ${event-context:item=ErrorHead}${newline} ${message} 发生异常: ${onexception:${exception:format=tostring} ${newline} 堆栈信息为: ${stacktrace} ${newline}------------------------------------ "
50         fileName="D:/CrmLog/Logs/${floderError}/${shortdate}.txt"
51         archiveFileName="D:/CrmLog/archives/${floderError}/${shortdate}.{#####}.txt"
52         archiveAboveSize="1024000"
53         archiveNumbering="Sequence"
54         concurrentWrites="true"
55         keepFileOpen="false"
56         encoding="utf-8"/>
57     <!--错误记录 结束-->
58   </targets>
59
60
61
62   <rules>
63     <!-- Add custom rule here -->
64     <logger name="Microsoft.Xrm.DataProvider*" minLevel="Debug" writeTo="DataProviderExecutionETWTarget" final="true"/>
65     <logger name="Microsoft.Xrm.DataPipeline" minLevel="Debug" writeTo="DataProviderExecutionETWTarget" final="true"/>
66     <logger name="*" minLevel="Debug" writeTo="debug_info_file" />
67     <logger name="*" levels="Error" writeTo="error_file" />
68
69     <!-- Add default XrmTrace logging rule "*" here if you want to override in production-->
70
71   </rules>
72 </nlog>
