RealisicWater-HLSL

extern uniform float4 g_vec4Velocity;
extern uniform float2 g_vec2Dimension;
extern uniform float3 g_vec3CenterCoord;
extern uniform float3 g_vec3ViewCoord;
extern uniform float3 g_vec3LightCoord;
extern uniform float4x4 g_mat4ViewProj;
extern uniform float4x4 g_mat4ProjTexture;

// @desc: Tangent space matrix.
const float3x3 g_mat3Tangent = { 1.0f, 0.0f, 0.0f, 0.0f, 0.0f, 1.0f, 0.0f, 1.0f, 0.0f };

// @dec: The import of vertex shader.
struct VS_INPUT
{
    float2 m_vec2TexCoord : TEXCOORD0;
    float2 m_vec2VertexCoord : POSITION;
};

// @desc: The export of vertex shader.
struct VS_OUTPUT
{
    float4 m_vec4ClipCoord : POSITION;
    float2 m_vec2ProjTexCoord : TEXCOORD0;
    float4 m_vec4NormalTexCoord : TEXCOORD1;
    float3 m_vec3WorldViewDirection : TEXCOORD2;
    float3 m_vec3TangentViewDirection : TEXCOORD3;
    float3 m_vec3TangentLightDirection : TEXCOORD4;
};

// @desc: The entry of vertex shader.
VS_OUTPUT VS_Main(const VS_INPUT In)
{
    // Calculate view direction and light direction in tangnent space.
    VS_OUTPUT Out;
    const float4 vec4VertexCoord = { In.m_vec2VertexCoord.x*g_vec2Dimension.x + g_vec3CenterCoord.x,
                                     g_vec3CenterCoord.y,
                                     In.m_vec2VertexCoord.y*g_vec2Dimension.y + g_vec3CenterCoord.z, 1.0f };
    Out.m_vec3WorldViewDirection = g_vec3ViewCoord - vec4VertexCoord.xyz;
    Out.m_vec3TangentViewDirection = mul(g_mat3Tangent, Out.m_vec3WorldViewDirection);
    Out.m_vec3TangentLightDirection = mul(g_mat3Tangent, g_vec3LightCoord - vec4VertexCoord.xyz);

    // Calculate projected texture coordinate and normal texture coordinate.
    const float4 vec4ProjTexCoord = mul(vec4VertexCoord, g_mat4ProjTexture);
    Out.m_vec2ProjTexCoord = vec4ProjTexCoord.xy/vec4ProjTexCoord.w;
    Out.m_vec4NormalTexCoord = float4(In.m_vec2TexCoord + g_vec4Velocity.xy, In.m_vec2TexCoord + g_vec4Velocity.zw);

    // Calculate the coordinate of vertex in clipping space.
    Out.m_vec4ClipCoord = mul(vec4VertexCoord, g_mat4ViewProj);
    return Out;
}

extern uniform float3 g_vec3Irradiance;
extern uniform float3 g_vec3Diffuse;
extern uniform float3 g_vec3Specular;
extern uniform float g_fSmoothness;
extern uniform float g_fPerturbation;
extern uniform float2 g_vec2FrenelPara;
extern uniform Texture2D g_LowFrequencyNormalMap;
sampler2D g_LowFrequencyNormalSampler = sampler_state
{
    Texture = <g_LowFrequencyNormalMap>;
    MinFilter = LINEAR;
    MagFilter = LINEAR;
    MipFilter = LINEAR;
    AddressU = WRAP;
    AddressV = WRAP;
};
extern uniform Texture2D g_HighFrequencyNormalMap;
sampler2D g_HighFrequencyNormalSampler = sampler_state
{
    Texture = <g_HighFrequencyNormalMap>;
    MinFilter = LINEAR;
    MagFilter = LINEAR;
    MipFilter = LINEAR;
    AddressU = WRAP;
    AddressV = WRAP;
};
extern uniform Texture2D g_ReflectMap;
sampler2D g_ReflectSampler = sampler_state
{
    Texture = <g_ReflectMap>;
    MinFilter = LINEAR;
    MagFilter = LINEAR;
    MipFilter = LINEAR;
    AddressU = CLAMP;
    AddressV = CLAMP;
};
extern uniform Texture2D g_RefractMap;
sampler2D g_RefractSampler = sampler_state
{
    Texture = <g_RefractMap>;
    MinFilter = LINEAR;
    MagFilter = LINEAR;
    MipFilter = LINEAR;
    AddressU = CLAMP;
    AddressV = CLAMP;
};

// @desc: The original surface normal.
const float3 g_vec3OriginNormal = { 0.0f, 1.0f, 0.0f };

// @desc: The import of pixel shader.
struct PS_INPUT
{
    float2 m_vec2ProjTexCoord : TEXCOORD0;
    float4 m_vec4NormalTexCoord : TEXCOORD1;
    float3 m_vec3WorldViewDirection : TEXCOORD2;
    float3 m_vec3TangentViewDirection : TEXCOORD3;
    float3 m_vec3TangentLightDirection : TEXCOORD4;
};

// @desc: The entry of pixel shader.
float4 PS_Main(const PS_INPUT In) : COLOR
{
    // Calculate synthetical normal.
    const float3 vec3LowFrequencyNormal = (tex2D(g_LowFrequencyNormalSampler, In.m_vec4NormalTexCoord.xy).xyz - 0.5f)*2.0f;
    const float3 vec3HighFrequencyNormal = (tex2D(g_HighFrequencyNormalSampler, In.m_vec4NormalTexCoord.zw).xyz - 0.5f)*2.0f;
    const float3 vec3SynthNormal = normalize(vec3LowFrequencyNormal + vec3HighFrequencyNormal);

    // Calculate diffuse gene.
    const float3 vec3TangentLightDirection = normalize(In.m_vec3TangentLightDirection);
    const float fDiffuseGene = max(dot(vec3SynthNormal, vec3TangentLightDirection), 0.0f);

    // Calculate specular gene.
    float fSpecularGene = 0.0f;
    if (fDiffuseGene > 0.0f)
    {
        const float3 vec3TangentViewDirection = normalize(In.m_vec3TangentViewDirection);
        const float3 vec3Reflection = reflect(-vec3TangentLightDirection, vec3SynthNormal);
        fSpecularGene = pow(max(dot(vec3Reflection, vec3TangentViewDirection), 0.0f), g_fSmoothness);
    }

    // Fectch the sample of reflect texture and refract texture.
    const float2 vec2DistortProjTexCoord = In.m_vec2ProjTexCoord + g_fPerturbation*vec3SynthNormal.xy;
    const float3 vec3Reflect = tex2D(g_ReflectSampler, vec2DistortProjTexCoord).xyz;
    const float3 vec3Refract = tex2D(g_RefractSampler, vec2DistortProjTexCoord).xyz;

    // Calculate fresnel law.
    const float fViewGene = dot(normalize(In.m_vec3WorldViewDirection), g_vec3OriginNormal);
    const float fFresnelGene = g_vec2FrenelPara.x + g_vec2FrenelPara.y*pow(1.0f - fViewGene, 5.0f);
    const float3 vec3Fresnel = lerp(vec3Refract, vec3Reflect, fFresnelGene);

    // Calculate the exitance of light.
    const float3 vec3Exitance = (fDiffuseGene*g_vec3Diffuse*vec3Fresnel + fSpecularGene*g_vec3Specular)*g_vec3Irradiance;
    return float4(vec3Exitance, 1.0f);
}

// @desc: Technique and pass.
technique FluidVision
{
    pass P0
    {
        VertexShader = compile vs_1_0 VS_Main();
        PixelShader  = compile ps_2_0 PS_Main();
    }
}
