WPF DataGrid,mvvm, DI via Microsoft.Extensions.DependencyInjection , ContextMenu save datagridrow as picture without blocking ui issues

Install-Package Microsoft.Extensions.DependencyInjection;
Install-Package CommunityToolKit.mvvm;





private void InitCommands()
{
    SaveListBoxItemsAsPicturesCommand=new RelayCommand<object>(async (obj) => await SaveListBoxItemsAsPicturesCommandExecuted(obj));
}

private async Task SaveListBoxItemsAsPicturesCommandExecuted(object? obj)
{
    if (obj==null)
    {
        return;
    }

    var dg = obj as DataGrid;
    if (dg==null)
    {
        return;
    }

    var items = dg.Items.Cast<Book>().ToList();
    string jpgDir = $"JPG_{DateTime.Now.ToString("yyyyMMddHHmmsssffff")}";
    if (!Directory.Exists(jpgDir))
    {
        Directory.CreateDirectory(jpgDir);
    }

    int jpgIdx = 0;
    foreach (var item in items)
    {
        var dgRow = await Application.Current.Dispatcher.InvokeAsync(() =>
        {
            dg.ScrollIntoView(item);
            dg.UpdateLayout();
            var tempItem = dg.ItemContainerGenerator.ContainerFromItem(item) as DataGridRow;
            return tempItem;
        });

        if (dgRow==null)
        {
            continue;
        }

        var rtb = await Application.Current.Dispatcher.InvokeAsync(() =>
        {
            var dpi = VisualTreeHelper.GetDpi(dgRow);
            var bmp = new RenderTargetBitmap((int)(dgRow.ActualWidth*dpi.DpiScaleX),
                (int)(dgRow.ActualHeight*dpi.DpiScaleY),
                dpi.PixelsPerInchX,
                dpi.PixelsPerInchY,
                PixelFormats.Pbgra32);
            bmp.Render(dgRow);
            if (bmp.CanFreeze)
            {
                bmp.Freeze();
            }
            return bmp;
        });

        string jpgFileName = System.IO.Path.Combine(jpgDir, $"{++jpgIdx}.jpg");

        await Task.Run(() =>
        {
            SaveRtbAsPictures(rtb, jpgFileName);
        });
    }
}

private void SaveRtbAsPictures(BitmapSource bmpSource, string jpgFileName)
{
    using (FileStream fileStream = new FileStream(jpgFileName, FileMode.Create))
    {
        JpegBitmapEncoder encoder = new JpegBitmapEncoder();
        encoder.Frames.Add(BitmapFrame.Create(bmpSource));
        encoder.Save(fileStream);
        Debug.WriteLine($"Jpg File:{jpgFileName}");
    }
}



















//app.cs
using Microsoft.Extensions.DependencyInjection;
using System.Configuration;
using System.Data;
using System.Windows;

namespace WpfApp12
{
    /// <summary>
    /// Interaction logic for App.xaml
    /// </summary>
    public partial class App : Application
    {
        ServiceProvider serviceProvider;
        protected override void OnStartup(StartupEventArgs e)
        {
            base.OnStartup(e);
            var serviceCollection = new ServiceCollection();
            ConfigureServices(serviceCollection);
            serviceProvider = serviceCollection.BuildServiceProvider();

            var mainWin = serviceProvider.GetRequiredService<MainWindow>();
            mainWin.Show();
        }

        private void ConfigureServices(ServiceCollection serviceCollection)
        {
            serviceCollection.AddSingleton<IIDService, IDService>();
            serviceCollection.AddSingleton<INameService, NameService>();
            serviceCollection.AddSingleton<IISBNService, ISBNService>();
            serviceCollection.AddSingleton<MainWindow>();
            serviceCollection.AddSingleton<MainVM>();
        }

        protected override void OnExit(ExitEventArgs e)
        {
            base.OnExit(e);
            serviceProvider?.Dispose();
        }
    }

}


//xaml
<Window x:Class="WpfApp12.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
        xmlns:local="clr-namespace:WpfApp12"
        WindowState="Maximized"
        mc:Ignorable="d"
        Title="{Binding StatusMsg,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
        Height="450" Width="800">
    <Grid>
        <DataGrid ItemsSource="{Binding BooksCollection,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                  VirtualizingPanel.IsVirtualizing="True"
                  VirtualizingPanel.VirtualizationMode="Recycling"
                  AutoGenerateColumns="False"
                  CanUserAddRows="False">

            <DataGrid.Columns>
                <DataGridTemplateColumn>
                    <DataGridTemplateColumn.CellTemplate>
                        <DataTemplate>
                            <Grid Width="{Binding DataContext.GridWidth,RelativeSource={RelativeSource AncestorType=Window}}"
                                  Height="{Binding DataContext.GridHeight,RelativeSource={RelativeSource AncestorType=Window}}">
                                <Grid.Resources>
                                    <Style TargetType="TextBlock">
                                        <Setter Property="FontSize" Value="50"/>
                                        <Setter Property="HorizontalAlignment" Value="Center"/>
                                        <Setter Property="VerticalAlignment" Value="Center"/>
                                        <Style.Triggers>
                                            <Trigger Property="IsMouseOver" Value="True">
                                                <Setter Property="Foreground" Value="Red"/>
                                                <Setter Property="FontSize" Value="100"/>
                                            </Trigger>
                                        </Style.Triggers>
                                    </Style>
                                </Grid.Resources>
                                <Grid.Background>
                                    <ImageBrush ImageSource="{Binding ImgSource}"/>
                                </Grid.Background>
                                <Grid.RowDefinitions>
                                    <RowDefinition/>
                                    <RowDefinition/>
                                </Grid.RowDefinitions>
                                <Grid.ColumnDefinitions>
                                    <ColumnDefinition/>
                                    <ColumnDefinition/>
                                </Grid.ColumnDefinitions>
                                <TextBlock Text="{Binding ID}" Grid.Column="0" Grid.Row="0"/>
                                <TextBlock Text="{Binding Name}" Grid.Column="1" Grid.Row="0"/>
                                <TextBlock Text="{Binding ISBN}" Grid.Column="0"  Grid.ColumnSpan="2" Grid.Row="1"/>
                            </Grid>
                        </DataTemplate>
                    </DataGridTemplateColumn.CellTemplate>
                </DataGridTemplateColumn>
            </DataGrid.Columns>
            <DataGrid.ContextMenu>
                <ContextMenu>
                    <MenuItem Header="Save Items As Pictures"
                              Command="{Binding SaveListBoxItemsAsPicturesCommand}"
                              CommandParameter="{Binding RelativeSource={RelativeSource AncestorType=ContextMenu},Path=PlacementTarget}"/>
                </ContextMenu>
            </DataGrid.ContextMenu>
        </DataGrid>
    </Grid>
</Window>



//xaml.cs
using CommunityToolkit.Mvvm.ComponentModel;
using CommunityToolkit.Mvvm.Input;
using System.Collections.ObjectModel;
using System.Diagnostics;
using System.IO;
using System.Runtime.Intrinsics.X86;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;

namespace WpfApp12
{
    /// <summary>
    /// Interaction logic for MainWindow.xaml
    /// </summary>
    public partial class MainWindow : Window
    {
        public MainWindow()
        {
            InitializeComponent();
        }

        public MainWindow(MainVM vm)
        {
            InitializeComponent();
            this.DataContext=vm;
            this.SizeChanged+=MainWindow_SizeChanged;
        }

        private void MainWindow_SizeChanged(object sender, SizeChangedEventArgs e)
        {
            if (DataContext is MainVM vm)
            {
                var fe = this.Content as FrameworkElement;
                if (fe != null)
                {
                    vm.GridWidth= fe.ActualWidth;
                    vm.GridHeight= fe.ActualHeight/2;
                }
            }
        }
    }

    public partial class MainVM : ObservableObject
    {
        IIDService idService;
        IISBNService iSBNService;
        INameService nameService;
        public MainVM(IIDService idServiceValue, IISBNService iSBNServiceValue,
            INameService nameServiceValue)
        {
            idService = idServiceValue;
            iSBNService= iSBNServiceValue;
            nameService = nameServiceValue;
            InitData();
            InitCommands();
        }

        private void InitCommands()
        {
            SaveListBoxItemsAsPicturesCommand=new RelayCommand<object>(async (obj) => await SaveListBoxItemsAsPicturesCommandExecuted(obj));
        }

        private async Task SaveListBoxItemsAsPicturesCommandExecuted(object? obj)
        {
            if (obj==null)
            {
                return;
            }

            var dg = obj as DataGrid;
            if (dg==null)
            {
                return;
            }

            var items = dg.Items.Cast<Book>().ToList();
            string jpgDir = $"JPG_{DateTime.Now.ToString("yyyyMMddHHmmsssffff")}";
            if (!Directory.Exists(jpgDir))
            {
                Directory.CreateDirectory(jpgDir);
            }

            int jpgIdx = 0;
            foreach (var item in items)
            {
                var dgRow = await Application.Current.Dispatcher.InvokeAsync(() =>
                {
                    dg.ScrollIntoView(item);
                    dg.UpdateLayout();
                    var tempItem = dg.ItemContainerGenerator.ContainerFromItem(item) as DataGridRow;
                    return tempItem;
                });

                if (dgRow==null)
                {
                    continue;
                }

                var rtb = await Application.Current.Dispatcher.InvokeAsync(() =>
                {
                    var dpi = VisualTreeHelper.GetDpi(dgRow);
                    var bmp = new RenderTargetBitmap((int)(dgRow.ActualWidth*dpi.DpiScaleX),
                        (int)(dgRow.ActualHeight*dpi.DpiScaleY),
                        dpi.PixelsPerInchX,
                        dpi.PixelsPerInchY,
                        PixelFormats.Pbgra32);
                    bmp.Render(dgRow);
                    if (bmp.CanFreeze)
                    {
                        bmp.Freeze();
                    }
                    return bmp;
                });

                string jpgFileName = System.IO.Path.Combine(jpgDir, $"{++jpgIdx}.jpg");

                await Task.Run(() =>
                {
                    SaveRtbAsPictures(rtb, jpgFileName);
                });
            }
        }

        private void SaveRtbAsPictures(BitmapSource bmpSource, string jpgFileName)
        {
            using (FileStream fileStream = new FileStream(jpgFileName, FileMode.Create))
            {
                JpegBitmapEncoder encoder = new JpegBitmapEncoder();
                encoder.Frames.Add(BitmapFrame.Create(bmpSource));
                encoder.Save(fileStream);
                Debug.WriteLine($"Jpg File:{jpgFileName}");
            }
        }

        private async Task InitData()
        {
            string imgDir = @"../../../Images";
            if (!Directory.Exists(imgDir))
            {
                return;
            }

            var imgs = Directory.GetFiles(imgDir);
            if (imgs==null || !imgs.Any())
            {
                return;
            }

            int imgsCount = imgs.Count();

            BooksCollection=new ObservableCollection<Book>();
            List<Book> booksList = new List<Book>();
            await Task.Run(async () =>
            {
                for (int i = 0; i<1000000; i++)
                {
                    booksList.Add(new Book()
                    {
                        ID=idService.GetID(),
                        Name=nameService.GetName(),
                        ISBN=iSBNService.GetISBN(),
                        ImgSource=GetImgSourceViaUrl(imgs[i%imgsCount])
                    });

                    if (i%100000==0)
                    {
                        await PopulateBooksCollection(booksList);
                    }
                }

                if (booksList.Count>0)
                {
                    await PopulateBooksCollection(booksList);
                }
            });
        }

        private async Task PopulateBooksCollection(List<Book> booksList)
        {
            var tempList = booksList.ToList();
            booksList.Clear();
            await Application.Current.Dispatcher.InvokeAsync(() =>
            {
                foreach (var bk in tempList)
                {
                    BooksCollection.Add(bk);
                }
                StatusMsg=$"BooksCollection.Count:{BooksCollection.Count}";
            });
        }

        private ImageSource GetImgSourceViaUrl(string imgUrl)
        {
            BitmapImage bmi = new BitmapImage();
            if (!File.Exists(imgUrl))
            {
                return bmi;
            }

            bmi.BeginInit();
            bmi.UriSource=new Uri(imgUrl, UriKind.RelativeOrAbsolute);
            bmi.EndInit();
            if (bmi.CanFreeze)
            {
                bmi.Freeze();
            }
            return bmi;
        }

        [ObservableProperty]
        private double gridWidth;

        [ObservableProperty]
        private double gridHeight;

        [ObservableProperty]
        private ObservableCollection<Book> booksCollection;

        [ObservableProperty]
        private string statusMsg;

        public RelayCommand<object> SaveListBoxItemsAsPicturesCommand { get; set; }
    }

    public class ISBNService : IISBNService
    {
        int idx = 0;
        public string GetISBN()
        {
            return $"ISBN_{++idx}_{Guid.NewGuid().ToString():N}";
        }
    }

    public interface IISBNService
    {
        string GetISBN();
    }


    public class NameService : INameService
    {
        int idx = 0;
        public string GetName()
        {
            return $"Name_{++idx}";
        }
    }

    public interface INameService
    {
        string GetName();
    }

    public interface IIDService
    {
        public int GetID();
    }

    public class IDService : IIDService
    {
        int id = 0;

        public int GetID()
        {
            return ++id;
        }
    }


    public class Book
    {
        public int ID { get; set; }
        public string Name { get; set; }
        public string ISBN { get; set; }
        public ImageSource ImgSource { get; set; }
    }
}
