python 图形界面查看sqlite

python简单程序 代码来自网络

点击查看代码

from tkinter import *
from tkinter.ttk import Treeview
from tkinter.filedialog import askopenfilename

import sqlite3

class TkSqlit3:
  def __init__(self,root):
    self.root = root
    self.frame = Frame(root)
    self.frame.pack(fill="both")
    #sql结果展示
    self.treeviewResult = None
    #存储db路径
    self.db3 = None
    self.varSql = StringVar()
    #数据库操作对象
    self.conn = None
    self.cursor = None
    #添加菜单
    menubar = Menu(root)
    menubar.add_command(label='打开',command=self.openSelectDialog)
    root.config(menu=menubar)
    #sql输入窗口
    sqlInput = Entry(self.frame,textvariable=self.varSql)
    sqlInput.pack(fill=X)
    sqlInput.bind('<Return>', self.showSQLResult)
    #表名列表
    self.lbTable = Listbox(self.frame,height = 100)
    self.lbTable.pack(side=LEFT,fill=Y)
    self.lbTable.bind("<<ListboxSelect>>",self.tableSelect)
    #滚动条
    self.scrollBarX = Scrollbar(self.frame, orient="horizontal")
    self.scrollBarX.pack(side=BOTTOM, fill=X)
    self.scrollBarY = Scrollbar(self.frame, orient="vertical")
    self.scrollBarY.pack(side=RIGHT, fill=Y)

  def openSelectDialog(self):
    self.db3 = askopenfilename(filetypes=[('db', '*.db')],initialdir='.')
    self.conn = sqlite3.connect(self.db3)
    self.cursor = self.conn.cursor()
    self.root.title(self.db3)
    self.cursor.execute("select name from sqlite_master where type='table'")
    for item in self.cursor.fetchall():
      self.lbTable.insert(END,item[0])

  def showSQLResult(self,event):
    result = self.cursor.execute(self.varSql.get())
    heads = [ x[0] for x in self.cursor.description]
    result = self.cursor.fetchall()
    self.showDataTable(heads,result)

  def tableSelect(self,event):
    idx = self.lbTable.curselection()[0]
    tableSelect = self.lbTable.get(idx)
    self.cursor.execute(f"select * from {tableSelect}")
    heads = [ x[0] for x in self.cursor.description]
    result = self.cursor.fetchall()
    self.showDataTable(heads,result)

  def showDataTable(self,heads,result):
    if self.treeviewResult:
      self.treeviewResult.destroy()
    self.treeviewResult = Treeview(
      self.frame,
      height = len(result),
      columns = [str(i) for i in range(len(heads))],
      show='headings',
      xscrollcommand=self.scrollBarX.set,
      yscrollcommand=self.scrollBarY.set)
    self.scrollBarX.config(command=self.treeviewResult.xview)
    self.scrollBarY.config(command=self.treeviewResult.yview)
    for i,text in enumerate(heads):
      self.treeviewResult.column(str(i),width = 100, anchor="w")
      self.treeviewResult.heading(str(i),text=text)
    for i,row in enumerate(result):
      self.treeviewResult.insert('',i,values=row)
    self.treeviewResult.pack(side=LEFT, fill=BOTH, expand=True)

if __name__ == "__main__":
  root = Tk()
  root.geometry("%dx%d" %(800, 600))
  TkSqlit3(root)
  root.mainloop()
