wpf number scroll number and down

//usercontrol.xaml
<UserControl x:Class="WpfApp201.UCScrollNum"
             xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
             xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
             xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
             xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
             xmlns:local="clr-namespace:WpfApp201"
             mc:Ignorable="d"
            d:DesignHeight="180" d:DesignWidth="150">
    <Grid>
        <Grid>
            <Grid.RowDefinitions>
                <RowDefinition Height="180"/>
            </Grid.RowDefinitions>
            <Grid.ColumnDefinitions>
                <ColumnDefinition/>
                <ColumnDefinition Width="50"/>
                <ColumnDefinition/>
            </Grid.ColumnDefinitions>
            <Border Background="#F0F0F0"
                    CornerRadius="5"
                    BorderThickness="1"
                    BorderBrush="#CCCCCC"
                    Grid.Row="0"
                    Grid.Column="1">

                <Grid>
                    <Grid.RowDefinitions>
                        <RowDefinition/>
                        <RowDefinition/>
                        <RowDefinition/>
                    </Grid.RowDefinitions>

                    <TextBlock x:Name="numTbk1"
                           Text="0"
                           FontSize="50"
                           Grid.Row="0"
                           Grid.Column="0"
                           HorizontalAlignment="Center"
                           Visibility="{Binding UpTbkVisibility,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}" />

                    <TextBlock  x:Name="numTbk2"
                           Text="0"
                           FontSize="50"
                           Grid.Row="1"
                           Grid.Column="0"
                           HorizontalAlignment="Center"
                           Visibility="{Binding MiddleTbkVisibility,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"/>

                    <TextBlock  x:Name="numTbk3"
                            Text="0"
                            FontSize="50"
                            Grid.Row="2"
                            Grid.Column="0"
                            HorizontalAlignment="Center"
                            Visibility="{Binding DownTbkVisibility,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"/>
                </Grid>
            </Border>
        </Grid>
    </Grid>
</UserControl>



//usercontrol.xaml.cs
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Linq;
using System.Runtime.CompilerServices;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Animation;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;

namespace WpfApp201
{
    /// <summary>
    /// Interaction logic for UCScrollNum.xaml
    /// </summary>
    public partial class UCScrollNum : UserControl, INotifyPropertyChanged
    {
        public UCScrollNum()
        {
            InitializeComponent();
            this.DataContext = this;
        }



        public bool UCIsIncremented
        {
            get { return (bool)GetValue(UCIsIncrementedProperty); }
            set { SetValue(UCIsIncrementedProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCIsIncremented.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCIsIncrementedProperty =
            DependencyProperty.Register("UCIsIncremented", typeof(bool),
                typeof(UCScrollNum), new PropertyMetadata(true, OnUCIsIncrementedChanged));

        private static void OnUCIsIncrementedChanged(DependencyObject d, DependencyPropertyChangedEventArgs e)
        {

        }

        public Visibility UpTbkVisibility
        {
            get { return (Visibility)GetValue(UpTbkVisibilityProperty); }
            set { SetValue(UpTbkVisibilityProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UpTbkVisibility.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UpTbkVisibilityProperty =
            DependencyProperty.Register("UpTbkVisibility", typeof(Visibility),
                typeof(UCScrollNum), new PropertyMetadata(Visibility.Visible));






        public Visibility MiddleTbkVisibility
        {
            get { return (Visibility)GetValue(MiddleTbkVisibilityProperty); }
            set { SetValue(MiddleTbkVisibilityProperty, value); }
        }

        // Using a DependencyProperty as the backing store for MiddleTbkVisibility.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty MiddleTbkVisibilityProperty =
            DependencyProperty.Register("MiddleTbkVisibility", typeof(Visibility),
                typeof(UCScrollNum), new PropertyMetadata(Visibility.Visible));







        public Visibility DownTbkVisibility
        {
            get { return (Visibility)GetValue(DownTbkVisibilityProperty); }
            set { SetValue(DownTbkVisibilityProperty, value); }
        }

        // Using a DependencyProperty as the backing store for DownTbkVisibility.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty DownTbkVisibilityProperty =
            DependencyProperty.Register("DownTbkVisibility", typeof(Visibility),
                typeof(UCScrollNum), new PropertyMetadata(Visibility.Visible));




        public double UCScrollDuration
        {
            get { return (double)GetValue(UCScrollDurationProperty); }
            set { SetValue(UCScrollDurationProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCScrollDuration.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCScrollDurationProperty =
            DependencyProperty.Register("UCScrollDuration", typeof(double),
                typeof(UCScrollNum), new PropertyMetadata(1000.0d));






        public int UCValue
        {
            get { return (int)GetValue(UCValueProperty); }
            set { SetValue(UCValueProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCValue.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCValueProperty =
            DependencyProperty.Register("UCValue", typeof(int),
                typeof(UCScrollNum), new PropertyMetadata(0, OnUCValueChanged));

        private static void OnUCValueChanged(DependencyObject d, DependencyPropertyChangedEventArgs e)
        {
            var ucScrollNum = d as UCScrollNum;
            int newValue = 0;
            if (ucScrollNum != null && Int32.TryParse(e.NewValue?.ToString(), out newValue))
            {
                ucScrollNum.NumValue = newValue;
            }
        }

        public event PropertyChangedEventHandler PropertyChanged;
        private void OnPropertyChanged([CallerMemberName] string propName = "")
        {
            var handler = PropertyChanged;
            if (handler != null)
            {
                handler?.Invoke(this, new PropertyChangedEventArgs(propName));
            }
        }

        private int numValue = 0;

        public int NumValue
        {
            get
            {
                return numValue;
            }
            set
            {
                if (numValue != value)
                {
                    numValue = value;
                    OnPropertyChanged(nameof(NumValue));
                    OnUCValueChanged();
                }
            }
        }

        private void OnUCValueChanged()
        {
            if(UCIsIncremented)
            {
                int value = NumValue;
                int oldValue = value;
                if (++value > 9)
                {
                    value = 0;
                }
                int nextValue = value + 1;
                if (nextValue > 9)
                {
                    nextValue = 0;
                }
                AnimateChange(oldValue, value, nextValue, 30, -30, UCScrollDuration);
                Console.WriteLine($"{DateTime.Now},UCIsIncremented:{UCIsIncremented},oldValue:{oldValue},value:{value},nextValue:{nextValue}");
            }
            else
            {
                int value = NumValue;
                int oldValue = value;
                if(--value<0)
                {
                    value = 9;
                }
                int nextValue = value - 1;
                if(nextValue<0)
                {
                    nextValue = 9;
                }
                AnimateChange(nextValue, value,oldValue , -30, 30, UCScrollDuration);
                Console.WriteLine($"{DateTime.Now},UCIsIncremented:{UCIsIncremented},oldValue:{oldValue},value:{value},nextValue:{nextValue}");
            }
        }

        private void AnimateChange(int oldValue, int nowValue, int nextValue, int fromValue = 0, int toValue = 0, double durationValue = 1000)
        {
            Application.Current?.Dispatcher.BeginInvoke(new Action(() =>
            {
                numTbk1.Text = oldValue.ToString();
                numTbk2.Text = nowValue.ToString();
                numTbk3.Text = nextValue.ToString();
                var animation = new DoubleAnimation
                {
                    From = fromValue,
                    To = toValue,
                    Duration = TimeSpan.FromMilliseconds(durationValue)
                };

                // Apply animation
                var transform = new TranslateTransform();
                numTbk1.RenderTransform = transform;
                numTbk2.RenderTransform = transform;
                numTbk3.RenderTransform = transform;
                transform.BeginAnimation(TranslateTransform.YProperty, animation);
            }));
        }
    }
}



//window.xaml


<Window x:Class="WpfApp201.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
        xmlns:local="clr-namespace:WpfApp201"
        mc:Ignorable="d"
        xmlns:behavior="http://schemas.microsoft.com/xaml/behaviors"
        Title="MainWindow" Height="380" Width="500">
    <behavior:Interaction.Triggers>
        <behavior:EventTrigger EventName="MouseDown">
            <behavior:InvokeCommandAction Command="{Binding MouseDownCommand}"/>
        </behavior:EventTrigger>
    </behavior:Interaction.Triggers>
    <Grid>
        <Grid.RowDefinitions>
            <RowDefinition/>
            <RowDefinition Height="Auto"/>
            <RowDefinition/>
        </Grid.RowDefinitions>
        <local:UCScrollNum
             Grid.Row="1"
             HorizontalAlignment="Center"
             UCValue="{Binding DataContext.NumValue,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged,
             RelativeSource={RelativeSource Mode=FindAncestor,AncestorType={x:Type Window}}}"
             UCIsIncremented="{Binding DataContext.IsValueIncremented,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged,
            RelativeSource={RelativeSource Mode=FindAncestor,AncestorType={x:Type Window}}}"/>
    </Grid>
</Window>



//window.xaml.cs
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;

namespace WpfApp201
{
    /// <summary>
    /// Interaction logic for MainWindow.xaml
    /// </summary>
    public partial class MainWindow : Window
    {
        public MainWindow()
        {
            InitializeComponent();
            var vm = new MainVM();
            this.DataContext = vm;
        }
    }

    public class MainVM : INotifyPropertyChanged
    {
        private System.Timers.Timer tmr;

        public MainVM()
        {
            InitTmr();
        }

        private void InitTmr()
        {
             if(tmr==null)
            {
                tmr= new System.Timers.Timer();
                tmr.Interval = 1000;
                tmr.Elapsed += Tmr_Elapsed;
                tmr.Start();
            }
        }

        private void Tmr_Elapsed(object sender, System.Timers.ElapsedEventArgs e)
        {

            if(IsValueIncremented)
            {
                ++NumValue;
            }
            else
            {
                --NumValue;
            }
        }

        private ICommand mouseDownCommand;
        public ICommand MouseDownCommand
        {
            get
            {
                if(mouseDownCommand == null)
                {
                    mouseDownCommand = new DelCommand(MouseDownCommandExecuted, MouseDownCommandCanExecute);
                }
                return mouseDownCommand;
            }
        }

        private bool MouseDownCommandCanExecute(object obj)
        {
            return true;
        }

        private void MouseDownCommandExecuted(object obj)
        {
            IsValueIncremented = !IsValueIncremented;
        }

        public event PropertyChangedEventHandler PropertyChanged;
        private void OnPropertyChanged(string propertyName)
        {
            var handler = PropertyChanged;
            if (handler != null)
            {
                handler?.Invoke(this, new PropertyChangedEventArgs(propertyName));
            }
        }

        private int numValue;
        public int NumValue
        {
            get
            {
                return numValue;
            }
            set
            {
                if(value!=numValue)
                {
                    if(value>9)
                    {
                        value = 0;
                    }
                    if(value<0)
                    {
                        value = 9;
                    }
                    numValue = value;
                    OnPropertyChanged(nameof(NumValue));
                }
            }
        }

        private int num=60;
        public int Num
        {
            get
            {
                return num;
            }
            set
            {
                if(value!=num)
                {
                    num = value;
                    OnPropertyChanged(nameof(Num));
                    OnNumChanged();
                }
            }
        }

        private void OnNumChanged()
        {
            var tempNum = Num;
            HundredsNum = tempNum / 100;
            TensNum = tempNum % 100 / 10;
            UIntsNum= tempNum % 10;
            Console.WriteLine($"Num:{Num},HundredsNum:{HundredsNum},TensNum:{TensNum},UIntsNum:{UIntsNum}");
        }

        private int hundredsNum;
        public int HundredsNum
        {
            get
            {
                return hundredsNum;
            }
            set
            {
                if (value != hundredsNum)
                {
                    hundredsNum = value;
                    OnPropertyChanged(nameof(HundredsNum));
                }
            }
        }


        private int tensNum;
        public int TensNum
        {
            get
            {
                return tensNum;
            }
            set
            {
                if (value != tensNum)
                {
                    tensNum = value;
                    OnPropertyChanged(nameof(TensNum));
                }
            }
        }


        private int uIntsNum;
        public int UIntsNum
        {
            get
            {
                return uIntsNum;
            }
            set
            {
                if (value != uIntsNum)
                {
                    uIntsNum = value;
                    OnPropertyChanged(nameof(UIntsNum));
                }
            }
        }


        private bool isValueIncremented = true;
        public bool IsValueIncremented
        {
            get
            {
                return isValueIncremented;
            }
            set
            {
                if (value != isValueIncremented)
                {
                    isValueIncremented = value;
                    OnPropertyChanged(nameof(IsValueIncremented));
                }
            }
        }


        public class DelCommand : ICommand
        {
            private Action<object> execute;
            private Predicate<object> canExecute;
            public DelCommand(Action<object> executeValue, Predicate<object> canExecuteValue)
            {
                execute = executeValue;
                canExecute = canExecuteValue;
            }

            public event EventHandler CanExecuteChanged
            {
                add
                {
                    CommandManager.RequerySuggested += value;
                }
                remove
                {
                    CommandManager.RequerySuggested -= value;
                }
            }

            public bool CanExecute(object parameter)
            {
                if (canExecute == null)
                {
                    return true;
                }
                return canExecute(parameter);
            }

            public void Execute(object parameter)
            {
                execute(parameter);
            }
        }
    }
}
