跟着Leo机器学习实战——K-近邻算法

github代码获取

https://github.com/LeoLeos/MachineLearningLeo

概述（核心思想）

选出以待分类的一个样本与他最近的K个已知标签的样本中,这K个样本中的属于相同label的个数最多,则将这个待分类样本分给这一类.

举例

如果K=3，绿色圆点的最近的3个邻居是2个红色小三角形和1个蓝色小正方形，少数从属于多数，基于统计的方法，判定绿色的这个待分类点属于红色的三角形一类。
如果K=5，绿色圆点的最近的5个邻居是2个红色三角形和3个蓝色的正方形，还是少数从属于多数，基于统计的方法，判定绿色的这个待分类点属于蓝色的正方形一类。

优点

精确度高，对异常值不敏感，无数据输入假定

缺点

计算复杂度和空间复杂度高

实战–使用KNN改进约会网站的配对效果

准备数据

    def file2matrix(filename):
        fr = open(filename)
        numberOfLines = len(fr.readlines())         #获取文件行数
      returnMat = zeros((numberOfLines,3))        #构建零矩阵
      classLabelVector = []                       #构建准备存储label向量
      fr = open(filename)
        index = 0
      #将文件转化为矩阵
      for line in fr.readlines():
            #去掉每行首尾空格回车符
		    line = line.strip()
            listFromLine = line.split('\t')
            returnMat[index,:] = listFromLine[0:3]
        classLabelVector<span class="token punctuation">.</span>append<span class="token punctuation">(</span><span class="token builtin">int</span><span class="token punctuation">(</span>listFromLine<span class="token punctuation">[</span><span class="token operator">-</span><span class="token number">1</span><span class="token punctuation">]</span><span class="token punctuation">)</span><span class="token punctuation">)</span>
        index <span class="token operator">+=</span> <span class="token number">1</span>
  <span class="token keyword">return</span> returnMat<span class="token punctuation">,</span>classLabelVector

datingDataMat<span class="token punctuation">,</span>datingLabels<span class="token operator">=</span>kNN<span class="token punctuation">.</span>file2matrix<span class="token punctuation">(</span><span class="token string">'datingTestSet2.txt'</span><span class="token punctuation">)</span>
<span class="token comment">#print(returnMat,classLabelVector)  </span>
<span class="token comment">#实例化画图视图  </span>
fig <span class="token operator">=</span> plt<span class="token punctuation">.</span>figure<span class="token punctuation">(</span><span class="token punctuation">)</span>
<span class="token comment">#选择子图  </span>
ax <span class="token operator">=</span> fig<span class="token punctuation">.</span>add_subplot<span class="token punctuation">(</span><span class="token number">111</span><span class="token punctuation">)</span>
ax<span class="token punctuation">.</span>scatter<span class="token punctuation">(</span>datingDataMat<span class="token punctuation">[</span><span class="token punctuation">:</span><span class="token punctuation">,</span><span class="token number">1</span><span class="token punctuation">]</span><span class="token punctuation">,</span>datingDataMat<span class="token punctuation">[</span><span class="token punctuation">:</span><span class="token punctuation">,</span><span class="token number">2</span><span class="token punctuation">]</span><span class="token punctuation">,</span><span class="token number">15.0</span><span class="token operator">*</span>array<span class="token punctuation">(</span>datingLabels<span class="token punctuation">)</span><span class="token punctuation">,</span><span class="token number">15.0</span><span class="token operator">*</span>array<span class="token punctuation">(</span>datingLabels<span class="token punctuation">)</span><span class="token punctuation">)</span>
ax<span class="token punctuation">.</span>scatter<span class="token punctuation">(</span>datingDataMat<span class="token punctuation">[</span><span class="token punctuation">:</span><span class="token punctuation">,</span><span class="token number">0</span><span class="token punctuation">]</span><span class="token punctuation">,</span>datingDataMat<span class="token punctuation">[</span><span class="token punctuation">:</span><span class="token punctuation">,</span><span class="token number">1</span><span class="token punctuation">]</span><span class="token punctuation">,</span><span class="token number">15.0</span><span class="token operator">*</span>array<span class="token punctuation">(</span>datingLabels<span class="token punctuation">)</span><span class="token punctuation">,</span><span class="token number">15.0</span><span class="token operator">*</span>array<span class="token punctuation">(</span>datingLabels<span class="token punctuation">)</span><span class="token punctuation">)</span>
<span class="token comment">#显示画图结果  </span>
plt<span class="token punctuation">.</span>show<span class="token punctuation">(</span><span class="token punctuation">)</span>

算法核心（分类器）

    def classify0(inX, dataSet, labels, k):
        dataSetSize = dataSet.shape[0]
        diffMat = tile(inX, (dataSetSize,1)) - dataSet      #tile产生以inX为元素包，形成(dataSetSize,1)矩阵，返回inX与dataSet各点坐标差值。
	    sqDiffMat = diffMat**2 #计算点inX与各点欧式距离平方。
        sqDistances = sqDiffMat.sum(axis=1)     #以行为点，对列求和
        distances = sqDistances**0.5 #开方
        sortedDistIndicies = distances.argsort()        #从小到大排序的下标
        classCount={}
        for i in range(k):
	        voteIlabel = labels[sortedDistIndicies[i]]      #获取按sortedDistIndicies排序的label
	        classCount[voteIlabel] = classCount.get(voteIlabel,0) + 1 #获取与距离最小的前k个分给voteIlabel类有几次
        sortedClassCount = sorted(classCount.items(), key=operator.itemgetter(1), reverse=True)     #按分给某一类的次数排序
        return sortedClassCount[0][0]       #返回分给次数最多的label

归一化公式

new = (oldValue-minValue)/(maxValue-minValue)

def autoNorm(dataSet):
    minVals = dataSet.min(0)
    maxVals = dataSet.max(0)
    ranges = maxVals - minVals
    #产生与输入矩阵一样大小的零矩阵
	normDataSet = zeros(shape(dataSet))
    #获取行数
    m = dataSet.shape[0]
    #对输入矩阵减去最小值
    normDataSet = dataSet - tile(minVals, (m,1))
    #除以maxVals 与 minVals的差值
    normDataSet = normDataSet/tile(ranges, (m,1))   #element wise divide
  #返回归一化之后的矩阵，最大值与最小值的差以及最小值
  return normDataSet, ranges, minVals

测试算法

def datingClassTest():
    #设置测试样本与样本数比例
    hoRatio = 0.50 #hold out 10%
 #加载数据
 	datingDataMat,datingLabels = file2matrix('datingTestSet2.txt')       #load data setfrom file
 #归一化
 	normMat, ranges, minVals = autoNorm(datingDataMat)
    m = normMat.shape[0]
    #设置k值
    numTestVecs = int(m*hoRatio)
    #初始化错误率
  	errorCount = 0.0
  for i in range(numTestVecs):
        #判别normMat[i,:]测试样本的类别
        classifierResult = classify0(normMat[i,:],normMat[numTestVecs:m,:],datingLabels[numTestVecs:m],3)
        print("the classifier came back with: %d, the real answer is: %d" % (classifierResult, datingLabels[i]))
        if (classifierResult != datingLabels[i]): errorCount += 1.0
        print("the total error rate is: %f" % (errorCount/float(numTestVecs)))
    print(errorCount)

预测

def classifyPerson():
   resultList = ['not at all', 'in small does', 'in large does']
   percentTats = float(input('percentTage of time spent playing video game?'))
   ffMiles = float(input('frequent filer miles earned per years?'))
   iceCream = float(input('liters of ice cream consumed per year?'))
   datingDataMat, datingLabels = file2matrix('datingTestSet2.txt')
   normMat,ranges, minVals = autoNorm(datingDataMat)
   #将三者转化成数组，之前打错成大括号，变成列表，报错！
   inArr = array([ffMiles, percentTats, iceCream])
   #调用kNN函数进行预测
   classifierResult = classify0((inArr - minVals)/ranges,normMat, datingLabels, 3)
   print('You will probably like this person:',resultList[classifierResult - 1])

手写数字系统识别

流程

准备数据：将图像转换为测试向量

def img2vector(filename):
    #初始化零向量矩阵
    returnVect = zeros((1,1024))
    fr = open(filename)
    for i in range(32):
        lineStr = fr.readline()
        for j in range(32):
            #按行，列写入像素数值
 		    returnVect[0,32*i+j] = int(lineStr[j])
    return returnVect       #返回图片向量

测试算法：使用k-近邻算法识别手写数字

def handwritingClassTest():
    hwLabels = []
    trainingFileList = listdir('trainingDigits')           #load the training set加载训练集
    m = len(trainingFileList)       #训练集样本数
    trainingMat = zeros((m,1024))       #为美国样本初始化一个零向量，以存储每个样本的向量
  for i in range(m):
        fileNameStr = trainingFileList[i]
        fileStr = fileNameStr.split('.')[0]     #take off .txt
        classNumStr = int(fileStr.split('_')[0])
        hwLabels.append(classNumStr)
        trainingMat[i,:] = img2vector('trainingDigits/%s' % fileNameStr)
        testFileList = listdir('testDigits')        #iterate through the test set加载测试集
  errorCount = 0.0
  mTest = len(testFileList)
  for i in range(mTest):
        fileNameStr = testFileList[i]
        fileStr = fileNameStr.split('.')[0]     #take off .txt
        classNumStr = int(fileStr.split('_')[0])
        vectorUnderTest = img2vector('testDigits/%s' % fileNameStr)     #将测试集的每个样本逐步向量化
        classifierResult = classify0(vectorUnderTest, trainingMat, hwLabels, 3)     #为其分类
        print ("the classifier came back with: %d, the real answer is: %d" % (classifierResult, classNumStr))
        if (classifierResult != classNumStr): errorCount += 1.0 #计算分错类的个数
  print ("\nthe total number of errors is: %d" % errorCount)
  print ("\nthe total error rate is: %f" % (errorCount/float(mTest)))     #错误率
