Dijkstra算法求单源最短路径(有向网)

Dijkstra函数：

 1 //Dist[MAXVEX]，各顶点最短路径长度
 2 //Path[MAXVEX][MAXVEX]，若Path[i][j] = 1, 则 j 是从源点到 i 间最短路径上的顶点
 3 void Dijkstra(AdjMatrix* G, int start, int Dist[], int Path[][MAXVEX])
 4 {
 5     int mindist = 0;
 6     int i = 0, j = 0, k = 0, s = 0;
 7     int final[MAXVEX] = { 0 };
 8
 9     for (i = 0; i < G->vexnum; i++)//初始化最短路径及其权值
10     {
11         final[i] = 0;
12         Dist[i] = G->arcs[start][i];
13         if (Dist[i] < INFINITY)
14         {
15             Path[i][start] = 1;
16             Path[i][i] = 1;
17         }
18     }
19     Dist[start] = 0;
20     final[start] = 1;
21
22     //开始主循环，每次求得start到某个顶点的最短路径
23     for (i = 1; i < G->vexnum; i++)
24     {
25         mindist = INFINITY;
26         for (j = 0; j < G->vexnum; j++)
27         {
28             if (!final[j])
29             {
30                 if (Dist[j] < mindist)//顶点j离start更近
31                 {
32                     k = j;
33                     mindist = Dist[j];
34                 }
35             }
36         }
37         final[k] = 1;
38         for (j = 0; j < G->vexnum; j++)//更新当前最短路径及距离
39         {
40             if (!final[j] && (mindist + G->arcs[k][j] < Dist[j]))//若顶点k的最短路径距离 + k 到 j 的距离 < j 的原来最短路径距离
41             {
42                 Dist[j] = mindist + G->arcs[k][j];
43                 for (s = 0; s < G->vexnum; s++)// j 的最短路径 = k 的最短路径 + k 顶点
44                 {
45                     Path[j][s] = Path[k][s];
46                 }
47                 Path[j][j] = 1;
48             }
49         }
50     }
51 }

源代码：

  1 #define _CRT_SECURE_NO_WARNINGS
  2 #include <stdio.h>
  3 #include <stdlib.h>
  4 #define MAXVEX 20
  5 #define INFINITY 32767
  6
  7 typedef struct
  8 {
  9     int vexnum, arcnum;
 10     char vex[MAXVEX];
 11     int arcs[MAXVEX][MAXVEX];
 12 }AdjMatrix;//邻接矩阵
 13
 14 //Dist[MAXVEX]，各顶点最短路径长度
 15 //Path[MAXVEX][MAXVEX]，若Path[i][j] = 1, 则 j 是从源点到 i 间最短路径上的顶点
 16 void Dijkstra(AdjMatrix* G, int start, int Dist[], int Path[][MAXVEX])
 17 {
 18     int mindist = 0;
 19     int i = 0, j = 0, k = 0, s = 0;
 20     int final[MAXVEX] = { 0 };
 21
 22     for (i = 0; i < G->vexnum; i++)//初始化最短路径及其权值
 23     {
 24         final[i] = 0;
 25         Dist[i] = G->arcs[start][i];
 26         if (Dist[i] < INFINITY)
 27         {
 28             Path[i][start] = 1;
 29             Path[i][i] = 1;
 30         }
 31     }
 32     Dist[start] = 0;
 33     final[start] = 1;
 34
 35     //开始主循环，每次求得start到某个顶点的最短路径
 36     for (i = 1; i < G->vexnum; i++)
 37     {
 38         mindist = INFINITY;
 39         for (j = 0; j < G->vexnum; j++)
 40         {
 41             if (!final[j])
 42             {
 43                 if (Dist[j] < mindist)//顶点j离start更近
 44                 {
 45                     k = j;
 46                     mindist = Dist[j];
 47                 }
 48             }
 49         }
 50         final[k] = 1;
 51         for (j = 0; j < G->vexnum; j++)//更新当前最短路径及距离
 52         {
 53             if (!final[j] && (mindist + G->arcs[k][j] < Dist[j]))//若顶点k的最短路径距离 + k 到 j 的距离 < j 的原来最短路径距离
 54             {
 55                 Dist[j] = mindist + G->arcs[k][j];
 56                 for (s = 0; s < G->vexnum; s++)// j 的最短路径 = k 的最短路径 + k 顶点
 57                 {
 58                     Path[j][s] = Path[k][s];
 59                 }
 60                 Path[j][j] = 1;
 61             }
 62         }
 63     }
 64 }
 65
 66 int LocateVex(AdjMatrix* G, char vex)
 67 {
 68     int i = 0;
 69     for (i = 0; i < G->vexnum; i++)
 70     {
 71         if (G->vex[i] == vex)
 72         {
 73             return i;
 74         }
 75     }
 76     return -1;
 77 }
 78
 79 void Create(AdjMatrix* G)
 80 {
 81     int i = 0, j = 0, k = 0;
 82     int weight = 0;
 83     char vex1 = '\0', vex2 = '\0';
 84
 85     printf("请输入顶点数和弧数(逗号分隔)：");
 86     scanf("%d%*c%d", &G->vexnum, &G->arcnum);
 87
 88     for (i = 0; i < G->vexnum; i++)//弧初始化
 89     {
 90         for (j = 0; j < G->vexnum; j++)
 91         {
 92             G->arcs[i][j] = INFINITY;
 93         }
 94     }
 95     for (i = 0; i < G->vexnum; i++)
 96     {
 97         printf("请输入第%d个顶点：", i + 1);
 98         scanf(" %c", &G->vex[i]);
 99     }
100     for (k = 0; k < G->arcnum; k++)
101     {
102         printf("请输入第%d条弧的尾、头和权值(逗号分隔)：", k + 1);
103         scanf(" %c%*c%c%*c%d", &vex1, &vex2, &weight);
104         i = LocateVex(G, vex1);
105         j = LocateVex(G, vex2);
106         G->arcs[i][j] = weight;
107     }
108 }
109
110 void Print(AdjMatrix* G, int Dist[], int Path[][MAXVEX])
111 {
112     int i = 0, j = 0;
113     for (i = 1; i < G->vexnum; i++)
114     {
115         if (Dist[i] == INFINITY)
116         {
117             printf("%c无最短路径\n", G->vex[i]);
118             continue;
119         }
120         else
121         {
122             printf("%c的最短路径长度：%d\t", G->vex[i], Dist[i]);
123             printf("最短路径为：");
124         }
125         for (j = 0; j < G->vexnum; j++)
126         {
127             if (Path[i][j])
128             {
129                 printf("%c ", G->vex[j]);
130             }
131         }
132         printf("\n");
133     }
134 }
135
136 int main(void)
137 {
138     AdjMatrix G;
139     int Dist[MAXVEX] = { 0 };//各顶点最短路径长度
140     int Path[MAXVEX][MAXVEX] = { 0 };//若Path[i][j] = 1, 则 j 是从源点到 i 间最短路径上的顶点
141     Create(&G);
142     Dijkstra(&G, 0, Dist, Path);
143     Print(&G, Dist, Path);
144     system("Pause");
145     return 0;
146 }
源代码
