//xaml
<Window x:Class="WpfApp302.MainWindow"
xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
xmlns:local="clr-namespace:WpfApp302"
mc:Ignorable="d" WindowState="Maximized"
Title="MainWindow" Height="450" Width="800">
<Window.Resources>
<Style TargetType="Thumb">
</Style>
</Window.Resources>
<Grid>
<Canvas x:Name="cvs" Panel.ZIndex="2" HorizontalAlignment="Stretch" VerticalAlignment="Stretch">
<Thumb x:Name="tb" Canvas.Left="100" Canvas.Top="0"
Background="Blue" Width="15"
Height="{Binding Path=ActualHeight, RelativeSource={RelativeSource Mode=FindAncestor,AncestorType=Canvas}}"
DragDelta="tb_DragDelta"
DragStarted="tb_DragStarted" DragCompleted="tb_DragCompleted">
<Thumb.Template>
<ControlTemplate>
<Border BorderBrush="Black" BorderThickness="2">
<Rectangle Fill="Blue"/>
</Border>
</ControlTemplate>
</Thumb.Template>
</Thumb>
</Canvas>
</Grid>
</Window>
//cs
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;
namespace WpfApp302
{
/// <summary>
/// Interaction logic for MainWindow.xaml
/// </summary>
public partial class MainWindow : Window
{
public MainWindow()
{
InitializeComponent();
LinearGradientBrush lineBrush = new LinearGradientBrush();
lineBrush.StartPoint = new Point(0, 0);
lineBrush.EndPoint = new Point(1, 1);
GradientStop gs1 = new GradientStop();
gs1.Offset = 0;
gs1.Color = Colors.Red;
lineBrush.GradientStops.Add(gs1);
GradientStop gs2 = new GradientStop();
gs2.Offset = 0.25;
gs2.Color = Colors.Brown;
lineBrush.GradientStops.Add(gs2);
GradientStop gs3 = new GradientStop();
gs3.Offset = 0.5;
gs3.Color = Colors.OrangeRed;
lineBrush.GradientStops.Add(gs3);
GradientStop gs4=new GradientStop();
gs4.Offset = 0.75;
gs4.Color = Colors.Orange;
lineBrush.GradientStops.Add(gs4);
GradientStop gs5 = new GradientStop();
gs5.Offset = 1;
gs5.Color = Colors.Yellow;
lineBrush.GradientStops.Add(gs5);
cvs.Background= lineBrush;
}
private void tb_DragDelta(object sender, System.Windows.Controls.Primitives.DragDeltaEventArgs e)
{
double xValue = Canvas.GetLeft(tb) + e.HorizontalChange;
Canvas.SetLeft(tb, xValue);
//Canvas.SetTop(tb, Canvas.GetTop(tb) + e.VerticalChange);
this.Title = $"X:{xValue}";
double yadjust = cvs.Height + e.VerticalChange;
double xadjust = cvs.Width + e.HorizontalChange;
if((xadjust>=0) && (yadjust>=0))
{
}
}
private void tb_DragStarted(object sender, System.Windows.Controls.Primitives.DragStartedEventArgs e)
{
tb.Background = Brushes.Orange;
}
private void tb_DragCompleted(object sender, System.Windows.Controls.Primitives.DragCompletedEventArgs e)
{
tb.Background = Brushes.Blue;
}
}
}
![]()
![]()
