using System.Collections;
using System.Collections.Generic;
using System.Threading;
using UnityEngine;
[System.Serializable]
public class fangkuai{
public Vector3 a;
public Vector3 b;
public Vector3 c;
public Vector3 d;
}
public class xiangliang : MonoBehaviour
{
public GameObject game;
public Vector3 a;
public Vector3 b;
public Vector3 c;
public Vector3 d;
public Vector3 p;
[Header("设置横竖向校准点个数")]
public int Width;
public int Height;
private int w;
private int h;
void Start()
{
if (Width <= 2) Width = 2;
if (Height <= 2) Height = 2;
w=Width-1;
h=Height-1;
a = sa.position;
b = sb.position;
c = sc.position;
d = sd.position;
CreateQuadrilateralAnchor();
CreateCalibrationPoint();
StartThread();
}
[Header("四边形")]
public Transform sa;
public Transform sb;
public Transform sc;
public Transform sd;
[Header("需要校准的点")]
public Transform sp;
[Header("矫正点个数")]
private int index = 0;
[Header("矫正点坐标数组")]
public List<Vector3> vector3s;
[Header("四边形数组")]
public fangkuai[] fangkuais;
//创建四边形定位点
void CreateQuadrilateralAnchor() {
for (float y = 0; y <= h; y++)
{
for (float x = 0; x <= w; x++)
{
Vector3 v1 = (sb.position - sa.position) * (x / w) + sa.position;
Vector3 v2 = (sc.position - sd.position) * (x / w) + sd.position;
Vector3 v3 = (sd.position - sa.position) * (y / h) + sa.position;
Vector3 v4 = (sc.position - sb.position) * (y / h) + sb.position;
Vector3 pos = CrossPoint(v1, v2, v3, v4);
GameObject g = Instantiate(game, pos, Quaternion.identity);
index++;
g.name = index.ToString();
vector3s.Add(pos);
}
}
//设置长度
fangkuais = new fangkuai[w * h];
int Sindex = 0;
for (int y = 0; y < h; y++)
{
for (int x = 0; x < w; x++)
{
fangkuai fangkuai = new fangkuai();
int ps = (y * (w + 1)) + x;
fangkuai.a = vector3s[ps];
fangkuai.b = vector3s[ps + 1];
fangkuai.d = vector3s[ps + w + 1];
fangkuai.c = vector3s[ps + w + 2];
fangkuais[Sindex] = fangkuai;
Sindex++;
}
}
}
[Header("矫正后四边形")]
public Transform fa;
public Transform fb;
public Transform fc;
public Transform fd;
[Header("分布点个数")]
private int findex = 0;
[Header("矫正后点坐标数组")]
public List<Vector3> fvector3s;
[Header("校正后四边形数组")]
public fangkuai[] ffangkuais;
[Header("矫正后四边形位置")]
public Transform Jiao;
public Vector3 JiaoPos;
//创建校准点
void CreateCalibrationPoint() {
for (float y = 0; y <= h; y++)
{
for (float x = 0; x <= w; x++)
{
Vector3 v1 = (fb.position - fa.position) * (x / w) + fa.position;
Vector3 v2 = (fc.position - fd.position) * (x / w) + fd.position;
Vector3 v3 = (fd.position - fa.position) * (y / h) + fa.position;
Vector3 v4 = (fc.position - fb.position) * (y / h) + fb.position;
Vector3 pos = CrossPoint(v1, v2, v3, v4);
GameObject g = Instantiate(game, pos, Quaternion.identity);
findex++;
g.name = "f" + findex.ToString();
fvector3s.Add(pos);
}
}
//设置长度
ffangkuais = new fangkuai[w * h];
int Findex = 0;
for (int y = 0; y < h; y++)
{
for (int x = 0; x < w; x++)
{
fangkuai fangkuai = new fangkuai();
int ps = (y * (w + 1)) + x;
fangkuai.a = fvector3s[ps];
fangkuai.b = fvector3s[ps + 1];
fangkuai.c = fvector3s[ps + w + 2];
fangkuai.d = fvector3s[ps + w + 1];
ffangkuais[Findex] = fangkuai;
Findex++;
}
}
}
private Thread thread = null;
//创建线程
void StartThread()
{
thread = new Thread(F1);
thread.Start();
}
/// <summary>
/// 线程开启循环
/// </summary>
public bool Isthr = true;
//线程循环
void F1()
{
while (Isthr)
{
OnStart();
}
}
void Update()
{
p = sp.position;
Jiao.position = JiaoPos;
}
//开始处理校准
void OnStart() {
if (IsThePointWithinTheQuadrilateral(p, a, b, c, d))
{
Debug.Log("在四边形内");
for (int i = 0; i < fangkuais.Length; i++)
{
if (IsThePointWithinTheQuadrilateral(p, fangkuais[i].a, fangkuais[i].b, fangkuais[i].c, fangkuais[i].d))
{
Debug.Log("在四边形集合第" + i + "个四边形内");
SiBianXing(i, ffangkuais[i].a, ffangkuais[i].b, ffangkuais[i].c, ffangkuais[i].d, p, fangkuais[i].a, fangkuais[i].b, fangkuais[i].c, fangkuais[i].d);
return;
}
else {
// Debug.Log("不在四边形集合第" + i + "个四边形内");
if (IsThePointOnTheInnerLineOfTheSegment(p, fangkuais[i].a, fangkuais[i].b))
{
Debug.Log("在四边形集合第" + i + "个四边形线段ab边上");
SiBianXingBian(i, ffangkuais[i].a, ffangkuais[i].b,p, fangkuais[i].a, fangkuais[i].b);
return;
}
else {
if (IsThePointOnTheInnerLineOfTheSegment(p, fangkuais[i].b, fangkuais[i].c))
{
Debug.Log("在四边形集合第" + i + "个四边形线段bc边上");
SiBianXingBian(i, ffangkuais[i].b, ffangkuais[i].c, p, fangkuais[i].b, fangkuais[i].c);
return;
}
else {
if (IsThePointOnTheInnerLineOfTheSegment(p, fangkuais[i].c, fangkuais[i].d))
{
Debug.Log("在四边形集合第" + i + "个四边形线段cd边上");
SiBianXingBian(i, ffangkuais[i].c, ffangkuais[i].d, p, fangkuais[i].c, fangkuais[i].d);
return;
}
else {
if (IsThePointOnTheInnerLineOfTheSegment(p, fangkuais[i].d, fangkuais[i].a))
{
Debug.Log("在四边形集合第" + i + "个四边形线段da边上");
SiBianXingBian(i, ffangkuais[i].d, ffangkuais[i].a, p, fangkuais[i].d, fangkuais[i].a);
return;
}
else {
Debug.Log("不在四边形集合第" + i + "个四边形内和四条边上");
}
}
}
}
}
}
}
else {
Debug.Log("不在四边形内");
}
}
//在四边形内
void SiBianXing(int i, Vector3 fa, Vector3 fb, Vector3 fc, Vector3 fd, Vector3 p,Vector3 a,Vector3 b,Vector3 c,Vector3 d ) {
Vector3 SJiaoDian = CrossPoint(a, c, b, d);
Vector3 FJiaoDian = CrossPoint(fa, fc, fb, fd);
if (SJiaoDian == p)
{
Debug.Log("在四边形集合第" + i + "个四边形的焦点上");
JiaoPos = FJiaoDian;
}
else
{
if (InTriangleOrNot(p, SJiaoDian, a, b))
{
Debug.Log("在四边形集合第" + i + "个四边形的ab侧的三角形内");
SanJiaoXing(i, FJiaoDian, fa, fb, p, SJiaoDian, a, b);
return;
}
else
{
if (InTriangleOrNot(p, SJiaoDian, b, c))
{
Debug.Log("在四边形集合第" + i + "个四边形的bc侧的三角形内");
SanJiaoXing(i, FJiaoDian, fb, fc, p, SJiaoDian, b, c);
return;
}
else
{
if (InTriangleOrNot(p, SJiaoDian, c, d))
{
Debug.Log("在四边形集合第" + i + "个四边形的cd侧的三角形内");
SanJiaoXing(i, FJiaoDian, fc, fd, p, SJiaoDian, c, d);
return;
}
else
{
if (InTriangleOrNot(p, SJiaoDian, d, a))
{
Debug.Log("在四边形集合第" + i + "个四边形的da侧的三角形内");
SanJiaoXing(i, FJiaoDian, fd, fa, p, SJiaoDian, d, a);
return;
}
else
{
if (IsThePointOnTheDiagonal(p, a, c))
{
Debug.Log("在四边形集合第" + i + "个四边形的ac对角线内");
DuiJiaoXian(i, FJiaoDian, fa, fc,p,SJiaoDian,a,c);
return;
}
else
{
if (IsThePointOnTheDiagonal(p, b, d))
{
Debug.Log("在四边形集合第" + i + "个四边形的bd对角线内");
DuiJiaoXian(i, FJiaoDian, fb, fd, p, SJiaoDian, b, d);
return;
}
else
{
Debug.Log("不在四边形集合第" + i + "个四边形内");
}
}
}
}
}
}
}
}
//在三角形内
void SanJiaoXing(int i, Vector3 fa, Vector3 fb, Vector3 fc, Vector3 p, Vector3 a, Vector3 b ,Vector3 c) {
float Di1 = Vector3.Distance(p, a);
Vector2 SJiaoDian = CrossPoint(p,a,b,c);
float Di2 = Vector3.Distance(SJiaoDian, a);
float BiLi1 = Di1 / Di2;
float Di3 = Vector3.Distance(SJiaoDian, b);
float Di4 = Vector3.Distance(c, b);
float BiLi2 = Di3 / Di4;
Vector3 FJiaoDian = (fc - fb) * BiLi2 + fb;
Vector3 JiaoZheng = (FJiaoDian-fa) * BiLi1 + fa;
JiaoPos = JiaoZheng;
return;
}
//在对角线上
void DuiJiaoXian(int i, Vector3 fj,Vector3 fa,Vector3 fb,Vector3 p,Vector3 sj,Vector3 a,Vector3 b) {
float Di1 = Vector3.Distance(a,sj );
float Di2 = Vector3.Distance(p, a);
float Di3 = Vector3.Distance(p, sj);
if (Di1 > Di2)
{
Debug.Log("在四边形集合第" + i + "个四边形的ac对角线上半段");
float Bili1 = Di3 / Di1;
Vector3 JiaoZheng = (fa-fj) * Bili1 + fj;
JiaoPos = JiaoZheng;
}
else {
Debug.Log("在四边形集合第" + i + "个四边形的ac对角线下半段");
float Di4 = Vector3.Distance(sj, b);
float Bili2 = Di3 / Di4;
Vector3 JiaoZheng = ( fb- fj ) * Bili2 + fj;
JiaoPos = JiaoZheng;
}
return;
}
//在四边形边上
void SiBianXingBian(int i, Vector3 fa, Vector3 fb, Vector3 p, Vector3 a, Vector3 b) {
float Di1 = Vector3.Distance(p, a);
float Di2 = Vector3.Distance(a, b);
float BiLi = Di1 / Di2;
Vector3 JiaoZheng = (fb - fa) * BiLi + fa;
JiaoPos = JiaoZheng;
return;
}
// 点是否在三角形内
bool InTriangleOrNot(Vector3 p, Vector3 a, Vector3 b, Vector3 c)
{
Vector3 pa = a - p;
Vector3 pb = b - p;
Vector3 pc = c - p;
Vector3 pab = Vector3.Cross(pa, pb);
Vector3 pbc = Vector3.Cross(pb, pc);
Vector3 pca = Vector3.Cross(pc, pa);
float d1 = Vector3.Dot(pab, pbc);
float d2 = Vector3.Dot(pab, pca);
float d3 = Vector3.Dot(pbc, pca);
if (d1 > 0 && d2 > 0 && d3 > 0) return true;
return false;
}
//点是否在对角线上
bool IsThePointOnTheDiagonal(Vector2 p, Vector2 a, Vector2 b)
{
float A = a.y - b.y;
float B = b.x - a.x;
float C = (a.x * b.y) - (b.x * a.y);
if ((A * p.x) + (B * p.y) + C == 0)
{
return true;
}
return false;
}
//点是否在线段内线上
bool IsThePointOnTheInnerLineOfTheSegment(Vector2 p, Vector2 a, Vector2 b)
{
float A = a.y - b.y;
float B = b.x - a.x;
float C = (a.x * b.y) - (b.x * a.y);
if ((A * p.x) + (B * p.y) + C == 0)
{
if (Vector3.Distance(p, a) <= Vector3.Distance(a, b) && Vector3.Distance(p, b) <= Vector3.Distance(a, b)) {
return true;
}
}
return false;
}
// 点是否在四边形内
bool IsThePointWithinTheQuadrilateral(Vector3 p,Vector3 a,Vector3 b,Vector3 c,Vector3 d)
{
Vector3 pa = a - p;
Vector3 pb = b - p;
Vector3 pc = c - p;
Vector3 pd = d - p;
Vector3 pab = Vector3.Cross(pa, pb);
Vector3 pbc = Vector3.Cross(pb, pc);
Vector3 pcd = Vector3.Cross(pc, pd);
Vector3 pca = Vector3.Cross(pd, pa);
float d1 = Vector3.Dot(pab, pbc);
float d2 = Vector3.Dot(pab, pcd);
float d3 = Vector3.Dot(pab, pca);
float d4 = Vector3.Dot(pbc, pcd);
float d5 = Vector3.Dot(pbc, pca);
float d6 = Vector3.Dot(pcd, pca);
// float d4 = Vector3.Dot(pbc, pca);
if (d1 > 0 && d2 > 0 && d3 > 0 && d4 > 0 && d5 > 0 && d6 > 0)
{
return true;
}
return false;
}
// 两条直线焦点
Vector2 CrossPoint(Vector2 line1, Vector2 line2, Vector2 line3, Vector2 line4) //交点
{
float x_member, x_denominator, y_member, y_denominator;
Vector2 cross_point;
x_denominator = line4.x * line2.y - line4.x * line1.y - line3.x * line2.y + line3.x * line1.y
- line2.x * line4.y + line2.x * line3.y + line1.x * line4.y - line1.x * line3.y;
x_member = line3.y * line4.x * line2.x - line4.y * line3.x * line2.x - line3.y * line4.x * line1.x + line4.y * line3.x * line1.x
- line1.y * line2.x * line4.x + line2.y * line1.x * line4.x + line1.y * line2.x * line3.x - line2.y * line1.x * line3.x;
if (x_denominator == 0)
cross_point.x = 0;
else
cross_point.x = x_member / x_denominator;
y_denominator = line4.y * line2.x - line4.y * line1.x - line3.y * line2.x + line1.x * line3.y
- line2.y * line4.x + line2.y * line3.x + line1.y * line4.x - line1.y * line3.x;
y_member = -line3.y * line4.x * line2.y + line4.y * line3.x * line2.y + line3.y * line4.x * line1.y - line4.y * line3.x * line1.y
+ line1.y * line2.x * line4.y - line1.y * line2.x * line3.y - line2.y * line1.x * line4.y + line2.y * line1.x * line3.y;
if (y_denominator == 0)
cross_point.y = 0;
else
cross_point.y = y_member / y_denominator;
return cross_point; //平行返回(0,0)
}
void OnDestroy()
{
ThreadQuit();
}
void ThreadQuit()
{
Isthr = false;
thread.Abort();
// thread.Interrupt();
}
void OnApplicationQuit()
{
ThreadQuit();
}
}
