D-BUS、GDBUS【IPC】

D-BUS、GDBUS简述

D-BUS简述

reference :
https://blog.csdn.net/f110300641/article/details/106823611，
https://dbus.freedesktop.org/doc/dbus-specification.html,
Linux进程间通信：dbus的使用（2）—— D-Bus介绍及signal、method测试例程_dbus signal-CSDN博客

D-BUS是一种低开销、易于使用的进程间通信系统（IPC）。


消息总线

  • 消息总线分为：

    • 会话总线（session bus）
    • 系统总线（system bus）
    特性 Session Bus System Bus
    启动时机 用户登录时 系统启动时（由 systemd 管理）
    权限 用户级权限 ​root 权限
    配置文件 ​session.conf，用户级服务描述文件 ​system.conf，系统服务描述文件
    典型应用 桌面应用集成（如通知系统） 硬件事件（如 USB 插入）、系统服务通信
    地址固定性 动态地址（环境变量指定） 固定地址（/var/run/dbus/system_bus_socket）

  • dbus-daemon（消息总线​守护进程​ ）

    • dbus-daemon与session bus是一一对应的，每个活跃的用户会话（Session）都拥有一个独立的 ​dbus-daemon​ 进程，专门负责管理该会话内的所有消息路由和服务注册。二者是同一实体的逻辑与物理表现。
    • 此进程的生命周期与用户会话绑定：用户登录时创建，用户注销时终止。
    • system bus同样有一个对应的dbus-daemon。

消息

  • dbus中的消息有四种类型：

    • method call
    • method return
    • signal
    • error

  • signal与method的区别：

    • signal是一对多，method是一对一
    • signal是单向的，不返回。method消息发出后，发出方会收到返回消息。

对象路径、接口

  • 连接（Bus name）标识与会话总线的连接，表示一个dbus服务

  • 对象路径（Object Path）唯一标识服务中的对象实例（类似文件路径），标识资源的路径。命名规则：采用斜杠分隔的层次结构，如 /org/kde/Device1。

  • 接口名称（Interface Name），定义对象的能力契约，包含方法、信号和属性（类似抽象类）。可以被不同的对象实现。采用反向域名格式（如 org.freedesktop.DBus.Properties），需在总线范围内唯一。接口与对象是解耦的，二者名称并不需要严格对应。

  • 方法和信号隶属于接口。

层级关系：

Bus name -》Path-》Interface-》Method/Signal

D-BUS使用

  • 安装：sudo apt install dbus​

  • 包含头文件：#include <dbus/dbus.h>​

  • signal

    • 发送方步骤：

      1. 建立与会话总线的连接
      2. 给该连接注册名称（可选）
      3. 创建信号
      4. 发送信号
      5. 释放资源

    • 接收方步骤：

      1. 建立与会话总线的连接
      2. 给该连接注册名称（可选）
      3. 添加监听匹配规则（需要发送方的接口名、信号名，以及路径（可选），如果给定路径，则只接收该路径对象的信号，否则接收所有实现该接口的对象信号）
      4. 循环监听
      5. 信号参数解析

  • method_call & method_reply

    • 被调用方步骤：

      1. 建立连接

      2. 注册连接名称（必须）

      3. 循环监听

      4. 解析调用消息并处理

        1. 读取消息中携带的参数，进行相应的处理
        2. 创建返回消息，将处理结果传入返回消息变量中
        3. 发送返回消息

    • 调用方步骤：

      1. 建立连接
      2. 注册连接名称
      3. 创建调用消息（需要被调用方的连接名、对象路径、接口名和方法名），给定调用参数
      4. 发送消息
      5. 接收响应

信号发送接收示例

发送

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <dbus/dbus.h>
#include <unistd.h>

int send_a_signal(char *sigvalue)

{

// 创建所需变量

DBusError err;

DBusConnection *connection;

DBusMessage *msg;

DBusMessageIter arg;

dbus_uint32_t  serial = 0;

int ret;


// 步骤1:建立与session bus的连接
dbus_error_init(&amp;err);  // 初始化错误结构体
connection = dbus_bus_get(DBUS_BUS_SESSION, &amp;err );  // 获取一个与session bus的连接
if(dbus_error_is_set(&amp;err)){
	fprintf(stderr, &quot;ConnectionErr : %s\n&quot;, err.message);
	dbus_error_free(&amp;err);
}
if(connection == NULL)
	return -1;

// 步骤2:给连接注册一个名字，这个步骤不是必须的



if 1


ret = dbus_bus_request_name(connection, &quot;org.example.SignalSource&quot;, DBUS_NAME_FLAG_REPLACE_EXISTING, &amp;err);
if(dbus_error_is_set(&amp;err)){
	fprintf(stderr,&quot;Name Err :%s\n&quot;, err.message);
	dbus_error_free(&amp;err);
}
if(ret != DBUS_REQUEST_NAME_REPLY_PRIMARY_OWNER)
	return -1;



endif


// 步骤3:发送一个信号
// 创建message，message参数中包含这个信号的路径，接口，以及信号名
if((msg = dbus_message_new_signal(&quot;/org/example/SignalService/Sender&quot;, &quot;org.example.Signal.Test&quot;, &quot;Test&quot;))== NULL){
	fprintf(stderr, &quot;MessageNULL\n&quot;);
	return -1;
}
// 给这个messge具体的内容
dbus_message_iter_init_append(msg, &amp;arg);
if(!dbus_message_iter_append_basic(&amp;arg, DBUS_TYPE_STRING, &amp;sigvalue)){
	fprintf(stderr, &quot;Out OfMemory!\n&quot;);
	return -1;
}

// 步骤4: 将信号通过连接发送
if(!dbus_connection_send(connection, msg, &amp;serial)){
	fprintf(stderr, &quot;Out of Memory!\n&quot;);
	return -1;
}
dbus_connection_flush(connection);
printf(&quot;Signal Send\n&quot;);

// 步骤5: 释放资源。
dbus_message_unref(msg);
return 0;



}


int main( int argc, char **argv){

send_a_signal("Hello,world!");

return 0;

}

部分函数详述

dbus_connection_send

dbus_bool_t dbus_connection_send(
    DBusConnection *connection,  // D-Bus 连接对象指针
    DBusMessage    *message,     // 待发送的消息对象指针
    dbus_uint32_t  *serial       // 返回消息序列号（可选）
);

  • ​​connection​：

    • 类型：DBusConnection*​
    • 作用：通过 dbus_bus_get(DBUS_BUS_SESSION/SYSTEM, ...) 获取的会话或系统总线连接对象

  • ​message：

    • 类型：DBusMessage*​
    • 作用：需发送的消息对象

  • ​serial：

    • 类型：dbus_uint32_t ，实质就是无符号32位整数
    • 作用：可选参数。若传入非 NULL 指针，函数会将消息的唯一序列号写入该地址，用于跟踪消息（如调试），该序列号唯一企鹅递增。该消息的值由dbus内部程序写入，使用者不该写入值。

接收

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <dbus/dbus.h>
#include <unistd.h>

void listen_signal()

{

// 创建所需变量

DBusMessage *msg;

DBusMessageIter arg;

DBusConnection *connection;

DBusError err;

int ret;

char * sigvalue;


// 步骤1:建立与session bus的连接
dbus_error_init(&amp;err);
connection = dbus_bus_get(DBUS_BUS_SESSION, &amp;err);
if(dbus_error_is_set(&amp;err)){
	fprintf(stderr, &quot;ConnectionError %s\n&quot;, err.message);
	dbus_error_free(&amp;err);
}
if(connection == NULL)
return;

// 步骤2:给连接注册一个名称，非必需但推荐
ret = dbus_bus_request_name(connection, &quot;org.example.SignalReceiver&quot;, DBUS_NAME_FLAG_REPLACE_EXISTING, &amp;err);
if(dbus_error_is_set(&amp;err)){
	fprintf(stderr, &quot;Name Error%s\n&quot;, err.message);
	dbus_error_free(&amp;err);
}
if(ret != DBUS_REQUEST_NAME_REPLY_PRIMARY_OWNER)
return;

// 步骤3:添加监听匹配规则
dbus_bus_add_match(connection, &quot;type='signal', interface='org.example.Signal.Test', path='/org/example/SignalService/Sender'&quot;, &amp;err);
dbus_connection_flush(connection);  // 立即将规则发送给 dbus-daemon，确保实时生效
if(dbus_error_is_set(&amp;err)){
	fprintf(stderr, &quot;Match Error%s\n&quot;, err.message);
	dbus_error_free(&amp;err);
}

// 步骤4:在循环中监听，每隔开1秒，就去试图自己的连接中获取这个信号。这里给出的是从连接中获取任何消息的方式，所以获取后去检查一下这个消息是否我们期望的信号，并获取内容。我们也可以通过这个方式来获取method call消息。
while(1){
	dbus_connection_read_write(connection, 0);  // 非阻塞读写
	msg = dbus_connection_pop_message(connection);
	if(msg == NULL){
		sleep(1);
		continue;
	}

	if(dbus_message_is_signal(msg, &quot;org.example.Signal.Test&quot;, &quot;Test&quot;)){
		if(!dbus_message_iter_init(msg, &amp;arg))
			fprintf(stderr, &quot;MessageHas no Param&quot;);
		else if(dbus_message_iter_get_arg_type(&amp;arg) != DBUS_TYPE_STRING)
			fprintf(stderr, &quot;Param isnot string&quot;);
		else
			dbus_message_iter_get_basic(&amp;arg, &amp;sigvalue);
		printf(&quot;Got Singal withvalue : %s\n&quot;, sigvalue);
	}
	dbus_message_unref(msg);
}//End of while



}


int main(int argc, char **argv){

listen_signal();

return 0;

}

编译

CMakeLists.txt

cmake_minimum_required(VERSION 3.16)

project(dbus_test)


aux_source_directory(. SRCS)


add_executable(test ${SRCS})


target_link_libraries(test dbus-1)

编译可能遇到的问题

  • 缺少<dbus/dbus.h>，解决方法：

    • 安装dbus库，若仍未解决，执行下一步

    • ​sudo ln -sf /usr/include/dbus-1.0/dbus /usr/include/dbus，原因：

      • 默认安装的dbus可能在/usr/include/dbus-1.0下
      • 而程序中自动包含的头文件默认是去/usr/include下查找，上述操作是在/usr/include创建了所需头文件的软连接

  • 缺少dbus-arch-deps.h，解决方法：

    • ​sudo ln -sf /usr/include/dbus-1.0/dbus/dbus-arch-deps.h /usr/include/dbus，原因同上

方法调用示例

被调用方

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <dbus/dbus.h>
#include <unistd.h>

void reply_to_method_call(DBusMessage *msg, DBusConnection *conn)

{

DBusMessage *reply;

DBusMessageIter iter;

dbus_uint32_t serial = 0;

int param1, param2;

// 1 读取消息中携带的参数

if(!dbus_message_iter_init(msg, &iter))

{

printf("Message has noargs\n");

return;

}

// 读取第一个参数

if(dbus_message_iter_get_arg_type(&iter) != DBUS_TYPE_INT32)

{

printf("arg1 type error, should intger!\n");

return;

}

else

{

dbus_message_iter_get_basic(&iter, &param1);

dbus_message_iter_next(&iter);  // 迭代器后移一位

}

// 读取第二个参数

if(dbus_message_iter_get_arg_type(&iter) != DBUS_TYPE_INT32)

{

printf("arg2 type error, should intger!\n");

}

else

{

dbus_message_iter_get_basic(&iter, &param2);

}


printf(&quot;receive method call, param is %d and %d\n&quot;, param1, param2);
int result = param1 + param2;

// 2 创建返回消息reply
reply = dbus_message_new_method_return(msg);
// 通过消息迭代器在返回消息中填入结果
dbus_message_iter_init_append(reply, &amp;iter);
if(!dbus_message_iter_append_basic(&amp;iter, DBUS_TYPE_INT32, &amp;result)){
	printf(&quot;Out ofMemory!\n&quot;);
	exit(1);
}

// 3 发送返回消息
if(!dbus_connection_send(conn, reply, &amp;serial)){
	printf(&quot;Out of Memory\n&quot;);
	exit(1);
}
dbus_connection_flush(conn);
dbus_message_unref(reply);



}


void listen_dbus()

{

DBusMessage *msg;

DBusConnection *connection;

DBusError err;


// 步骤1 建立连接
dbus_error_init(&amp;err);
connection = dbus_bus_get(DBUS_BUS_SESSION, &amp;err);
if(dbus_error_is_set(&amp;err)){
    fprintf(stderr, &quot;ConnectionError %s\n&quot;, err.message);
    dbus_error_free(&amp;err);
}
if(connection == NULL)
    return;

// 步骤2 设置连接名
int ret = dbus_bus_request_name(connection, &quot;org.example.MethodCallable&quot;, DBUS_NAME_FLAG_REPLACE_EXISTING, &amp;err);
if(dbus_error_is_set(&amp;err)){
    fprintf(stderr, &quot;Name Error %s\n&quot;, err.message);
    dbus_error_free(&amp;err);
}
while(1)
{
    // 步骤3 循环监听
    dbus_connection_read_write(connection, 0);
	msg = dbus_connection_pop_message(connection);

	if(msg == NULL){
		sleep(1);
		continue;
	}
    // 步骤4 解析调用消息并处理
    if(strcmp(dbus_message_get_path(msg), &quot;/org/example/MethodService/Object&quot;) == 0){
		if(dbus_message_is_method_call(msg, &quot;org.example.MethodService.Add&quot;, &quot;AddMethod&quot;)){
			reply_to_method_call(msg, connection);
        }
    }
    dbus_message_unref(msg);
}



}


int main(int argc, char **argv){

listen_dbus();

return 0;

}

调用方

#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <dbus/dbus.h>
#include <unistd.h>

DBusConnection* connect_dbus()

{

DBusError err;

DBusConnection *connection;

int ret;


// 步骤1 建立连接
dbus_error_init(&amp;err);
connection = dbus_bus_get(DBUS_BUS_SESSION, &amp;err);
if(dbus_error_is_set(&amp;err)){
	fprintf(stderr, &quot;ConnectionErr : %s\n&quot;, err.message);
	dbus_error_free(&amp;err);
}
if(connection == NULL)
	return NULL;

// 步骤2 注册连接名称
ret = dbus_bus_request_name(connection, &quot;org.example.MethodCall&quot;, DBUS_NAME_FLAG_REPLACE_EXISTING, &amp;err);
if(dbus_error_is_set(&amp;err)){
	fprintf(stderr, &quot;Name Err :%s\n&quot;, err.message);
	dbus_error_free(&amp;err);
}
if(ret != DBUS_REQUEST_NAME_REPLY_PRIMARY_OWNER)
	return NULL;

return connection;



}


void send_a_method_call(DBusConnection *connection, int param1, int param2)

{

DBusError err;

DBusMessage *msg;

DBusMessageIter iter;

DBusPendingCall *pending;

int result;


// 步骤3 创建调用消息
dbus_error_init(&amp;err);
msg = dbus_message_new_method_call(&quot;org.example.MethodCallable&quot;, &quot;/org/example/MethodService/Object&quot;,
    &quot;org.example.MethodService.Add&quot;, &quot;AddMethod&quot;);
if(msg == NULL){
	fprintf(stderr, &quot;MessageNULL&quot;);
	return;
}

// 给定调用参数
dbus_message_iter_init_append(msg, &amp;iter);
if(!dbus_message_iter_append_basic(&amp;iter, DBUS_TYPE_INT32, &amp;param1)){
	fprintf(stderr, &quot;Out of Memory!&quot;);
	exit(1);
}

if(!dbus_message_iter_append_basic(&amp;iter, DBUS_TYPE_INT32, &amp;param2)){
	fprintf(stderr, &quot;Out of Memory!&quot;);
	exit(1);
}

// 步骤4 发送消息，pending用于接收调用后的方法响应
if(!dbus_connection_send_with_reply(connection, msg, &amp;pending, -1)){
	fprintf(stderr, &quot;Out of Memory!&quot;);
	exit(1);
}

if(pending == NULL){
	fprintf(stderr, &quot;Pending CallNULL: connection is disconnected &quot;);
	dbus_message_unref(msg);
	return;
}

dbus_connection_flush(connection);
dbus_message_unref(msg);

// 步骤5 接收响应
dbus_pending_call_block(pending);
// 从响应中拿取数据
msg = dbus_pending_call_steal_reply(pending);
if (msg == NULL) {
	fprintf(stderr, &quot;ReplyNull\n&quot;);
	exit(1);
}
dbus_pending_call_unref(pending);
// 读取响应数据
if(!dbus_message_iter_init(msg, &amp;iter))
	fprintf(stderr, &quot;Message has no ret!\n&quot;);
else if (dbus_message_iter_get_arg_type(&amp;iter) != DBUS_TYPE_INT32)
	fprintf(stderr, &quot;Argument is not integer!\n&quot;);
else
	dbus_message_iter_get_basic(&amp;iter, &amp;result);

printf(&quot;Got Reply: %d\n&quot;, result);
dbus_message_unref(msg);



}


int main()

{

send_a_method_call(connect_dbus(), 5, 10);


return 0;



}

GDBUS

**reference：**​Gio – 2.0: 迁移到 GDBus - GTK 文档

GDBUS简述

GDBus是DBus协议的现代C语言实现，属于GLib的一部分，具有以下特点：

  • 独立实现

    GDBus并非基于libdbus，而是重新实现了DBus协议，使用GIO流（GIO Stream）作为传输层，避免了libdbus的多线程问题

  • 类型系统优化

    使用GVariant处理数据（替代dbus-glib的GObject类型系统），完美匹配DBus的二进制数据类型（如整型、字符串、结构体等），简化了数据序列化

  • 异步与集成

    原生支持异步操作（如g_dbus_proxy_call()），避免阻塞主线程，并深度集成GLib事件循环（GMainLoop），适合GUI应用开发

  • 工具链支持

    提供gdbus-codegen工具，根据XML接口描述文件自动生成C代码（如代理类、服务端骨架），减少手写样板代码

维度 DBus（协议） GDBus（实现）
定位 进程间通信规范 GLib库提供的DBus实现
核心实现 多实现并存（libdbus、sd-bus等） 独立实现，基于GIO流
开发便利性 底层API复杂 高层封装，支持异步与代码生成
生态依赖 无 依赖GLib/GObject
适用场景 所有DBus兼容系统 GNOME应用或深度集成GLib的项目

常用函数

​g_bus_own_name​​

声明
guint
g_bus_own_name (
  GBusType bus_type,
  const gchar* name,
  GBusNameOwnerFlags flags,
  GBusAcquiredCallback bus_acquired_handler,
  GBusNameAcquiredCallback name_acquired_handler,
  GBusNameLostCallback name_lost_handler,
  gpointer user_data,
  GDestroyNotify user_data_free_func
)
描述

连接到bus_type指定的总线，并在该总线注册一个连接名称，在总线获取成功时调用bus_acquired_handler，并分别在名称获取或丢失时调用name_acquired_handler和name_lost_handler。

参数

  • ​**bus\_type**​

    • 类型：GBusType ​
    • 说明：一般都是G_BUS_TYPE_SESSION​

  • ​name​

    • 类型：const gchar*​
    • 要给本连接注册的well-known名称

  • ​flags​

    • 类型：GBusNameOwnerFlags ​
    • 说明：多数时取值G_BUS_NAME_OWNER_FLAGS_REPLACE| G_BUS_NAME_OWNER_FLAGS_ALLOW_REPLACEMENT，意为如果另一个消息总线连接拥有该名称并指定了 G_BUS_NAME_OWNER_FLAGS_ALLOW_REPLACEMENT，则从该连接中取走该名称。

  • ​bus_acquired_handler​

    • 类型：

      void
(* GBusAcquiredCallback) (
  GDBusConnection* connection,
  const gchar* name,
  gpointer user_data
)

    • 说明：在连接到类型为bus_type的总线或NULL时调用的处理程序。

  • ​name_acquired_handler​

    • 类型：

      void
(* GBusNameAcquiredCallback) (
  GDBusConnection* connection,
  const gchar* name,
  gpointer user_data
)

    • 说明：在名称被获取时调用。

  • ​name_lost_handler​

    • 类型：

      void
(* GBusNameLostCallback) (
  GDBusConnection* connection,
  const gchar* name,
  gpointer user_data
)

    • 说明：当名称丢失或连接被关闭时调用。

  • ​user_data​

    • 类型：gpointer，实质是void*​
    • 说明：传递给处理器的用户数据。参数可以是NULL。数据由函数的调用者拥有。

  • ​user_data_free_func​

    • 类型

      void
(* GDestroyNotify) (
  gpointer data
)

    • 说明：指定在销毁数据元素时调用的函数类型。它将指针传递给数据元素，并应释放为此分配的任何内存和资源。参数可以为 NULL。

返回值
  • 类型：guint​
  • 说明：一个可用于与 g_bus_unown_name() 一起使用的标识符（永远不会是 0），用于停止拥有该名称。

g_bus_unown_name​

声明
void
g_bus_unown_name (
  guint owner_id
)
描述

停止拥有一个名称。

参数
  • ​owner_id
    ​g_bus_own_name的返回值

​g_signal_connect​

声明
#define g_signal_connect (
  instance,
  detailed_signal,
  c_handler,
  data
)
说明：

将 GCallback 函数连接到特定对象的信号。这里是这样一种思想：XML文件中定义了Method，客户端调用该Method时，会向服务端发出一个处理该方法的信号。若是服务端使用此函数将信号与一个回调函数连接，就会在收到信号时触发该回调函数。这种handle-method信号由gdbus-codegen工具根据XML文件中定义的方法自动生成的信号。

详细说明：GObject.signal_connect - GTK 文档。

参数

  • ​instance​

    • 类型：形如ExampleAnimal，是由gdbus-codegen工具根据XML文件生成的文件中定义的结构体类型。
    • 具体内容：形如example_animal_skeleton_new()函数创建的对象实例。标识
      ​example_animal_skeleton_new也是gdbus-codegen工具根据XML文件生成的函数。
      ​example_animal是根据gdbus-codegen工具选项和XML文件内容生成的名称，会作为所有生成的函数或是宏的名称的前缀。其中example是gdbus-codegen工具选项--c-namespace Example定义的，animal则是XML文件中定义的接口名称。

  • ​detailed_signal​

    • 类型：一个标识XML文件中定义的方法的字符串。

    • 具体内容：handle-{methodname}，其中handle是固定前缀，methodname是由XML文件中定义的方法名转换而来的。具体转换方式为从驼峰命名转换成小写且以-连接。如GetIp → get-ip。可以在gdbus-codegen生成的代码中查找信号名，形如

      static const _ExtendedGDBusMethodInfo _example_animal_method_info_poke =
{
  {
    -1,
    (gchar *) "Poke",
    (GDBusArgInfo **) &_example_animal_method_info_poke_IN_ARG_pointers,
    (GDBusArgInfo **) &_example_animal_method_info_poke_OUT_ARG_pointers,
    NULL
  },
  "handle-poke",
  FALSE
};

      形式的结构体赋值语句，结构体的原型为

      typedef struct
{
  GDBusMethodInfo parent_struct;
  const gchar *signal_name;
  gboolean pass_fdlist;
} _ExtendedGDBusMethodInfo;

      也就是说，"handle-poke"就是生成代码为Poke方法创建的信号。

  • ​c_handler​

    • 类型：形如

      static gboolean on_animal_poke (
    ExampleAnimal *object,
    GDBusMethodInvocation *invocation,
    gboolean arg_make_sad,
    gboolean arg_make_happy,
	gpointer user_data
	)

      形式的函数指针。要使用G_CALLBACK转换该函数指针。

    • 具体说明：相较于生成的头文件中struct _ExampleAnimalIface​

      struct _ExampleAnimalIface
{
  GTypeInterface parent_iface;

      gboolean (*handle_poke) (

ExampleAnimal *object,

GDBusMethodInvocation *invocation,

gboolean arg_make_sad,

gboolean arg_make_happy);


      const gchar * (*get_foo) (ExampleAnimal *object);


      const gchar * (*get_mood) (ExampleAnimal *object);


      void (*jumped) (

ExampleAnimal *object,

gdouble arg_height);


      const gchar * (*get_bar) (ExampleAnimal *object);


      };

      内定义的handle_poke函数指针，该函数中多了一个gpointer类型的参数，gpointer实质是void*类型，用于传递自定义的一些数据。此处的函数指针名称不作要求，但一般形式都是on_接口名_方法名。

  • data

    • 类型：gpointer​
    • 用于传递自定义的一些数据，如不需要，可为NULL

g_main_loop_new​

声明
GMainLoop*
g_main_loop_new (
  GMainContext* context,
  gboolean is_running
)
描述

创建一个新的 GMainLoop 结构体。GMainLoop 结构是一个不透明的数据类型，它表示 GLib 或 GTK 应用程序的主事件循环。

参数

  • ​context​

    • 类型：GMainContext*。GMainContext 结构体是不透明的数据类型，用于表示要主循环中处理的一组源。
    • 说明：此参数可以为NULL，如果为 NULL，将使用全局默认的主上下文。数据由函数的调用者持有。

  • ​is_running​

    • 设置为 TRUE 以指示循环正在运行。这并不很重要，因为调用 g\_main\_loop\_run() 无论如何都会将其设置为 TRUE。
返回值
  • 类型：GMainLoop​
  • 说明：一个新的 GMainLoop。函数的调用者负责数据的所有权，并负责释放它。

g_main_loop_run​

声明
void
g_main_loop_run (
  GMainLoop* loop
)
描述

运行主循环，直到在循环上调用 g\_main\_loop\_quit()。如果这是在循环的 GMainContext 线程上调用，它将处理循环的事件，否则它将只等待。

参数

  • ​loop​

    ​g_main_loop_new返回的对象

g_main_loop_unref​

声明
void
g_main_loop_unref (
  GMainLoop* loop
)
描述

通过一个 GMainLoop 对象的引用次数减一。如果结果是零，则释放循环及其所有相关内存。

g_main_loop_quit​

声明
void
g_main_loop_quit (
  GMainLoop* loop
)
描述

停止 GMainLoop 的运行。对于此循环的任何 g\_main\_loop\_run() 调用都将返回。

注意，当调用 g\_main\_loop\_quit() 时，已调度的事件源仍将被执行。

流程

服务端流程

  1. ​g_main_loop_new创建主事件循环对象
  2. ​g_bus_own_name创建连接并注册连接名称，且注册回调函数（所有事件都在回调函数中处理）
  3. ​g_main_loop_run启动主事件循环
  4. ​g_bus_unown_name停止拥有之前注册的连接名称
  5. ​g_main_loop_unref释放主事件循环对象资源

客户端流程

  1. ​g_main_loop_new创建主事件循环对象
  2. ​example_object_manager_client_new_for_bus_sync​同步创建并返回一个对象管理代理客户端（该函数是gdbus-codegen根据XML文件生成的头文件和源文件中包含的函数，并且有异步版本）
  3. 使用上一步获取到的对象管理代理客户端，进行方法调用，以及可选的连接该对象的信号和回调函数。
  4. ​g_main_loop_run启动主事件循环
  5. 停止循环，释放资源

整体流程

  1. 创建XML文件，在其中写定接口，接口中包含方法、信号、属性等定义；

  2. 使用gdbus-codegen工具根据XML文件生成代码，包括一个头文件和一个源文件；

  3. 引入生成的头文件，利用其中包含的函数和宏等编写代码；

  4. 编译运行。

示例代码

gdbus-example-objectmanager.xml​

<node>
  <!-- org.gtk.GDBus.Example.ObjectManager.Animal:
       @short_description: Example docs generated by gdbus-codegen
       @since: 2.30

   This D-Bus interface is used to describe a simple animal.
--&gt;



<interface name="org.gtk.GDBus.Example.ObjectManager.Animal">

<!-- Mood: The mood of the animal.

@since: 2.30


     Known values for this property include
     &lt;literal&gt;Happy&lt;/literal&gt; and &lt;literal&gt;Sad&lt;/literal&gt;. Use the
     org.gtk.GDBus.Example.ObjectManager.Animal.Poke() method to
     change this property.

     This property influences how often the animal jumps up and
     down, see the
     #org.gtk.GDBus.Example.ObjectManager.Animal::Jumped signal
     for more details.
--&gt;
&lt;property name=&quot;Mood&quot; type=&quot;s&quot; access=&quot;read&quot;/&gt;

&lt;!--
    Poke:
    @make_sad: Whether to make the animal sad.
    @make_happy: Whether to make the animal happy.
    @since: 2.30

    Method used to changing the mood of the animal. See also the
    #org.gtk.GDBus.Example.ObjectManager.Animal:Mood property.
  --&gt;
&lt;method name=&quot;Poke&quot;&gt;
  &lt;arg direction=&quot;in&quot; type=&quot;b&quot; name=&quot;make_sad&quot;/&gt;
  &lt;arg direction=&quot;in&quot; type=&quot;b&quot; name=&quot;make_happy&quot;/&gt;
  &lt;arg direction=&quot;out&quot; type=&quot;b&quot; name=&quot;result&quot;/&gt;
&lt;/method&gt;

&lt;!--
    Jumped:
    @height: Height, in meters, that the animal jumped.
    @since: 2.30

    Emitted when the animal decides to jump.
  --&gt;
&lt;signal name=&quot;Jumped&quot;&gt;
  &lt;arg type=&quot;d&quot; name=&quot;height&quot;/&gt;
&lt;/signal&gt;

&lt;!--
    Foo:
    Property with no &lt;quote&gt;since&lt;/quote&gt; annotation (should inherit the 2.30 from its containing interface).
  --&gt;
&lt;property name=&quot;Foo&quot; type=&quot;s&quot; access=&quot;read&quot;/&gt;

&lt;!--
    Bar:
    @since: 2.36
    Property with a later &lt;quote&gt;since&lt;/quote&gt; annotation.
  --&gt;
&lt;property name=&quot;Bar&quot; type=&quot;s&quot; access=&quot;read&quot;/&gt;



</interface>


<!-- org.gtk.GDBus.Example.ObjectManager.Cat:

@short_description: More example docs generated by gdbus-codegen


   This D-Bus interface is used to describe a cat. Right now there
   are no properties, methods or signals associated with this
   interface so it is essentially a &lt;ulink
   url=&quot;http://en.wikipedia.org/wiki/Marker_interface_pattern&quot;&gt;Marker
   Interface&lt;/ulink&gt;.

   Note that D-Bus objects implementing this interface also
   implement the #org.gtk.GDBus.Example.ObjectManager.Animal
   interface.
--&gt;



<interface name="org.gtk.GDBus.Example.ObjectManager.Cat">

</interface>

</node>

​gdbus-example-server.c​

#include "generated-code.h"
#include <gio/gio.h>

/* ---------------------------------------------------------------------------------------------------- */


static GDBusObjectManagerServer *manager = NULL;

// handle-poke信号对应的回调函数

static gboolean

on_animal_poke(ExampleAnimal *animal,

GDBusMethodInvocation *invocation,

gboolean make_sad,

gboolean make_happy,

gboolean result,

gpointer user_data)

{

g_print("receive call!\n");

if ((make_sad && make_happy) || (!make_sad && !make_happy))

{

g_dbus_method_invocation_return_dbus_error(invocation,

"org.gtk.GDBus.Examples.ObjectManager.Error.Failed",

"Exactly one of make_sad or make_happy must be TRUE");

goto out;

}


if (make_sad)
{
    if (g_strcmp0(example_animal_get_mood(animal), &quot;Sad&quot;) == 0)
    {
        g_dbus_method_invocation_return_dbus_error(invocation,
                                                   &quot;org.gtk.GDBus.Examples.ObjectManager.Error.SadAnimalIsSad&quot;,
                                                   &quot;Sad animal is already sad&quot;);
        goto out;
    }
    result = TRUE;
    g_print(&quot;set_mood!\n&quot;);
    example_animal_set_mood(animal, &quot;Sad&quot;);
    g_print(&quot;complete_poke!\n&quot;);
    example_animal_complete_poke(animal, invocation, result);
    static gdouble height = 0.0;
    height += 10.0; // Increment height for each poke
    g_print(&quot;emit_jumped!\n&quot;);
    example_animal_emit_jumped(animal, height); // Emit the jumped signal with a height of 55.55
    goto out;
}

if (make_happy)
{
    if (g_strcmp0(example_animal_get_mood(animal), &quot;Happy&quot;) == 0)
    {
        g_dbus_method_invocation_return_dbus_error(invocation,
                                                   &quot;org.gtk.GDBus.Examples.ObjectManager.Error.HappyAnimalIsHappy&quot;,
                                                   &quot;Happy animal is already happy&quot;);
        goto out;
    }

    example_animal_set_mood(animal, &quot;Happy&quot;);
    example_animal_complete_poke(animal, invocation, result);
    goto out;
}

g_assert_not_reached();



out:

return TRUE;

}


static void

on_bus_acquired(GDBusConnection *connection,

const gchar *name,

gpointer user_data)

{

ExampleObjectSkeleton *object;

guint n;


g_print(&quot;Acquired a message bus connection\n&quot;);

/* Create a new org.freedesktop.DBus.ObjectManager rooted at /example/Animals */
manager = g_dbus_object_manager_server_new(&quot;/example/Animals&quot;);

for (n = 0; n &lt; 10; n++)
{
    gchar *s;
    ExampleAnimal *animal;

    /* Create a new D-Bus object at the path /example/Animals/N where N is 000..009 */
    s = g_strdup_printf(&quot;/example/Animals/%03d&quot;, n);
    object = example_object_skeleton_new(s);
    g_free(s);

    /* Make the newly created object export the interface
     * org.gtk.GDBus.Example.ObjectManager.Animal (note
     * that @object takes its own reference to @animal).
     */
    animal = example_animal_skeleton_new();
    example_animal_set_mood(animal, &quot;Happy&quot;);
    example_object_skeleton_set_animal(object, animal);
    g_object_unref(animal);

    /* Cats are odd animals - so some of our objects implement the
     * org.gtk.GDBus.Example.ObjectManager.Cat interface in addition
     * to the .Animal interface
     */
    if (n % 2 == 1)
    {
        ExampleCat *cat;
        cat = example_cat_skeleton_new();
        example_object_skeleton_set_cat(object, cat);
        g_object_unref(cat);
    }

    /* Handle Poke() D-Bus method invocations on the .Animal interface */
    g_signal_connect(animal,
                     &quot;handle-poke&quot;,
                     G_CALLBACK(on_animal_poke),
                     NULL); /* user_data */

    /* Export the object (@manager takes its own reference to @object) */
    g_dbus_object_manager_server_export(manager, G_DBUS_OBJECT_SKELETON(object));
    g_object_unref(object);
}

/* Export all objects */
g_dbus_object_manager_server_set_connection(manager, connection);



}


static void

on_name_acquired(GDBusConnection *connection,

const gchar *name,

gpointer user_data)

{

g_print("Acquired the name %s\n", name);

}


static void

on_name_lost(GDBusConnection *connection,

const gchar *name,

gpointer user_data)

{

g_print("Lost the name %s\n", name);

}


gint main(gint argc, gchar *argv[])

{

GMainLoop *loop;

guint id;


loop = g_main_loop_new(NULL, FALSE);

// 连接到会话总线并注册well-known，同时注册相应的回调函数
id = g_bus_own_name(G_BUS_TYPE_SESSION,
                    &quot;org.gtk.GDBus.Examples.ObjectManager&quot;,
                    G_BUS_NAME_OWNER_FLAGS_ALLOW_REPLACEMENT |
                        G_BUS_NAME_OWNER_FLAGS_REPLACE,
                    on_bus_acquired,
                    on_name_acquired,
                    on_name_lost,
                    loop,
                    NULL);

g_main_loop_run(loop);

g_bus_unown_name(id);
g_main_loop_unref(loop);

return 0;



}

​gdbus-example-client.c​

#include "generated-code.h"
#include <gio/gio.h>

/* ---------------------------------------------------------------------------------------------------- */

// jumped信号对应的回调函数

static void

on_jumped_emit(

ExampleAnimal *object,

gdouble arg_height,

gpointer user_data)

{

g_print("       - Jumped signal emitted with height: %f\n", arg_height);

}


// 处理manager中所有接口，包括方法的调用等

static void

handle_objects(GDBusObjectManager *manager)

{

GList *objects; // GList是双向链表

GList *l;


// 打印manager所在的路径
g_print(&quot;Object manager at %s\n&quot;, g_dbus_object_manager_get_object_path(manager));
// 从manager中获取对象链表首位结点
objects = g_dbus_object_manager_get_objects(manager);
// 遍历所有对象
for (l = objects; l != NULL; l = l-&gt;next)
{
    ExampleObject *object = EXAMPLE_OBJECT(l-&gt;data);
    GList *interfaces;
    GList *ll;
    g_print(&quot; - Object at %s\n&quot;, g_dbus_object_get_object_path(G_DBUS_OBJECT(object)));

    // 遍历对象中的所有接口
    interfaces = g_dbus_object_get_interfaces(G_DBUS_OBJECT(object));
    for (ll = interfaces; ll != NULL; ll = ll-&gt;next)
    {
        GDBusInterface *interface = G_DBUS_INTERFACE(ll-&gt;data);
        g_print(&quot;   - Interface %s\n&quot;, g_dbus_interface_get_info(interface)-&gt;name);

        if (EXAMPLE_IS_ANIMAL(interface))
        {
            ExampleAnimal *animal = NULL;
            animal = EXAMPLE_ANIMAL(interface);
            gboolean result = FALSE;
            GError *error = NULL;
            // 同步调用Poke方法
            example_animal_call_poke_sync(animal, TRUE, FALSE, &amp;result, NULL, &amp;error);
            if (error != NULL)
            {
                // 解析错误消息
                g_print(&quot;     - error message: %s\n&quot;, error-&gt;message); // 如 &quot;Sad animal is already sad&quot;
                g_error_free(error);                                   // 释放错误对象
            }
            else
            {
                g_print(&quot;     - call result: %d\n&quot;, result);
                g_signal_connect(animal,
                                 &quot;jumped&quot;,
                                 G_CALLBACK(on_jumped_emit),
                                 NULL);
            }
        }
    }
    g_list_free_full(interfaces, g_object_unref);
}
g_list_free_full(objects, g_object_unref);



}


static void

on_object_added(GDBusObjectManager *manager,

GDBusObject *object,

gpointer user_data)

{

gchar *owner;

owner = g_dbus_object_manager_client_get_name_owner(G_DBUS_OBJECT_MANAGER_CLIENT(manager));

g_print("Added object at %s (owner %s)\n", g_dbus_object_get_object_path(object), owner);

g_free(owner);

}


static void

on_object_removed(GDBusObjectManager *manager,

GDBusObject *object,

gpointer user_data)

{

gchar *owner;

owner = g_dbus_object_manager_client_get_name_owner(G_DBUS_OBJECT_MANAGER_CLIENT(manager));

g_print("Removed object at %s (owner %s)\n", g_dbus_object_get_object_path(object), owner);

g_free(owner);

}


static void

on_notify_name_owner(GObject *object,

GParamSpec *pspec,

gpointer user_data)

{

GDBusObjectManagerClient *manager = G_DBUS_OBJECT_MANAGER_CLIENT(object);

gchar *name_owner;


name_owner = g_dbus_object_manager_client_get_name_owner(manager);
g_print(&quot;name-owner: %s\n&quot;, name_owner);
g_free(name_owner);



}


static void

on_interface_proxy_properties_changed(GDBusObjectManagerClient *manager,

GDBusObjectProxy *object_proxy,

GDBusProxy *interface_proxy,

GVariant *changed_properties,

const gchar *const *invalidated_properties,

gpointer user_data)

{

GVariantIter iter;

const gchar *key;

GVariant *value;

gchar *s;


g_print(&quot;Properties Changed on %s:\n&quot;, g_dbus_object_get_object_path(G_DBUS_OBJECT(object_proxy)));
g_variant_iter_init(&amp;iter, changed_properties);
while (g_variant_iter_next(&amp;iter, &quot;{&amp;sv}&quot;, &amp;key, &amp;value))
{
    s = g_variant_print(value, TRUE);
    g_print(&quot;  %s -&gt; %s\n&quot;, key, s);
    g_variant_unref(value);
    g_free(s);
}



}


gint main(gint argc, gchar *argv[])

{

GDBusObjectManager *manager;

GMainLoop *loop;

GError *error;

gchar *name_owner;


manager = NULL;
loop = NULL;

loop = g_main_loop_new(NULL, FALSE);

error = NULL;
// 获取/example/Animals下所有实现&quot;org.gtk.GDBus.Examples.ObjectManager&quot;的对象。org.gtk.GDBus.Examples.ObjectManage可以只是完整接口的前缀
manager = example_object_manager_client_new_for_bus_sync(G_BUS_TYPE_SESSION,
                                                         G_DBUS_OBJECT_MANAGER_CLIENT_FLAGS_NONE,
                                                         &quot;org.gtk.GDBus.Examples.ObjectManager&quot;,
                                                         &quot;/example/Animals&quot;,
                                                         NULL, /* GCancellable */
                                                         &amp;error);
if (manager == NULL)
{
    g_printerr(&quot;Error getting object manager client: %s&quot;, error-&gt;message);
    g_error_free(error);
    goto out;
}

// 获取 unique-name并打印
name_owner = g_dbus_object_manager_client_get_name_owner(G_DBUS_OBJECT_MANAGER_CLIENT(manager));
g_print(&quot;name-owner: %s\n&quot;, name_owner);
g_free(name_owner);

// 处理manager中的对象
handle_objects(manager);

// 连接manager中的对象的信号与回调函数
g_signal_connect(manager,
                 &quot;notify::name-owner&quot;,
                 G_CALLBACK(on_notify_name_owner),
                 NULL);
g_signal_connect(manager,
                 &quot;object-added&quot;,
                 G_CALLBACK(on_object_added),
                 NULL);
g_signal_connect(manager,
                 &quot;object-removed&quot;,
                 G_CALLBACK(on_object_removed),
                 NULL);
g_signal_connect(manager,
                 &quot;interface-proxy-properties-changed&quot;,
                 G_CALLBACK(on_interface_proxy_properties_changed),
                 NULL);

g_main_loop_run(loop);



out:

// 释放资源

if (manager != NULL)

g_object_unref(manager);

if (loop != NULL)

g_main_loop_unref(loop);


return 0;



}

CMakeLists​

cmake_minimum_required(VERSION 3.16)
project(MyDBusApp)

查找依赖


find_package(PkgConfig REQUIRED)

pkg_check_modules(GLIB REQUIRED glib-2.0 gio-2.0 gio-unix-2.0 dbus-1)

include_directories(\({GLIB_INCLUDE_DIRS})
link_directories(\){GLIB_LIBRARY_DIRS})


编译主程序


add_executable(server gdbus-example-server.c generated-code.c)

add_executable(client gdbus-example-client.c generated-code.c)


target_link_libraries(server ${GLIB_LIBRARIES})

target_link_libraries(client ${GLIB_LIBRARIES})

编译过程

  1. 首先使用gdbus-codegen生成代码。

    gdbus-codegen --interface-prefix org.gtk.GDBus.Example.ObjectManager. \
              --generate-c-code generated-code                        \
              --c-namespace Example                       \
              --c-generate-object-manager                 \
              --generate-docbook generated-docs                       \
              gdbus-example-objectmanager.xml

  2. 创建gdbus客户端和服务端程序

  3. 创建CMakeLists.txt​

  4. 创建build文件夹，进入build文件夹，cmake ..，然后make​

运行

先执行服务端程序，再执行客户端程序。

关于gdbus-codegen生成的代码的介绍

生成的代码中包括了绝大多数我们在开发gdbus程序中需要的函数或者别的一些信息。以上文中的XML文件生成的代码举例说明，由于生成的代码文件很大，仅挑选一些片段在此。完整版见gdbus-codegen生成代码1。

struct _ExampleAnimalIface
{
  GTypeInterface parent_iface;

gboolean (*handle_poke) (

ExampleAnimal *object,

GDBusMethodInvocation *invocation,

gboolean arg_make_sad,

gboolean arg_make_happy);


const gchar * (*get_foo) (ExampleAnimal *object);


const gchar * (*get_mood) (ExampleAnimal *object);


void (*jumped) (

ExampleAnimal *object,

gdouble arg_height);


const gchar * (*get_bar) (ExampleAnimal *object);


};

  • 该结构体中，几乎是直接给出了handle_poke和jumped信号的回调函数声明，真正的回调函数也只需要在参数列表中增加一个gpointer user_data参数即可。
#define EXAMPLE_TYPE_CAT (example_cat_get_type ())
#define EXAMPLE_CAT(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_CAT, ExampleCat))
#define EXAMPLE_IS_CAT(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_CAT))
#define EXAMPLE_CAT_GET_IFACE(o) (G_TYPE_INSTANCE_GET_INTERFACE ((o), EXAMPLE_TYPE_CAT, ExampleCatIface))
  • 上面的几个宏给出了判断对象类型和将对象类型进行转换的方法
/* 被调用方返回结果 */
void example_animal_complete_poke (
    ExampleAnimal *object,
    GDBusMethodInvocation *invocation,
    gboolean result);

/* D-Bus signal emissions functions: */

void example_animal_emit_jumped (

ExampleAnimal *object,

gdouble arg_height);


/* D-Bus method calls: */

void example_animal_call_poke (

ExampleAnimal *proxy,

gboolean arg_make_sad,

gboolean arg_make_happy,

GCancellable *cancellable,

GAsyncReadyCallback callback,

gpointer user_data);


// 调用方调用完成获取返回结果

gboolean example_animal_call_poke_finish (

ExampleAnimal *proxy,

gboolean *out_result,

GAsyncResult *res,

GError **error);


gboolean example_animal_call_poke_sync (

ExampleAnimal *proxy,

gboolean arg_make_sad,

gboolean arg_make_happy,

gboolean *out_result,

GCancellable *cancellable,

GError **error);

  • 以上代码给出了

    • 接口中定义的信号的发送函数
    • 接口中定义的方法的同步和异步调用函数，以及调用方完成调用函数
    • 接口中定义方法的被调用方完成调用函数example_animal_complete_poke ​
// 在头文件中
typedef struct
{
  GDBusMethodInfo parent_struct;
  const gchar *signal_name;
  gboolean pass_fdlist;
} _ExtendedGDBusMethodInfo;

// 在源文件中

static const _ExtendedGDBusMethodInfo _example_animal_method_info_poke =

{

{

-1,

(gchar *) "Poke",

(GDBusArgInfo **) &_example_animal_method_info_poke_IN_ARG_pointers,

(GDBusArgInfo **) &_example_animal_method_info_poke_OUT_ARG_pointers,

NULL

},

"handle-poke",

FALSE

};

  • 以上代码给出了XML文件接口中定义的方法的相关信息，"Poke"是定义的方法名，"handle-poke"是为该方法生成的信号名。

‍

  1. gdbus-codegen生成代码

    头文件

    /*
 * This file is generated by gdbus-codegen, do not modify it.
 *
 * The license of this code is the same as for the D-Bus interface description
 * it was derived from. Note that it links to GLib, so must comply with the
 * LGPL linking clauses.
 */

    ifndef GENERATED_CODE_H


    define GENERATED_CODE_H


    include <gio/gio.h>


    G_BEGIN_DECLS


    /* ------------------------------------------------------------------------ /

/     Declarations for org.gtk.GDBus.Example.ObjectManager.Animal */


    define EXAMPLE_TYPE_ANIMAL (example_animal_get_type ())


    define EXAMPLE_ANIMAL(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_ANIMAL, ExampleAnimal))


    define EXAMPLE_IS_ANIMAL(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_ANIMAL))


    define EXAMPLE_ANIMAL_GET_IFACE(o) (G_TYPE_INSTANCE_GET_INTERFACE ((o), EXAMPLE_TYPE_ANIMAL, ExampleAnimalIface))


    struct _ExampleAnimal;

typedef struct _ExampleAnimal ExampleAnimal;

typedef struct _ExampleAnimalIface ExampleAnimalIface;


    struct _ExampleAnimalIface

{

GTypeInterface parent_iface;


    gboolean (*handle_poke) (

ExampleAnimal *object,

GDBusMethodInvocation *invocation,

gboolean arg_make_sad,

gboolean arg_make_happy);


    const gchar * (*get_foo) (ExampleAnimal *object);


    const gchar * (*get_mood) (ExampleAnimal *object);


    void (*jumped) (

ExampleAnimal *object,

gdouble arg_height);


    const gchar * (*get_bar) (ExampleAnimal *object);


    };


    GType example_animal_get_type (void) G_GNUC_CONST;


    GDBusInterfaceInfo *example_animal_interface_info (void);

guint example_animal_override_properties (GObjectClass *klass, guint property_id_begin);


    /* D-Bus method call completion functions: */

void example_animal_complete_poke (

ExampleAnimal *object,

GDBusMethodInvocation *invocation,

gboolean result);


    /* D-Bus signal emissions functions: */

void example_animal_emit_jumped (

ExampleAnimal *object,

gdouble arg_height);


    /* D-Bus method calls: */

void example_animal_call_poke (

ExampleAnimal *proxy,

gboolean arg_make_sad,

gboolean arg_make_happy,

GCancellable *cancellable,

GAsyncReadyCallback callback,

gpointer user_data);


    gboolean example_animal_call_poke_finish (

ExampleAnimal *proxy,

gboolean *out_result,

GAsyncResult *res,

GError **error);


    gboolean example_animal_call_poke_sync (

ExampleAnimal *proxy,

gboolean arg_make_sad,

gboolean arg_make_happy,

gboolean *out_result,

GCancellable *cancellable,

GError **error);


    /* D-Bus property accessors: */

const gchar *example_animal_get_mood (ExampleAnimal *object);

gchar *example_animal_dup_mood (ExampleAnimal *object);

void example_animal_set_mood (ExampleAnimal *object, const gchar *value);


    const gchar *example_animal_get_foo (ExampleAnimal *object);

gchar *example_animal_dup_foo (ExampleAnimal *object);

void example_animal_set_foo (ExampleAnimal *object, const gchar *value);


    const gchar *example_animal_get_bar (ExampleAnimal *object);

gchar *example_animal_dup_bar (ExampleAnimal *object);

void example_animal_set_bar (ExampleAnimal *object, const gchar *value);


    /* ---- */


    define EXAMPLE_TYPE_ANIMAL_PROXY (example_animal_proxy_get_type ())


    define EXAMPLE_ANIMAL_PROXY(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_ANIMAL_PROXY, ExampleAnimalProxy))


    define EXAMPLE_ANIMAL_PROXY_CLASS(k) (G_TYPE_CHECK_CLASS_CAST ((k), EXAMPLE_TYPE_ANIMAL_PROXY, ExampleAnimalProxyClass))


    define EXAMPLE_ANIMAL_PROXY_GET_CLASS(o) (G_TYPE_INSTANCE_GET_CLASS ((o), EXAMPLE_TYPE_ANIMAL_PROXY, ExampleAnimalProxyClass))


    define EXAMPLE_IS_ANIMAL_PROXY(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_ANIMAL_PROXY))


    define EXAMPLE_IS_ANIMAL_PROXY_CLASS(k) (G_TYPE_CHECK_CLASS_TYPE ((k), EXAMPLE_TYPE_ANIMAL_PROXY))


    typedef struct _ExampleAnimalProxy ExampleAnimalProxy;

typedef struct _ExampleAnimalProxyClass ExampleAnimalProxyClass;

typedef struct _ExampleAnimalProxyPrivate ExampleAnimalProxyPrivate;


    struct _ExampleAnimalProxy

{

/< private >/

GDBusProxy parent_instance;

ExampleAnimalProxyPrivate *priv;

};


    struct _ExampleAnimalProxyClass

{

GDBusProxyClass parent_class;

};


    GType example_animal_proxy_get_type (void) G_GNUC_CONST;


    if GLIB_CHECK_VERSION(2, 44, 0)


    G_DEFINE_AUTOPTR_CLEANUP_FUNC (ExampleAnimalProxy, g_object_unref)


    endif


    void example_animal_proxy_new (

GDBusConnection     *connection,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GAsyncReadyCallback  callback,

gpointer             user_data);

ExampleAnimal *example_animal_proxy_new_finish (

GAsyncResult        *res,

GError             **error);

ExampleAnimal *example_animal_proxy_new_sync (

GDBusConnection     *connection,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GError             **error);


    void example_animal_proxy_new_for_bus (

GBusType             bus_type,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GAsyncReadyCallback  callback,

gpointer             user_data);

ExampleAnimal *example_animal_proxy_new_for_bus_finish (

GAsyncResult        *res,

GError             **error);

ExampleAnimal *example_animal_proxy_new_for_bus_sync (

GBusType             bus_type,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GError             **error);


    /* ---- */


    define EXAMPLE_TYPE_ANIMAL_SKELETON (example_animal_skeleton_get_type ())


    define EXAMPLE_ANIMAL_SKELETON(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_ANIMAL_SKELETON, ExampleAnimalSkeleton))


    define EXAMPLE_ANIMAL_SKELETON_CLASS(k) (G_TYPE_CHECK_CLASS_CAST ((k), EXAMPLE_TYPE_ANIMAL_SKELETON, ExampleAnimalSkeletonClass))


    define EXAMPLE_ANIMAL_SKELETON_GET_CLASS(o) (G_TYPE_INSTANCE_GET_CLASS ((o), EXAMPLE_TYPE_ANIMAL_SKELETON, ExampleAnimalSkeletonClass))


    define EXAMPLE_IS_ANIMAL_SKELETON(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_ANIMAL_SKELETON))


    define EXAMPLE_IS_ANIMAL_SKELETON_CLASS(k) (G_TYPE_CHECK_CLASS_TYPE ((k), EXAMPLE_TYPE_ANIMAL_SKELETON))


    typedef struct _ExampleAnimalSkeleton ExampleAnimalSkeleton;

typedef struct _ExampleAnimalSkeletonClass ExampleAnimalSkeletonClass;

typedef struct _ExampleAnimalSkeletonPrivate ExampleAnimalSkeletonPrivate;


    struct _ExampleAnimalSkeleton

{

/< private >/

GDBusInterfaceSkeleton parent_instance;

ExampleAnimalSkeletonPrivate *priv;

};


    struct _ExampleAnimalSkeletonClass

{

GDBusInterfaceSkeletonClass parent_class;

};


    GType example_animal_skeleton_get_type (void) G_GNUC_CONST;


    if GLIB_CHECK_VERSION(2, 44, 0)


    G_DEFINE_AUTOPTR_CLEANUP_FUNC (ExampleAnimalSkeleton, g_object_unref)


    endif


    ExampleAnimal *example_animal_skeleton_new (void);


    /* ------------------------------------------------------------------------ /

/     Declarations for org.gtk.GDBus.Example.ObjectManager.Cat */


    define EXAMPLE_TYPE_CAT (example_cat_get_type ())


    define EXAMPLE_CAT(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_CAT, ExampleCat))


    define EXAMPLE_IS_CAT(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_CAT))


    define EXAMPLE_CAT_GET_IFACE(o) (G_TYPE_INSTANCE_GET_INTERFACE ((o), EXAMPLE_TYPE_CAT, ExampleCatIface))


    struct _ExampleCat;

typedef struct _ExampleCat ExampleCat;

typedef struct _ExampleCatIface ExampleCatIface;


    struct _ExampleCatIface

{

GTypeInterface parent_iface;

};


    GType example_cat_get_type (void) G_GNUC_CONST;


    GDBusInterfaceInfo *example_cat_interface_info (void);

guint example_cat_override_properties (GObjectClass *klass, guint property_id_begin);


    /* ---- */


    define EXAMPLE_TYPE_CAT_PROXY (example_cat_proxy_get_type ())


    define EXAMPLE_CAT_PROXY(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_CAT_PROXY, ExampleCatProxy))


    define EXAMPLE_CAT_PROXY_CLASS(k) (G_TYPE_CHECK_CLASS_CAST ((k), EXAMPLE_TYPE_CAT_PROXY, ExampleCatProxyClass))


    define EXAMPLE_CAT_PROXY_GET_CLASS(o) (G_TYPE_INSTANCE_GET_CLASS ((o), EXAMPLE_TYPE_CAT_PROXY, ExampleCatProxyClass))


    define EXAMPLE_IS_CAT_PROXY(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_CAT_PROXY))


    define EXAMPLE_IS_CAT_PROXY_CLASS(k) (G_TYPE_CHECK_CLASS_TYPE ((k), EXAMPLE_TYPE_CAT_PROXY))


    typedef struct _ExampleCatProxy ExampleCatProxy;

typedef struct _ExampleCatProxyClass ExampleCatProxyClass;

typedef struct _ExampleCatProxyPrivate ExampleCatProxyPrivate;


    struct _ExampleCatProxy

{

/< private >/

GDBusProxy parent_instance;

ExampleCatProxyPrivate *priv;

};


    struct _ExampleCatProxyClass

{

GDBusProxyClass parent_class;

};


    GType example_cat_proxy_get_type (void) G_GNUC_CONST;


    if GLIB_CHECK_VERSION(2, 44, 0)


    G_DEFINE_AUTOPTR_CLEANUP_FUNC (ExampleCatProxy, g_object_unref)


    endif


    void example_cat_proxy_new (

GDBusConnection     *connection,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GAsyncReadyCallback  callback,

gpointer             user_data);

ExampleCat *example_cat_proxy_new_finish (

GAsyncResult        *res,

GError             **error);

ExampleCat *example_cat_proxy_new_sync (

GDBusConnection     *connection,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GError             **error);


    void example_cat_proxy_new_for_bus (

GBusType             bus_type,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GAsyncReadyCallback  callback,

gpointer             user_data);

ExampleCat *example_cat_proxy_new_for_bus_finish (

GAsyncResult        *res,

GError             **error);

ExampleCat *example_cat_proxy_new_for_bus_sync (

GBusType             bus_type,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GError             **error);


    /* ---- */


    define EXAMPLE_TYPE_CAT_SKELETON (example_cat_skeleton_get_type ())


    define EXAMPLE_CAT_SKELETON(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_CAT_SKELETON, ExampleCatSkeleton))


    define EXAMPLE_CAT_SKELETON_CLASS(k) (G_TYPE_CHECK_CLASS_CAST ((k), EXAMPLE_TYPE_CAT_SKELETON, ExampleCatSkeletonClass))


    define EXAMPLE_CAT_SKELETON_GET_CLASS(o) (G_TYPE_INSTANCE_GET_CLASS ((o), EXAMPLE_TYPE_CAT_SKELETON, ExampleCatSkeletonClass))


    define EXAMPLE_IS_CAT_SKELETON(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_CAT_SKELETON))


    define EXAMPLE_IS_CAT_SKELETON_CLASS(k) (G_TYPE_CHECK_CLASS_TYPE ((k), EXAMPLE_TYPE_CAT_SKELETON))


    typedef struct _ExampleCatSkeleton ExampleCatSkeleton;

typedef struct _ExampleCatSkeletonClass ExampleCatSkeletonClass;

typedef struct _ExampleCatSkeletonPrivate ExampleCatSkeletonPrivate;


    struct _ExampleCatSkeleton

{

/< private >/

GDBusInterfaceSkeleton parent_instance;

ExampleCatSkeletonPrivate *priv;

};


    struct _ExampleCatSkeletonClass

{

GDBusInterfaceSkeletonClass parent_class;

};


    GType example_cat_skeleton_get_type (void) G_GNUC_CONST;


    if GLIB_CHECK_VERSION(2, 44, 0)


    G_DEFINE_AUTOPTR_CLEANUP_FUNC (ExampleCatSkeleton, g_object_unref)


    endif


    ExampleCat *example_cat_skeleton_new (void);


    /* ---- */


    define EXAMPLE_TYPE_OBJECT (example_object_get_type ())


    define EXAMPLE_OBJECT(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_OBJECT, ExampleObject))


    define EXAMPLE_IS_OBJECT(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_OBJECT))


    define EXAMPLE_OBJECT_GET_IFACE(o) (G_TYPE_INSTANCE_GET_INTERFACE ((o), EXAMPLE_TYPE_OBJECT, ExampleObject))


    struct _ExampleObject;

typedef struct _ExampleObject ExampleObject;

typedef struct _ExampleObjectIface ExampleObjectIface;


    struct _ExampleObjectIface

{

GTypeInterface parent_iface;

};


    GType example_object_get_type (void) G_GNUC_CONST;


    ExampleAnimal *example_object_get_animal (ExampleObject *object);

ExampleCat *example_object_get_cat (ExampleObject *object);

ExampleAnimal *example_object_peek_animal (ExampleObject *object);

ExampleCat *example_object_peek_cat (ExampleObject *object);


    define EXAMPLE_TYPE_OBJECT_PROXY (example_object_proxy_get_type ())


    define EXAMPLE_OBJECT_PROXY(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_OBJECT_PROXY, ExampleObjectProxy))


    define EXAMPLE_OBJECT_PROXY_CLASS(k) (G_TYPE_CHECK_CLASS_CAST ((k), EXAMPLE_TYPE_OBJECT_PROXY, ExampleObjectProxyClass))


    define EXAMPLE_OBJECT_PROXY_GET_CLASS(o) (G_TYPE_INSTANCE_GET_CLASS ((o), EXAMPLE_TYPE_OBJECT_PROXY, ExampleObjectProxyClass))


    define EXAMPLE_IS_OBJECT_PROXY(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_OBJECT_PROXY))


    define EXAMPLE_IS_OBJECT_PROXY_CLASS(k) (G_TYPE_CHECK_CLASS_TYPE ((k), EXAMPLE_TYPE_OBJECT_PROXY))


    typedef struct _ExampleObjectProxy ExampleObjectProxy;

typedef struct _ExampleObjectProxyClass ExampleObjectProxyClass;

typedef struct _ExampleObjectProxyPrivate ExampleObjectProxyPrivate;


    struct _ExampleObjectProxy

{

/< private >/

GDBusObjectProxy parent_instance;

ExampleObjectProxyPrivate *priv;

};


    struct _ExampleObjectProxyClass

{

GDBusObjectProxyClass parent_class;

};


    GType example_object_proxy_get_type (void) G_GNUC_CONST;


    if GLIB_CHECK_VERSION(2, 44, 0)


    G_DEFINE_AUTOPTR_CLEANUP_FUNC (ExampleObjectProxy, g_object_unref)


    endif


    ExampleObjectProxy *example_object_proxy_new (GDBusConnection *connection, const gchar *object_path);


    define EXAMPLE_TYPE_OBJECT_SKELETON (example_object_skeleton_get_type ())


    define EXAMPLE_OBJECT_SKELETON(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_OBJECT_SKELETON, ExampleObjectSkeleton))


    define EXAMPLE_OBJECT_SKELETON_CLASS(k) (G_TYPE_CHECK_CLASS_CAST ((k), EXAMPLE_TYPE_OBJECT_SKELETON, ExampleObjectSkeletonClass))


    define EXAMPLE_OBJECT_SKELETON_GET_CLASS(o) (G_TYPE_INSTANCE_GET_CLASS ((o), EXAMPLE_TYPE_OBJECT_SKELETON, ExampleObjectSkeletonClass))


    define EXAMPLE_IS_OBJECT_SKELETON(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_OBJECT_SKELETON))


    define EXAMPLE_IS_OBJECT_SKELETON_CLASS(k) (G_TYPE_CHECK_CLASS_TYPE ((k), EXAMPLE_TYPE_OBJECT_SKELETON))


    typedef struct _ExampleObjectSkeleton ExampleObjectSkeleton;

typedef struct _ExampleObjectSkeletonClass ExampleObjectSkeletonClass;

typedef struct _ExampleObjectSkeletonPrivate ExampleObjectSkeletonPrivate;


    struct _ExampleObjectSkeleton

{

/< private >/

GDBusObjectSkeleton parent_instance;

ExampleObjectSkeletonPrivate *priv;

};


    struct _ExampleObjectSkeletonClass

{

GDBusObjectSkeletonClass parent_class;

};


    GType example_object_skeleton_get_type (void) G_GNUC_CONST;


    if GLIB_CHECK_VERSION(2, 44, 0)


    G_DEFINE_AUTOPTR_CLEANUP_FUNC (ExampleObjectSkeleton, g_object_unref)


    endif


    ExampleObjectSkeleton *example_object_skeleton_new (const gchar *object_path);

void example_object_skeleton_set_animal (ExampleObjectSkeleton *object, ExampleAnimal *interface_);

void example_object_skeleton_set_cat (ExampleObjectSkeleton *object, ExampleCat *interface_);


    /* ---- */


    define EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT (example_object_manager_client_get_type ())


    define EXAMPLE_OBJECT_MANAGER_CLIENT(o) (G_TYPE_CHECK_INSTANCE_CAST ((o), EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT, ExampleObjectManagerClient))


    define EXAMPLE_OBJECT_MANAGER_CLIENT_CLASS(k) (G_TYPE_CHECK_CLASS_CAST ((k), EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT, ExampleObjectManagerClientClass))


    define EXAMPLE_OBJECT_MANAGER_CLIENT_GET_CLASS(o) (G_TYPE_INSTANCE_GET_CLASS ((o), EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT, ExampleObjectManagerClientClass))


    define EXAMPLE_IS_OBJECT_MANAGER_CLIENT(o) (G_TYPE_CHECK_INSTANCE_TYPE ((o), EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT))


    define EXAMPLE_IS_OBJECT_MANAGER_CLIENT_CLASS(k) (G_TYPE_CHECK_CLASS_TYPE ((k), EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT))


    typedef struct _ExampleObjectManagerClient ExampleObjectManagerClient;

typedef struct _ExampleObjectManagerClientClass ExampleObjectManagerClientClass;

typedef struct _ExampleObjectManagerClientPrivate ExampleObjectManagerClientPrivate;


    struct _ExampleObjectManagerClient

{

/< private >/

GDBusObjectManagerClient parent_instance;

ExampleObjectManagerClientPrivate *priv;

};


    struct _ExampleObjectManagerClientClass

{

GDBusObjectManagerClientClass parent_class;

};


    if GLIB_CHECK_VERSION(2, 44, 0)


    G_DEFINE_AUTOPTR_CLEANUP_FUNC (ExampleObjectManagerClient, g_object_unref)


    endif


    GType example_object_manager_client_get_type (void) G_GNUC_CONST;


    GType example_object_manager_client_get_proxy_type (GDBusObjectManagerClient *manager, const gchar *object_path, const gchar *interface_name, gpointer user_data);


    void example_object_manager_client_new (

GDBusConnection        *connection,

GDBusObjectManagerClientFlags  flags,

const gchar            *name,

const gchar            *object_path,

GCancellable           *cancellable,

GAsyncReadyCallback     callback,

gpointer                user_data);

GDBusObjectManager *example_object_manager_client_new_finish (

GAsyncResult        *res,

GError             **error);

GDBusObjectManager *example_object_manager_client_new_sync (

GDBusConnection        *connection,

GDBusObjectManagerClientFlags  flags,

const gchar            *name,

const gchar            *object_path,

GCancellable           *cancellable,

GError                **error);


    void example_object_manager_client_new_for_bus (

GBusType                bus_type,

GDBusObjectManagerClientFlags  flags,

const gchar            *name,

const gchar            *object_path,

GCancellable           *cancellable,

GAsyncReadyCallback     callback,

gpointer                user_data);

GDBusObjectManager *example_object_manager_client_new_for_bus_finish (

GAsyncResult        *res,

GError             **error);

GDBusObjectManager *example_object_manager_client_new_for_bus_sync (

GBusType                bus_type,

GDBusObjectManagerClientFlags  flags,

const gchar            *name,

const gchar            *object_path,

GCancellable           *cancellable,

GError                **error);


    G_END_DECLS


    endif /* GENERATED_CODE_H */

    源文件

    /*
 * This file is generated by gdbus-codegen, do not modify it.
 *
 * The license of this code is the same as for the D-Bus interface description
 * it was derived from. Note that it links to GLib, so must comply with the
 * LGPL linking clauses.
 */

    ifdef HAVE_CONFIG_H


    include "config.h"


    endif


    include "generated-code.h"


    include <string.h>


    ifdef G_OS_UNIX


    include <gio/gunixfdlist.h>


    endif


    typedef struct

{

GDBusArgInfo parent_struct;

gboolean use_gvariant;

} _ExtendedGDBusArgInfo;


    typedef struct

{

GDBusMethodInfo parent_struct;

const gchar *signal_name;

gboolean pass_fdlist;

} _ExtendedGDBusMethodInfo;


    typedef struct

{

GDBusSignalInfo parent_struct;

const gchar *signal_name;

} _ExtendedGDBusSignalInfo;


    typedef struct

{

GDBusPropertyInfo parent_struct;

const gchar *hyphen_name;

guint use_gvariant : 1;

guint emits_changed_signal : 1;

} _ExtendedGDBusPropertyInfo;


    typedef struct

{

GDBusInterfaceInfo parent_struct;

const gchar *hyphen_name;

} _ExtendedGDBusInterfaceInfo;


    typedef struct

{

const _ExtendedGDBusPropertyInfo info;

guint prop_id;

GValue orig_value; /     the value before the change */

} ChangedProperty;


    static void

_changed_property_free (ChangedProperty *data)

{

g_value_unset (&data->orig_value);

g_free (data);

}


    static gboolean

_g_strv_equal0 (gchar **a, gchar **b)

{

gboolean ret = FALSE;

guint n;

if (a == NULL && b == NULL)

{

ret = TRUE;

goto out;

}

if (a == NULL || b == NULL)

goto out;

if (g_strv_length (a) != g_strv_length (b))

goto out;

for (n = 0; a[n] != NULL; n++)

if (g_strcmp0 (a[n], b[n]) != 0)

goto out;

ret = TRUE;

out:

return ret;

}


    static gboolean

_g_variant_equal0 (GVariant *a, GVariant *b)

{

gboolean ret = FALSE;

if (a == NULL && b == NULL)

{

ret = TRUE;

goto out;

}

if (a == NULL || b == NULL)

goto out;

ret = g_variant_equal (a, b);

out:

return ret;

}


    G_GNUC_UNUSED static gboolean

_g_value_equal (const GValue *a, const GValue b)

{

gboolean ret = FALSE;

g_assert (G_VALUE_TYPE (a) == G_VALUE_TYPE (b));

switch (G_VALUE_TYPE (a))

{

case G_TYPE_BOOLEAN:

ret = (g_value_get_boolean (a) == g_value_get_boolean (b));

break;

case G_TYPE_UCHAR:

ret = (g_value_get_uchar (a) == g_value_get_uchar (b));

break;

case G_TYPE_INT:

ret = (g_value_get_int (a) == g_value_get_int (b));

break;

case G_TYPE_UINT:

ret = (g_value_get_uint (a) == g_value_get_uint (b));

break;

case G_TYPE_INT64:

ret = (g_value_get_int64 (a) == g_value_get_int64 (b));

break;

case G_TYPE_UINT64:

ret = (g_value_get_uint64 (a) == g_value_get_uint64 (b));

break;

case G_TYPE_DOUBLE:

{

/     Avoid -Wfloat-equal warnings by doing a direct bit compare */

gdouble da = g_value_get_double (a);

gdouble db = g_value_get_double (b);

ret = memcmp (&da, &db, sizeof (gdouble)) == 0;

}

break;

case G_TYPE_STRING:

ret = (g_strcmp0 (g_value_get_string (a), g_value_get_string (b)) == 0);

break;

case G_TYPE_VARIANT:

ret = _g_variant_equal0 (g_value_get_variant (a), g_value_get_variant (b));

break;

default:

if (G_VALUE_TYPE (a) == G_TYPE_STRV)

ret = _g_strv_equal0 (g_value_get_boxed (a), g_value_get_boxed (b));

else

g_critical ("_g_value_equal() does not handle type %s", g_type_name (G_VALUE_TYPE (a)));

break;

}

return ret;

}


    /* ------------------------------------------------------------------------




    • Code for interface org.gtk.GDBus.Example.ObjectManager.Animal
      •

    •



      •



    */


    /**




    • SECTION:ExampleAnimal
      •

    • @title: ExampleAnimal
      •

    • @short_description: Generated C code for the org.gtk.GDBus.Example.ObjectManager.Animal D-Bus interface
      •

    •

    • This section contains code for working with the <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link> D-Bus interface in C.

*/
      •



    /* ---- Introspection data for org.gtk.GDBus.Example.ObjectManager.Animal ---- */


    static const _ExtendedGDBusArgInfo _example_animal_method_info_poke_IN_ARG_make_sad =

{

{

-1,

(gchar *) "make_sad",

(gchar *) "b",

NULL

},

FALSE

};


    static const _ExtendedGDBusArgInfo _example_animal_method_info_poke_IN_ARG_make_happy =

{

{

-1,

(gchar *) "make_happy",

(gchar *) "b",

NULL

},

FALSE

};


    static const GDBusArgInfo * const _example_animal_method_info_poke_IN_ARG_pointers[] =

{

&_example_animal_method_info_poke_IN_ARG_make_sad.parent_struct,

&_example_animal_method_info_poke_IN_ARG_make_happy.parent_struct,

NULL

};


    static const _ExtendedGDBusArgInfo _example_animal_method_info_poke_OUT_ARG_result =

{

{

-1,

(gchar *) "result",

(gchar *) "b",

NULL

},

FALSE

};


    static const GDBusArgInfo * const _example_animal_method_info_poke_OUT_ARG_pointers[] =

{

&_example_animal_method_info_poke_OUT_ARG_result.parent_struct,

NULL

};


    static const _ExtendedGDBusMethodInfo _example_animal_method_info_poke =

{

{

-1,

(gchar *) "Poke",

(GDBusArgInfo **) &_example_animal_method_info_poke_IN_ARG_pointers,

(GDBusArgInfo **) &_example_animal_method_info_poke_OUT_ARG_pointers,

NULL

},

"handle-poke",

FALSE

};


    static const GDBusMethodInfo * const _example_animal_method_info_pointers[] =

{

&_example_animal_method_info_poke.parent_struct,

NULL

};


    static const _ExtendedGDBusArgInfo _example_animal_signal_info_jumped_ARG_height =

{

{

-1,

(gchar *) "height",

(gchar *) "d",

NULL

},

FALSE

};


    static const GDBusArgInfo * const _example_animal_signal_info_jumped_ARG_pointers[] =

{

&_example_animal_signal_info_jumped_ARG_height.parent_struct,

NULL

};


    static const _ExtendedGDBusSignalInfo _example_animal_signal_info_jumped =

{

{

-1,

(gchar *) "Jumped",

(GDBusArgInfo **) &_example_animal_signal_info_jumped_ARG_pointers,

NULL

},

"jumped"

};


    static const GDBusSignalInfo * const _example_animal_signal_info_pointers[] =

{

&_example_animal_signal_info_jumped.parent_struct,

NULL

};


    static const _ExtendedGDBusPropertyInfo _example_animal_property_info_mood =

{

{

-1,

(gchar *) "Mood",

(gchar *) "s",

G_DBUS_PROPERTY_INFO_FLAGS_READABLE,

NULL

},

"mood",

FALSE,

TRUE

};


    static const _ExtendedGDBusPropertyInfo _example_animal_property_info_foo =

{

{

-1,

(gchar *) "Foo",

(gchar *) "s",

G_DBUS_PROPERTY_INFO_FLAGS_READABLE,

NULL

},

"foo",

FALSE,

TRUE

};


    static const _ExtendedGDBusPropertyInfo _example_animal_property_info_bar =

{

{

-1,

(gchar *) "Bar",

(gchar *) "s",

G_DBUS_PROPERTY_INFO_FLAGS_READABLE,

NULL

},

"bar",

FALSE,

TRUE

};


    static const GDBusPropertyInfo * const _example_animal_property_info_pointers[] =

{

&_example_animal_property_info_mood.parent_struct,

&_example_animal_property_info_foo.parent_struct,

&_example_animal_property_info_bar.parent_struct,

NULL

};


    static const _ExtendedGDBusInterfaceInfo _example_animal_interface_info =

{

{

-1,

(gchar *) "org.gtk.GDBus.Example.ObjectManager.Animal",

(GDBusMethodInfo **) &_example_animal_method_info_pointers,

(GDBusSignalInfo **) &_example_animal_signal_info_pointers,

(GDBusPropertyInfo **) &_example_animal_property_info_pointers,

NULL

},

"animal",

};


    /**




    • example_animal_interface_info:
      •

    •

    • Gets a machine-readable description of the <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link> D-Bus interface.
      •

    •

    • Returns: (transfer none): A #GDBusInterfaceInfo. Do not free.
      •

    •

    • Since: 2.30

*/

GDBusInterfaceInfo *

example_animal_interface_info (void)

{

return (GDBusInterfaceInfo *) &_example_animal_interface_info.parent_struct;

}
      •



    /**




    • example_animal_override_properties:
      •

    • @klass: The class structure for a #GObject derived class.
      •

    • @property_id_begin: The property id to assign to the first overridden property.
      •

    •

    • Overrides all #GObject properties in the #ExampleAnimal interface for a concrete class.
      •

    • The properties are overridden in the order they are defined.
      •

    •

    • Returns: The last property id.
      •

    •

    • Since: 2.30

*/

guint

example_animal_override_properties (GObjectClass *klass, guint property_id_begin)

{

g_object_class_override_property (klass, property_id_begin++, "mood");

g_object_class_override_property (klass, property_id_begin++, "foo");

g_object_class_override_property (klass, property_id_begin++, "bar");

return property_id_begin - 1;

}
      •



    /**




    • ExampleAnimal:
      •

    •

    • Abstract interface type for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link>.
      •

    •

    • Since: 2.30

*/
      •



    /**




    • ExampleAnimalIface:
      •

    • @parent_iface: The parent interface.
      •

    • @handle_poke: Handler for the #ExampleAnimal::handle-poke signal.
      •

    • @get_foo: Getter for the #ExampleAnimal:foo property.
      •

    • @get_mood: Getter for the #ExampleAnimal:mood property.
      •

    • @jumped: Handler for the #ExampleAnimal::jumped signal.
      •

    • @get_bar: Getter for the #ExampleAnimal:bar property.
      •

    •

    • Virtual table for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link>.
      •

    •

    • Since: 2.30

*/
      •



    typedef ExampleAnimalIface ExampleAnimalInterface;

G_DEFINE_INTERFACE (ExampleAnimal, example_animal, G_TYPE_OBJECT)


    static void

example_animal_default_init (ExampleAnimalIface iface)

{

/     GObject signals for incoming D-Bus method calls: /

/    *




    • ExampleAnimal::handle-poke:
      •

    • @object: A #ExampleAnimal.
      •

    • @invocation: A #GDBusMethodInvocation.
      •

    • @arg_make_sad: Argument passed by remote caller.
      •

    • @arg_make_happy: Argument passed by remote caller.
      •

    •

    • Signal emitted when a remote caller is invoking the <link linkend="gdbus-method-org-gtk-GDBus-Example-ObjectManager-Animal.Poke">Poke()</link> D-Bus method.
      •

    •

    • If a signal handler returns %TRUE, it means the signal handler will handle the invocation (e.g. take a reference to @invocation and eventually call example_animal_complete_poke() or e.g. g_dbus_method_invocation_return_error() on it) and no order signal handlers will run. If no signal handler handles the invocation, the %G_DBUS_ERROR_UNKNOWN_METHOD error is returned.
      •

    •

    • Returns: %TRUE if the invocation was handled, %FALSE to let other signal handlers run.
      •

    •

    • Since: 2.30

*/

g_signal_new ("handle-poke",

G_TYPE_FROM_INTERFACE (iface),

G_SIGNAL_RUN_LAST,

G_STRUCT_OFFSET (ExampleAnimalIface, handle_poke),

g_signal_accumulator_true_handled,

NULL,

g_cclosure_marshal_generic,

G_TYPE_BOOLEAN,

3,

G_TYPE_DBUS_METHOD_INVOCATION, G_TYPE_BOOLEAN, G_TYPE_BOOLEAN);
      •



    /* GObject signals for received D-Bus signals: /

/    *




    • ExampleAnimal::jumped:
      •

    • @object: A #ExampleAnimal.
      •

    • @arg_height: Argument.
      •

    •

    • On the client-side, this signal is emitted whenever the D-Bus signal <link linkend="gdbus-signal-org-gtk-GDBus-Example-ObjectManager-Animal.Jumped">"Jumped"</link> is received.
      •

    •

    • On the service-side, this signal can be used with e.g. g_signal_emit_by_name() to make the object emit the D-Bus signal.
      •

    •

    • Since: 2.30

*/

g_signal_new ("jumped",

G_TYPE_FROM_INTERFACE (iface),

G_SIGNAL_RUN_LAST,

G_STRUCT_OFFSET (ExampleAnimalIface, jumped),

NULL,

NULL,

g_cclosure_marshal_generic,

G_TYPE_NONE,

1, G_TYPE_DOUBLE);
      •



    /* GObject properties for D-Bus properties: /

/    *




    • ExampleAnimal:mood:
      •

    •

    • Represents the D-Bus property <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Mood">"Mood"</link>.
      •

    •

    • Since the D-Bus property for this #GObject property is readable but not writable, it is meaningful to read from it on both the client- and service-side. It is only meaningful, however, to write to it on the service-side.
      •

    •

    • Since: 2.30

/

g_object_interface_install_property (iface,

g_param_spec_string ("mood", "Mood", "Mood", NULL, G_PARAM_READWRITE | G_PARAM_STATIC_STRINGS));

/      *
      •

    • ExampleAnimal:foo:
      •

    •

    • Represents the D-Bus property <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Foo">"Foo"</link>.
      •

    •

    • Since the D-Bus property for this #GObject property is readable but not writable, it is meaningful to read from it on both the client- and service-side. It is only meaningful, however, to write to it on the service-side.
      •

    •

    • Since: 2.30

/

g_object_interface_install_property (iface,

g_param_spec_string ("foo", "Foo", "Foo", NULL, G_PARAM_READWRITE | G_PARAM_STATIC_STRINGS));

/      *
      •

    • ExampleAnimal:bar:
      •

    •

    • Represents the D-Bus property <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Bar">"Bar"</link>.
      •

    •

    • Since the D-Bus property for this #GObject property is readable but not writable, it is meaningful to read from it on both the client- and service-side. It is only meaningful, however, to write to it on the service-side.
      •

    •

    • Since: 2.36

*/

g_object_interface_install_property (iface,

g_param_spec_string ("bar", "Bar", "Bar", NULL, G_PARAM_READWRITE | G_PARAM_STATIC_STRINGS));

}
      •



    /**




    • example_animal_get_mood: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    •

    • Gets the value of the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Mood">"Mood"</link> D-Bus property.
      •

    •

    • Since this D-Bus property is readable, it is meaningful to use this function on both the client- and service-side.
      •

    •

    • The returned value is only valid until the property changes so on the client-side it is only safe to use this function on the thread where @object was constructed. Use example_animal_dup_mood() if on another thread.
      •

    •

    • Returns: (transfer none) (nullable): The property value or %NULL if the property is not set. Do not free the returned value, it belongs to @object.
      •

    •

    • Since: 2.30

*/

const gchar *

example_animal_get_mood (ExampleAnimal *object)

{

return EXAMPLE_ANIMAL_GET_IFACE (object)->get_mood (object);

}
      •



    /**




    • example_animal_dup_mood: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    •

    • Gets a copy of the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Mood">"Mood"</link> D-Bus property.
      •

    •

    • Since this D-Bus property is readable, it is meaningful to use this function on both the client- and service-side.
      •

    •

    • Returns: (transfer full) (nullable): The property value or %NULL if the property is not set. The returned value should be freed with g_free().
      •

    •

    • Since: 2.30

*/

gchar *

example_animal_dup_mood (ExampleAnimal *object)

{

gchar *value;

g_object_get (G_OBJECT (object), "mood", &value, NULL);

return value;

}
      •



    /**




    • example_animal_set_mood: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    • @value: The value to set.
      •

    •

    • Sets the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Mood">"Mood"</link> D-Bus property to @value.
      •

    •

    • Since this D-Bus property is not writable, it is only meaningful to use this function on the service-side.
      •

    •

    • Since: 2.30

*/

void

example_animal_set_mood (ExampleAnimal *object, const gchar *value)

{

g_object_set (G_OBJECT (object), "mood", value, NULL);

}
      •



    /**




    • example_animal_get_foo: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    •

    • Gets the value of the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Foo">"Foo"</link> D-Bus property.
      •

    •

    • Since this D-Bus property is readable, it is meaningful to use this function on both the client- and service-side.
      •

    •

    • The returned value is only valid until the property changes so on the client-side it is only safe to use this function on the thread where @object was constructed. Use example_animal_dup_foo() if on another thread.
      •

    •

    • Returns: (transfer none) (nullable): The property value or %NULL if the property is not set. Do not free the returned value, it belongs to @object.
      •

    •

    • Since: 2.30

*/

const gchar *

example_animal_get_foo (ExampleAnimal *object)

{

return EXAMPLE_ANIMAL_GET_IFACE (object)->get_foo (object);

}
      •



    /**




    • example_animal_dup_foo: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    •

    • Gets a copy of the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Foo">"Foo"</link> D-Bus property.
      •

    •

    • Since this D-Bus property is readable, it is meaningful to use this function on both the client- and service-side.
      •

    •

    • Returns: (transfer full) (nullable): The property value or %NULL if the property is not set. The returned value should be freed with g_free().
      •

    •

    • Since: 2.30

*/

gchar *

example_animal_dup_foo (ExampleAnimal *object)

{

gchar *value;

g_object_get (G_OBJECT (object), "foo", &value, NULL);

return value;

}
      •



    /**




    • example_animal_set_foo: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    • @value: The value to set.
      •

    •

    • Sets the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Foo">"Foo"</link> D-Bus property to @value.
      •

    •

    • Since this D-Bus property is not writable, it is only meaningful to use this function on the service-side.
      •

    •

    • Since: 2.30

*/

void

example_animal_set_foo (ExampleAnimal *object, const gchar *value)

{

g_object_set (G_OBJECT (object), "foo", value, NULL);

}
      •



    /**




    • example_animal_get_bar: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    •

    • Gets the value of the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Bar">"Bar"</link> D-Bus property.
      •

    •

    • Since this D-Bus property is readable, it is meaningful to use this function on both the client- and service-side.
      •

    •

    • The returned value is only valid until the property changes so on the client-side it is only safe to use this function on the thread where @object was constructed. Use example_animal_dup_bar() if on another thread.
      •

    •

    • Returns: (transfer none) (nullable): The property value or %NULL if the property is not set. Do not free the returned value, it belongs to @object.
      •

    •

    • Since: 2.36

*/

const gchar *

example_animal_get_bar (ExampleAnimal *object)

{

return EXAMPLE_ANIMAL_GET_IFACE (object)->get_bar (object);

}
      •



    /**




    • example_animal_dup_bar: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    •

    • Gets a copy of the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Bar">"Bar"</link> D-Bus property.
      •

    •

    • Since this D-Bus property is readable, it is meaningful to use this function on both the client- and service-side.
      •

    •

    • Returns: (transfer full) (nullable): The property value or %NULL if the property is not set. The returned value should be freed with g_free().
      •

    •

    • Since: 2.36

*/

gchar *

example_animal_dup_bar (ExampleAnimal *object)

{

gchar *value;

g_object_get (G_OBJECT (object), "bar", &value, NULL);

return value;

}
      •



    /**




    • example_animal_set_bar: (skip)
      •

    • @object: A #ExampleAnimal.
      •

    • @value: The value to set.
      •

    •

    • Sets the <link linkend="gdbus-property-org-gtk-GDBus-Example-ObjectManager-Animal.Bar">"Bar"</link> D-Bus property to @value.
      •

    •

    • Since this D-Bus property is not writable, it is only meaningful to use this function on the service-side.
      •

    •

    • Since: 2.36

*/

void

example_animal_set_bar (ExampleAnimal *object, const gchar *value)

{

g_object_set (G_OBJECT (object), "bar", value, NULL);

}
      •



    /**




    • example_animal_emit_jumped:
      •

    • @object: A #ExampleAnimal.
      •

    • @arg_height: Argument to pass with the signal.
      •

    •

    • Emits the <link linkend="gdbus-signal-org-gtk-GDBus-Example-ObjectManager-Animal.Jumped">"Jumped"</link> D-Bus signal.
      •

    •

    • Since: 2.30

*/

void

example_animal_emit_jumped (

ExampleAnimal *object,

gdouble arg_height)

{

g_signal_emit_by_name (object, "jumped", arg_height);

}
      •



    /**




    • example_animal_call_poke:
      •

    • @proxy: A #ExampleAnimalProxy.
      •

    • @arg_make_sad: Argument to pass with the method invocation.
      •

    • @arg_make_happy: Argument to pass with the method invocation.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @callback: A #GAsyncReadyCallback to call when the request is satisfied or %NULL.
      •

    • @user_data: User data to pass to @callback.
      •

    •

    • Asynchronously invokes the <link linkend="gdbus-method-org-gtk-GDBus-Example-ObjectManager-Animal.Poke">Poke()</link> D-Bus method on @proxy.
      •

    • When the operation is finished, @callback will be invoked in the thread-default main loop of the thread you are calling this method from (see g_main_context_push_thread_default()).
      •

    • You can then call example_animal_call_poke_finish() to get the result of the operation.
      •

    •

    • See example_animal_call_poke_sync() for the synchronous, blocking version of this method.
      •

    •

    • Since: 2.30

*/

void

example_animal_call_poke (

ExampleAnimal *proxy,

gboolean arg_make_sad,

gboolean arg_make_happy,

GCancellable *cancellable,

GAsyncReadyCallback callback,

gpointer user_data)

{

g_dbus_proxy_call (G_DBUS_PROXY (proxy),

"Poke",

g_variant_new ("(bb)",

arg_make_sad,

arg_make_happy),

G_DBUS_CALL_FLAGS_NONE,

-1,

cancellable,

callback,

user_data);

}
      •



    /**




    • example_animal_call_poke_finish:
      •

    • @proxy: A #ExampleAnimalProxy.
      •

    • @out_result: (out) (optional): Return location for return parameter or %NULL to ignore.
      •

    • @res: The #GAsyncResult obtained from the #GAsyncReadyCallback passed to example_animal_call_poke().
      •

    • @error: Return location for error or %NULL.
      •

    •

    • Finishes an operation started with example_animal_call_poke().
      •

    •

    • Returns: (skip): %TRUE if the call succeded, %FALSE if @error is set.
      •

    •

    • Since: 2.30

*/

gboolean

example_animal_call_poke_finish (

ExampleAnimal *proxy,

gboolean *out_result,

GAsyncResult *res,

GError **error)

{

GVariant *_ret;

_ret = g_dbus_proxy_call_finish (G_DBUS_PROXY (proxy), res, error);

if (_ret == NULL)

goto _out;

g_variant_get (_ret,

"(b)",

out_result);

g_variant_unref (_ret);

_out:

return _ret != NULL;

}
      •



    /**




    • example_animal_call_poke_sync:
      •

    • @proxy: A #ExampleAnimalProxy.
      •

    • @arg_make_sad: Argument to pass with the method invocation.
      •

    • @arg_make_happy: Argument to pass with the method invocation.
      •

    • @out_result: (out) (optional): Return location for return parameter or %NULL to ignore.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @error: Return location for error or %NULL.
      •

    •

    • Synchronously invokes the <link linkend="gdbus-method-org-gtk-GDBus-Example-ObjectManager-Animal.Poke">Poke()</link> D-Bus method on @proxy. The calling thread is blocked until a reply is received.
      •

    •

    • See example_animal_call_poke() for the asynchronous version of this method.
      •

    •

    • Returns: (skip): %TRUE if the call succeded, %FALSE if @error is set.
      •

    •

    • Since: 2.30

*/

gboolean

example_animal_call_poke_sync (

ExampleAnimal *proxy,

gboolean arg_make_sad,

gboolean arg_make_happy,

gboolean *out_result,

GCancellable *cancellable,

GError **error)

{

GVariant *_ret;

_ret = g_dbus_proxy_call_sync (G_DBUS_PROXY (proxy),

"Poke",

g_variant_new ("(bb)",

arg_make_sad,

arg_make_happy),

G_DBUS_CALL_FLAGS_NONE,

-1,

cancellable,

error);

if (_ret == NULL)

goto _out;

g_variant_get (_ret,

"(b)",

out_result);

g_variant_unref (_ret);

_out:

return _ret != NULL;

}
      •



    /**




    • example_animal_complete_poke:
      •

    • @object: A #ExampleAnimal.
      •

    • @invocation: (transfer full): A #GDBusMethodInvocation.
      •

    • @result: Parameter to return.
      •

    •

    • Helper function used in service implementations to finish handling invocations of the <link linkend="gdbus-method-org-gtk-GDBus-Example-ObjectManager-Animal.Poke">Poke()</link> D-Bus method. If you instead want to finish handling an invocation by returning an error, use g_dbus_method_invocation_return_error() or similar.
      •

    •

    • This method will free @invocation, you cannot use it afterwards.
      •

    •

    • Since: 2.30

*/

void

example_animal_complete_poke (

ExampleAnimal *object,

GDBusMethodInvocation *invocation,

gboolean result)

{

g_dbus_method_invocation_return_value (invocation,

g_variant_new ("(b)",

result));

}
      •



    /* ------------------------------------------------------------------------ */


    /**




    • ExampleAnimalProxy:
      •

    •

    • The #ExampleAnimalProxy structure contains only private data and should only be accessed using the provided API.
      •

    •

    • Since: 2.30

*/
      •



    /**




    • ExampleAnimalProxyClass:
      •

    • @parent_class: The parent class.
      •

    •

    • Class structure for #ExampleAnimalProxy.
      •

    •

    • Since: 2.30

*/
      •



    struct _ExampleAnimalProxyPrivate

{

GData *qdata;

};


    static void example_animal_proxy_iface_init (ExampleAnimalIface *iface);


    if GLIB_VERSION_MAX_ALLOWED >= GLIB_VERSION_2_38


    G_DEFINE_TYPE_WITH_CODE (ExampleAnimalProxy, example_animal_proxy, G_TYPE_DBUS_PROXY,

G_ADD_PRIVATE (ExampleAnimalProxy)

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_ANIMAL, example_animal_proxy_iface_init))


    else


    G_DEFINE_TYPE_WITH_CODE (ExampleAnimalProxy, example_animal_proxy, G_TYPE_DBUS_PROXY,

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_ANIMAL, example_animal_proxy_iface_init))


    endif


    static void

example_animal_proxy_finalize (GObject *object)

{

ExampleAnimalProxy *proxy = EXAMPLE_ANIMAL_PROXY (object);

g_datalist_clear (&proxy->priv->qdata);

G_OBJECT_CLASS (example_animal_proxy_parent_class)->finalize (object);

}


    static void

example_animal_proxy_get_property (GObject      *object,

guint         prop_id,

GValue       *value,

GParamSpec   *pspec G_GNUC_UNUSED)

{

const _ExtendedGDBusPropertyInfo *info;

GVariant *variant;

g_assert (prop_id != 0 && prop_id - 1 < 3);

info = (const _ExtendedGDBusPropertyInfo *) _example_animal_property_info_pointers[prop_id - 1];

variant = g_dbus_proxy_get_cached_property (G_DBUS_PROXY (object), info->parent_struct.name);

if (info->use_gvariant)

{

g_value_set_variant (value, variant);

}

else

{

if (variant != NULL)

g_dbus_gvariant_to_gvalue (variant, value);

}

if (variant != NULL)

g_variant_unref (variant);

}


    static void

example_animal_proxy_set_property_cb (GDBusProxy *proxy,

GAsyncResult *res,

gpointer      user_data)

{

const _ExtendedGDBusPropertyInfo *info = user_data;

GError *error;

GVariant *_ret;

error = NULL;

_ret = g_dbus_proxy_call_finish (proxy, res, &error);

if (!_ret)

{

g_warning ("Error setting property '%s' on interface org.gtk.GDBus.Example.ObjectManager.Animal: %s (%s, %d)",

info->parent_struct.name,

error->message, g_quark_to_string (error->domain), error->code);

g_error_free (error);

}

else

{

g_variant_unref (_ret);

}

}


    static void

example_animal_proxy_set_property (GObject      *object,

guint         prop_id,

const GValue *value,

GParamSpec   *pspec G_GNUC_UNUSED)

{

const _ExtendedGDBusPropertyInfo *info;

GVariant *variant;

g_assert (prop_id != 0 && prop_id - 1 < 3);

info = (const _ExtendedGDBusPropertyInfo *) _example_animal_property_info_pointers[prop_id - 1];

variant = g_dbus_gvalue_to_gvariant (value, G_VARIANT_TYPE (info->parent_struct.signature));

g_dbus_proxy_call (G_DBUS_PROXY (object),

"org.freedesktop.DBus.Properties.Set",

g_variant_new ("(ssv)", "org.gtk.GDBus.Example.ObjectManager.Animal", info->parent_struct.name, variant),

G_DBUS_CALL_FLAGS_NONE,

-1,

NULL, (GAsyncReadyCallback) example_animal_proxy_set_property_cb, (GDBusPropertyInfo *) &info->parent_struct);

g_variant_unref (variant);

}


    static void

example_animal_proxy_g_signal (GDBusProxy *proxy,

const gchar *sender_name G_GNUC_UNUSED,

const gchar *signal_name,

GVariant *parameters)

{

_ExtendedGDBusSignalInfo *info;

GVariantIter iter;

GVariant *child;

GValue *paramv;

gsize num_params;

gsize n;

guint signal_id;

info = (_ExtendedGDBusSignalInfo *) g_dbus_interface_info_lookup_signal ((GDBusInterfaceInfo *) &_example_animal_interface_info.parent_struct, signal_name);

if (info == NULL)

return;

num_params = g_variant_n_children (parameters);

paramv = g_new0 (GValue, num_params + 1);

g_value_init (&paramv[0], EXAMPLE_TYPE_ANIMAL);

g_value_set_object (&paramv[0], proxy);

g_variant_iter_init (&iter, parameters);

n = 1;

while ((child = g_variant_iter_next_value (&iter)) != NULL)

{

_ExtendedGDBusArgInfo *arg_info = (_ExtendedGDBusArgInfo *) info->parent_struct.args[n - 1];

if (arg_info->use_gvariant)

{

g_value_init (&paramv[n], G_TYPE_VARIANT);

g_value_set_variant (&paramv[n], child);

n++;

}

else

g_dbus_gvariant_to_gvalue (child, &paramv[n++]);

g_variant_unref (child);

}

signal_id = g_signal_lookup (info->signal_name, EXAMPLE_TYPE_ANIMAL);

g_signal_emitv (paramv, signal_id, 0, NULL);

for (n = 0; n < num_params + 1; n++)

g_value_unset (&paramv[n]);

g_free (paramv);

}


    static void

example_animal_proxy_g_properties_changed (GDBusProxy *_proxy,

GVariant *changed_properties,

const gchar *const *invalidated_properties)

{

ExampleAnimalProxy *proxy = EXAMPLE_ANIMAL_PROXY (_proxy);

guint n;

const gchar *key;

GVariantIter *iter;

_ExtendedGDBusPropertyInfo *info;

g_variant_get (changed_properties, "a{sv}", &iter);

while (g_variant_iter_next (iter, "{&sv}", &key, NULL))

{

info = (_ExtendedGDBusPropertyInfo *) g_dbus_interface_info_lookup_property ((GDBusInterfaceInfo *) &_example_animal_interface_info.parent_struct, key);

g_datalist_remove_data (&proxy->priv->qdata, key);

if (info != NULL)

g_object_notify (G_OBJECT (proxy), info->hyphen_name);

}

g_variant_iter_free (iter);

for (n = 0; invalidated_properties[n] != NULL; n++)

{

info = (_ExtendedGDBusPropertyInfo *) g_dbus_interface_info_lookup_property ((GDBusInterfaceInfo *) &_example_animal_interface_info.parent_struct, invalidated_properties[n]);

g_datalist_remove_data (&proxy->priv->qdata, invalidated_properties[n]);

if (info != NULL)

g_object_notify (G_OBJECT (proxy), info->hyphen_name);

}

}


    static const gchar *

example_animal_proxy_get_mood (ExampleAnimal *object)

{

ExampleAnimalProxy *proxy = EXAMPLE_ANIMAL_PROXY (object);

GVariant *variant;

const gchar *value = NULL;

variant = g_dbus_proxy_get_cached_property (G_DBUS_PROXY (proxy), "Mood");

if (variant != NULL)

{

value = g_variant_get_string (variant, NULL);

g_variant_unref (variant);

}

return value;

}


    static const gchar *

example_animal_proxy_get_foo (ExampleAnimal *object)

{

ExampleAnimalProxy *proxy = EXAMPLE_ANIMAL_PROXY (object);

GVariant *variant;

const gchar *value = NULL;

variant = g_dbus_proxy_get_cached_property (G_DBUS_PROXY (proxy), "Foo");

if (variant != NULL)

{

value = g_variant_get_string (variant, NULL);

g_variant_unref (variant);

}

return value;

}


    static const gchar *

example_animal_proxy_get_bar (ExampleAnimal *object)

{

ExampleAnimalProxy *proxy = EXAMPLE_ANIMAL_PROXY (object);

GVariant *variant;

const gchar *value = NULL;

variant = g_dbus_proxy_get_cached_property (G_DBUS_PROXY (proxy), "Bar");

if (variant != NULL)

{

value = g_variant_get_string (variant, NULL);

g_variant_unref (variant);

}

return value;

}


    static void

example_animal_proxy_init (ExampleAnimalProxy *proxy)

{


    if GLIB_VERSION_MAX_ALLOWED >= GLIB_VERSION_2_38


    proxy->priv = example_animal_proxy_get_instance_private (proxy);


    else


    proxy->priv = G_TYPE_INSTANCE_GET_PRIVATE (proxy, EXAMPLE_TYPE_ANIMAL_PROXY, ExampleAnimalProxyPrivate);


    endif


    g_dbus_proxy_set_interface_info (G_DBUS_PROXY (proxy), example_animal_interface_info ());

}


    static void

example_animal_proxy_class_init (ExampleAnimalProxyClass *klass)

{

GObjectClass *gobject_class;

GDBusProxyClass *proxy_class;


    gobject_class = G_OBJECT_CLASS (klass);

gobject_class->finalize     = example_animal_proxy_finalize;

gobject_class->get_property = example_animal_proxy_get_property;

gobject_class->set_property = example_animal_proxy_set_property;


    proxy_class = G_DBUS_PROXY_CLASS (klass);

proxy_class->g_signal = example_animal_proxy_g_signal;

proxy_class->g_properties_changed = example_animal_proxy_g_properties_changed;


    example_animal_override_properties (gobject_class, 1);


    if GLIB_VERSION_MAX_ALLOWED < GLIB_VERSION_2_38


    g_type_class_add_private (klass, sizeof (ExampleAnimalProxyPrivate));


    endif


    }


    static void

example_animal_proxy_iface_init (ExampleAnimalIface *iface)

{

iface->get_mood = example_animal_proxy_get_mood;

iface->get_foo = example_animal_proxy_get_foo;

iface->get_bar = example_animal_proxy_get_bar;

}


    /**




    • example_animal_proxy_new:
      •

    • @connection: A #GDBusConnection.
      •

    • @flags: Flags from the #GDBusProxyFlags enumeration.
      •

    • @name: (nullable): A bus name (well-known or unique) or %NULL if @connection is not a message bus connection.
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @callback: A #GAsyncReadyCallback to call when the request is satisfied.
      •

    • @user_data: User data to pass to @callback.
      •

    •

    • Asynchronously creates a proxy for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link>. See g_dbus_proxy_new() for more details.
      •

    •

    • When the operation is finished, @callback will be invoked in the thread-default main loop of the thread you are calling this method from (see g_main_context_push_thread_default()).
      •

    • You can then call example_animal_proxy_new_finish() to get the result of the operation.
      •

    •

    • See example_animal_proxy_new_sync() for the synchronous, blocking version of this constructor.
      •

    •

    • Since: 2.30

*/

void

example_animal_proxy_new (

GDBusConnection     *connection,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GAsyncReadyCallback  callback,

gpointer             user_data)

{

g_async_initable_new_async (EXAMPLE_TYPE_ANIMAL_PROXY, G_PRIORITY_DEFAULT, cancellable, callback, user_data, "g-flags", flags, "g-name", name, "g-connection", connection, "g-object-path", object_path, "g-interface-name", "org.gtk.GDBus.Example.ObjectManager.Animal", NULL);

}
      •



    /**




    • example_animal_proxy_new_finish:
      •

    • @res: The #GAsyncResult obtained from the #GAsyncReadyCallback passed to example_animal_proxy_new().
      •

    • @error: Return location for error or %NULL
      •

    •

    • Finishes an operation started with example_animal_proxy_new().
      •

    •

    • Returns: (transfer full) (type ExampleAnimalProxy): The constructed proxy object or %NULL if @error is set.
      •

    •

    • Since: 2.30

*/

ExampleAnimal *

example_animal_proxy_new_finish (

GAsyncResult        *res,

GError             **error)

{

GObject *ret;

GObject *source_object;

source_object = g_async_result_get_source_object (res);

ret = g_async_initable_new_finish (G_ASYNC_INITABLE (source_object), res, error);

g_object_unref (source_object);

if (ret != NULL)

return EXAMPLE_ANIMAL (ret);

else

return NULL;

}
      •



    /**




    • example_animal_proxy_new_sync:
      •

    • @connection: A #GDBusConnection.
      •

    • @flags: Flags from the #GDBusProxyFlags enumeration.
      •

    • @name: (nullable): A bus name (well-known or unique) or %NULL if @connection is not a message bus connection.
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @error: Return location for error or %NULL
      •

    •

    • Synchronously creates a proxy for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link>. See g_dbus_proxy_new_sync() for more details.
      •

    •

    • The calling thread is blocked until a reply is received.
      •

    •

    • See example_animal_proxy_new() for the asynchronous version of this constructor.
      •

    •

    • Returns: (transfer full) (type ExampleAnimalProxy): The constructed proxy object or %NULL if @error is set.
      •

    •

    • Since: 2.30

*/

ExampleAnimal *

example_animal_proxy_new_sync (

GDBusConnection     *connection,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GError             **error)

{

GInitable *ret;

ret = g_initable_new (EXAMPLE_TYPE_ANIMAL_PROXY, cancellable, error, "g-flags", flags, "g-name", name, "g-connection", connection, "g-object-path", object_path, "g-interface-name", "org.gtk.GDBus.Example.ObjectManager.Animal", NULL);

if (ret != NULL)

return EXAMPLE_ANIMAL (ret);

else

return NULL;

}
      •



    /**




    • example_animal_proxy_new_for_bus:
      •

    • @bus_type: A #GBusType.
      •

    • @flags: Flags from the #GDBusProxyFlags enumeration.
      •

    • @name: A bus name (well-known or unique).
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @callback: A #GAsyncReadyCallback to call when the request is satisfied.
      •

    • @user_data: User data to pass to @callback.
      •

    •

    • Like example_animal_proxy_new() but takes a #GBusType instead of a #GDBusConnection.
      •

    •

    • When the operation is finished, @callback will be invoked in the thread-default main loop of the thread you are calling this method from (see g_main_context_push_thread_default()).
      •

    • You can then call example_animal_proxy_new_for_bus_finish() to get the result of the operation.
      •

    •

    • See example_animal_proxy_new_for_bus_sync() for the synchronous, blocking version of this constructor.
      •

    •

    • Since: 2.30

*/

void

example_animal_proxy_new_for_bus (

GBusType             bus_type,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GAsyncReadyCallback  callback,

gpointer             user_data)

{

g_async_initable_new_async (EXAMPLE_TYPE_ANIMAL_PROXY, G_PRIORITY_DEFAULT, cancellable, callback, user_data, "g-flags", flags, "g-name", name, "g-bus-type", bus_type, "g-object-path", object_path, "g-interface-name", "org.gtk.GDBus.Example.ObjectManager.Animal", NULL);

}
      •



    /**




    • example_animal_proxy_new_for_bus_finish:
      •

    • @res: The #GAsyncResult obtained from the #GAsyncReadyCallback passed to example_animal_proxy_new_for_bus().
      •

    • @error: Return location for error or %NULL
      •

    •

    • Finishes an operation started with example_animal_proxy_new_for_bus().
      •

    •

    • Returns: (transfer full) (type ExampleAnimalProxy): The constructed proxy object or %NULL if @error is set.
      •

    •

    • Since: 2.30

*/

ExampleAnimal *

example_animal_proxy_new_for_bus_finish (

GAsyncResult        *res,

GError             **error)

{

GObject *ret;

GObject *source_object;

source_object = g_async_result_get_source_object (res);

ret = g_async_initable_new_finish (G_ASYNC_INITABLE (source_object), res, error);

g_object_unref (source_object);

if (ret != NULL)

return EXAMPLE_ANIMAL (ret);

else

return NULL;

}
      •



    /**




    • example_animal_proxy_new_for_bus_sync:
      •

    • @bus_type: A #GBusType.
      •

    • @flags: Flags from the #GDBusProxyFlags enumeration.
      •

    • @name: A bus name (well-known or unique).
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @error: Return location for error or %NULL
      •

    •

    • Like example_animal_proxy_new_sync() but takes a #GBusType instead of a #GDBusConnection.
      •

    •

    • The calling thread is blocked until a reply is received.
      •

    •

    • See example_animal_proxy_new_for_bus() for the asynchronous version of this constructor.
      •

    •

    • Returns: (transfer full) (type ExampleAnimalProxy): The constructed proxy object or %NULL if @error is set.
      •

    •

    • Since: 2.30

*/

ExampleAnimal *

example_animal_proxy_new_for_bus_sync (

GBusType             bus_type,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GError             **error)

{

GInitable *ret;

ret = g_initable_new (EXAMPLE_TYPE_ANIMAL_PROXY, cancellable, error, "g-flags", flags, "g-name", name, "g-bus-type", bus_type, "g-object-path", object_path, "g-interface-name", "org.gtk.GDBus.Example.ObjectManager.Animal", NULL);

if (ret != NULL)

return EXAMPLE_ANIMAL (ret);

else

return NULL;

}
      •



    /* ------------------------------------------------------------------------ */


    /**




    • ExampleAnimalSkeleton:
      •

    •

    • The #ExampleAnimalSkeleton structure contains only private data and should only be accessed using the provided API.
      •

    •

    • Since: 2.30

*/
      •



    /**




    • ExampleAnimalSkeletonClass:
      •

    • @parent_class: The parent class.
      •

    •

    • Class structure for #ExampleAnimalSkeleton.
      •

    •

    • Since: 2.30

*/
      •



    struct _ExampleAnimalSkeletonPrivate

{

GValue *properties;

GList *changed_properties;

GSource *changed_properties_idle_source;

GMainContext *context;

GMutex lock;

};


    static void

_example_animal_skeleton_handle_method_call (

GDBusConnection *connection G_GNUC_UNUSED,

const gchar *sender G_GNUC_UNUSED,

const gchar *object_path G_GNUC_UNUSED,

const gchar *interface_name,

const gchar *method_name,

GVariant *parameters,

GDBusMethodInvocation *invocation,

gpointer user_data)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (user_data);

_ExtendedGDBusMethodInfo *info;

GVariantIter iter;

GVariant *child;

GValue *paramv;

gsize num_params;

guint num_extra;

gsize n;

guint signal_id;

GValue return_value = G_VALUE_INIT;

info = (_ExtendedGDBusMethodInfo *) g_dbus_method_invocation_get_method_info (invocation);

g_assert (info != NULL);

num_params = g_variant_n_children (parameters);

num_extra = info->pass_fdlist ? 3 : 2;  paramv = g_new0 (GValue, num_params + num_extra);

n = 0;

g_value_init (&paramv[n], EXAMPLE_TYPE_ANIMAL);

g_value_set_object (&paramv[n++], skeleton);

g_value_init (&paramv[n], G_TYPE_DBUS_METHOD_INVOCATION);

g_value_set_object (&paramv[n++], invocation);

if (info->pass_fdlist)

{


    ifdef G_OS_UNIX


      g_value_init (&amp;paramv[n], G_TYPE_UNIX_FD_LIST);
  g_value_set_object (&amp;paramv[n++], g_dbus_message_get_unix_fd_list (g_dbus_method_invocation_get_message (invocation)));



    else


      g_assert_not_reached ();



    endif


    }



    g_variant_iter_init (&iter, parameters);

while ((child = g_variant_iter_next_value (&iter)) != NULL)

{

_ExtendedGDBusArgInfo *arg_info = (_ExtendedGDBusArgInfo *) info->parent_struct.in_args[n - num_extra];

if (arg_info->use_gvariant)

{

g_value_init (&paramv[n], G_TYPE_VARIANT);

g_value_set_variant (&paramv[n], child);

n++;

}

else

g_dbus_gvariant_to_gvalue (child, &paramv[n++]);

g_variant_unref (child);

}

signal_id = g_signal_lookup (info->signal_name, EXAMPLE_TYPE_ANIMAL);

g_value_init (&return_value, G_TYPE_BOOLEAN);

g_signal_emitv (paramv, signal_id, 0, &return_value);

if (!g_value_get_boolean (&return_value))

g_dbus_method_invocation_return_error (invocation, G_DBUS_ERROR, G_DBUS_ERROR_UNKNOWN_METHOD, "Method %s is not implemented on interface %s", method_name, interface_name);

g_value_unset (&return_value);

for (n = 0; n < num_params + num_extra; n++)

g_value_unset (&paramv[n]);

g_free (paramv);

}


    static GVariant *

_example_animal_skeleton_handle_get_property (

GDBusConnection *connection G_GNUC_UNUSED,

const gchar *sender G_GNUC_UNUSED,

const gchar *object_path G_GNUC_UNUSED,

const gchar *interface_name G_GNUC_UNUSED,

const gchar *property_name,

GError **error,

gpointer user_data)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (user_data);

GValue value = G_VALUE_INIT;

GParamSpec *pspec;

_ExtendedGDBusPropertyInfo *info;

GVariant *ret;

ret = NULL;

info = (_ExtendedGDBusPropertyInfo *) g_dbus_interface_info_lookup_property ((GDBusInterfaceInfo *) &_example_animal_interface_info.parent_struct, property_name);

g_assert (info != NULL);

pspec = g_object_class_find_property (G_OBJECT_GET_CLASS (skeleton), info->hyphen_name);

if (pspec == NULL)

{

g_set_error (error, G_DBUS_ERROR, G_DBUS_ERROR_INVALID_ARGS, "No property with name %s", property_name);

}

else

{

g_value_init (&value, pspec->value_type);

g_object_get_property (G_OBJECT (skeleton), info->hyphen_name, &value);

ret = g_dbus_gvalue_to_gvariant (&value, G_VARIANT_TYPE (info->parent_struct.signature));

g_value_unset (&value);

}

return ret;

}


    static gboolean

_example_animal_skeleton_handle_set_property (

GDBusConnection *connection G_GNUC_UNUSED,

const gchar *sender G_GNUC_UNUSED,

const gchar *object_path G_GNUC_UNUSED,

const gchar *interface_name G_GNUC_UNUSED,

const gchar *property_name,

GVariant *variant,

GError **error,

gpointer user_data)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (user_data);

GValue value = G_VALUE_INIT;

GParamSpec *pspec;

_ExtendedGDBusPropertyInfo *info;

gboolean ret;

ret = FALSE;

info = (_ExtendedGDBusPropertyInfo *) g_dbus_interface_info_lookup_property ((GDBusInterfaceInfo *) &_example_animal_interface_info.parent_struct, property_name);

g_assert (info != NULL);

pspec = g_object_class_find_property (G_OBJECT_GET_CLASS (skeleton), info->hyphen_name);

if (pspec == NULL)

{

g_set_error (error, G_DBUS_ERROR, G_DBUS_ERROR_INVALID_ARGS, "No property with name %s", property_name);

}

else

{

if (info->use_gvariant)

g_value_set_variant (&value, variant);

else

g_dbus_gvariant_to_gvalue (variant, &value);

g_object_set_property (G_OBJECT (skeleton), info->hyphen_name, &value);

g_value_unset (&value);

ret = TRUE;

}

return ret;

}


    static const GDBusInterfaceVTable _example_animal_skeleton_vtable =

{

_example_animal_skeleton_handle_method_call,

_example_animal_skeleton_handle_get_property,

_example_animal_skeleton_handle_set_property,

{NULL}

};


    static GDBusInterfaceInfo *

example_animal_skeleton_dbus_interface_get_info (GDBusInterfaceSkeleton *skeleton G_GNUC_UNUSED)

{

return example_animal_interface_info ();

}


    static GDBusInterfaceVTable *

example_animal_skeleton_dbus_interface_get_vtable (GDBusInterfaceSkeleton *skeleton G_GNUC_UNUSED)

{

return (GDBusInterfaceVTable *) &_example_animal_skeleton_vtable;

}


    static GVariant *

example_animal_skeleton_dbus_interface_get_properties (GDBusInterfaceSkeleton *_skeleton)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (_skeleton);


    GVariantBuilder builder;

guint n;

g_variant_builder_init (&builder, G_VARIANT_TYPE ("a{sv}"));

if (_example_animal_interface_info.parent_struct.properties == NULL)

goto out;

for (n = 0; _example_animal_interface_info.parent_struct.properties[n] != NULL; n++)

{

GDBusPropertyInfo *info = _example_animal_interface_info.parent_struct.properties[n];

if (info->flags & G_DBUS_PROPERTY_INFO_FLAGS_READABLE)

{

GVariant *value;

value = _example_animal_skeleton_handle_get_property (g_dbus_interface_skeleton_get_connection (G_DBUS_INTERFACE_SKELETON (skeleton)), NULL, g_dbus_interface_skeleton_get_object_path (G_DBUS_INTERFACE_SKELETON (skeleton)), "org.gtk.GDBus.Example.ObjectManager.Animal", info->name, NULL, skeleton);

if (value != NULL)

{

g_variant_take_ref (value);

g_variant_builder_add (&builder, "{sv}", info->name, value);

g_variant_unref (value);

}

}

}

out:

return g_variant_builder_end (&builder);

}


    static gboolean _example_animal_emit_changed (gpointer user_data);


    static void

example_animal_skeleton_dbus_interface_flush (GDBusInterfaceSkeleton *_skeleton)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (_skeleton);

gboolean emit_changed = FALSE;


    g_mutex_lock (&skeleton->priv->lock);

if (skeleton->priv->changed_properties_idle_source != NULL)

{

g_source_destroy (skeleton->priv->changed_properties_idle_source);

skeleton->priv->changed_properties_idle_source = NULL;

emit_changed = TRUE;

}

g_mutex_unlock (&skeleton->priv->lock);


    if (emit_changed)

_example_animal_emit_changed (skeleton);

}


    static void

_example_animal_on_signal_jumped (

ExampleAnimal *object,

gdouble arg_height)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (object);


    GList      *connections, *l;

GVariant   *signal_variant;

connections = g_dbus_interface_skeleton_get_connections (G_DBUS_INTERFACE_SKELETON (skeleton));


    signal_variant = g_variant_ref_sink (g_variant_new ("(d)",

arg_height));

for (l = connections; l != NULL; l = l->next)

{

GDBusConnection *connection = l->data;

g_dbus_connection_emit_signal (connection,

NULL, g_dbus_interface_skeleton_get_object_path (G_DBUS_INTERFACE_SKELETON (skeleton)), "org.gtk.GDBus.Example.ObjectManager.Animal", "Jumped",

signal_variant, NULL);

}

g_variant_unref (signal_variant);

g_list_free_full (connections, g_object_unref);

}


    static void example_animal_skeleton_iface_init (ExampleAnimalIface *iface);


    if GLIB_VERSION_MAX_ALLOWED >= GLIB_VERSION_2_38


    G_DEFINE_TYPE_WITH_CODE (ExampleAnimalSkeleton, example_animal_skeleton, G_TYPE_DBUS_INTERFACE_SKELETON,

G_ADD_PRIVATE (ExampleAnimalSkeleton)

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_ANIMAL, example_animal_skeleton_iface_init))


    else


    G_DEFINE_TYPE_WITH_CODE (ExampleAnimalSkeleton, example_animal_skeleton, G_TYPE_DBUS_INTERFACE_SKELETON,

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_ANIMAL, example_animal_skeleton_iface_init))


    endif


    static void

example_animal_skeleton_finalize (GObject *object)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (object);

guint n;

for (n = 0; n < 3; n++)

g_value_unset (&skeleton->priv->properties[n]);

g_free (skeleton->priv->properties);

g_list_free_full (skeleton->priv->changed_properties, (GDestroyNotify) _changed_property_free);

if (skeleton->priv->changed_properties_idle_source != NULL)

g_source_destroy (skeleton->priv->changed_properties_idle_source);

g_main_context_unref (skeleton->priv->context);

g_mutex_clear (&skeleton->priv->lock);

G_OBJECT_CLASS (example_animal_skeleton_parent_class)->finalize (object);

}


    static void

example_animal_skeleton_get_property (GObject      *object,

guint         prop_id,

GValue       *value,

GParamSpec   *pspec G_GNUC_UNUSED)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (object);

g_assert (prop_id != 0 && prop_id - 1 < 3);

g_mutex_lock (&skeleton->priv->lock);

g_value_copy (&skeleton->priv->properties[prop_id - 1], value);

g_mutex_unlock (&skeleton->priv->lock);

}


    static gboolean

_example_animal_emit_changed (gpointer user_data)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (user_data);

GList *l;

GVariantBuilder builder;

GVariantBuilder invalidated_builder;

guint num_changes;


    g_mutex_lock (&skeleton->priv->lock);

g_variant_builder_init (&builder, G_VARIANT_TYPE ("a{sv}"));

g_variant_builder_init (&invalidated_builder, G_VARIANT_TYPE ("as"));

for (l = skeleton->priv->changed_properties, num_changes = 0; l != NULL; l = l->next)

{

ChangedProperty *cp = l->data;

GVariant *variant;

const GValue *cur_value;


      cur_value = &amp;skeleton-&gt;priv-&gt;properties[cp-&gt;prop_id - 1];
  if (!_g_value_equal (cur_value, &amp;cp-&gt;orig_value))
    {
      variant = g_dbus_gvalue_to_gvariant (cur_value, G_VARIANT_TYPE (cp-&gt;info-&gt;parent_struct.signature));
      g_variant_builder_add (&amp;builder, &quot;{sv}&quot;, cp-&gt;info-&gt;parent_struct.name, variant);
      g_variant_unref (variant);
      num_changes++;
    }
}



    if (num_changes > 0)

{

GList *connections, *ll;

GVariant *signal_variant;

signal_variant = g_variant_ref_sink (g_variant_new ("(sa{sv}as)", "org.gtk.GDBus.Example.ObjectManager.Animal",

&builder, &invalidated_builder));

connections = g_dbus_interface_skeleton_get_connections (G_DBUS_INTERFACE_SKELETON (skeleton));

for (ll = connections; ll != NULL; ll = ll->next)

{

GDBusConnection *connection = ll->data;


          g_dbus_connection_emit_signal (connection,
                                     NULL, g_dbus_interface_skeleton_get_object_path (G_DBUS_INTERFACE_SKELETON (skeleton)),
                                     &quot;org.freedesktop.DBus.Properties&quot;,
                                     &quot;PropertiesChanged&quot;,
                                     signal_variant,
                                     NULL);
    }
  g_variant_unref (signal_variant);
  g_list_free_full (connections, g_object_unref);
}



    else

{

g_variant_builder_clear (&builder);

g_variant_builder_clear (&invalidated_builder);

}

g_list_free_full (skeleton->priv->changed_properties, (GDestroyNotify) _changed_property_free);

skeleton->priv->changed_properties = NULL;

skeleton->priv->changed_properties_idle_source = NULL;

g_mutex_unlock (&skeleton->priv->lock);

return FALSE;

}


    static void

_example_animal_schedule_emit_changed (ExampleAnimalSkeleton *skeleton, const _ExtendedGDBusPropertyInfo *info, guint prop_id, const GValue *orig_value)

{

ChangedProperty *cp;

GList *l;

cp = NULL;

for (l = skeleton->priv->changed_properties; l != NULL; l = l->next)

{

ChangedProperty *i_cp = l->data;

if (i_cp->info == info)

{

cp = i_cp;

break;

}

}

if (cp == NULL)

{

cp = g_new0 (ChangedProperty, 1);

cp->prop_id = prop_id;

cp->info = info;

skeleton->priv->changed_properties = g_list_prepend (skeleton->priv->changed_properties, cp);

g_value_init (&cp->orig_value, G_VALUE_TYPE (orig_value));

g_value_copy (orig_value, &cp->orig_value);

}

}


    static void

example_animal_skeleton_notify (GObject      *object,

GParamSpec *pspec G_GNUC_UNUSED)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (object);

g_mutex_lock (&skeleton->priv->lock);

if (skeleton->priv->changed_properties != NULL &&

skeleton->priv->changed_properties_idle_source == NULL)

{

skeleton->priv->changed_properties_idle_source = g_idle_source_new ();

g_source_set_priority (skeleton->priv->changed_properties_idle_source, G_PRIORITY_DEFAULT);

g_source_set_callback (skeleton->priv->changed_properties_idle_source, _example_animal_emit_changed, g_object_ref (skeleton), (GDestroyNotify) g_object_unref);

g_source_set_name (skeleton->priv->changed_properties_idle_source, "[generated] _example_animal_emit_changed");

g_source_attach (skeleton->priv->changed_properties_idle_source, skeleton->priv->context);

g_source_unref (skeleton->priv->changed_properties_idle_source);

}

g_mutex_unlock (&skeleton->priv->lock);

}


    static void

example_animal_skeleton_set_property (GObject      *object,

guint         prop_id,

const GValue *value,

GParamSpec   *pspec)

{

const _ExtendedGDBusPropertyInfo *info;

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (object);

g_assert (prop_id != 0 && prop_id - 1 < 3);

info = (const _ExtendedGDBusPropertyInfo *) _example_animal_property_info_pointers[prop_id - 1];

g_mutex_lock (&skeleton->priv->lock);

g_object_freeze_notify (object);

if (!_g_value_equal (value, &skeleton->priv->properties[prop_id - 1]))

{

if (g_dbus_interface_skeleton_get_connection (G_DBUS_INTERFACE_SKELETON (skeleton)) != NULL &&

info->emits_changed_signal)

_example_animal_schedule_emit_changed (skeleton, info, prop_id, &skeleton->priv->properties[prop_id - 1]);

g_value_copy (value, &skeleton->priv->properties[prop_id - 1]);

g_object_notify_by_pspec (object, pspec);

}

g_mutex_unlock (&skeleton->priv->lock);

g_object_thaw_notify (object);

}


    static void

example_animal_skeleton_init (ExampleAnimalSkeleton *skeleton)

{


    if GLIB_VERSION_MAX_ALLOWED >= GLIB_VERSION_2_38


    skeleton->priv = example_animal_skeleton_get_instance_private (skeleton);


    else


    skeleton->priv = G_TYPE_INSTANCE_GET_PRIVATE (skeleton, EXAMPLE_TYPE_ANIMAL_SKELETON, ExampleAnimalSkeletonPrivate);


    endif


    g_mutex_init (&skeleton->priv->lock);

skeleton->priv->context = g_main_context_ref_thread_default ();

skeleton->priv->properties = g_new0 (GValue, 3);

g_value_init (&skeleton->priv->properties[0], G_TYPE_STRING);

g_value_init (&skeleton->priv->properties[1], G_TYPE_STRING);

g_value_init (&skeleton->priv->properties[2], G_TYPE_STRING);

}


    static const gchar *

example_animal_skeleton_get_mood (ExampleAnimal *object)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (object);

const gchar *value;

g_mutex_lock (&skeleton->priv->lock);

value = g_value_get_string (&(skeleton->priv->properties[0]));

g_mutex_unlock (&skeleton->priv->lock);

return value;

}


    static const gchar *

example_animal_skeleton_get_foo (ExampleAnimal *object)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (object);

const gchar *value;

g_mutex_lock (&skeleton->priv->lock);

value = g_value_get_string (&(skeleton->priv->properties[1]));

g_mutex_unlock (&skeleton->priv->lock);

return value;

}


    static const gchar *

example_animal_skeleton_get_bar (ExampleAnimal *object)

{

ExampleAnimalSkeleton *skeleton = EXAMPLE_ANIMAL_SKELETON (object);

const gchar *value;

g_mutex_lock (&skeleton->priv->lock);

value = g_value_get_string (&(skeleton->priv->properties[2]));

g_mutex_unlock (&skeleton->priv->lock);

return value;

}


    static void

example_animal_skeleton_class_init (ExampleAnimalSkeletonClass *klass)

{

GObjectClass *gobject_class;

GDBusInterfaceSkeletonClass *skeleton_class;


    gobject_class = G_OBJECT_CLASS (klass);

gobject_class->finalize = example_animal_skeleton_finalize;

gobject_class->get_property = example_animal_skeleton_get_property;

gobject_class->set_property = example_animal_skeleton_set_property;

gobject_class->notify       = example_animal_skeleton_notify;


    example_animal_override_properties (gobject_class, 1);


    skeleton_class = G_DBUS_INTERFACE_SKELETON_CLASS (klass);

skeleton_class->get_info = example_animal_skeleton_dbus_interface_get_info;

skeleton_class->get_properties = example_animal_skeleton_dbus_interface_get_properties;

skeleton_class->flush = example_animal_skeleton_dbus_interface_flush;

skeleton_class->get_vtable = example_animal_skeleton_dbus_interface_get_vtable;


    if GLIB_VERSION_MAX_ALLOWED < GLIB_VERSION_2_38


    g_type_class_add_private (klass, sizeof (ExampleAnimalSkeletonPrivate));


    endif


    }


    static void

example_animal_skeleton_iface_init (ExampleAnimalIface *iface)

{

iface->jumped = _example_animal_on_signal_jumped;

iface->get_mood = example_animal_skeleton_get_mood;

iface->get_foo = example_animal_skeleton_get_foo;

iface->get_bar = example_animal_skeleton_get_bar;

}


    /**




    • example_animal_skeleton_new:
      •

    •

    • Creates a skeleton object for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link>.
      •

    •

    • Returns: (transfer full) (type ExampleAnimalSkeleton): The skeleton object.
      •

    •

    • Since: 2.30

*/

ExampleAnimal *

example_animal_skeleton_new (void)

{

return EXAMPLE_ANIMAL (g_object_new (EXAMPLE_TYPE_ANIMAL_SKELETON, NULL));

}
      •



    /* ------------------------------------------------------------------------




    • Code for interface org.gtk.GDBus.Example.ObjectManager.Cat
      •

    •



      •



    */


    /**




    • SECTION:ExampleCat
      •

    • @title: ExampleCat
      •

    • @short_description: Generated C code for the org.gtk.GDBus.Example.ObjectManager.Cat D-Bus interface
      •

    •

    • This section contains code for working with the <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link> D-Bus interface in C.

*/
      •



    /* ---- Introspection data for org.gtk.GDBus.Example.ObjectManager.Cat ---- */


    static const _ExtendedGDBusInterfaceInfo _example_cat_interface_info =

{

{

-1,

(gchar *) "org.gtk.GDBus.Example.ObjectManager.Cat",

NULL,

NULL,

NULL,

NULL

},

"cat",

};


    /**




    • example_cat_interface_info:
      •

    •

    • Gets a machine-readable description of the <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link> D-Bus interface.
      •

    •

    • Returns: (transfer none): A #GDBusInterfaceInfo. Do not free.

*/

GDBusInterfaceInfo *

example_cat_interface_info (void)

{

return (GDBusInterfaceInfo *) &_example_cat_interface_info.parent_struct;

}
      •



    /**




    • example_cat_override_properties:
      •

    • @klass: The class structure for a #GObject derived class.
      •

    • @property_id_begin: The property id to assign to the first overridden property.
      •

    •

    • Overrides all #GObject properties in the #ExampleCat interface for a concrete class.
      •

    • The properties are overridden in the order they are defined.
      •

    •

    • Returns: The last property id.

*/

guint

example_cat_override_properties (GObjectClass *klass, guint property_id_begin)

{

return property_id_begin - 1;

}
      •



    /**




    • ExampleCat:
      •

    •

    • Abstract interface type for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link>.

*/
      •



    /**




    • ExampleCatIface:
      •

    • @parent_iface: The parent interface.
      •

    •

    • Virtual table for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link>.

*/
      •



    typedef ExampleCatIface ExampleCatInterface;

G_DEFINE_INTERFACE (ExampleCat, example_cat, G_TYPE_OBJECT)


    static void

example_cat_default_init (ExampleCatIface *iface)

{

}


    /* ------------------------------------------------------------------------ */


    /**




    • ExampleCatProxy:
      •

    •

    • The #ExampleCatProxy structure contains only private data and should only be accessed using the provided API.

*/
      •



    /**




    • ExampleCatProxyClass:
      •

    • @parent_class: The parent class.
      •

    •

    • Class structure for #ExampleCatProxy.

*/
      •



    struct _ExampleCatProxyPrivate

{

GData *qdata;

};


    static void example_cat_proxy_iface_init (ExampleCatIface *iface);


    if GLIB_VERSION_MAX_ALLOWED >= GLIB_VERSION_2_38


    G_DEFINE_TYPE_WITH_CODE (ExampleCatProxy, example_cat_proxy, G_TYPE_DBUS_PROXY,

G_ADD_PRIVATE (ExampleCatProxy)

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_CAT, example_cat_proxy_iface_init))


    else


    G_DEFINE_TYPE_WITH_CODE (ExampleCatProxy, example_cat_proxy, G_TYPE_DBUS_PROXY,

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_CAT, example_cat_proxy_iface_init))


    endif


    static void

example_cat_proxy_finalize (GObject *object)

{

ExampleCatProxy *proxy = EXAMPLE_CAT_PROXY (object);

g_datalist_clear (&proxy->priv->qdata);

G_OBJECT_CLASS (example_cat_proxy_parent_class)->finalize (object);

}


    static void

example_cat_proxy_get_property (GObject      *object,

guint         prop_id,

GValue       *value,

GParamSpec   *pspec G_GNUC_UNUSED)

{

}


    static void

example_cat_proxy_set_property (GObject      *object,

guint         prop_id,

const GValue *value,

GParamSpec   *pspec G_GNUC_UNUSED)

{

}


    static void

example_cat_proxy_g_signal (GDBusProxy *proxy,

const gchar *sender_name G_GNUC_UNUSED,

const gchar *signal_name,

GVariant *parameters)

{

_ExtendedGDBusSignalInfo *info;

GVariantIter iter;

GVariant *child;

GValue *paramv;

gsize num_params;

gsize n;

guint signal_id;

info = (_ExtendedGDBusSignalInfo *) g_dbus_interface_info_lookup_signal ((GDBusInterfaceInfo *) &_example_cat_interface_info.parent_struct, signal_name);

if (info == NULL)

return;

num_params = g_variant_n_children (parameters);

paramv = g_new0 (GValue, num_params + 1);

g_value_init (&paramv[0], EXAMPLE_TYPE_CAT);

g_value_set_object (&paramv[0], proxy);

g_variant_iter_init (&iter, parameters);

n = 1;

while ((child = g_variant_iter_next_value (&iter)) != NULL)

{

_ExtendedGDBusArgInfo *arg_info = (_ExtendedGDBusArgInfo *) info->parent_struct.args[n - 1];

if (arg_info->use_gvariant)

{

g_value_init (&paramv[n], G_TYPE_VARIANT);

g_value_set_variant (&paramv[n], child);

n++;

}

else

g_dbus_gvariant_to_gvalue (child, &paramv[n++]);

g_variant_unref (child);

}

signal_id = g_signal_lookup (info->signal_name, EXAMPLE_TYPE_CAT);

g_signal_emitv (paramv, signal_id, 0, NULL);

for (n = 0; n < num_params + 1; n++)

g_value_unset (&paramv[n]);

g_free (paramv);

}


    static void

example_cat_proxy_g_properties_changed (GDBusProxy *_proxy,

GVariant *changed_properties,

const gchar *const *invalidated_properties)

{

ExampleCatProxy *proxy = EXAMPLE_CAT_PROXY (_proxy);

guint n;

const gchar *key;

GVariantIter *iter;

_ExtendedGDBusPropertyInfo *info;

g_variant_get (changed_properties, "a{sv}", &iter);

while (g_variant_iter_next (iter, "{&sv}", &key, NULL))

{

info = (_ExtendedGDBusPropertyInfo *) g_dbus_interface_info_lookup_property ((GDBusInterfaceInfo *) &_example_cat_interface_info.parent_struct, key);

g_datalist_remove_data (&proxy->priv->qdata, key);

if (info != NULL)

g_object_notify (G_OBJECT (proxy), info->hyphen_name);

}

g_variant_iter_free (iter);

for (n = 0; invalidated_properties[n] != NULL; n++)

{

info = (_ExtendedGDBusPropertyInfo *) g_dbus_interface_info_lookup_property ((GDBusInterfaceInfo *) &_example_cat_interface_info.parent_struct, invalidated_properties[n]);

g_datalist_remove_data (&proxy->priv->qdata, invalidated_properties[n]);

if (info != NULL)

g_object_notify (G_OBJECT (proxy), info->hyphen_name);

}

}


    static void

example_cat_proxy_init (ExampleCatProxy *proxy)

{


    if GLIB_VERSION_MAX_ALLOWED >= GLIB_VERSION_2_38


    proxy->priv = example_cat_proxy_get_instance_private (proxy);


    else


    proxy->priv = G_TYPE_INSTANCE_GET_PRIVATE (proxy, EXAMPLE_TYPE_CAT_PROXY, ExampleCatProxyPrivate);


    endif


    g_dbus_proxy_set_interface_info (G_DBUS_PROXY (proxy), example_cat_interface_info ());

}


    static void

example_cat_proxy_class_init (ExampleCatProxyClass *klass)

{

GObjectClass *gobject_class;

GDBusProxyClass *proxy_class;


    gobject_class = G_OBJECT_CLASS (klass);

gobject_class->finalize     = example_cat_proxy_finalize;

gobject_class->get_property = example_cat_proxy_get_property;

gobject_class->set_property = example_cat_proxy_set_property;


    proxy_class = G_DBUS_PROXY_CLASS (klass);

proxy_class->g_signal = example_cat_proxy_g_signal;

proxy_class->g_properties_changed = example_cat_proxy_g_properties_changed;


    if GLIB_VERSION_MAX_ALLOWED < GLIB_VERSION_2_38


    g_type_class_add_private (klass, sizeof (ExampleCatProxyPrivate));


    endif


    }


    static void

example_cat_proxy_iface_init (ExampleCatIface *iface)

{

}


    /**




    • example_cat_proxy_new:
      •

    • @connection: A #GDBusConnection.
      •

    • @flags: Flags from the #GDBusProxyFlags enumeration.
      •

    • @name: (nullable): A bus name (well-known or unique) or %NULL if @connection is not a message bus connection.
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @callback: A #GAsyncReadyCallback to call when the request is satisfied.
      •

    • @user_data: User data to pass to @callback.
      •

    •

    • Asynchronously creates a proxy for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link>. See g_dbus_proxy_new() for more details.
      •

    •

    • When the operation is finished, @callback will be invoked in the thread-default main loop of the thread you are calling this method from (see g_main_context_push_thread_default()).
      •

    • You can then call example_cat_proxy_new_finish() to get the result of the operation.
      •

    •

    • See example_cat_proxy_new_sync() for the synchronous, blocking version of this constructor.

*/

void

example_cat_proxy_new (

GDBusConnection     *connection,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GAsyncReadyCallback  callback,

gpointer             user_data)

{

g_async_initable_new_async (EXAMPLE_TYPE_CAT_PROXY, G_PRIORITY_DEFAULT, cancellable, callback, user_data, "g-flags", flags, "g-name", name, "g-connection", connection, "g-object-path", object_path, "g-interface-name", "org.gtk.GDBus.Example.ObjectManager.Cat", NULL);

}
      •



    /**




    • example_cat_proxy_new_finish:
      •

    • @res: The #GAsyncResult obtained from the #GAsyncReadyCallback passed to example_cat_proxy_new().
      •

    • @error: Return location for error or %NULL
      •

    •

    • Finishes an operation started with example_cat_proxy_new().
      •

    •

    • Returns: (transfer full) (type ExampleCatProxy): The constructed proxy object or %NULL if @error is set.

*/

ExampleCat *

example_cat_proxy_new_finish (

GAsyncResult        *res,

GError             **error)

{

GObject *ret;

GObject *source_object;

source_object = g_async_result_get_source_object (res);

ret = g_async_initable_new_finish (G_ASYNC_INITABLE (source_object), res, error);

g_object_unref (source_object);

if (ret != NULL)

return EXAMPLE_CAT (ret);

else

return NULL;

}
      •



    /**




    • example_cat_proxy_new_sync:
      •

    • @connection: A #GDBusConnection.
      •

    • @flags: Flags from the #GDBusProxyFlags enumeration.
      •

    • @name: (nullable): A bus name (well-known or unique) or %NULL if @connection is not a message bus connection.
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @error: Return location for error or %NULL
      •

    •

    • Synchronously creates a proxy for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link>. See g_dbus_proxy_new_sync() for more details.
      •

    •

    • The calling thread is blocked until a reply is received.
      •

    •

    • See example_cat_proxy_new() for the asynchronous version of this constructor.
      •

    •

    • Returns: (transfer full) (type ExampleCatProxy): The constructed proxy object or %NULL if @error is set.

*/

ExampleCat *

example_cat_proxy_new_sync (

GDBusConnection     *connection,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GError             **error)

{

GInitable *ret;

ret = g_initable_new (EXAMPLE_TYPE_CAT_PROXY, cancellable, error, "g-flags", flags, "g-name", name, "g-connection", connection, "g-object-path", object_path, "g-interface-name", "org.gtk.GDBus.Example.ObjectManager.Cat", NULL);

if (ret != NULL)

return EXAMPLE_CAT (ret);

else

return NULL;

}
      •



    /**




    • example_cat_proxy_new_for_bus:
      •

    • @bus_type: A #GBusType.
      •

    • @flags: Flags from the #GDBusProxyFlags enumeration.
      •

    • @name: A bus name (well-known or unique).
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @callback: A #GAsyncReadyCallback to call when the request is satisfied.
      •

    • @user_data: User data to pass to @callback.
      •

    •

    • Like example_cat_proxy_new() but takes a #GBusType instead of a #GDBusConnection.
      •

    •

    • When the operation is finished, @callback will be invoked in the thread-default main loop of the thread you are calling this method from (see g_main_context_push_thread_default()).
      •

    • You can then call example_cat_proxy_new_for_bus_finish() to get the result of the operation.
      •

    •

    • See example_cat_proxy_new_for_bus_sync() for the synchronous, blocking version of this constructor.

*/

void

example_cat_proxy_new_for_bus (

GBusType             bus_type,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GAsyncReadyCallback  callback,

gpointer             user_data)

{

g_async_initable_new_async (EXAMPLE_TYPE_CAT_PROXY, G_PRIORITY_DEFAULT, cancellable, callback, user_data, "g-flags", flags, "g-name", name, "g-bus-type", bus_type, "g-object-path", object_path, "g-interface-name", "org.gtk.GDBus.Example.ObjectManager.Cat", NULL);

}
      •



    /**




    • example_cat_proxy_new_for_bus_finish:
      •

    • @res: The #GAsyncResult obtained from the #GAsyncReadyCallback passed to example_cat_proxy_new_for_bus().
      •

    • @error: Return location for error or %NULL
      •

    •

    • Finishes an operation started with example_cat_proxy_new_for_bus().
      •

    •

    • Returns: (transfer full) (type ExampleCatProxy): The constructed proxy object or %NULL if @error is set.

*/

ExampleCat *

example_cat_proxy_new_for_bus_finish (

GAsyncResult        *res,

GError             **error)

{

GObject *ret;

GObject *source_object;

source_object = g_async_result_get_source_object (res);

ret = g_async_initable_new_finish (G_ASYNC_INITABLE (source_object), res, error);

g_object_unref (source_object);

if (ret != NULL)

return EXAMPLE_CAT (ret);

else

return NULL;

}
      •



    /**




    • example_cat_proxy_new_for_bus_sync:
      •

    • @bus_type: A #GBusType.
      •

    • @flags: Flags from the #GDBusProxyFlags enumeration.
      •

    • @name: A bus name (well-known or unique).
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @error: Return location for error or %NULL
      •

    •

    • Like example_cat_proxy_new_sync() but takes a #GBusType instead of a #GDBusConnection.
      •

    •

    • The calling thread is blocked until a reply is received.
      •

    •

    • See example_cat_proxy_new_for_bus() for the asynchronous version of this constructor.
      •

    •

    • Returns: (transfer full) (type ExampleCatProxy): The constructed proxy object or %NULL if @error is set.

*/

ExampleCat *

example_cat_proxy_new_for_bus_sync (

GBusType             bus_type,

GDBusProxyFlags      flags,

const gchar         *name,

const gchar         *object_path,

GCancellable        *cancellable,

GError             **error)

{

GInitable *ret;

ret = g_initable_new (EXAMPLE_TYPE_CAT_PROXY, cancellable, error, "g-flags", flags, "g-name", name, "g-bus-type", bus_type, "g-object-path", object_path, "g-interface-name", "org.gtk.GDBus.Example.ObjectManager.Cat", NULL);

if (ret != NULL)

return EXAMPLE_CAT (ret);

else

return NULL;

}
      •



    /* ------------------------------------------------------------------------ */


    /**




    • ExampleCatSkeleton:
      •

    •

    • The #ExampleCatSkeleton structure contains only private data and should only be accessed using the provided API.

*/
      •



    /**




    • ExampleCatSkeletonClass:
      •

    • @parent_class: The parent class.
      •

    •

    • Class structure for #ExampleCatSkeleton.

*/
      •



    struct _ExampleCatSkeletonPrivate

{

GValue *properties;

GList *changed_properties;

GSource *changed_properties_idle_source;

GMainContext *context;

GMutex lock;

};


    static void

_example_cat_skeleton_handle_method_call (

GDBusConnection *connection G_GNUC_UNUSED,

const gchar *sender G_GNUC_UNUSED,

const gchar *object_path G_GNUC_UNUSED,

const gchar *interface_name,

const gchar *method_name,

GVariant *parameters,

GDBusMethodInvocation *invocation,

gpointer user_data)

{

ExampleCatSkeleton *skeleton = EXAMPLE_CAT_SKELETON (user_data);

_ExtendedGDBusMethodInfo *info;

GVariantIter iter;

GVariant *child;

GValue *paramv;

gsize num_params;

guint num_extra;

gsize n;

guint signal_id;

GValue return_value = G_VALUE_INIT;

info = (_ExtendedGDBusMethodInfo *) g_dbus_method_invocation_get_method_info (invocation);

g_assert (info != NULL);

num_params = g_variant_n_children (parameters);

num_extra = info->pass_fdlist ? 3 : 2;  paramv = g_new0 (GValue, num_params + num_extra);

n = 0;

g_value_init (&paramv[n], EXAMPLE_TYPE_CAT);

g_value_set_object (&paramv[n++], skeleton);

g_value_init (&paramv[n], G_TYPE_DBUS_METHOD_INVOCATION);

g_value_set_object (&paramv[n++], invocation);

if (info->pass_fdlist)

{


    ifdef G_OS_UNIX


      g_value_init (&amp;paramv[n], G_TYPE_UNIX_FD_LIST);
  g_value_set_object (&amp;paramv[n++], g_dbus_message_get_unix_fd_list (g_dbus_method_invocation_get_message (invocation)));



    else


      g_assert_not_reached ();



    endif


    }



    g_variant_iter_init (&iter, parameters);

while ((child = g_variant_iter_next_value (&iter)) != NULL)

{

_ExtendedGDBusArgInfo *arg_info = (_ExtendedGDBusArgInfo *) info->parent_struct.in_args[n - num_extra];

if (arg_info->use_gvariant)

{

g_value_init (&paramv[n], G_TYPE_VARIANT);

g_value_set_variant (&paramv[n], child);

n++;

}

else

g_dbus_gvariant_to_gvalue (child, &paramv[n++]);

g_variant_unref (child);

}

signal_id = g_signal_lookup (info->signal_name, EXAMPLE_TYPE_CAT);

g_value_init (&return_value, G_TYPE_BOOLEAN);

g_signal_emitv (paramv, signal_id, 0, &return_value);

if (!g_value_get_boolean (&return_value))

g_dbus_method_invocation_return_error (invocation, G_DBUS_ERROR, G_DBUS_ERROR_UNKNOWN_METHOD, "Method %s is not implemented on interface %s", method_name, interface_name);

g_value_unset (&return_value);

for (n = 0; n < num_params + num_extra; n++)

g_value_unset (&paramv[n]);

g_free (paramv);

}


    static GVariant *

_example_cat_skeleton_handle_get_property (

GDBusConnection *connection G_GNUC_UNUSED,

const gchar *sender G_GNUC_UNUSED,

const gchar *object_path G_GNUC_UNUSED,

const gchar *interface_name G_GNUC_UNUSED,

const gchar *property_name,

GError **error,

gpointer user_data)

{

ExampleCatSkeleton *skeleton = EXAMPLE_CAT_SKELETON (user_data);

GValue value = G_VALUE_INIT;

GParamSpec *pspec;

_ExtendedGDBusPropertyInfo *info;

GVariant *ret;

ret = NULL;

info = (_ExtendedGDBusPropertyInfo *) g_dbus_interface_info_lookup_property ((GDBusInterfaceInfo *) &_example_cat_interface_info.parent_struct, property_name);

g_assert (info != NULL);

pspec = g_object_class_find_property (G_OBJECT_GET_CLASS (skeleton), info->hyphen_name);

if (pspec == NULL)

{

g_set_error (error, G_DBUS_ERROR, G_DBUS_ERROR_INVALID_ARGS, "No property with name %s", property_name);

}

else

{

g_value_init (&value, pspec->value_type);

g_object_get_property (G_OBJECT (skeleton), info->hyphen_name, &value);

ret = g_dbus_gvalue_to_gvariant (&value, G_VARIANT_TYPE (info->parent_struct.signature));

g_value_unset (&value);

}

return ret;

}


    static gboolean

_example_cat_skeleton_handle_set_property (

GDBusConnection *connection G_GNUC_UNUSED,

const gchar *sender G_GNUC_UNUSED,

const gchar *object_path G_GNUC_UNUSED,

const gchar *interface_name G_GNUC_UNUSED,

const gchar *property_name,

GVariant *variant,

GError **error,

gpointer user_data)

{

ExampleCatSkeleton *skeleton = EXAMPLE_CAT_SKELETON (user_data);

GValue value = G_VALUE_INIT;

GParamSpec *pspec;

_ExtendedGDBusPropertyInfo *info;

gboolean ret;

ret = FALSE;

info = (_ExtendedGDBusPropertyInfo *) g_dbus_interface_info_lookup_property ((GDBusInterfaceInfo *) &_example_cat_interface_info.parent_struct, property_name);

g_assert (info != NULL);

pspec = g_object_class_find_property (G_OBJECT_GET_CLASS (skeleton), info->hyphen_name);

if (pspec == NULL)

{

g_set_error (error, G_DBUS_ERROR, G_DBUS_ERROR_INVALID_ARGS, "No property with name %s", property_name);

}

else

{

if (info->use_gvariant)

g_value_set_variant (&value, variant);

else

g_dbus_gvariant_to_gvalue (variant, &value);

g_object_set_property (G_OBJECT (skeleton), info->hyphen_name, &value);

g_value_unset (&value);

ret = TRUE;

}

return ret;

}


    static const GDBusInterfaceVTable _example_cat_skeleton_vtable =

{

_example_cat_skeleton_handle_method_call,

_example_cat_skeleton_handle_get_property,

_example_cat_skeleton_handle_set_property,

{NULL}

};


    static GDBusInterfaceInfo *

example_cat_skeleton_dbus_interface_get_info (GDBusInterfaceSkeleton *skeleton G_GNUC_UNUSED)

{

return example_cat_interface_info ();

}


    static GDBusInterfaceVTable *

example_cat_skeleton_dbus_interface_get_vtable (GDBusInterfaceSkeleton *skeleton G_GNUC_UNUSED)

{

return (GDBusInterfaceVTable *) &_example_cat_skeleton_vtable;

}


    static GVariant *

example_cat_skeleton_dbus_interface_get_properties (GDBusInterfaceSkeleton *_skeleton)

{

ExampleCatSkeleton *skeleton = EXAMPLE_CAT_SKELETON (_skeleton);


    GVariantBuilder builder;

guint n;

g_variant_builder_init (&builder, G_VARIANT_TYPE ("a{sv}"));

if (_example_cat_interface_info.parent_struct.properties == NULL)

goto out;

for (n = 0; _example_cat_interface_info.parent_struct.properties[n] != NULL; n++)

{

GDBusPropertyInfo *info = _example_cat_interface_info.parent_struct.properties[n];

if (info->flags & G_DBUS_PROPERTY_INFO_FLAGS_READABLE)

{

GVariant *value;

value = _example_cat_skeleton_handle_get_property (g_dbus_interface_skeleton_get_connection (G_DBUS_INTERFACE_SKELETON (skeleton)), NULL, g_dbus_interface_skeleton_get_object_path (G_DBUS_INTERFACE_SKELETON (skeleton)), "org.gtk.GDBus.Example.ObjectManager.Cat", info->name, NULL, skeleton);

if (value != NULL)

{

g_variant_take_ref (value);

g_variant_builder_add (&builder, "{sv}", info->name, value);

g_variant_unref (value);

}

}

}

out:

return g_variant_builder_end (&builder);

}


    static void

example_cat_skeleton_dbus_interface_flush (GDBusInterfaceSkeleton *_skeleton)

{

}


    static void example_cat_skeleton_iface_init (ExampleCatIface *iface);


    if GLIB_VERSION_MAX_ALLOWED >= GLIB_VERSION_2_38


    G_DEFINE_TYPE_WITH_CODE (ExampleCatSkeleton, example_cat_skeleton, G_TYPE_DBUS_INTERFACE_SKELETON,

G_ADD_PRIVATE (ExampleCatSkeleton)

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_CAT, example_cat_skeleton_iface_init))


    else


    G_DEFINE_TYPE_WITH_CODE (ExampleCatSkeleton, example_cat_skeleton, G_TYPE_DBUS_INTERFACE_SKELETON,

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_CAT, example_cat_skeleton_iface_init))


    endif


    static void

example_cat_skeleton_finalize (GObject *object)

{

ExampleCatSkeleton *skeleton = EXAMPLE_CAT_SKELETON (object);

g_list_free_full (skeleton->priv->changed_properties, (GDestroyNotify) _changed_property_free);

if (skeleton->priv->changed_properties_idle_source != NULL)

g_source_destroy (skeleton->priv->changed_properties_idle_source);

g_main_context_unref (skeleton->priv->context);

g_mutex_clear (&skeleton->priv->lock);

G_OBJECT_CLASS (example_cat_skeleton_parent_class)->finalize (object);

}


    static void

example_cat_skeleton_init (ExampleCatSkeleton *skeleton)

{


    if GLIB_VERSION_MAX_ALLOWED >= GLIB_VERSION_2_38


    skeleton->priv = example_cat_skeleton_get_instance_private (skeleton);


    else


    skeleton->priv = G_TYPE_INSTANCE_GET_PRIVATE (skeleton, EXAMPLE_TYPE_CAT_SKELETON, ExampleCatSkeletonPrivate);


    endif


    g_mutex_init (&skeleton->priv->lock);

skeleton->priv->context = g_main_context_ref_thread_default ();

}


    static void

example_cat_skeleton_class_init (ExampleCatSkeletonClass *klass)

{

GObjectClass *gobject_class;

GDBusInterfaceSkeletonClass *skeleton_class;


    gobject_class = G_OBJECT_CLASS (klass);

gobject_class->finalize = example_cat_skeleton_finalize;


    skeleton_class = G_DBUS_INTERFACE_SKELETON_CLASS (klass);

skeleton_class->get_info = example_cat_skeleton_dbus_interface_get_info;

skeleton_class->get_properties = example_cat_skeleton_dbus_interface_get_properties;

skeleton_class->flush = example_cat_skeleton_dbus_interface_flush;

skeleton_class->get_vtable = example_cat_skeleton_dbus_interface_get_vtable;


    if GLIB_VERSION_MAX_ALLOWED < GLIB_VERSION_2_38


    g_type_class_add_private (klass, sizeof (ExampleCatSkeletonPrivate));


    endif


    }


    static void

example_cat_skeleton_iface_init (ExampleCatIface *iface)

{

}


    /**




    • example_cat_skeleton_new:
      •

    •

    • Creates a skeleton object for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link>.
      •

    •

    • Returns: (transfer full) (type ExampleCatSkeleton): The skeleton object.

*/

ExampleCat *

example_cat_skeleton_new (void)

{

return EXAMPLE_CAT (g_object_new (EXAMPLE_TYPE_CAT_SKELETON, NULL));

}
      •



    /* ------------------------------------------------------------------------




    • Code for Object, ObjectProxy and ObjectSkeleton
      •

    •



      •



    */


    /**




    • SECTION:ExampleObject
      •

    • @title: ExampleObject
      •

    • @short_description: Specialized GDBusObject types
      •

    •

    • This section contains the #ExampleObject, #ExampleObjectProxy, and #ExampleObjectSkeleton types which make it easier to work with objects implementing generated types for D-Bus interfaces.

*/
      •



    /**




    • ExampleObject:
      •

    •

    • The #ExampleObject type is a specialized container of interfaces.

*/
      •



    /**




    • ExampleObjectIface:
      •

    • @parent_iface: The parent interface.
      •

    •

    • Virtual table for the #ExampleObject interface.

*/
      •



    typedef ExampleObjectIface ExampleObjectInterface;

G_DEFINE_INTERFACE_WITH_CODE (ExampleObject, example_object, G_TYPE_OBJECT, g_type_interface_add_prerequisite (g_define_type_id, G_TYPE_DBUS_OBJECT)😉


    static void

example_object_default_init (ExampleObjectIface iface)

{

/    *




    • ExampleObject:animal:
      •

    •

    • The #ExampleAnimal instance corresponding to the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link>, if any.
      •

    •

    • Connect to the #GObject::notify signal to get informed of property changes.
      •

    •

    • Since: 2.30

*/

g_object_interface_install_property (iface, g_param_spec_object ("animal", "animal", "animal", EXAMPLE_TYPE_ANIMAL, G_PARAM_READWRITE | G_PARAM_STATIC_STRINGS));
      •



    /**




    • ExampleObject🐱
      •

    •

    • The #ExampleCat instance corresponding to the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link>, if any.
      •

    •

    • Connect to the #GObject::notify signal to get informed of property changes.

*/

g_object_interface_install_property (iface, g_param_spec_object ("cat", "cat", "cat", EXAMPLE_TYPE_CAT, G_PARAM_READWRITE | G_PARAM_STATIC_STRINGS));
      •



    }


    /**




    • example_object_get_animal:
      •

    • @object: A #ExampleObject.
      •

    •

    • Gets the #ExampleAnimal instance for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link> on @object, if any.
      •

    •

    • Returns: (transfer full) (nullable): A #ExampleAnimal that must be freed with g_object_unref() or %NULL if @object does not implement the interface.
      •

    •

    • Since: 2.30

*/

ExampleAnimal *example_object_get_animal (ExampleObject *object)

{

GDBusInterface *ret;

ret = g_dbus_object_get_interface (G_DBUS_OBJECT (object), "org.gtk.GDBus.Example.ObjectManager.Animal");

if (ret == NULL)

return NULL;

return EXAMPLE_ANIMAL (ret);

}
      •



    /**




    • example_object_get_cat:
      •

    • @object: A #ExampleObject.
      •

    •

    • Gets the #ExampleCat instance for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link> on @object, if any.
      •

    •

    • Returns: (transfer full) (nullable): A #ExampleCat that must be freed with g_object_unref() or %NULL if @object does not implement the interface.

*/

ExampleCat *example_object_get_cat (ExampleObject *object)

{

GDBusInterface *ret;

ret = g_dbus_object_get_interface (G_DBUS_OBJECT (object), "org.gtk.GDBus.Example.ObjectManager.Cat");

if (ret == NULL)

return NULL;

return EXAMPLE_CAT (ret);

}
      •



    /**




    • example_object_peek_animal: (skip)
      •

    • @object: A #ExampleObject.
      •

    •

    • Like example_object_get_animal() but doesn't increase the reference count on the returned object.
      •

    •

    • It is not safe to use the returned object if you are on another thread than the one where the #GDBusObjectManagerClient or #GDBusObjectManagerServer for @object is running.
      •

    •

    • Returns: (transfer none) (nullable): A #ExampleAnimal or %NULL if @object does not implement the interface. Do not free the returned object, it is owned by @object.
      •

    •

    • Since: 2.30

*/

ExampleAnimal *example_object_peek_animal (ExampleObject *object)

{

GDBusInterface *ret;

ret = g_dbus_object_get_interface (G_DBUS_OBJECT (object), "org.gtk.GDBus.Example.ObjectManager.Animal");

if (ret == NULL)

return NULL;

g_object_unref (ret);

return EXAMPLE_ANIMAL (ret);

}
      •



    /**




    • example_object_peek_cat: (skip)
      •

    • @object: A #ExampleObject.
      •

    •

    • Like example_object_get_cat() but doesn't increase the reference count on the returned object.
      •

    •

    • It is not safe to use the returned object if you are on another thread than the one where the #GDBusObjectManagerClient or #GDBusObjectManagerServer for @object is running.
      •

    •

    • Returns: (transfer none) (nullable): A #ExampleCat or %NULL if @object does not implement the interface. Do not free the returned object, it is owned by @object.

*/

ExampleCat *example_object_peek_cat (ExampleObject *object)

{

GDBusInterface *ret;

ret = g_dbus_object_get_interface (G_DBUS_OBJECT (object), "org.gtk.GDBus.Example.ObjectManager.Cat");

if (ret == NULL)

return NULL;

g_object_unref (ret);

return EXAMPLE_CAT (ret);

}
      •



    static void

example_object_notify (GDBusObject *object, GDBusInterface *interface)

{

_ExtendedGDBusInterfaceInfo *info = (_ExtendedGDBusInterfaceInfo ) g_dbus_interface_get_info (interface);

/     info can be NULL if the other end is using a D-Bus interface we don't know




    • anything about, for example old generated code in this process talking to
      •

    • newer generated code in the other process. */

if (info != NULL)

g_object_notify (G_OBJECT (object), info->hyphen_name);

}
      •



    /**




    • ExampleObjectProxy:
      •

    •

    • The #ExampleObjectProxy structure contains only private data and should only be accessed using the provided API.

*/
      •



    /**




    • ExampleObjectProxyClass:
      •

    • @parent_class: The parent class.
      •

    •

    • Class structure for #ExampleObjectProxy.

*/
      •



    static void

example_object_proxy__example_object_iface_init (ExampleObjectIface *iface G_GNUC_UNUSED)

{

}


    static void

example_object_proxy__g_dbus_object_iface_init (GDBusObjectIface *iface)

{

iface->interface_added = example_object_notify;

iface->interface_removed = example_object_notify;

}


    G_DEFINE_TYPE_WITH_CODE (ExampleObjectProxy, example_object_proxy, G_TYPE_DBUS_OBJECT_PROXY,

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_OBJECT, example_object_proxy__example_object_iface_init)

G_IMPLEMENT_INTERFACE (G_TYPE_DBUS_OBJECT, example_object_proxy__g_dbus_object_iface_init))


    static void

example_object_proxy_init (ExampleObjectProxy *object G_GNUC_UNUSED)

{

}


    static void

example_object_proxy_set_property (GObject      *gobject,

guint         prop_id,

const GValue *value G_GNUC_UNUSED,

GParamSpec   *pspec)

{

G_OBJECT_WARN_INVALID_PROPERTY_ID (gobject, prop_id, pspec);

}


    static void

example_object_proxy_get_property (GObject      *gobject,

guint         prop_id,

GValue       *value,

GParamSpec   *pspec)

{

ExampleObjectProxy *object = EXAMPLE_OBJECT_PROXY (gobject);

GDBusInterface *interface;


    switch (prop_id)

{

case 1:

interface = g_dbus_object_get_interface (G_DBUS_OBJECT (object), "org.gtk.GDBus.Example.ObjectManager.Animal");

g_value_take_object (value, interface);

break;


    case 2:
  interface = g_dbus_object_get_interface (G_DBUS_OBJECT (object), &quot;org.gtk.GDBus.Example.ObjectManager.Cat&quot;);
  g_value_take_object (value, interface);
  break;

default:
  G_OBJECT_WARN_INVALID_PROPERTY_ID (gobject, prop_id, pspec);
  break;



    }

}


    static void

example_object_proxy_class_init (ExampleObjectProxyClass *klass)

{

GObjectClass *gobject_class = G_OBJECT_CLASS (klass);


    gobject_class->set_property = example_object_proxy_set_property;

gobject_class->get_property = example_object_proxy_get_property;


    g_object_class_override_property (gobject_class, 1, "animal");

g_object_class_override_property (gobject_class, 2, "cat");

}


    /**




    • example_object_proxy_new:
      •

    • @connection: A #GDBusConnection.
      •

    • @object_path: An object path.
      •

    •

    • Creates a new proxy object.
      •

    •

    • Returns: (transfer full): The proxy object.

*/

ExampleObjectProxy *

example_object_proxy_new (GDBusConnection *connection,

const gchar *object_path)

{

g_return_val_if_fail (G_IS_DBUS_CONNECTION (connection), NULL);

g_return_val_if_fail (g_variant_is_object_path (object_path), NULL);

return EXAMPLE_OBJECT_PROXY (g_object_new (EXAMPLE_TYPE_OBJECT_PROXY, "g-connection", connection, "g-object-path", object_path, NULL));

}
      •



    /**




    • ExampleObjectSkeleton:
      •

    •

    • The #ExampleObjectSkeleton structure contains only private data and should only be accessed using the provided API.

*/
      •



    /**




    • ExampleObjectSkeletonClass:
      •

    • @parent_class: The parent class.
      •

    •

    • Class structure for #ExampleObjectSkeleton.

*/
      •



    static void

example_object_skeleton__example_object_iface_init (ExampleObjectIface *iface G_GNUC_UNUSED)

{

}


    static void

example_object_skeleton__g_dbus_object_iface_init (GDBusObjectIface *iface)

{

iface->interface_added = example_object_notify;

iface->interface_removed = example_object_notify;

}


    G_DEFINE_TYPE_WITH_CODE (ExampleObjectSkeleton, example_object_skeleton, G_TYPE_DBUS_OBJECT_SKELETON,

G_IMPLEMENT_INTERFACE (EXAMPLE_TYPE_OBJECT, example_object_skeleton__example_object_iface_init)

G_IMPLEMENT_INTERFACE (G_TYPE_DBUS_OBJECT, example_object_skeleton__g_dbus_object_iface_init))


    static void

example_object_skeleton_init (ExampleObjectSkeleton *object G_GNUC_UNUSED)

{

}


    static void

example_object_skeleton_set_property (GObject      *gobject,

guint         prop_id,

const GValue *value,

GParamSpec   *pspec)

{

ExampleObjectSkeleton *object = EXAMPLE_OBJECT_SKELETON (gobject);

GDBusInterfaceSkeleton *interface;


    switch (prop_id)

{

case 1:

interface = g_value_get_object (value);

if (interface != NULL)

{

g_warn_if_fail (EXAMPLE_IS_ANIMAL (interface));

g_dbus_object_skeleton_add_interface (G_DBUS_OBJECT_SKELETON (object), interface);

}

else

{

g_dbus_object_skeleton_remove_interface_by_name (G_DBUS_OBJECT_SKELETON (object), "org.gtk.GDBus.Example.ObjectManager.Animal");

}

break;


    case 2:
  interface = g_value_get_object (value);
  if (interface != NULL)
    {
      g_warn_if_fail (EXAMPLE_IS_CAT (interface));
      g_dbus_object_skeleton_add_interface (G_DBUS_OBJECT_SKELETON (object), interface);
    }
  else
    {
      g_dbus_object_skeleton_remove_interface_by_name (G_DBUS_OBJECT_SKELETON (object), &quot;org.gtk.GDBus.Example.ObjectManager.Cat&quot;);
    }
  break;

default:
  G_OBJECT_WARN_INVALID_PROPERTY_ID (gobject, prop_id, pspec);
  break;



    }

}


    static void

example_object_skeleton_get_property (GObject      *gobject,

guint         prop_id,

GValue       *value,

GParamSpec   *pspec)

{

ExampleObjectSkeleton *object = EXAMPLE_OBJECT_SKELETON (gobject);

GDBusInterface *interface;


    switch (prop_id)

{

case 1:

interface = g_dbus_object_get_interface (G_DBUS_OBJECT (object), "org.gtk.GDBus.Example.ObjectManager.Animal");

g_value_take_object (value, interface);

break;


    case 2:
  interface = g_dbus_object_get_interface (G_DBUS_OBJECT (object), &quot;org.gtk.GDBus.Example.ObjectManager.Cat&quot;);
  g_value_take_object (value, interface);
  break;

default:
  G_OBJECT_WARN_INVALID_PROPERTY_ID (gobject, prop_id, pspec);
  break;



    }

}


    static void

example_object_skeleton_class_init (ExampleObjectSkeletonClass *klass)

{

GObjectClass *gobject_class = G_OBJECT_CLASS (klass);


    gobject_class->set_property = example_object_skeleton_set_property;

gobject_class->get_property = example_object_skeleton_get_property;


    g_object_class_override_property (gobject_class, 1, "animal");

g_object_class_override_property (gobject_class, 2, "cat");

}


    /**




    • example_object_skeleton_new:
      •

    • @object_path: An object path.
      •

    •

    • Creates a new skeleton object.
      •

    •

    • Returns: (transfer full): The skeleton object.

*/

ExampleObjectSkeleton *

example_object_skeleton_new (const gchar *object_path)

{

g_return_val_if_fail (g_variant_is_object_path (object_path), NULL);

return EXAMPLE_OBJECT_SKELETON (g_object_new (EXAMPLE_TYPE_OBJECT_SKELETON, "g-object-path", object_path, NULL));

}
      •



    /**




    • example_object_skeleton_set_animal:
      •

    • @object: A #ExampleObjectSkeleton.
      •

    • @interface_: (nullable): A #ExampleAnimal or %NULL to clear the interface.
      •

    •

    • Sets the #ExampleAnimal instance for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Animal.top_of_page">org.gtk.GDBus.Example.ObjectManager.Animal</link> on @object.
      •

    •

    • Since: 2.30

*/

void example_object_skeleton_set_animal (ExampleObjectSkeleton *object, ExampleAnimal *interface_)

{

g_object_set (G_OBJECT (object), "animal", interface_, NULL);

}
      •



    /**




    • example_object_skeleton_set_cat:
      •

    • @object: A #ExampleObjectSkeleton.
      •

    • @interface_: (nullable): A #ExampleCat or %NULL to clear the interface.
      •

    •

    • Sets the #ExampleCat instance for the D-Bus interface <link linkend="gdbus-interface-org-gtk-GDBus-Example-ObjectManager-Cat.top_of_page">org.gtk.GDBus.Example.ObjectManager.Cat</link> on @object.

*/

void example_object_skeleton_set_cat (ExampleObjectSkeleton *object, ExampleCat *interface_)

{

g_object_set (G_OBJECT (object), "cat", interface_, NULL);

}
      •



    /* ------------------------------------------------------------------------




    • Code for ObjectManager client
      •

    •



      •



    */


    /**




    • SECTION:ExampleObjectManagerClient
      •

    • @title: ExampleObjectManagerClient
      •

    • @short_description: Generated GDBusObjectManagerClient type
      •

    •

    • This section contains a #GDBusObjectManagerClient that uses example_object_manager_client_get_proxy_type() as the #GDBusProxyTypeFunc.

*/
      •



    /**




    • ExampleObjectManagerClient:
      •

    •

    • The #ExampleObjectManagerClient structure contains only private data and should only be accessed using the provided API.

*/
      •



    /**




    • ExampleObjectManagerClientClass:
      •

    • @parent_class: The parent class.
      •

    •

    • Class structure for #ExampleObjectManagerClient.

*/
      •



    G_DEFINE_TYPE (ExampleObjectManagerClient, example_object_manager_client, G_TYPE_DBUS_OBJECT_MANAGER_CLIENT)


    static void

example_object_manager_client_init (ExampleObjectManagerClient *manager G_GNUC_UNUSED)

{

}


    static void

example_object_manager_client_class_init (ExampleObjectManagerClientClass *klass G_GNUC_UNUSED)

{

}


    /**




    • example_object_manager_client_get_proxy_type:
      •

    • @manager: A #GDBusObjectManagerClient.
      •

    • @object_path: The object path of the remote object (unused).
      •

    • @interface_name: (nullable): Interface name of the remote object or %NULL to get the object proxy #GType.
      •

    • @user_data: User data (unused).
      •

    •

    • A #GDBusProxyTypeFunc that maps @interface_name to the generated #GDBusObjectProxy derived and #GDBusProxy derived types.
      •

    •

    • Returns: A #GDBusProxy derived #GType if @interface_name is not %NULL, otherwise the #GType for #ExampleObjectProxy.

*/

GType

example_object_manager_client_get_proxy_type (GDBusObjectManagerClient *manager G_GNUC_UNUSED, const gchar *object_path G_GNUC_UNUSED, const gchar *interface_name, gpointer user_data G_GNUC_UNUSED)

{

static gsize once_init_value = 0;

static GHashTable *lookup_hash;

GType ret;
      •



    if (interface_name == NULL)

return EXAMPLE_TYPE_OBJECT_PROXY;

if (g_once_init_enter (&once_init_value))

{

lookup_hash = g_hash_table_new (g_str_hash, g_str_equal);

g_hash_table_insert (lookup_hash, (gpointer) "org.gtk.GDBus.Example.ObjectManager.Animal", GSIZE_TO_POINTER (EXAMPLE_TYPE_ANIMAL_PROXY));

g_hash_table_insert (lookup_hash, (gpointer) "org.gtk.GDBus.Example.ObjectManager.Cat", GSIZE_TO_POINTER (EXAMPLE_TYPE_CAT_PROXY));

g_once_init_leave (&once_init_value, 1);

}

ret = (GType) GPOINTER_TO_SIZE (g_hash_table_lookup (lookup_hash, interface_name));

if (ret == (GType) 0)

ret = G_TYPE_DBUS_PROXY;

return ret;

}


    /**




    • example_object_manager_client_new:
      •

    • @connection: A #GDBusConnection.
      •

    • @flags: Flags from the #GDBusObjectManagerClientFlags enumeration.
      •

    • @name: (nullable): A bus name (well-known or unique) or %NULL if @connection is not a message bus connection.
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @callback: A #GAsyncReadyCallback to call when the request is satisfied.
      •

    • @user_data: User data to pass to @callback.
      •

    •

    • Asynchronously creates #GDBusObjectManagerClient using example_object_manager_client_get_proxy_type() as the #GDBusProxyTypeFunc. See g_dbus_object_manager_client_new() for more details.
      •

    •

    • When the operation is finished, @callback will be invoked in the thread-default main loop of the thread you are calling this method from (see g_main_context_push_thread_default()).
      •

    • You can then call example_object_manager_client_new_finish() to get the result of the operation.
      •

    •

    • See example_object_manager_client_new_sync() for the synchronous, blocking version of this constructor.

*/

void

example_object_manager_client_new (

GDBusConnection        *connection,

GDBusObjectManagerClientFlags  flags,

const gchar            *name,

const gchar            *object_path,

GCancellable           *cancellable,

GAsyncReadyCallback     callback,

gpointer                user_data)

{

g_async_initable_new_async (EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT, G_PRIORITY_DEFAULT, cancellable, callback, user_data, "flags", flags, "name", name, "connection", connection, "object-path", object_path, "get-proxy-type-func", example_object_manager_client_get_proxy_type, NULL);

}
      •



    /**




    • example_object_manager_client_new_finish:
      •

    • @res: The #GAsyncResult obtained from the #GAsyncReadyCallback passed to example_object_manager_client_new().
      •

    • @error: Return location for error or %NULL
      •

    •

    • Finishes an operation started with example_object_manager_client_new().
      •

    •

    • Returns: (transfer full) (type ExampleObjectManagerClient): The constructed object manager client or %NULL if @error is set.

*/

GDBusObjectManager *

example_object_manager_client_new_finish (

GAsyncResult        *res,

GError             **error)

{

GObject *ret;

GObject *source_object;

source_object = g_async_result_get_source_object (res);

ret = g_async_initable_new_finish (G_ASYNC_INITABLE (source_object), res, error);

g_object_unref (source_object);

if (ret != NULL)

return G_DBUS_OBJECT_MANAGER (ret);

else

return NULL;

}
      •



    /**




    • example_object_manager_client_new_sync:
      •

    • @connection: A #GDBusConnection.
      •

    • @flags: Flags from the #GDBusObjectManagerClientFlags enumeration.
      •

    • @name: (nullable): A bus name (well-known or unique) or %NULL if @connection is not a message bus connection.
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @error: Return location for error or %NULL
      •

    •

    • Synchronously creates #GDBusObjectManagerClient using example_object_manager_client_get_proxy_type() as the #GDBusProxyTypeFunc. See g_dbus_object_manager_client_new_sync() for more details.
      •

    •

    • The calling thread is blocked until a reply is received.
      •

    •

    • See example_object_manager_client_new() for the asynchronous version of this constructor.
      •

    •

    • Returns: (transfer full) (type ExampleObjectManagerClient): The constructed object manager client or %NULL if @error is set.

*/

GDBusObjectManager *

example_object_manager_client_new_sync (

GDBusConnection        *connection,

GDBusObjectManagerClientFlags  flags,

const gchar            *name,

const gchar            *object_path,

GCancellable           *cancellable,

GError                **error)

{

GInitable *ret;

ret = g_initable_new (EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT, cancellable, error, "flags", flags, "name", name, "connection", connection, "object-path", object_path, "get-proxy-type-func", example_object_manager_client_get_proxy_type, NULL);

if (ret != NULL)

return G_DBUS_OBJECT_MANAGER (ret);

else

return NULL;

}
      •



    /**




    • example_object_manager_client_new_for_bus:
      •

    • @bus_type: A #GBusType.
      •

    • @flags: Flags from the #GDBusObjectManagerClientFlags enumeration.
      •

    • @name: A bus name (well-known or unique).
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @callback: A #GAsyncReadyCallback to call when the request is satisfied.
      •

    • @user_data: User data to pass to @callback.
      •

    •

    • Like example_object_manager_client_new() but takes a #GBusType instead of a #GDBusConnection.
      •

    •

    • When the operation is finished, @callback will be invoked in the thread-default main loop of the thread you are calling this method from (see g_main_context_push_thread_default()).
      •

    • You can then call example_object_manager_client_new_for_bus_finish() to get the result of the operation.
      •

    •

    • See example_object_manager_client_new_for_bus_sync() for the synchronous, blocking version of this constructor.

*/

void

example_object_manager_client_new_for_bus (

GBusType                bus_type,

GDBusObjectManagerClientFlags  flags,

const gchar            *name,

const gchar            *object_path,

GCancellable           *cancellable,

GAsyncReadyCallback     callback,

gpointer                user_data)

{

g_async_initable_new_async (EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT, G_PRIORITY_DEFAULT, cancellable, callback, user_data, "flags", flags, "name", name, "bus-type", bus_type, "object-path", object_path, "get-proxy-type-func", example_object_manager_client_get_proxy_type, NULL);

}
      •



    /**




    • example_object_manager_client_new_for_bus_finish:
      •

    • @res: The #GAsyncResult obtained from the #GAsyncReadyCallback passed to example_object_manager_client_new_for_bus().
      •

    • @error: Return location for error or %NULL
      •

    •

    • Finishes an operation started with example_object_manager_client_new_for_bus().
      •

    •

    • Returns: (transfer full) (type ExampleObjectManagerClient): The constructed object manager client or %NULL if @error is set.

*/

GDBusObjectManager *

example_object_manager_client_new_for_bus_finish (

GAsyncResult        *res,

GError             **error)

{

GObject *ret;

GObject *source_object;

source_object = g_async_result_get_source_object (res);

ret = g_async_initable_new_finish (G_ASYNC_INITABLE (source_object), res, error);

g_object_unref (source_object);

if (ret != NULL)

return G_DBUS_OBJECT_MANAGER (ret);

else

return NULL;

}
      •



    /**




    • example_object_manager_client_new_for_bus_sync:
      •

    • @bus_type: A #GBusType.
      •

    • @flags: Flags from the #GDBusObjectManagerClientFlags enumeration.
      •

    • @name: A bus name (well-known or unique).
      •

    • @object_path: An object path.
      •

    • @cancellable: (nullable): A #GCancellable or %NULL.
      •

    • @error: Return location for error or %NULL
      •

    •

    • Like example_object_manager_client_new_sync() but takes a #GBusType instead of a #GDBusConnection.
      •

    •

    • The calling thread is blocked until a reply is received.
      •

    •

    • See example_object_manager_client_new_for_bus() for the asynchronous version of this constructor.
      •

    •

    • Returns: (transfer full) (type ExampleObjectManagerClient): The constructed object manager client or %NULL if @error is set.

*/

GDBusObjectManager *

example_object_manager_client_new_for_bus_sync (

GBusType                bus_type,

GDBusObjectManagerClientFlags  flags,

const gchar            *name,

const gchar            *object_path,

GCancellable           *cancellable,

GError                **error)

{

GInitable *ret;

ret = g_initable_new (EXAMPLE_TYPE_OBJECT_MANAGER_CLIENT, cancellable, error, "flags", flags, "name", name, "bus-type", bus_type, "object-path", object_path, "get-proxy-type-func", example_object_manager_client_get_proxy_type, NULL);

if (ret != NULL)

return G_DBUS_OBJECT_MANAGER (ret);

else

return NULL;

}
      •

    ↩

posted @ 2025-08-03 21:07  重光拾  阅读(57)  评论(0)    收藏  举报
